SAFETY RULES
INSTALLATION
FEATURES
WARNING:
Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in electric
shock, fire and/or serious injury.
READ ALL INSTRUCTIONS
Know your product. Read operator’s manual carefully.
Learn its applications and limitations, as well as the
specific potential hazards related to this product.
Following this rule will reduce the risk of serious personal
injury.
This accessory should only be used with the RYOBI
Link Modular Storage System. Using this accessory
with other storage systems could result in a falling hazard
that can cause death or serious personal injury.
The maximum weight of all the items placed on each
wall rail must not exceed 206 lbs.
Do not exceed the maximum weight capacity for the
wall rails or accessories.
Secure and mount each wall rail according to the wall
rail’s operator’s manual. DO NOT place accessories on
wall rails that have been improperly secured or mounted.
To reduce risk of injury, do not use accessories which
are not specifically designed and recommended by
the manufacturer.
Do not use wall rail if it is damaged or broken. A
damaged or broken wall rail may not mount securely and/
or it might not provide adequate support for the items
stored on it.
Ensure the wall rails are securely mounted. Make sure
they do not rock, slide, or move before storing products
or tools.
Do not allow children or untrained individuals to use
wall rails or accessories.
Store idle power tools out of the reach of children.
Always remove battery pack and bits/blades when
storing battery powered tools on organizer shelf.
SAVE THESE INSTRUCTIONS. Refer to them frequently
and use them to instruct other users. If you loan someone
this product, also loan these instructions.
WARNING:
To reduce the risk of injury, do not attempt to use this
product until you have read thoroughly and understand
completely this operator’s manual and the operators
manual for any wall rail used.
ATTACHING/REMOVING THE TOOL
ORGANIZER SHELF
See Figures 1 - 3.
Mount the wall rails as described in the wall rails
operator’s manual.
Position the brackets on the back of the shelf between
two of the raised octagonal patterns on the wall rail.
Insert the tabs on the shelf into the vertical slots on the
wall rail.
Ensure the shelf is level with the brackets on the back of
the shelf firmly against the wall rail, then push down on
the shelf until the brackets are secured into the octagonal
patterns on the rail.
Verify the shelf is still level and the tabs are fully inserted
into the slots on the wall rail
IMPORTANT! To ensure the shelf is seated properly,
check that the holes through the back wall of the shelf
are lined up with the corresponding holes in the wall
rail.
If desired, insert #6 screws into these holes in the back
wall of the shelf and into the holes in the wall rail for extra
support.
To remove a tool organizer shelf:
If applicable, remove #6 screws from the shelf.
Slide the shelf up and away from the wall rail.
OPERATOR’S MANUAL
TOOL ORGANIZER SHELF
STM401 PRODUCT SPECIFICATIONS
Maximum Weight Capacity*
Wall rail 206 lbs. (75 lbs. per linear foot) .............................
Tool organizer shelf 50 lbs. each ....................................
* Wall rails must be secured to the wall according to the
instructions in the wall rail’s operator’s manual to achieve
maximum weight capacity.
ONE WORLD TECHNOLOGIES, INC.
P.O. Box 1288, Anderson, SC 29622
Phone 1-800-525-2579 • www.ryobitools.com
Fig. 1
Fig. 2
Fig. 3
A - Top shelf (tablette du haut, estante superior)
B - Cubicle (cabinet, cubículo)
C - Hand tool storage (rangement pour outils à main,
almacenamiento de herramientas de mano)
A - Tabs (languettes, lengüetas)
B - Slots (fentes, ranuras)
C - Bracket (support, soporte)
A - Bracket (support, soporte)
A
A
B
C
A
C
B
