Warnings and Cautions
1of2
Assembly Instruction Sheet #IS-AS1716PN
For Style AS1716PN
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2015 QuoizelInc.
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing the fixture. We strongly
recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool before removal. Do not subject
glass parts to any shock while in operation or shattering may result.
August2015
Please go to for product cleaning tips. Go to the selection.
(4) B10 Candelabra Base 60W Maximum.
30-45 minutes
Identify and inspect all parts before beginning installation. Check package content list and diagrams below to be sure all parts are
present. If any parts are missing or damaged, do not attempt to assemble, install, or operate the fixture. Contact customer service for replacement
parts.
www.quoizel.com Care + Maintenance
Light Source:
Estimated Assembly Time:
Preparation:
Tools Required: Flathead screwdriver, Phillips screwdriver, pliers, wire cutters, wire strippers, electrical tape, safety glasses.
STEP 5 - Install Shade to Fixture
A. This fixture uses candelabra
bulb with screw base. Maximum
60 watts. Insert bulb and screw
snugly into place.
Your fixture is now assembled
and ready to use. Enjoy!
Figure 5
Socket
Bulb
Package Contents
B
Crossbar
x 1
Lock Washer
x 1
Hex Nut
x 2
Nipple
x 1
A
STEP 2 Install Crossbar-
A. A)Attach the Crossbar ( to the Outlet Box with the head of the Green
Ground Screw facing you. Secure it with Outlet Box Screws (not
included) Tighten until snug. .
Figure 1
Outlet Box
Outlet Box Screw
(not included)
Green Ground
Screw
G
Fixture
Body
x 1
STEP 3 Install Fixture Body-
*Pliers is required for this step.
A. Thread Hex Nut (C) to the middle of the Nipple (D). Place Lock
Washer (B) over the Nipple (D) and then thread the Nipple (D) into
the Crossbar (A) until the Nipple (D) is about 0.375” above the
Crossbar (A).
Figure 3
C
D
Lock Nut
x 1
E
A
B
C
D
D
STEP 4 - Wire Connections
A. Use standard wire connectors (not included) to make all wire
connections. (Connectors are not included with fixture.) Twist
connectors until wires are tightly joined together. Wrap each
connection with approved electrical tape and carefully stuff all the
connected wires into the Outlet Box.
White wire
from supply White wire
from fixture
Black wire from
supply (or Red)
Black wire
from fixture
Ground wire
from supply
Ground wire
from fixture
Figure 4
F
Side Arm
x 3
STEP 1 Assemble Side Arms-
A. Remove Hex Nut and Washer from the Side Arm (F). Attach the loop
end of the Side Arm (F) to the inside arm of the Fixture Body (G).
Hex Nut
Washer
F
G
Ceiling
Canopy
Inside
Arm
Loop
Pass the nipple at the top
end of the Side Arm (F)
through the hole on the
Ceiling Canopy. Place the
Washer back onto top end
of the Side Arm (F) and by
using Spanner (H) thread
the Hex Nut onto the Side
Arm (F) to secure them
together. Hand tighten until
snug.
Figure 2
A
Ceiling
Canopy
G
(Step 3 Continued)
B. Place the Ceiling Canopy of the Fixture
Body (G) over the Nipple (D) against the
ceiling to determine the correct position
of the Nipple (D). Thread the Lock Nut (E)
onto the Nipple (D). Adjust the Nipple (D)
to allow the Ceiling Canopy of the
Fixture Body (G) to rest against
the ceiling when held in place by
the Lock Nut (E).
C. Remove the Lock Nut (E) and the
Fixture Body (G). Tighten the Hex
Nut (C) against the Crossbar (A)
to secure in place.
D. Refer to Step 4 for wire
connections.
E. Place the Ceiling Canopy of the
Fixture Body (G) back over the
Nipple (D) and secure with the
Lock Nut (E). Hand tighten until
snug.
HSpanner
x 1
H
