FREQUENCY RANGE
Channel 1 Frequency: 49.870, Channel 2 Frequency: 49.850
Carrier Frequency: 49.850 to 49.870
Field Strength is 80 dB Micro-volts per meter at 3 meters.
Features & Components
Quick Start Guide Using Your Monitor (continued)
Use and Care
Helpful Hints
Using Your Monitor
One (1) Year Limited Warranty
Troubleshooting
IF YOU ARE STILL HAVING PROBLEMS, PLEASE CALL TOLL FREE FOR HELP! (800) 544-1108.
©2012 Cosco Management, Inc. All Rights Reserved. Todos derechos reservados.
www.djgusa.com (800) 544-1108 www.safety1st.com Made in CHINA.
Hecho en CHINA. Styles and colors may vary. Los estilos y los colores pueden variar.
Distributed by (distribuido por) Dorel Juvenile Group, Inc., 2525 State St., Columbus,
IN 47201-7494 Dorel Distribution
Canada, 873 Hodge, St. Laurent, 5/2/12
QC H4N 2B1 4358-5848
Regist er for our eNewsletter and
wat ch our experts on Saf ety 1
st
T V
safety1st.com
IMPORTANT:
Safety Instructions
Battery Installation & Use
CAUTION!
THE USER SHOULD NOT ATTEMPT TO
SERVICE OR REPAIR THE MONITOR.
ALL SERVICING SHOULD BE REFERRED
TO SAFETY 1ST CUSTOMER SERVICE
DEPARTMENT: (800) 544-1108.
Please read the following instructions and warnings carefully.
Keep these instructions for future reference.
Tool needed: Phillips Head Screwdriver (not included)
Thank you for purchasing a Safety 1st product. We are not only about safety,
we're also about your satisfaction. If you have any questions or comments,
please call our Consumer Relations department at 1-800-544-1108 or
e-mail us at consumer@safety1st.com
User Guide
MO066
Parent Unit/
Receiver (2)
A
B
C
D
E
F
G
H
I
J
K
L
M
N
Baby Unit/
Transmitter
AC Adapters (3)
Parent Unit (2 Receivers)
Speaker
Power/Channel Switch
Low Battery Indicator
Power On Indicator
Volume Dial
External Earphone Jack
AC Adapter Jack
Belt Clip & Carry Loop
Battery Compartment (3 AAA batteries)
Baby Unit (Transmitter)
Power/Channel Switch
Power On Indicator
Microphone
AC Adapter Jack
AC Adapter
AC Adapter (3)
A
B
C
D
J
K
L
E
F
G
H
I
M
N
• mix old and new batteries.DO NOT
• mix alkaline, standard (carbon zinc), or rechargeable DO NOT
(nickel-cadmium) batteries.
• Only batteries of the same or equivalent type as recommended are to be used.
• Exhausted batteries are to be removed from the unit.
• Keep batteries out of child’s reach. Swallowing a battery could be fatal.
• Used batteries should be disposed of properly.
Do not dispose of batteries in fire - they may explode or leak and cause injury.
• Remove batteries when stored for long periods of non-use.
• use audio monitor system in portable mode when batteries are low.DO NOT
• Ensure that the battery compartment is completely secure after replacing batteries.
BATTERY INSTALLATION:
1. Move belt clip out of way. Unscrew battery
compartment cover as shown.
2. Insert 3 AAA batteries.
3. Replace the battery compartment cover
and tighten screw. To obtain maximum
performance, ALWAYS use alkaline type
batteries in this monitor.
• Parent Unit is a Receiver. Baby Unit is a Transmitter.
• Check the reception regularly.
• Certain electronic devices are sensitive to magnetic
fields and may be damaged permanently or temporarily
disabled if exposed to a magnetic field that is too strong.
• To remove AC adapter from the outlet, firmly grasp the
adapter "brick." DO NOT pull on the cord, as this could damage it.
• The LEDs emit IR (infra red) light that is not harmful.
This monitor is not intended to be used as a medical monitor and
its use should not replace proper adult supervision. You should
check your child’s activity at regular intervals as this monitor will
not alert parents to the silent activities of a child.
CAUTION!
For indoor use only. To reduce the risk of fire or electrical shock,
do not expose this product to water or moisture. NEVER attempt
to disassemble the product. This is dangerous and will void
the warranty.
WARNING!
Plug in here
1 Connect AC adapter to the side of
Parent Unit.
2 Connect AC adapter to the side of Baby Unit.
3 Plug Parent Unit and plug Baby Unit
into wall to operate AC power.
4 Turn Parent Unit on. Slide Power/Channel
switch to desired channel selection.
Power On Indicator will illuminate. Make sure
volume is turned down to avoid squealing.
5 Turn Baby Unit on. Slide Power/Channel
switch to same channel selection as Parent
Unit. Refer to Channel Selection section.
Power On Indicator will illuminate.
Plug in here
Power On &
Channel Select
here
Channel 1
Channel 2
Power On &
Channel Select
here
Channel 1
Channel 2
DO NOT PLACE UNITS IN CRIB OR MOUNT ON CRIB.
KEEP OUT OF REACH OF CHILDREN.
AC ADAPTER
The Parent Unit operates on household electricity with the AC Adapter or
with 3 AAA batteries (not included). The Baby Unit operates on household electricity
with the AC Adapter only. The Parent Unit will automatically convert to AC operation
when used with the AC Adapter. It is not necessary to remove the battery during AC
operation. The Parent Unit will automatically switch back to battery power when plug
is disconnected from the AC Adapter.
The AC Adapter should be used whenever possible on the Parent Unit to save battery
life. This is done by inserting the AC Adapter into the AC Adapter Jack. Then simply
plug the AC Adapter into a nearby standard household outlet (120V AC outlet). The AC
Adapters may become slightly warm to the touch during operation. This is normal.
This AC Adapter is a low voltage power source which allows you to use your house-
hold electricity to run the Baby and Parent Units when it connects to the AC Adapter
Jack in the Parent Unit and in the Baby Unit, and plugs into any standard electrical
outlet in your home.
To remove AC adapter from the outlet, firmly grasp the adapter "brick."
DO NOT pull on the cord, as this could damage it.
CAUTION: This AC Adapter was made with a specific design for the Safety 1st
Monitor. It cannot be used with any other appliance, and never use a different type
of adapter with this Monitor.
Parent Unit (Receiver):
CHANNEL SELECTION
The Monitor can broadcast over four preset factory frequencies or channels. Use
setting “1” making sure that both units are set to “1”. If you experience static or noise
interference, simply switch both units to channel “2”.
POWER INDICATOR
The power indicator is a green LED that indicates that the unit is on and functioning.
VOLUME DIAL
Volume can be easily adjusted to any desired listening level by rotating the Volume
Dial, so you can be sure to hear your baby at all times. The sounds are transmitted
through the wide range speaker. It is essential to check reception regularly. Refer to
Use and Care section.
LOW BATTERY INDICATOR
Low battery power is indicated by the red LED, which signals when the battery needs
to be replaced.
EARPHONE JACK
Earphones (not included) can be plugged into earphone jack on side of Parent Unit.
When earphones are in place, it will mute the speaker.
LINK INDICATOR - OUT OF RANGE
Static noise will be heard if both units are not set
to the same channels or if they are too far apart.
BELT CLIP
The Belt Clip is convenient for portability.
You can clip the Parent Unit to your
belt or waistband after a battery has
been installed. The Belt Clip also
easily converts to a carry loop.
Belt Clip
(down)
Carry Loop
(up)
Baby Unit (Transmitter):
PROPER POSITIONING
IMPORTANT: When choosing locations to set up the Baby Unit and Parent Unit, follow
these guidelines:
• For best sound quality, place Baby Unit 6 feet (2 meters) away from the baby.
• Adjust volume dial on Parent Unit to appropriate level to minimize feedback.
• During use of the monitor, sound quality deteriorates as you reach the
limits of the monitor's range. If this happens, you will need to move the
Parent Unit in closer proximity to the Baby Unit.
• Adjust the volume to a comfortable level for your environment.
The first time you use your monitoring system, two adults
should test it in the following way:
• Place Parent Unit at least 20 ft. (6m) away from Baby Unit.
• Have an adult speak into Baby Unit at various levels (soft to loud)
while another adult checks Parent Unit for the proper sound reception.
Try Parent Unit in every location that it will be used.
Care and Cleaning:
Use a soft, dry cloth to keep your monitor free from dust.
DO NOT immerse product in water.
IMPORTANT:
Use household electricity whenever possible. When the AC Adapter is used with your
household electricity, you will find that the power is stronger and more consistent than
when you rely solely on the battery. Range and sound quality also depends on the
construction of your house. Steel reinforced wall, for example, reduces the effective
range of the monitor. Conserve the battery so you will have power when you don’t
have easy access to AC outlets.
Make sure that both Units are on the same channel.
Even though you may hear you baby’s sounds, proper use of this system requires that
both Units must be on the same channel. If the Units are on different channels, the
signals from the Baby Unit may still be strong enough to be picked up by the Parent
Unit, but there will be a lot of static.
When not using the Unit, remove AC Adapter
and be sure the power button is “OFF”.
When you are not using the AC Adapter, remove it from the Unit and store it in a safe,
dry place until you need it again. If the AC Adapter is plugged into the Parent Unit but
not being used in an electrical outlet, the AC Adapter will prevent battery operation
of the Unit.
When using the AC Adapter with household electricity,
make sure the outlet is “ON”.
Some electrical outlets are powered through a switch in the room. If the Baby Unit is
plugged in and turned “ON”, the power indicator light should be lit. If it is not, try
turning the light switch in the room “ON”.
Dorel Juvenile Group, Inc. warrants to the original purchaser that this Crystal Clear Audio Monitor
2 Receiver Set, is free from material and workmanship defects when used under normal
conditions for a period of one (1) year from the date of purchase. Should the product contain
defects in material or workmanship Dorel Juvenile Group, Inc., will repair or replace the product,
at our option, free of charge. Purchaser will be responsible for all costs associated with
packaging and shipping the product to Dorel Juvenile Group Consumer Relations Department at
the address noted below and all other freight or insurance costs associated with the return.
Dorel Juvenile group will bear the cost of shipping the repaired or replaced product to the
purchaser. Product should be returned in its original package accompanied by a proof of
purchase, either a sales receipt or other proof that the product is within the warranty period.
This warranty is void if the owner repairs or modifies the product or the product has been
damaged as a result of misuse.
This warranty excludes any liability other than that express stated previously, including but not
limited to, and incidental or inconsequential damages.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS
THAT MAY VARY FROM STATE TO STATE.
Thank you again for purchasing a Safety 1st product. We are not only about safety, we’re also
about your satisfaction. If you have any questions or comments, please call our Consumer
Relations department at 1-800-544-1108 or e-mail us at consumer@safety1st.com.
FCC Statement
Radio and Television Interference
Note: This equipment has been tested and found to comply with the limits for a class B digital
device, pursuant to part 15 of the FCC Rules and applicable Industry Canada specifications.
These Limits are designed to provide reasonable protection against harmful interference in a
residential installation. For body worn operation, this product has been tested and meets the
FCC RF exposure guidelines when used with the belt clip supplied or designed with this product.
Use of other accessories may not ensure compliance with the FCC exposure guidelines.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does not cause harmful interference to radio or television
reception, which can be determined by turning this equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
To operate this equipment under the Federal Communications Commission rules.
WARNING: Changes or modifications not expressively approved by Dorel Juvenile Group can void
your authority to operate this equipment.
This Category II radiocommunication device complies with Industry Canada Standard RSS-310.
Crystal Clear
Audio Monitor
2 Receiver Set
PROBLEM
Power indicator light
not working
Static or interference in the
signal transmission
Parent Unit is making
loud noises
Parent Unit is picking up
noises from outside
your home
Weak sound coming
from Parent Unit
Can’t hear baby’s sounds
POSSIBLE CAUSE
Power is not getting to the Unit
Baby and Parent Units may be
on different channels
Appliances with loud fans near Units
may be blocking transmission
Unit may be under fluorescent lights
Local interference from electrical or radio frequency
appliance near your location
Units are too close together
Volume dial on Parent Unit may be too high
Neighbors may have a baby monitor or cordless phone
Battery may be weak
Units may be too far away from each other
Speaker or microphone could be blocked
SOLUTION
Make sure wall outlet is working; may possibly need to be turned on by a switch
Make sure AC adapter is plugged into wall and the Unit
Make sure both Units are on the same channel
(2 channel options: 1 or 2)
Turn off the appliances that may be causing interference
Reduce the distance between the two Units or turn off lights
Switch channel setting on both Parent and Baby Units
Parent Unit needs to be at least 10 feet / 3 meters away from the Baby Unit
Turn down volume on the Parent Unit
Change both Units to the alternative channel
(2 channel options: 1 or 2)
Check battery; replace if necessary
Battery life is short Battery life in the parent unit will last approximately 24hrs Use unit cautiously during battery operation to conserve your battery life
Move the Units closer to each other
Keep speaker/microphone clear from obstructions
WARNING!
Strangulation Hazard - Children
have STRANGLED in cords.
Keep cords out of
reach of children
more than 3 feet
(0.9 m) away.
Strangulation Hazard - Children have STRANGLED
in cords. Keep cords out of reach of children more
than 3 feet (0.9 m) away.
WARNING!
It is essential to check reception regularly.
Please see Use and Care section.
VENTILATION: The Monitor should not be situated on a bed, sofa, rug, or
similar surface that may block the ventilation openings, or placed in an
enclosed installation, such as a book case or cabinet that may impede
the flow of air through the ventilation openings.
• Position the Transmitter, Receiver and AC adapters to allow adequate
ventilation and prevent these components from overheating.
HEAT: The Monitor should be situated away from heat sources such as
radiators, heat registers, stoves, or other appliances that produce heat.
Also keep these components out of direct sunlight.
POWER SOURCE: The Monitor should be connected to a power supply
only of the type described in these operating instructions.
POWER CORD PROTECTION: The power supply cord should be routed so
that it is not likely to be walked on or pinched by items placed upon or
against it. Pay particular attention to the cord at the plug, convenience
receptacle, and at the point it exits from the Monitor. NOTE: Do not
place adapter under a window where a child might use it to step
on and reach something that might be dangerous.
• Check to make sure outlet plates are not unusually hot to the touch.
If they are, immediately unplug cords from these outlets. Check that
all outlet connections are in good condition so that adapter is not loose
or that no wiring is exposed. Have a qualified, licensed electrician
check the wiring as soon as possible.
OBJECT AND LIQUID ENTRY: Care should be taken so that objects
do not fall onto, and liquids are not spilled into the enclosure through
the openings.
DAMAGE REQUIRING SERVICE: The Monitor should be serviced by
qualified service personnel when:
A. The power supply cord has been damaged; or
B. Objects have fallen or liquid has been spilled into the product; or
C. The Monitor has been exposed to rain; or
D. The Monitor does not appear to operate normally or exhibits
a marked change in its performance; or
E. The Monitor has been dropped or the enclosure damaged.
To protect your privacy, always turn the monitor off when not in use.
Always remember that you are using public airwaves. Sound
may be broadcast to other receiving devices outside your home.
Conversations, even from rooms nearby, may be broadcast.
CAUTION!
Produkt Specifikationer
| Mærke: | Safety 1st |
| Kategori: | Babyalarm |
| Model: | Crystal Clear |
Har du brug for hjælp?
Hvis du har brug for hjælp til Safety 1st Crystal Clear stil et spørgsmål nedenfor, og andre brugere vil svare dig
Babyalarm Safety 1st Manualer
22 August 2024
22 August 2024
29 Juli 2024
Babyalarm Manualer
- Babyalarm SilverCrest
- Babyalarm Amplicomms
- Babyalarm Denver
- Babyalarm Sencor
- Babyalarm Beurer
- Babyalarm Philips
- Babyalarm Concept
- Babyalarm Medisana
- Babyalarm Gigaset
- Babyalarm Emos
- Babyalarm Technaxx
- Babyalarm Grundig
- Babyalarm D-Link
- Babyalarm Motorola
- Babyalarm Kodak
- Babyalarm Tefal
- Babyalarm Hama
- Babyalarm Hyundai
- Babyalarm Belkin
- Babyalarm TriStar
- Babyalarm TRENDnet
- Babyalarm Sanitas
- Babyalarm Fysic
- Babyalarm Topcom
- Babyalarm Uniden
- Babyalarm Medion
- Babyalarm EZVIZ
- Babyalarm König
- Babyalarm Ariete
- Babyalarm Elro
- Babyalarm Geemarc
- Babyalarm Babymoov
- Babyalarm Beaba
- Babyalarm Withings
- Babyalarm Terraillon
- Babyalarm Angelcare
- Babyalarm Fisher-Price
- Babyalarm Graco
- Babyalarm Neonate
- Babyalarm PADWICO
- Babyalarm Vtech
- Babyalarm Chicco
- Babyalarm Lindam
- Babyalarm Reer
- Babyalarm Alcatel
- Babyalarm Tommee Tippee
- Babyalarm Jane
- Babyalarm Alecto
- Babyalarm Olympia
- Babyalarm Ansmann
- Babyalarm HQ
- Babyalarm Niceboy
- Babyalarm Marmitek
- Babyalarm Basetech
- Babyalarm Tesla
- Babyalarm Foscam
- Babyalarm Lorex
- Babyalarm Cobra
- Babyalarm Xblitz
- Babyalarm Joblotron
- Babyalarm Binatone
- Babyalarm Eufy
- Babyalarm Overmax
- Babyalarm Albrecht
- Babyalarm Nova
- Babyalarm Trebs
- Babyalarm Bébétel
- Babyalarm Manhattan
- Babyalarm Switel
- Babyalarm Brondi
- Babyalarm GoClever
- Babyalarm Lupilu
- Babyalarm Duux
- Babyalarm Audioline
- Babyalarm BT
- Babyalarm CAPiDi
- Babyalarm Tigex
- Babyalarm Lionelo
- Babyalarm Pabobo
- Babyalarm Oricom
- Babyalarm Oregon Scientific
- Babyalarm SereneLife
- Babyalarm Stabo
- Babyalarm Duronic
- Babyalarm TrueLife
- Babyalarm Kogan
- Babyalarm Cresta
- Babyalarm Chipolino
- Babyalarm Summer
- Babyalarm BabyOno
- Babyalarm Esscom
- Babyalarm Luvion
- Babyalarm Hartig And Helling
- Babyalarm NUK
- Babyalarm Tomy
- Babyalarm Babysense
- Babyalarm Jablotron
- Babyalarm Modern-Electronics
- Babyalarm Hartig Helling
- Babyalarm Levana
- Babyalarm Summer Infant
- Babyalarm IBaby
- Babyalarm Fischer Price
- Babyalarm Mobi
- Babyalarm MicroTalk
- Babyalarm Oretti
- Babyalarm Neno
- Babyalarm LeamsiQ
- Babyalarm Philips-Avent
- Babyalarm Heimvision
- Babyalarm BabySafe
- Babyalarm Chillax Baby
- Babyalarm Hubble Connected
- Babyalarm Peekyboo
Nyeste Babyalarm Manualer
23 December 2024
21 December 2024
18 December 2024
17 December 2024
15 December 2024
13 December 2024
13 December 2024
13 December 2024
13 December 2024
13 December 2024
