Carrying Case for V-Drums Portable CB-TDP Owner’s Manual
Before using this unit, carefully read the sections entitled “USING THE UNIT SAFELY” and “IMPORTANT NOTES.” These sections provide important information
concerning the proper operation of the unit. Additionally, in order to feel assured that you have gained a good grasp of every feature of your new unit, read
this manual should be read in its entirety. This manual should be saved and kept on hand as a convenient reference.
Storage
1. Place the cushion between the legs of the stand for the V-Drums Portable, and use the strap to secure it. Grasp the frame of the
V-Drums Portable, and place it in the carrying case.
* For details on how to fold up the V-Drums Portable, refer to the owner’s manual for the V-Drums Portable.
* Make sure that you have rmly tightened the screws of the V-Drums Portable.
Grasp the frame at these locations and
place the unit in the carrying case.
2. Remove the beater from the kick pedal. Place the kick pedal in the kick pedal pouch, and close the fastener.
* For details on how to remove the beater, refer to the owner’s manual for the kick pedal.
After removing the beater,
place it in the pocket of the carrying case.
Beater
3. Loosen the two anchor bolts of the hi-hat control pedal. Place the hi-hat control pedal in the hi-hat control pedal pouch, and close the
fastener.
* The anchor bolts have sharp tips; handle them with caution.
Do not extend the tips of the
anchor bolts more than 5 mm.
4. Place the kick pedal pouch and the hi-hat control pedal pouch in the carrying case, and close the fastener of the carrying case.
k pedal pou
Hat control pedal po
Position the pouches as shown in the diagram.
Contents
Carrying case Kick pedal pouch
The kick pedal should be stored in this pouch.
Hi-Hat control pedal pouch
The hi-hat control pedal should be stored in this pouch.
Cushion
WARNING
Adults must provide supervision in places where
children are present
When using the unit in locations where
children are present, be careful so no
mishandling of the unit can take place. An
adult should always be on hand to provide
supervision and guidance.
Do not drop or subject to strong impact
Do not drop this case or subject it to strong
impact while your instrument is stored in it.
CAUTION
Avoid climbing on top of the unit, or placing heavy
objects on it
Never climb on top of, nor place heavy
objects on this case while your instrument is
stored in it.
Copyright © 2012 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written permission of ROLAND
CORPORATION.
Roland and V-Drums are either registered trademarks or trademarks of Roland Corporation in the United States and/or
other countries.
Main Specications
Roland CB-TDP: Carrying Case
Main Material Polyester
Dimensions
580 (W) x 350 (D) x 680 (H) mm
22-7/8 x 13-13/16 x 26-13/16 inches
(Excluding protruding parts)
Weight 2.0 kg / 4 lbs 7 oz
Accessories
Kick pedal pouch, Hi-Hat control pedal
pouch ,Cushion, Bottom support panel,
Owner’s manual
* In the interest of product improvement, the
specications and/or appearance of this unit are
subject to change without prior notice.
This product is a carrying case for the Roland
V-Drums Portable.
Placement
• Do not expose the unit to direct sunlight, place it near
devices that radiate heat, leave it inside an enclosed
vehicle, or otherwise subject it to temperature
extremes. Excessive heat can deform or discolor the
unit.
Maintenance
• For everyday cleaning wipe the unit with a soft,
dry cloth or one that has been slightly dampened
with water. To remove stubborn dirt, use a cloth
impregnated with a mild, non-abrasive detergent.
Afterwards, be sure to wipe the unit thoroughly with
a soft, dry cloth.
• Never use benzine, thinners, alcohol or solvents of
any kind, to avoid the possibility of discoloration and/
or deformation.
• Do not launder or wash the entire case.
Bottom support pa
Strap
USING THE UNIT SAFELY
Used for instructions intended to alert the
user to the risk of injury or material
damage should the unit be used
improperly.
* Material damage refers to damage or
other adverse effects caused with
respect to the home and all its
furnishings, as well to domestic animals
or pets.
Used for instructions intended to alert the
user to the risk of death or severe injury
should the unit be used improperly.
The symbol alerts the user to things that must be
carried out. The specific thing that must be done is
indicated by the design contained within the circle. In the
case of the symbol at left, it means that the power-cord
plug must be unplugged from the outlet.
The symbol alerts the user to important instructions or
warnings.The specific meaning of the symbol is
determined by the design contained within the triangle. In
the case of the symbol at left, it is used for general
cautions, warnings, or alerts to danger.
The symbol alerts the user to items that must never be
carried out (are forbidden). The specific thing that must
not be done is indicated by the design contained within
the circle. In the case of the symbol at left, it means that
the unit must never be disassembled.
About WARNING and CAUTION Notices About the Symbols
ALWAYS OBSERVE THE FOLLOWING
IMPORTANT NOTES
* 5100032033- 01*
WARNING
This product contains chemicals known to cause cancer, birth defects and other reproductive harm, including lead.
For C.A. US (Proposition 65)
