Privileg PFVN 266 W Manual

Privileg Fryser PFVN 266 W

Læs nedenfor 📖 manual på dansk for Privileg PFVN 266 W (1 sider) i kategorien Fryser. Denne guide var nyttig for 6 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere

Download PDF
Side 1/1
EN
1. Control panel
2. LED’s lighting*
3. Ice packs*
4. Ice Mate* or Ice tray*
5. Drawer divider*
6. Bottle rack*
7. Glass shelves
8. Rating plate with commercial name
9. Door reversibility kit
10. Area for freezing fresh food or to store
frozen food
11. Area for storing frozen foods
12. Door seal
* Available on selected models
HOW TO START THE APPLIANCE
After plugging the appliance to the mains, it starts the
operation automatically. After starting the appliance,
wait at least 4-6 hours before placing food into the
appliance. When the appliance is connected to the
power supply, the display lights up and all the icons
appear on the display for approximately 1 second.
The default (factory) values of the freezer
compartment settings light-up.
HOW TO REVERSE THE DOOR SWING
- see enclosed Instructions for Use (Version_2)
Is recommended to reverse door swing by two persons.
There is not foreseen door reversibility for:
- models with integrated handle
- models with glass panel on the door.
Specifications, technical data and images may
vary from model to model
12
3
11
2
8
10
4
6
5
7
9
1
Read the Instructions for Use carefully before
using the appliance.
400004448200
QUICK START GUIDE
ALARMS TABLE
ALARM TYPE Signal Cause Cure
Door open alarm The acoustical alarm is activated and the Alarm Indicator blinks. The door has remained open for more than 2 minutes. Close the door or press the Stop Alarm to mute the acoustical alarm.
Temperature alarm The Temperature display blinks (°C) and the Alarm Indicator remains on. The inside temperature is not adequate. Press the Stop Alarm button ; the acoustical alarm stops, the Temperature Display
(°C) and the Alarm Indicator remain on until a temperature < -10°C is reached.
Party Mode alarm The Party Mode Indicator
blinks and the acoustical alarm is activated.
30 min. elapsed since Party Mode function has been activated. It is time to take
out the bottle from the freezer (see Instructions for Use for more details).
Press the Party Mode button or alternatively Stop Alarm button to deactivate the Party
Mode alarm - and remove the bottle from the freezer.
Long black-out alarm The Black Out Alarm icon remains on, the Alarm indicator blinks and the Temperature
display (°C) blinks, showing the maximum temperature reached during blackout. Prolonged power failure, able to cause the inside temperature to increase to 0°C. Press the Stop Alarm button ; the acoustical alarm stops, the Temperature Display
(°C) and the Alarm Indicator
remain on until a temperature < -10°C is reached.
Malfunction The letter “F” blinks on the display (°C). Product malfunction. Contact the After-sales Service.
DE GB
ON/STANDBY indicator
FAST FREEZE indicator
ON/STANDBY button
To put the product in Stand-by, press and hold for
3 seconds. All the icons turn off except On/Standby
indicator . To reactivate the appliance press once
(briefly) this button.
ECO NIGHT indicator
ECO NIGHT (NIGHT TIME RATE) button
Press to activate/deactivate the Eco Night function. The Eco
Night function enables appliance energy consumption to be
concentrated in the reduced rate hours, generally at night
(see the Instructions for Use).
BLACK OUT ALARM
Long Black-out Alarm indicator.
(see the Instructions for Use)
PARTY MODE indicator
PARTY MODE button
Press to activate/deactivate the Party Mode function.
Use this function to chill drinks inside the freezer
compartment.
Important: do not leave the bottle inside the freezer
compartment longer than the function is active
(30 minutes).
STOP ALARM button
Press in case of alarm.
ALARM indicator (see the below Alarms Table)
TEMPERATURE/FAST FREEZE button
Temperature Setting
The appliance is normally factory-set for operation at the recommended temperature of -18°C.
The internal temperature can be adjusted between -16°C and - 24°C, proceeding as follows:
• Press the temperature setting button (°C). The storage temperature can be changed by -1°C
with each pressure of the button: the value changes cyclically between -16°C and -24°C.
Fast Freeze
• Press for 3 seconds to activate the Fast Freeze function (see the Instructions for Use)
The function switches off automatically after about 50 hours.
TEMPERATURE DISPLAY
Printed in Italy 03/16 - Privileg® Registered trademark/TM Trademark of IRE Beteiligungs GmbH - Copyright IRE Beteiligungs GmbH 2014. All rights reserved
FR

Produkt Specifikationer

Mærke: Privileg
Kategori: Fryser
Model: PFVN 266 W
