Warranty

Marshall microphones are guaranteed against defects in material and workmanship for three years from date of purchase. Should you encounter any problem with this unit,

promptly contact the company you purchased it from for assistance. The original dated sales receipt will be necessary for any warranty claim. Do not send any unit directly

to us without prior authorization from our service department! Warranty coverage is limited to repair or replacement (at our option) of the microphone, and does not cover

incidental damages due to use of this unit, nor damage caused by accidental misuse of this product.

Marshall Electronics, Inc.

1910 East Maple Ave. El Segundo, CA 90245

Phone: (310) 333-0606 Fax: (310) 333-0688

E-mail: Sales@mxlmics.com

Internet: www.MXLmics.com

2003A

Studio Recording

Condenser Microphone

Type: Pressure gradient tube condenser mic

Diaphragm: 3-micron, gold-sputtered

Frequency Range: 20Hz - 20kHz

Polar Pattern: Cardioid

Sensitivity: -42.9 dB re 1V/Pa

Impedance: 200 ohms

S/N Ratio: 83 dB

Equivalent Noise Level: 11 dB (A-weighted IEC 651)

Max SPL for 0.5% THD: 152 dB SPL

Power Requirements: 48V phantom power (+/- 4V)

Size: 50mm x 190mm/1.97 in x 7.48 in

Weight: 453.59g/1 lb

Metal Finish: Black with black grill

Polar Pattern

Frequency Response

90270

180

ank you for purchasing the MXL2003A studio recording microphone. With proper care, this mic will provide many years of satisfaction. For best results,

please take a few moments to review this literature.

General Characteristics

is microphone has a 3-micron gold-sputtered diaphragm and a cardioid pickup pattern. Large capsule condensers are very sensitive, readily revealing very

subtle sonic details. ey also tend to pick up sounds outside the pattern more than some designs, which can lead to powerful feedback if you are not careful.

We strongly advise experimentation with placement and isolation requirements with the gain initially set low to avoid equipment (and hearing) damage!

Power Requirements

IMPORTANT: is unit requires phantom power at 48 volts, +/- 4 volts. Each unit has been thoroughly checked before shipping, so if you do not hear

sound, check that the phantom power on your mixer or separate power supply is switched on!

Shockmount

e high isolation shockmount may shift during shipping. Simply shift the elastic bands to center the microphone in the assembly. Be sure that the wire

clamp does not rest on the chassis of the mount, as this impairs mechanical isolation. Slide the mount all the way to the rim of the microphone grill for the

most secure hold.

Microphone Cables

is microphone connects to a mixer or preamp via XLR cable (not included). e microphone cable can have a profound eﬀect on the sound of any micro-

phone. Even the ﬁnest microphones will sound poor if the interconnect cable allows noise to enter, or causes distortion and loss of information. Use only the

best microphone cable your budget will allow. We recommend Mogami cable for the best results.

Care

Dust and foreign material can degrade the performance of a microphone over time so always store the unit in its case. For vocals closer than 3”, use a “popper

stopper” or a foam windscreen to avoid getting moisture on the diaphragm as this can substantially degrade the microphone’s performance. Store the micro-

phone in its original packaging in a cool, dry place along with the included packet of silica gel. ese steps will help keep the mic in proper working order and
