Side 1/13
Introduction
The ASI-4 is a 2 1/4” sunlight readable instrument that provides a wide range airspeed indication in both digital and
analog tape formats. Airspeed is based on the pressure generated by a pitot tube system and a static port is provided as
well for use by high speed aircraft. In addition, the ASI-4 provides a flight timer since takeoff and records the maximum
airspeed reached.
Airspeed can be indicated in statute miles per hour (mph), kilometers per hour (km/h) or nautical miles per hour (kts). The
analog airspeed tape can be scaled according to the aircraft’s flying speed range and ranges for Vs0, Vs1, Vfe, Vno and
Vne can be set. The ASI-4 also provides a programmable Vs and Vne airspeed alarm output. ASI sensitivity can be
calibrated by the user to cater for errors caused by pitot tube placement.
The ASI-4 instrument measures airspeed from 16mph to 250mph and is well suited to slower aircraft due to very good
sensitivity and linearity at low air speeds.
1 Features
Large 1.8” high resolution 160x128, sunlight readable, wide viewing angle, 1000 cd/m2 TFT LCD display
Measures airspeed from 16mph to 250mph and is well suited to slow aircraft due to very good sensitivity
and linearity at low air speeds
Includes a flight timer since takeoff
Airspeed units can be set to miles per hour (mph), kilometer per hour (km/h) or nautical miles per hour
(kts)
Analog tape with programmable ranges for Vs0, Vs1, Vfe, Vno and Vne
Contains a programmable Vs and Vne airspeed alarm output
Records maximum airspeed reached in permanent memory
Standard 2 1/4” aircraft enclosure (can be front or rear mounted)
Rotary control plus 2 independent buttons for easy menu navigation and user input
Wide input supply voltage range of 8 to 30V DC with built in voltage reversal and over voltage protection
for harsh electrical environments
1 year limited warranty
Vega ASI-4
Airspeed Indicator (ASI)
Operating Manual – English 1.00
