INSTALLATION INSTRUCTIONS
Professional Custom Liner - Models: LINER30
LINER36
LINER48
Parts included with your custom liner:
Stainless Steel custom liner for use with Professional series custom insert (models
VCI2xxDS)
Fittings bag with:
o 6 x ¾” flat head screws for cabinet installation
Tools required for installation:
Phillips head screwdriver
Tape measure
Level
To install your Thermador custom liner:
1) Plan the installation so that all minimum requirements are met. Please refer to your
range installation guide for the minimum required distances for safe use.
2) Prepare the framework/ cabinet to fit the cutout required for your liner. For dimensional
information, please refer to graphic (A) below. Note: The wall to which this is installed
should be flat and vertical, and capable of providing a firm hold for mounting screws and
plugs.
3) Fit the liner into the framework so that the bottom is flush with the bottom edges.
4) Secure the liner to the framework/ cabinet using the screws provided.
5) Install the custom insert and blowers according to the installation guides provided with
your unit.
(A)
