Features
USB Type-C Male (Connect to a host computer)
Rocstor introduces the Type-C 7-in-1 hub, equipped with HDMI, 2 USB-A, RJ45, SD/TF
card slots, and a Type-C female port, oering an optimal solution for expanding the
port options of Type-C or Thunderbolt 3 hosts (PC/Laptop/Mobile phone, etc.),
particularly benecial for those with a single Type-C port. With its integrated captive
cable designed for easy wrapping at the bottom, this hub enhances user experience
and convenience. It facilitates dual max 4k/60Hz HDMI video output while concurrent-
ly transferring USB 3.1 data at up to 5Gbps. The 2 USB-A ports enable simultaneous
connection of 2 USB devices, while the SD/Micro SD card slots allow for the insertion of
2 cards simultaneously for data transmission or accessing information on the host. The
RJ45 port provides access to Gigabit Ethernet for high-speed connectivity. Additional-
ly, the Type-C female port supports PD 3.0 with a maximum power delivery of 100W
for PD Charging. Compatible with all DP Alt mode supported Type-C hosts, this hub
ensures seamless compatibility and enhanced functionality.
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the packaging:
• Main Unit x1
• User Manual
HDMI（DP Alt Mode Only）
• Supports max 4K/60Hz
• Supports 8/10/12 bit color depth output
• Support output pixel format
RGB/YCbCr4:4:4/YCbCr4:2:2
• Supports HDR
• Supports HDCP 2.2&HDCP1.4
Note: When connecting a DP1.4 Alt mode
supported host, the max resolution of
HDMI is 4k/60Hz; When connecting a
DP1.2 Alt mode supported host, the max
resolution of HDMI is 4k/30Hz due to
bandwidth limitation
Upstream:
Downstream:
• Supports DP1.4 Alt mode, downward compatible with DP1.2 Alt mode
• Supports HBR3
Note: To get max bandwidth, the host should support DP1.4 Alt mode
USB-A X2
• Max 5Gbps data transmission per port
• Supports max 7.5W(5V/1.5A)
downstream charging the port next to
SD card slot ，another port supports
max 900mA downstream charging.
• 2 USB-A share max 2A output
• Supports short-circuit, over-current,
over-voltage protection
RJ45
• Supports Gigabit
Ethernet,10M/100M/1000M
• Supports Wake-On-LAN
• Supports full duplex ow control
• Light indicates the state, no
light when no Internet connected,
orange light turns on when network
connection is established, yellow light
ashes when transmitting data
SD/Micro SD 3.0
• Supports SD3.0 UHS-I up to 104MBps
data rate
• Allow 2 card slots to work simultaneously
Type-C Female X1
(for PD Charging)
• Supports max 100W PD charging
• Supports PD3.0 Fast Role Swap, the
connected device will not get
disconnected while plugging in and out
PD Adapter
• 15W is dedicated to the functioning of
this product, the rest power (max 85W)
will be passed to charge for the host
computer
Package Contents
Specication
Input
Output HDMI Female p1-x1
USB-A Female x2
RJ45 x1
SD/Micro SD 3.0 x1
Type-C Female x1
USB-C Male x1
3 Years
Operating Temperature
Storage Humidity
Storage Temperature
Operating Humidity
0°C to 45°C (32°F to 113°F)
10% to 90 % RH (no condensation)
-10°C to 70°C (14°F to 158°F)
10% to 90% RH (no condensation)
Introduction
Environmental
Input / Output Connector
Certications FCC, CE
Regulatory Approvals
User Manual English Version
Accessory Adapter
Warranty
Limited Warranty
Operating Temperature
Size 4.3x1.9x0.6in (110x50x16.2mm)
Mechanical
Weight 2.4lbs (75g)
®
Type-C to HDMI/USB-AX2/RJ45
with DP1.4 Alt mode
User Manual
Y10A305-S1
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
