(English) NWE30 (Deutsch) NWE30 Features
Specications
Accessories
Battery Options
Battery Installation
(Español) NWE30 (Francais) NWE30
Operating Instructions
1. Battery Installation
Insert the battery with the negative end towards the spring.
2. Activating the Whistle
The NWE30 has a twist-and-buzz interface. Tighten the tail cap to
turn it o and loosen the tail cap to turn it on. When it is on, it will
buzz once every 10 seconds. (It is normal that the product starts
working once the tail cap is in contact with the battery.)
Warnings:
1.
Due to the loud buzzing of 120dB and the beacon ashing of 2,000
lumens, it is recommended to cover the PC shell with the hand to
avoid getting startled before tightening the tail cap.
2. Ensure the battery is inserted with the negative end towards
the spring. The product will not work if the battery is incorrectly
inserted.
3. CAUTION! Possible dangerous radiation! Don't look into the light!
May be dangerous for your eyes.
4. Please DO NOT put it close to the ears to avoid harm to the hearing
when the product is working.
5. The standby time is approx. 6 months when a 1,600mAh CR123A
battery is inserted.
Smart Sensor Beacon Flashing
The NWE30 has a smart sensor beacon ashing function. When it is
turned on in the dark, it will automatically activate the beacon ashing
and cycle through the following modes: "Buzzing – O – Beacon
Flashing – O – Beacon Flashing – O"
Bedienungsanleitung
1. Einsetzen der Batterie
Setzen Sie die Batterie / den Akku mit dem negativen Pol in Richtung der
Feder ein.
2. Aktivieren des Notfall-Signalgerätes
Die Aktivierung des NWE30 erfolgt durch Drehen der Heckkappe. Ziehen Sie
die Heckkappe fest, um das Notfall-Signalgerät auszuschalten und lockern Sie
die Endkappe, um es einzuschalten. Wenn es eingeschaltet ist, ertönt der Ton
einmal alle 10 Sekunden. (Es ist normal, dass das Gerät zu arbeiten beginnt,
sobald die Endkappe in Kontakt mit der Batterie ist.)
Warnung
1. Aufgrund des lauten Tons von 120dB und des Blinkens vom Warnlicht mit
2000 Lumen wird empfohlen, das PC-Gehäuse mit der Hand abzudecken, um
sich vor dem Festziehen der Heckkappe nicht zu erschrecken.
2. Stellen Sie sicher, dass die Batterie mit dem negativen Ende in Richtung
Feder eingesetzt wird. Das Produkt funktioniert nicht, wenn die Batterie
falsch eingesetzt ist.
3. ACHTUNG! Möglicherweise gefährliche optische Strahlung! Bei Betrieb nicht
direkt in das Licht blicken. Dies kann für die Augen gefährlich sein.
4. Wenn das Notfall-Signalgerät in Betrieb ist, achten Sie auf ausreichenden
Abstand zu den Ohren, um Gehörschäden zu vermeiden.
5. Bei Verwendung einer 1600mAh CR123A-Batterie beträgt die Standby-Zeit
beträgt ca. 6 Monate.
Blinkendes Warnlicht
Das NWE30 verfügt über eine intelligente Sensor-Blinklicht-Funktion. Bei
Aktivierung im Dunkeln, wird automatisch das blinkende Warnlicht eingeschaltet
und durchläuft den folgenden Modus: "Notfall-Ton" - "Aus" - "Warnlicht blinken"
- "Aus" - "Warnlicht blinken" - "Aus".
Instructions
1. Installation de la batterie
Iinsérez la batterie avec l'extrémité négative vers le ressort.
2. Activer le siet
Le NWE30 possède une interface twist-and-buzz. Serrez le capuchon
arrière pour l'éteindre et desserrez le capuchon arrière pour l'activer.
Lorsqu'il est allumé, il sonnera une fois toutes les 10 secondes. (Il
est normal que le produit commence à fonctionner une fois que le
capuchon arrière est en contact avec la batterie.)
Avertissement:
1. En raison du siement fort de 120 dB et du clignotement de la
balise de 2 000 lumens, il est recommandé de couvrir la coque avec
la main pour éviter d'être surpris avant de serrer le capuchon arrière.
2. Assurez-vous que la batterie est insérée avec l'extrémité négative
vers le ressort. Le produit ne fonctionnera pas si la batterie n'est pas
insérée correctement.
3. ATTENTION! Rayonnement dangereux possible! Ne regardez pas la
lumière directement! Peut être dangereux pour vos yeux.
4. Veuillez NE PAS le placer près des oreilles pour éviter de nuire à l'ouïe
lorsque le produit fonctionne.
5. Le temps de veille est d'env. 6 mois lorsqu'une batterie CR123A de
1600 mAh est insérée.
Balise
Le NWE30 possède une fonction de clignotement de balise intelligent.
Lorsqu'il est allumé dans l'obscurité, il active automatiquement le
clignotement de la balise et passe en revue les modes suivants:
"Buzzing - O - Clignotant Balise - O - Clignotant Balise - O"
Instrucciones de operación
1. Instalación de batería
Inserte la batería con el polo negativo hacia el resorte.
2. Activación del silbato
El NWE30 tiene una interfaz de giro y zumbido. Apriete la tapa
trasera para apagar y aoje la tapa trasera para encender. Cuando
está encendido, zumbará una vez cada 10 segundos. (Es normal que
el producto empiece a funcionar una vez que la tapa trasera está en
contacto con la batería.)
Advertencias:
1. Debido al fuerte zumbido de 120dB y al parpadeo de la baliza de
2,000 lúmenes, se recomienda cubrir la carcasa de policarbonato
con la mano antes de apretar la tapa trasera para evitar sobresaltos.
2. Asegúrese de que la batería está insertada con el polo negativo
hacia el resorte. El producto no funcionará si la batería está
insertada incorrectamente.
3. ¡PRECAUCIÓN! ¡Posible radiación peligrosa! ¡No mire directamente a
la luz! Puede ser peligroso para sus ojos.
4. Por favor NO coloque cerca de los oídos para evitar daños en los
mismos cuando el producto esté funcionando.
5. El tiempo de espera es de aproximadamente 6 meses cuando se
inserta una batería CR123A de 1,600mAh.
Luz intermitente con sensor inteligente
El NWE30 tiene una función de luz intermitente con sensor inteligente.
Cuando es encendida en la obscuridad, automáticamente activará la
luz intermitente y cambiará entre los siguientes modos: "Zumbido
– Apagado – Baliza intermitente – Apagado – Baliza intermitente –
Apagado"
• Emergency Electronic Whistle with a buzzing output of 120dB
• Omnidirectional sound diraction system
• Smart sensor beacon ashing automatically in the dark with a
brightness output of 2,000 lumens
• Utilizes 4 x Luminus SST-20-W LEDs with a cylindrical PC diuser to
emit 360° beacon ashing
• Powered by 1 x CR123A battery with a max runtime of 72 hours
• Ultra compact, lightweight and durable design with a simple user
interface
• Rating in accordance with IP68 (2 meters submersible)
• Impact resistant to 1 meter
Diameter: φ25mm (φ0.98")
Height: 67mm (2.64")
Weight: 35g (1.23oz)
Key Clasp, Spare O-ring, CR123A Battery
Type Nominal Voltage Compatibility
Primary Lithium
Battery CR123A Y (Recommended)3V
Rechargeable
Li-ion Battery RCR123A 3.6V/3.7V Y (Recommended)
NWE30
120dB Buzzing Output
Sound Diffraction System
Smart Sensor Beacon Flashing
Emergency Electronic Whistle
SYSMAX Innovations Co., Ltd.
TEL: +86-20-83862000
FAX: +86-20-83882723
E-mail: info@nitecore.com
Web: www.nitecore.com
Address: Rm2601-06,Central
 Tower,No.5XiancunRoad,
 TianheDistrict,Guangzhou,
 510623,Guangdong,China
Please 󽗉nd us on facebook : NITECORE Flashlight
Thanks for purchasing NITECORE!
NWE01073020
Made in China
