Side 1/18

a Quick start guide

Action Camera ACAM07BK

For more information see the extended manual online: ned.is/acam07bk

Intended use

The Nedis ACAM07BK is a small and lightweight action camera that enables you to make HD

images and video.

This product is intended as a recording device.

The product is not intended for professional use.

Consult the local laws and regulations for this product before installing and using.

This product can be used by children aged from 8 years and above and persons with

reduced physical, sensory or mental capabilities or lack of experience and knowledge if they

have been given supervision or instruction concerning use of the product in a safe way and

understand the hazards involved. Children shall not play with the product. Cleaning and user

maintenance shall not be done by children without supervision.

Before using the charger, check the instruction manual supplied with the battery for the

correct operation instructions.

Any modication of the product may have consequences for safety, warranty and proper

functioning.

Specications

Product Action Camera

Article number ACAM07BK

Dimensions (l x w x h) 59 x 29 x 41 mm

Battery capacity 400 mAh

Memory MicroSD card (4 - 32 GB) (not included)

Camera lens 140° wide-angle lens

Image format .jpg

Image resolution 5MP

Video format .avi

Video resolution 1920 x 1080 px - 1280 x 720 px - 640 x 480 px

Frame speed 30 fps

Time lapse O / 2S / 10S

Recording time ≥ 70 minutes

Display 2.0 LTPS

Current Standby: 270 mAh

Working: 330 mAh

Charging time 3 hours

Maximum transmission power 12 dBm

Main parts A(image )

1 Power button

2 Camera lens

3 Display

4 Status indicator LED

5 Charging indicator LED

6 Power indicator LED

7 OK button

8 Battery cover

9 Microphone

q MicroSD card slot

w Micro USB port

e UP button

r DOWN button

t Speaker

y Micro USB cable

u Battery

i Battery label

Additional parts (not shown in illustration)

o Waterproof housing

p Mounting accessories

a Bandages

s 3M mats

d Tethers

f Lens cloth

Safety instructions

WARNING

• Ensure you have fully read and understood the instructions in this document before you

install or use the product. Keep the packaging and this document for future reference.

• Only use the product as described in this document.

• Do not use the product if a part is damaged or defective. Replace a damaged or defective

product immediately.

• Unplug the product from the power source and other equipment if problems occur.

• Switch o and unplug the product when not in use or before maintenance.

• This product may only be serviced by a qualied technician for maintenance to reduce the

risk of electric shock.

• Do not drop the product and avoid bumping.

• Do not expose the product to water or moisture without using the waterproof housing.

• Keep distance from ammable objects.

• Only use the provided USB charging cable.

• Charge the battery for at least 3 hours when you use it for the rst time.

• Do not use any charger other than that specically provided for use with the equipment.

• The charger must only be plugged into an earthed socket-outlet.

• During charging, the battery must be placed in a well-ventilated area.

• Do not leave a battery on prolonged charge when not in use.

• Disconnect the power supply before making or breaking the connections to the battery.

• Stop the charging process if the product gets too warm.

• Only power the product with the voltage corresponding to the markings on the product.

• Wipe the battery terminals with a clean dry cloth if they are dirty.

• Do not short-circuit a cell or a battery.

• Children of less than 8 years should be kept away.

• Cleaning and user maintenance shall not be done by children without supervision.

Inserting a microSD card B(image )

4A microSD card (not included) is required to take pictures or videos.

4Use a microSD card with a maximum of 32 GB storage capacity.

4Format the microSD card before use.

1. Insert the microSD card into the microSD card slot A

Insert the battery C(image )

1. Remove the battery cover A8.

2. Insert the battery Au in the battery compartment.

4Remove the battery by pulling the battery label Ai.

3. Close the battery compartment with A8.

4Make sure to match the (+) and (-) polarity markings.

Charging the product D(image )

Only use the provided USB charging cable.

4The product is delivered with a partially charged battery. For optimal battery life, fully

charge the battery before rst use.

4The battery recharging time is variable depending on the condition and capacity of the

battery.

4The product can be charged while recording video.

1. Plug the micro USB cable Ay into the micro USB port of the product Ar.

2. Plug the other end of Ay into a USB power source or adapter.

4Charging starts automatically.

4The charging indicator LED A

5 lights up.

4When the battery level is low, a low battery notication is shown on the screen and the

product turns o.

Attachment

Place the product in the waterproof housing. The waterproof housing can be tted with the

supplied mounting accessory to your clothing, action gear, helmet, etc.

Make sure the attachment is secure.

Make sure the product does not impede your movement, view, or operation of your action

gear.

4Only operate the product while you are safe and still.

Switching on the product

1. Press and hold the power button A

1 for 3 - 5 seconds to switch on the product.

4The status indicator LED A4 lights up red.

A welcome screen appears, and the product enters video mode.

Switching between modes

Switch between modes by pressing the power button A1.

Record photo and video images

• In video recording mode, press the OK button A7 to start or stop recording video.

• In photo shooting mode, press A7 to take a photo.

View photo and video images

• In playback mode, press the up button A

e or down button A

r to go to the next or

previous photo or video.

• Press A7 to play and stop videos.

Settings menu navigation

1. In the settings menu, use Ae and Ar to navigate between options.

2. Press A7 to select and conrm options.

4For a description of the settings menu, consult the extended manual online.

Transfer les to an external device

1. Connect the product to a device with Ay.

2. Transfer les you want to save to your device.

4Alternatively, take the microSD card from the product and insert it into a card reader that

is connected to your device.

Declaration of Conformity

We, Nedis B.V. declare as manufacturer that the product ACAM07BK from our brand Nedis®,

produced in China, has been tested according to all relevant CE standards and regulations

and that all tests have been passed successfully. This includes, but is not limited to the RED

2014/53/EU regulation.

The complete Declaration of Conformity (and the safety datasheet if applicable) can be

found and downloaded via:

nedis.com/acam07bk#support

For additional information regarding the compliance, contact the customer service:

Web: www.nedis.com

E-mail: service@nedis.com

Nedis B.V., de Tweeling 28

5215 MC ’s-Hertogenbosch, the Netherlands

c Kurzanleitung

Actionkamera ACAM07BK

Weitere Informationen nden Sie in der erweiterten Anleitung online:

ned.is/acam07bk

Bestimmungsgemäße Verwendung

Die Nedis ACAM07BK ist eine kleine und leichte Actionkamera, die Ihnen die Aufnahme von

HD Bildern und Videos ermöglicht.

Produkt Specifikationer

Mærke:	Nedis
Kategori:	Action kameraer
Model:	ACAM07BK
Bredde:	59 mm
Dybde:	29 mm
Højde:	41 mm
Vægt:	240 g
Produktfarve:	Sort
Opladningstid:	3 t
Batterikapacitet:	400 mAh
Indbygget skærm:	Ja
Pakkevægt:	331 g
Pakkedybde:	65 mm
Pakkebredde:	265 mm
Pakkehøjde:	125 mm
Skærm diagonal:	2 "
Kompatible hukommelseskort:	MicroSD (TransFlash)
Wi-Fi:	Ingen
Bluetooth:	Ingen
Batteriteknologi:	Lithium-Ion (Li-Ion)
HD-type:	Fuld HD
Understøttede videotilstande:	1080p
Understøttede videoformater:	AVI
Skærm:	TFT
Husmateriale:	Acrylonitrilbutadienstyren
Vandtæt op til:	30 m
Beskyttelsesfunktioner:	Vandtæt
Hurtig start guide:	Ja
Kabler inkluderet:	USB
Pakketype:	Kasse
Understøttede billedformater:	JPG
Near Field Communication (NFC):	Ingen
LED-indikatorer:	Ja
Udgangsspænding:	5 V
Udgangsstrøm:	1 A
Batterilevetid (maks.):	1.5 t
Batteridrevet:	Ja
GPS (satellit):	Ingen
Lagermedie:	Hukommelseskort
Emballageindhold:	Action camera with waterproof housing\nMounting kit\nBattery\nBandages\nUSB cable\n3M mats\nQuick start guide
Samlet antal megapixels:	12 MP
Maksimal videoopløsning:	1920 x 1080 pixel
Videoopløsninger:	640 x 480,1280 x 720,1920 x 1080 pixel
Maksimal størrelse på hukommelseskort:	32 GB
Maksimum billedhastighed:	30 fps
Vandafvisende:	Ja
Synsfelt vinkel (FOV):	100 °
Tidsperiode tilstand:	Ja
Batteri medfølger:	Ja
Flip-ud skærm:	Ingen
Hukommelseskort inkluderet:	Ingen
Undervandsbeholder:	Ja
Undervandskabinet vandtæt op til:	30 m
Klipbeslag:	Ja
Bandage(r) inkluderet:	Ja
Selvklæbende bagside:	Ja
