P/N: 1802056000211

NPort 5600 Series Quick

Installation Guide

Third Edition, November 2010

1. Overview

Welcome to the Moxa NPort 5600 Series. The NPort 5610-8/16

have 8 or 16 RS 232 ports, the NPort 5630 8/16 have 8 or 16 - -

RS-422/485 ports, and the NPort 5650-8/16 have 8 or 16

RS-232/422/485 ports.

2. Package Checklist

The NPort 5600 package should contain the following items:

• 1 8- 6-port or 1 port serial device server

• NPort Documentation & Software CD

• NPort 5600 Quick Installation Guide

Optional Accessories:

• CBL- - 8-RJ45M9 150: pin RJ45 to DB9 male cable, 150 cm

• CBL- - 8- RJ45F9 150: pin RJ45 to DB9 female cable, 150 cm

• CBL- - 8-RJ45M25 150: pin RJ45 to DB25 male cable, 150 cm

• CBL- - 8-RJ45F25 150: pin RJ45 to DB25 female cable, 150 cm

Notify your sales representative if any of the above items is

missing or damaged.

3. Hardware Introduction

The NPort 5600 Series has includes the following models: NPort

5610-8, NPort 5610-16, NPort 5610-8-48V, NPort 5610- -16 48V,

NPort 5630 8, NPort 5630- -16, NPort 5650 NPort 5650-8, -8- T,

NPort 5650- 16, NPort 5650 NPort 5650- - 16 T, -8-M-SC, NPort

5650 16- -M-SC, NPort 5650 and NPort 5650-8-S-SC, -16-S- SC.

NOTE

The wide temperature model does not support LCM display

panel

s or push bu s ttons. All of the LCM description below

apply only to s. standard temperature model

The front and rear panels are shown below:

Front panel of the NPort 5600 Series

Rear panel of the NPort 5610/5630/5650 (AC Power)

Rear panel of the NPort 5650 (Fiber Model)

Rear panel of the NPort 5610 (DC Power)

Front panel of the NPort 5650- T Series

Reset Button—press the Reset button continuously for 5 sec to

load factory defaults: Use a pointed object to press the reset

button. Release the button after the Ready LED stops blinking.

LED Indicators on the Front Panel—the front panels of the

NPort 5600 have several LED indicators, as described in the

following table.

Name

Color

Function

Ready

Off

Power is off, or power error condition exists.

Red

Steady on: Power is on and the NPort is

booting up.

Blinking: Indicates an IP conflict, or DHCP or

BOOTP server did not respond properly.

Green

Steady on: Power is on and the NPort is

functioning normally.

Blinking:

The NPort has been located by NPort

Administrator’s Location function.

1- 16

Orange

Serial port is receiving data.

Green

Serial port is transmitting data.

Off

No data is being transmitted or received

through the serial port.

LCM Display Panel—If the NPort is working properly, the LCM

panel will display a green color. The red Ready LED will also light

up, indicating that the NPort is receiving power. After the red

Ready LED turns green, you will see a display similar to:

This is where

• NP5610- 16 is the NPort’s name

• 38 is the NPort’s serial number

• 192.168.127.254 is the NPort’s IP address

LCM Panel Operation—There are four buttons on the NPort

5600’s front panel. These buttons are used to operate the server’s

LCM panel. Going from left to right, the buttons are:

Button

Action

Activates the main menu, or returns to a lower level.

︿

Scrolls up through a list of items shown on the LCM

panel’s second line.

﹀

Scrolls down through a list of items shown on the LCM

panel’s second line.

SEL Selects the option listed on the LCM panel’s second

line.

Detailed LCM Panel Operating instructions can be found on the

CD-ROM in the NPort 5600 Series User’s Manual.

Link Indicator on the rear panel of the NPort 5650 fiber

model—the rear panels of the NPort 5650 have a link indicator, as

described in the following table.

LED Name

LED Color

LED Function

Link

Off

Fiber disconnected.

Green

Fiber connected; data not transmitting.

Blinking

Fiber connected; data is transmitting.

4. Hardware Installation

STEP 1: After removing the NPort 5600 from the box, the first

thing you should do is attach the power adaptor.

STEP 2: Connecting the Power.

AC: Connect the NPort 5600’s 240 VAC power cord to the AC 1 -00

connector. T he “Ready” LED will show a solid red color until the

system is ready, at which time it will change to a green color.

DC: Connect the NPort 5610- -16/8 48V’s power cord to the DC

connector, and then follow the steps given below:

Loosen the screws on the V+ and V- terminals of

the NPort 5610-8/16- 48V’s terminal block.

Connect the power cord’s 48 VDC or - 48 VDC wire

to the terminal block’s V+ terminal, and the power

cord’s DC Power Ground wire to the terminal block’s V- terminal,

and then tighten the terminal block screws. (Note: The NPort

5610 8/16- - -48V can still operate even if the 48V/ 48V and DC

Power Ground are reversed.)

The “Ready” LED will show a solid red color until the system is

ready, at which time it will change to a green color.

Grounding the NPort 5610- - 8/16 48V:

Grounding and wire routing help limit the effects of

noise due to electromagnetic interference (EMI).

Run the ground connection from the ground

screw to the grounding surface prior to

connecting devices. The Shielded Ground

(sometimes called Protected Ground) contact is

the second contact from the right of the 5- pin power terminal block

connector located on the rear panel of the NPort 5610- -8/16 48V.

Connect the SG wire to the Earth ground.

STEP 3: Connect the NPort 5600 to a network. Use a standard

straight-through Ethernet cable to connect to a h sub or witch.

When setting up or testing the NPort 5600, you might find it

convenient to connect directly to your computer’s Ethernet port. In

this case, use a cross-over Ethernet cable.

Produkt Specifikationer

Mærke:	Moxa
Kategori:	Server
Model:	NPort 5650-16-M-SC
Vægt:	3440 g
Opbevaringstemperatur (T-T):	-40 - 85 °C
Relativ luftfugtighed ved drift (H-H):	5 - 95 %
Ethernet LAN-porte (RJ-45):	1
Driftstemperatur (T-T):	0 - 55 °C
Ethernet LAN-datahastigheder:	10, 100 Mbit/s
Certificering:	CE, FCC, EN 55022 Class A, FCC Part 15 Subpart B Class A, \r\nEN 60601-1-2 Class B, EN 55011
Understøttede netværksprotokoller:	ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, DNS, HTTP, SMTP, SNTP, ARP, PPP, RTelnet, RFC2217
Indgangsspænding:	100 - 240 V
Kompatible operativsystemer:	Windows 98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8 x86/x64, Windows 2012 X64\r\n\r\nSCO Unix, SCO OpenServer, UnixWare 7, UnixWare 2.1, SVR 4.2, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5.x, HP-UX 11i\r\n\r\nLinux kernel 2.4.x, 2.6.x, 3.x
Isolering:	1.5 kV
Flowkontrol support:	Ja
Administrationsprotokoller:	SNMP V1
Seriel grænsefladetype:	RS-232/422/485
Antal serielle porte:	16
Baud hastighed:	921.6 Kbit/s
RS-232 signaler:	CTS, DCD, DSR, DTR, GND, RTS
RS-422 signaler:	GND, RxD+, RxD-, TxD+, TxD-
RS-485 signaler:	Data+, Data-, GND
Sikkerhed:	UL 60950-1, EN 60950-1
Link/Act LED:	Ja
