Side 1/2
Upward Movement
Press the button, the TV mount will
move upward to the lowest-prole
position against the ceiling. Press the
OK button to stop the motion.
(Tips: Clear up all obstacles
within the range of motion.)
Left Side Movement
Press the button, the TV mount will move to
the left side (90° by default). When swiveling
the TV mount to the left 90°, then press the
OK button, the mount will return to the
default position (middle position).
Right Side Movement
Press the button, the TV mount will move to the right
side (90° by default). When swiveling the TV mount to
the right 90°, then press the button, the mount will OK
return to the default position (middle position).
Memory Setting 1
Press the button for 1 second and you will hear a
beep, indicating that the current position
has been saved to memory.
Recall Memory
Press the button and the mount will
automatically get to the position saved
in the corresponding button .mem1
Recall Memory
Press the button and the mount will
automatically get to the position saved
in the corresponding button .mem2
Memory Setting 2
Press the button for 1 second and
you will hear a beep, indicating that
the current position has been saved
to memory.
Downward Movement
Press the button, the TV mount will move
downward to the maximum tilt angle position (75° by
default). Press the button to stop the motion. OK
(Tips: Clear up all obstacles within the range of motion.)
: Stop Button
OK
Never operate the mount without a TV installed!
Before power connection, be sure that bracket and the TV installed correctly.
Keep the children away from power. Do not swivel the mount using hands.
!
RMT-03 AAA battery remote control, 2x (not included)
HL 49 ML / HL 49 MWL
Coding of Remote Controller and Control Box
Step 1: When the mount is powered on, press the small button on the control box with a thin tool as shown.
The unit emits a beep, indicating that the control box is on standby for program coding.
Step 2: Press the button on the remote control within 10 seconds after Step 1. The control box will repeat beeps forSET
approximately 10 seconds indicating that the remote control is being programmed. The process will automatically nish when you
no Ionger hear any beeps.
NOTE: The TV Mount can be matched with up to 20 remote controllers. To clean up the data of all the remote controllers and the
phone, press and hold the code matching button for 5 seconds then release. The unit will emits two beeps conrm the
successful clean up and vice versa.
Reset Mode
If the TV mount can‘t be adjusted to the highest position (0° against the ceiling) or the lowest position (max. tilting position), unplug and
re-plug the power. Then press and hold the button for 5 seconds. Mount will retract to the highest position, that means the system has OK
been successfully reset.
Note: Long press SET for 5 seconds to disconnect the device from the app.
Hereby, Transmedia Kabelverbindungen GmbH declares that the Folding Suspension Brackets for Flat Screens
HL 49 ML and HL 49 MWL are in compliance with Directive 2014/53/EU. The full text of the EU declaration of
conformity is available at the following internet address: https://www.transmedia-germany.com/download
revised 0
2023
