The All-Round Flashlight Expert
User Manual
MH27
Features
• Designed for law enforcement, hunting and tactical applications
• Utilizes a CREE XP-L HI V3 LED
• Integrated “Precision Digital Optics Technology” provides extreme reflector performance
• Maximum beam intensity up to 53,500cd
• Maximum beam distance up to 462 meters
• Uses one 18650 Li-ion battery for maximum runtime up to 708 hours
• High efficiency constant current circuit enables maximum output up to 1,000 lumens
• Equipped with unique tricolored (red, green and blue) tactical /signaling lights
• 4 brightness levels and 6 special modes are easily accessible via dual side switches
• Direct access to turbo and red modes
• Features advanced temperature regulation (ATR) technology
• Spring-loaded impact absorption mechanism with reverse polarity protection (Chinese patent:
201220677948.7)
• Intelligent Li-ion battery charging circuit (via Micro-USB charging port)
• A power indicator built into the side switch indicates remaining battery power (accurate to 0.1V)
• Intelligent memory function for brightness levels and special modes (except SOS and location
beacon)
• Tactical lanyard enclosed
• Stainless steel retaining ring protects core components from damage
• Toughened ultra-clear mineral glass with anti-reflective coating
• Constructed from aerospace grade aluminum alloy
• HAIII military grade hard-anodized
• Waterproof in accordance with IPX-8 (submersible to two meters)
• Impact resistant to 1.5 meters
• Tail stand capability
Dimensions
Length: 6.08” (154mm)
Head diameter: 1.57” (40mm)
Tail diameter: 1” (25.4mm)
Weight: 5.99oz (170g) (without battery)
Direct Access to Turbo
With the MH27 turned on, press and hold the Step-up switch for one second to enter turbo
mode (1,000 lumens) directly;
With the MH27 turned off, press and hold the Step-up switch , and press the tailcap switch all
the way down to enter turbo mode (1,000 lumens) directly.
Direct Access to Red
With the MH27 turned on, press and hold the Step-down switch for one second to enter red
illumination directly;
With the MH27 turned off, press and hold the Step-down switch , and press the tailcap switch
all the way down to enter red illumination directly;
Special Modes (Strobe/Location Beacon/SOS/Police
Warning Signals)
With the MH27 turned on, press the Step-up and Step-down switches simultaneously to enter
strobe mode.
Once in Strobe, press the Step-up switch once to enter Location Beacon, and once again to
enter SOS (no cycling back). Press the Step-down switch to enter modes in reverse order.
When in Strobe, press the Step-down switch to switch from strobe, blue and red police warning
signal, red police warning signal, to blue police warning signal (no cycling back). Press the Step-up
switch to enter modes in reverse order.
To exit special modes, press the Step-up and Step-down switches simultaneously again. The
MH27 will resume the brightness level last used.
Note: The MH27 has a memory feature. Upon turning-on, it will resume the brightness level or
special mode last used (with the exception of SOS and location beacon).
Charging
The MH27 features an intelligent charging function. Turn the MH27 on, connect the flashlight
charging port to a USB power source (USB adaptor, computer, etc) via a USB cord. The normal
charging time for an 18650 battery is 6 hours.
Output & Runtime
NOTICE:
The above data has been measured in accordance with the international flashlight testing standards
ANSI/NEMA FL1 using one x 3.7V 3400mAh Nitecore 18650 battery and 2 x 3V 1700mAh Nitecore
CR123 batteries under laboratory conditions. The data may vary slightly during real world use due to -
battery type, individual usage habits and environmental factors.
Operating Instructions
Battery Installation
Insert one 18650 battery or two CR123 batteries as
illustrated, with the positive (+) ends pointing to the
flashlight head.
Warning: DO NOT direct beam towards human or
animal eyes.
Momentary Illumination
Press the tailcap switch partway down and hold to
momentarily turn the light on. Release the tailcap switch to
turn the light off.
Accessories
Quality USB charger, holster, clip, tactical
ring, lanyard, spare charging port cover,
spare O ring, spare tailcap cover-
Battery Options
4.2V3.5V 3.7V 3.9V
Low Power Full Power
6.4V4.8V 5.6V 6.0V
Low Power Full Power
18650×1:
CR123×2:
Thanks for purchasing NITECORE!
Power Tips
With the flashlight turned off, press all three switches simultaneously to activate battery voltage
indication. Tthe blue power indicator will blink to indicate battery voltage (accurate to ±0.1V). For
example, when battery voltage is at 4.2V, the blue power indicator will blink 4 times, followed by a
1.5 second pause and another 2 blinks. Different voltages represent the corresponding remaining
battery power levels.
SYSMAX Industry Co., Ltd.
TEL: +86-20-83862000
FAX: +86-20-83882723
E-mail: info@nitecore.com
Web: www.nitecore.com
Address: Rm1401-03, Glorious Tower, 850 East Dongfeng Road,
Guangzhou, China 510600
20160914
*Warning: Charge 18650 rechargeable Li-ion batteries only. Do not charge
CR123 or RCR123 batteries.
TYPE
Nominal voltage
Compatible
Primary Lithium battery * CR123 3V Yes (Compatible but can
NOT be recharged)
Yes (Compatible but can
NOT be recharged)
18650 Rechargeable Li-ion battery 18650 3.7V Yes (Recommended and
can be recharged)
Rechargeable Li-ion battery * RCR123 3.7V
On/Off Operation
To turn the MH27 on, press the tailcap switch all the way down until a “click” is heard;
To turn the MH27 off, press the tailcap switch all the way down again until a “click” is heard;
Brightness Levels
With the MH27 turned on, press the Step-up switch repeatedly to switch from Blue, Green, Red,
Ultralow, Medium, High, and ends at Turbo.
With the MH27 turned on, press the Step-down switch repeatedly to switch between the above
mentioned levels and modes in reverse order until Blue.
1. Under normal charging conditions, the blue indicator in the side
switches will blink once every 1.5 seconds. When charging is
complete, the blue indicator will illuminate steadily.
2. If a problem is detected during the charging process, the MH27
will stop charging and the blue indicator will blink rapidly. This is
usually caused by damaged or incorrectly inserted batteries.
NOTE: After voltage reporting, the power indicator will blink once every 3 seconds to unveil the
location of the MH27. A full 18650 will keep the torch in this status operational for 1 year.
ATR Technology
Advanced temperature regulation (ATR) technology allows MH27 to dynamically adjust output
performance based on its internal temperature. This prevents damage from overheating and
prolongs its working life.
Changing / Charging Battery
When batteries are close to depletion, the brightness level will be locked at ultralow to protect
batteries. Please change batteries at this time.
Maintenance
Every 6 months, threads should be wiped with a clean cloth followed by a thin coating of
silicon-based lubricant.
Warranty Service
All NITECORE® products are warranted for quality. Any defective / malfunctioning NITECORE®
product can be repaired free of charge for a period of 60 months (5 years) from the date of
purchase. Beyond 60 months (5 years), a limited warranty applies, covering the cost of labor and
maintenance, but not the cost of accessories or replacement parts.
The warranty is nullified in all of the following situations:
1. The product(s) is/are broken down, reconstructed and/or modified by unauthorized
parties.
2. The product(s) is/are damaged through improper use.
3. The product(s) is/are damaged by leakage of batteries.
For the latest information on NITECORE® products and services, please contact a local
NITECORE® distributor or send an email to service@nitecore.com
※All images, text and statements specified herein this user manual are for reference purpose only.
Should any discrepancy occurs between this manual and information specified on
Please find us on facebook:
NITECORE Flashlights
4h45min
53,500cd
(Peak Beam Intensity)
462m
(Beam Distance)
IPX-8, 2m
(Waterproof AND Submersible)
1.5m
(Impact Resistant)
TURBO HIGH MID ULTRALOW
RED GREEN BLUE
19h19h19h
6h15min 28h28h28h
1 28h h 708h
505h20h45min
LUMENS
1000
LUMENS
250
LUMENS
55
LUMEN
1
LUMENS
13
LUMENS
19
LUMENS
3
