Side 1/1
正面
尺寸:185*170mm
材质:80g书写纸 (双面 黑白 印刷 对折)
SGP序列档使用说明
背面
• 双模式多角度可调
• 航空级铝合金
• 高精度霍尔传感器
• 多功能拉手
• 换档头可更换设计
• RGB机械式按键
产品介绍
QC
PASS
03
01
产品尺寸和固定孔位
02
使用教程
03
序列档
手柄握把
USB Type-B转Type-A数据线
RJ11数据线
M6螺钉及M6垫
六角扳手
外六角扳手
包装清单
04
USB连接类型: PC、转接器、MOZA基座
材质:铝合金&高强钢
尺寸规格:181.5*52*319.5 mm
安装孔:M6螺纹孔/M8通
净重:1.7Kg
产品参数
05
1. 将手柄把旋入连接杆并拧紧
2. 将序列档固定在模拟器支架上或使用桌面夹固定在桌面上
3. 使用包装内的USB Type-B转Type-A数据线连接序列档和电脑上的USB口;包装内的RJ11线
可以连接带序列档接口的MOZA基座
4. 打开MOZA Pit House进入图示的序列档页面确认设备是否正常连接以及各个挡位是否信
号正常
319.5
181.5 52
25
165
125
40
16.5
20
6- 8.5
8-M6
319.5
181.5 52
25
165
125
40
16.5
20
6- 8.5
8-M6
售后客服
Quick Guide
SGP Sequential Shifter User Guide
Product Features
• Dual-mode multi-angle adjustment
• Crafted from aviation-grade aluminum alloy
• Equipped with a high-precision Hall sensor
• Multi-function Handle
• Replaceable Shifter Knob
• RGB mechanical buttons
01
Dimensions
02
• Sequential shifter
• Shifter handle
• USB Type-B to Type-A data cable
• RJ11 data cable
• M6 screws and M6 washers
• Hex wrench
• External hex wrench
Package Contents
04
• Connection options: PC, compatible MOZA
bases, MOZA hub
• Materials: Aluminum alloy & high-strength
steel
• Dimensions: 181.5 x 52 x 319.5 mm
• Mounting Holes: M6 threaded holes/M8
through holes
• Net Weight: 1.7 Kg
Product Specifications
05
1. Fix the shifter handle to the lever and tighten it securely.
2. Attach the sequential shifter to the simulator stand or secure it to the desktop using the
desktop clamp.
3. Connect the sequential shifter to your computer using the included USB Type-B to
Type-A data cable. Alternatively, MOZA base with a shifter port can use the included
RJ11 cable instead.
4. Open MOZA Pit House, navigate to the illustrated sequential shifter page and ensure
that the device is correctly connected and that all inputs are signalling correctly.
SGP Sequential Shifter Instructions
03
