User Manual
Features
·The world’s smallest 4000 lumen LED flashlight
·Utilizes 4 x CREE XM-L2 U3 LEDs
·Integrated multi-function OLED display
·Thermal protection circuit prevents overheating
·Compatible with both 18650 Li-ion and CR123 batteries
·Intelligent charging circuit with voltage detection charges safely and rapidly
·Exceptionally long runtimes using 4 × 18650 Li-ion or 8 × CR123 batteries
·Capable of using 1 × 18650 or 2 x CR123 batteries in emergency situations
·Eight rapidly switchable brightness levels and modes to select from
·Innovative single button two-stage switch provides a user-friendly interface
(Chinese Patent: Z L201120062948.1)
·Toughened ultra-clear mineral glass with anti-reflective coating
·Integrated “Precision Digital Optics Technology” provides extreme reflector
performance
·Stainless steel bezel ring protects core components from damage
·Constructed from aerospace-grade aluminum alloy
·HAIII military grade hard-anodized
·Waterproof in accordance with IPX-8 (submersible to two meters)
Dimensions
Length: 142mm (5.6”)
Head diameter: 68 mm (2.68”)
Head side-length: 57mm (2.24”)
Tube diameter: 50mm (1.96”)
Weight: 438g (15.45oz) (without battery)
Accessories
Charger, quality holster, lanyard, and spare O-ring
Battery Options
Operation instructions
Battery installation
Unscrew the tailcap, insert 4 × 18650 Li-ion or 8 × CR123 batteries with the
positive (+) end pointing toward the flashlight head. Replace the tailcap. In
special circumstances, such as emergency situations, between one and three
18650 Li-ion or two and six CR123 batteries may be used.
Thanks for purchasing NITECORE!
Output & Runtime
NOTICE
The above data has been measured in accordance with the international
flashlight testing standards ANSI/NEMA FL1 using 4 x Nitecore 18650（3.7V
2600mAh) and 8 x Nitecore CR123 3V 1550mAh batteries under laboratory （
conditions. The data may vary during real-world use due to battery type,
individual usage habits and environmental factors.
®
The All-Round Flashlight Expert TM 26
Note 1: Due to the strain using less than 4 x 18650 or 8 CR123 places on
batteries, Nitecore recommends using this feature only when
necessary and for short periods of time. Please see point number 1
in the warning below.
Note 2: After loading batteries, “NITECORE” will be displayed on the OLED
screen for 2.5 seconds followed by battery voltage (accurate to
0.01V) after which the TM26 will enter into standby mode.
WARNING
1. Using less than 4 x 18650 or 8 x CR123 batteries can lead to turbo mode
malfunctioning, can trigger the overload protection circuit in Li-ion batteries
and can even lead to explosion of CR123 batteries. As such Nitecore
recommends this function is used with caution and only when necessary.
2. Insert batteries with the positive (+) end pointing toward the flashlight head.
3. Do not mix rechargeable and non-rechargeable batteries.
4. Do not mix batteries of different types/brands.
5. Do not mix batteries of different charge levels.
6. Do not use lithium batteries without a protected circuit board.
7. This product does not support unprotected 18650 Li-ion batteries. Please
also ensure that all the 18650 batteries used in the TM26 have a button top
configuration or they will not make contact with terminals in the battery
compartment. We recommend Nitecore 18650 batteries for the best
performance and reliability.
Charging the TM26
1. Connect the charging cable to the flashlight and the A/C power adapter to
the wall outlet as shown in the adjacent image. Fully charging four depleted
18650 batteries takes approximately 7 hours.
2. Under normal charging conditions, the on/off switch’s blue indicator light will
blink twice every second and the OLED screen with display the word
‘Charging...” together with battery voltage.
3. If a problem is detected while charging the TM26 will stop charging, the blue
indicator will blink rapidly and the OLED display will show the word
“ERROR”. This is usually caused by faulty or incorrectly inserted batteries.
4. When charging is complete, the blue indicator will remain on, and
“CHG.FINISHED” along with battery voltage will be displayed on the OLED
screen.
*Warning: Charge 18650 rechargeable Li-ion batteries only, do not attempt to
charge non-rechargeable batteries, CR123 or RCR123 batteries.
SIZE
Nominal voltage
Compatible
Primary Lithium battery * CR123 3V Yes (Compatible but can
NOT be recharged)
Yes (Compatible but can
NOT be recharged)
18650 Rechargeable Li-ion battery 18650 3.7V Yes (Recommended and
can be recharged)
Rechargeable Li-ion battery * RCR123 3.7V
TURBO HIGH MID LOW
LUMENS
1900
LUMENS
4000
LUMENS
700
LUMENS
230
45min
1
h
5
h min45
2
h min30
8
h min15
48
h
2
h min15
32
h
LOWER
LUMENS
3
1000
h
750
h
454m (Beam Distance)
51600cd (Peak Beam Intensity)
IPX-8, 2m
(Waterproof AND Submersible)
1.5m (Impact Resistant)
8×CR123
4×18650
