User Manual
Smart Dome Camera
SCC-C6455N
imagine the possibilities
Thanks you for purchasing this Samsung product.
To receive a more complete service, please visit
our website
www.samsungsecurity.com
00885A-NA_SCC-C6455N-ENG.indb 1 2009-08-05 오후 2:42
2_ overview
overview
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol indicates that dangerous voltage consisting a risk of
electric shock is present within this unit.
This symbol indicates that there are important operating and
maintenance instructions in the literature accompanying this unit.
WARNING
To reduce the risk of fire or electric shock, do not expose this appliance to rain or
moisture.
To prevent injury, this apparatus must be securely attached to the floor/wall in
accordance with the installation instructions.
Use only the 24V, 60Hz AC adaptor for power supply.
WARNING
Be sure to use only the standard adapter that is specified in the specification sheet.
Using any other adapter could cause fire, electrical shock, or damage to the
product.
Incorrectly connecting the power supply or replacing battery may cause explosion,
fire, electric shock, or damage to the product.
Do not connect multiple cameras to a single adapter. Exceeding the capacity may
cause abnormal heat generation or fire.
Securely plug the power cord into the power receptacle. Insecure connection may
cause fire.
When installing the camera, fasten it securely and firmly. The fall of camera may
cause personal injury.
1.
2.
3.
4.
5.
00885A-NA_SCC-C6455N-ENG.indb 2 2009-08-05 오후 2:42
English _3
English
Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or
containers filled with water on top of the camera. Doing so may cause personal
injury due to fire, electric shock, or falling objects.
Do not install the unit in humid, dusty, or sooty locations. Doing so may cause fire
or electric shock.
If any unusual smells or smoke come from the unit, stop using the product. In such
case, immediately disconnect the power source and contact the service center.
Continued use in such a condition may cause fire or electric shock.
If this product fails to operate normally, contact the nearest service center. Never
disassemble or modify this product in any way. (SAMSUNG is not liable for
problems caused by unauthorized modifications or attempted repair.)
When cleaning, do not spray water directly onto parts of the product. Doing so may
cause fire or electric shock
Do not expose the product to the direct airflow from an air conditioner.
Otherwise, it may cause moisture condensation inside the Clear Dome due to
temperature difference between internal and external of the dome camera.
If you install this product in a low-temp area such as inside a cold store, you must
seal up the wiring pipe with silicon, so that the external air can not flow inside the
housing.
Otherwise, external high, humid air may flow inside the housing, pooling moisture
or vapor inside the product due to a difference between internal and external
temperature.
6.
7.
8.
9.
10.
11.
12.
00885A-NA_SCC-C6455N-ENG.indb 3 2009-08-05 오후 2:42
overview
4_ overview
CAUTION
Do not drop objects on the product or apply strong blows to it. Keep away from a
location subject to excessive vibration or magnetic interference.
Do not install in a location subject to high temperature (over 50°C), low temperature
(below -10°F), or high humidity. Doing so may cause fire or electric shock.
If you want to relocate the already installed product, be sure to turn off the power
and then move or reinstall it.
Remove the power plug from the outlet when there is a lighting storm. Neglecting
to do so may cause fire or damage to the product.
Keep out of direct sunlight and heat radiation sources. It may cause fire.
Install it in a place with good ventilation.
Avoid aiming the camera directly towards extremely bright objects such as sun, as
this may damage the CCD image sensor.
Apparatus shall not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the apparatus.
The Mains plug is used as a disconnect device and shall stay readily operable at
any time.
When using the camera outdoors, moisture may occur inside the camera due
to temperature difference between indoors and outdoors. For this reason, it is
recommended to install the camera indoors. For outdoor use, use the camera with
built-in fan and heater.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
00885A-NA_SCC-C6455N-ENG.indb 4 2009-08-05 오후 2:42
English _5
English
FCC STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions :
1) This device may not cause harmful interference, and
2) This device must accept any interference received including interference that may
cause undesired operation.
Caution
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated
in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
IC Compliance Notice
This Class A digital apparatus meets all requirements of the Canadian
Interference.-Causing Equipment Regulations of ICES-003.
00885A-NA_SCC-C6455N-ENG.indb 5 2009-08-05 오후 2:42
overview
6_ overview
ImPORTANT SAFETy INSTRUCTIONS
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
Do not install near any heat sources such as radiators, heat registers, or other
apparatus (including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third prong
is provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Use only with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
Unplug this apparatus during lightning storms or when unused
for long periods of time.
Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as powersupply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
Apparatus shall not be exposed to dripping or splashing and no objects
filled with liquids, such as vases, shall be placed on the apparatus
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
00885A-NA_SCC-C6455N-ENG.indb 6 2009-08-05 오후 2:42
English _7
English
CONTENTS
OvERvIEW
2
6 Important Safety Instructions
7 Contents
8 Features
8 What’s Included
9 At a Glance
INSTALLATION &
CONNECTION
10
10 Preparing Installation
10 Installation
14 Initial Setup
17 Connecting With Other Device
SETUP
20
20 How to use the Keyboard
Controller
21 Main Menu
22 Profile
24 Camera Set
33 Intelligent Video
34 Privacy Zone
35 Preset
37 Auto Set
41 Zone Set
42 Alarm Set
44 Clock Set
44 Other Set
46 Communication
46 System Info
47 Language
APPENDIx
48
48 Shortcut Keys
49 Specifications
51 Product Appearance
00885A-NA_SCC-C6455N-ENG.indb 7 2009-08-05 오후 2:42
overview
8_ overview
FEATURES
With the state-of-the-art digital signal processing technology, full digital image
processing and special algorithm of 600-line high resolution implemented
High performance surveillance camera, equipped with x43 zoom lens and digital
zoom IC, enabling monitoring up to 688 times
WDR to cover the full screen irregardless of its brightness
DAY/NIGHT to improve the sensitivity by automatic conversion into the black and
white mode at night or in the environment with low illumination
White Balance to control the brightness to the illumination
Backlight Compensation under spotlight or utmost bright illumination
Auto Focus to automatically adjust the focus to the subject movement
Privacy zone to hide a specific area for personal privacy
PAN/TILT for precise control at high speed
WHAT’S INCLUDED
Please check if your camera and accessories are all included in the product package.
Camera Frame Set Cover
User Manual
User Manual Template Connectors
00885A-NA_SCC-C6455N-ENG.indb 8 2009-08-05  2:42:45
English _9
English
AT A GLANCE
CAmERA
FRAmE SET
Wipe out a dirty surface of the lens softly with a lens tissue or cloth to which you
have applied ethanol.
M
LENS
HOOK
HOOK
ALARM IN
ALARM OUT
RS-485
POWER
INPUT
00885A-NA_SCC-C6455N-ENG.indb 9 2009-08-05  2:42:50
10_ installation & connection
installation & connection
PREPARING INSTALLATION
Use the ceiling installation template when you install the camera on the ceiling on
your own.
Run the cables through the “ ” shaped hole on the center of the template, and
remove lms on the adhesives, and then attach the template on the desired location
on the ceiling.
When installing the frames set, align all template’s screw holes and those of the
frames set.
This template prevents dust entering from the ceiling into the camera assembly.
INSTALLATION
Press the “ ” on the “ ” to open the “ ”, and arrange SNAP FIT ADAPTOR ADAPTOR
cables so they pass out of the “ ”.FRAmE SET
1.
EXTERNAL
CABLES
FRAME SET FRAME SET
ADAPTOR SNAP FIT
ADAPTOR
SNAP FIT
<TEMPLATE>
CABLESCEILING CABLESCEILING TEMPLATE
00885A-NA_SCC-C6455N-ENG.indb 10 2009-08-05  2:42:54
English _11
English
Use the three “ ” to x the “ ” on a “ ” installation SCREWS FRAmE SET CAmERA
position.
Connect external cables to the “CONNECTORS(ALARm IN, POWER, RS-485,
ALARm OUT) CONNECTOR ADAPTOR”and connect the “ ” to the “ ”.
Insert the cable into the “ ”, and close the “ ”.FRAmE SET ADAPTOR
Then, wrap the “ ” with the “BNC JACK INSULATION TUBE”, and use an insulation
tape to seal up the end of the “INSULATION TUBE” so that the “ ” does BNC JACK
not protrude outside of the “INSULATION TUBE” coating.
For more information about cable connection, refer to “Connecting the adaptor
cable”. (page 19)
2.
3.
M
FRAME SET
ADAPTOR
SNAP FIT
INSULATION TUBE
BNC JACK
ALARM OUT
ALARM IN RS-485
POWER INPUT
FRAME SET
ADAPTOR
SCREW
SCREW
SCREW
<Fixing Hole Diagram>
00885A-NA_SCC-C6455N-ENG.indb 11 2009-08-05  2:43:00
installation & connection
12_ installation & connection
Connect the “SAFETy WIRE” of the “CAmERA” to the “BRACKET WIRE” on the
“FRAmE SET”. Arrange the “22P CONNECTOR” of the “CAmERA” in line with that
of the “ADAPTOR”, push the “HOOK” on either end of the “CAmERA” in the “RACK”
direction of the “FRAmE SET” to secure the two.
Then, ensure that all of the two “HOOKS” “clicks” to x to the “RACK” properly.
When the installation is completed, remove the “PROTECTIVE FILM” and
“PROTECTIVE TAPE” from on the lens.
4.
M
FRAME SET
22P CONNECTOR
CAMERA
SAFETY WIRE
BRACKET WIRE
FRAME SET
CAMERA
RACK
HOOK
RACK
HOOK
CAMERA
FRAME SET
PROTECTIVE FILM
PROTECTIVE TAPE
PROTECTIVE TAPE
00885A-NA_SCC-C6455N-ENG.indb 12 2009-08-05  2:43:08
English _13
English
Arrange the “ ” arrow in line with the “ ” arrow, and push in the COvER FRAmE SET
“ ”. Insert the “ ” to the end, and turn the “ ” clockwise. COvER COvER COvER
As shown in the gure below, turn it until you see the “ ” hole and hear a BUTTON
click.
Ensure that the “COVER” should not move any further if you turn the “ ” counter COVER
clockwise.
If you want to remove the “COvER”, hold down the “BUTTON” and turn the
“COvER” counter clockwise to remove the “COvER”.
5.
FRAME SET
BUTTON
CAMERA
COVER
COVER
BUTTON
COVER
00885A-NA_SCC-C6455N-ENG.indb 13 2009-08-05  2:43:11
installation & connection
14_ installation & connection
INITIAL SETUP
Camera Address Setup
Use SW606, SW605, and SW604 to specify the camera address.
You can specify between 0 and 255 for the address, where the hundreds digit is
with SW606, the tens digit with SW605, and the ones digit with SW604.
ex) Camera address: If the address is 1, follow the steps in the figure below.
Communication Protocol Setup
Use pins #1~#4 of SW603 to specify the communication protocol.
PIN
Comp PIN1 PIN2 PIN3 PIN4
A OFF OFF OFF OFF
B ON OFF OFF OFF
C OFF ON OFF OFF
D ON ON OFF OFF
E OFF OFF ON OFF
F ON OFF ON OFF
G OFF ON ON OFF
H ON ON ON OFF
I OFF OFF OFF ON
J ON OFF OFF ON
K OFF ON OFF ON
L ON ON OFF ON
M OFF OFF ON ON
N ON OFF ON ON
O OFF ON ON ON
P ON ON ON ON
A : SAMSUNG HALF
B : SAMSUNG FULL
<Bottom of the camera holder>
SW606
(x100)
SW605
(x10)
SW604
(x1)
00885A-NA_SCC-C6455N-ENG.indb 14 2009-08-05  2:43:14
English _15
English
Baud Rate Setup
Use pins #5, #6 of SW603 to set the baud rate.
BAUD RATE PIN 5 PIN 6
4800 BPS ON ON
9600 BPS OFF ON
19200 BPS ON OFF
38400 BPS OFF OFF
The factory default is 9600 BPS.
Setting RS-422A/RS-485 Termination
As it is shown in the structure map, when Controller and RS-422A/RS-485 is
connected, it should be terminated according to the Cable feature of impedance
on the each end of the transmitting line to transfer the signals in long distance by
controlling the reflection of the signals to the lowest.
Termination : Using numbers 1 and 2 PIN, turn to <ON> and it will be terminated.
Controller
Termination n < 32
Termination
SW1-ON
CAM n
CAM n-1
CAM 2CAM 1
TX+(DATA+)
TX-(DATA-)
RX- RX+RX+ RX- RX+ RX- RX+ RX-
<RS-485 Half Duplex Organization>
00885A-NA_SCC-C6455N-ENG.indb 15 2009-08-05  2:43:14
installation & connection
16_ installation & connection
A communication error may occur if you connect multiple cameras that are assigned
the same address in the network.
M
Controller
Termination
n < 32
Termination
SW1-ON
SW2-ON
CAM n
CAM n-1
CAM 2CAM 1
<RS-422A/RS-485 Full Duplex Organization>
00885A-NA_SCC-C6455N-ENG.indb 16 2009-08-05  2:43:14
English _17
English
CONNECTING WITH OTHER DEvICE
Connecting to a monitor
Connect one end of the BNC
video cable connector to the
Video Output Terminal (VIDEO
OUT).
Connect the other end of the
connector to the Video Input
Terminal of the monitor.
1.
2.
Video terminal on the
rear of monitor
BNC Cable
MONITOR
ALARM IN
POWER SOURCE
ALARM OUT
CONTROLLER/DVR
00885A-NA_SCC-C6455N-ENG.indb 17 2009-08-05  2:43:15
installation & connection
18_ installation & connection
To connect ALARm IN
Connect one end of the external device's signal line to a corresponding ALARM
IN port of the monitor.
Connect the other end of the signal line to the earth-grounding [ ] port.GND
To connect ALARm OUT
Connect one end of the external device's signal line to a corresponding ALARM
OUT port of the monitor.
Connect the other end of the signal line to the common [ ] port.COm
To connect the controller
Connect an external controller or DVR to the camera, with which you can adjust the
camera.
Connect the Rx+ pin of the
camera to the Tx+ pin of the
controller.
Connect the Rx- pin of the
camera to the Tx- pin of the
controller.
Connect the Tx+ pin of the
camera to the Rx+ pin of the
controller.
Connect the Tx- pin of the
camera to the Rx- pin of the
controller.
1.
2.
1.
2.
1.
2.
3.
4.
TxRx
00885A-NA_SCC-C6455N-ENG.indb 18 2009-08-05  2:43:16
English _19
English
Connecting the adaptor cable
Power Supply
Connect the cables as necessary, and turn on the camera to check if it works
properly.
Connect the adaptor to the power terminal of the camera.
Plug the power cord of the adaptor into the wall outlet.
1.
2.
Adaptor Board
00885A-NA_SCC-C6455N-ENG.indb 19 2009-08-05  2:43:16
20_ setup
setup
Connect the camera to the keyboard controller or DVR, with which you
can manipulate and change the settings of the camera.
HOW TO USE THE KEyBOARD CONTROLLER
Follow the steps below to set the camera menu using the controller.
Open the Camera Setup screen.
Use the joystick to navigate through the menus.
Press [ ] to select a menu item.ENTER
Use the joystick to change the value of the selected item.
Press [ ] to apply your changes.ENTER
Using OSD icons
_+
:
If these icons appear in the left and right corner of a menu item, you can use
the joystick to move to the previous or next menu.
(EXIT): Exits the menu setup screen.
Before exiting the setup screen, select <SAvE> to save your settings
to the whole menus, or < > to cancel them.QUIT
(RET): Saves your settings and returns to the previous screen.
(HOME): Returns to the main menu.
(SAVE): Use this icon if you want to save your settings after you specified the
mask area and privacy area, etc.
Once you saved your settings, the changes remain intact even if you
select < > on exit.QUIT
(DEL): Use this icon if you want to delete a mask, or privacy area, etc.
Once you deleted your settings, the deletions remain valid even if you
select < > on exit.QUIT
: This icon appears in the right of a menu containing sub menu items.
While any operation of PRESET, AUTO PAN, SCAN, and PATTERN is running, and if
the camera is turned off and back on without any particular manipulation, the
camera will resume the last run operation.
You can set the menu item only if the tilt angle is within 90°.
If you enter the menu setup screen with the camera positioned out of a tilt of 90°,
the camera will rotate by 180° to fall into the opposite position within a tilt of 90°.
1.
2.
3.
4.
5.
M
00885A-NA_SCC-C6455N-ENG.indb 20 2009-08-05 오후 2:43
22_ setup
setup
PROFILE
You can select one from the pre-determined configurations as appropriate to your
specific camera installation environment.
Your selection on each item in PROFILE will affect all other settings of the camera.
STANDARD
Automatically optimizes the camera settings
to the normal environment.
ITS
This setting enables you to analyze the traffic
situation and take the traffic information at a
glance.
BACKLIGHT
This setting enables you to view a sharp
background and object even in a severe
backlight scene.
DAY/NIGHT
Automatically optimizes the camera settings to the day and night scene.
GAMING
This automatically configures the settings so that you can work in a stable illumina-
tion condition as indoors.
CUSTOM
Your change to any of the PROFILE settings will switch the display to CUSTOM.
CAMERA SETUP MENU
STANDARD ITS BACKLIGHT DAY/NIGHT GAMING
Parent Menu Sub-menus
VPS OFF ON OFF OFF OFF
IRIS
ALC ALC ALC ALC ALC
ALC -----
LEVEL 00000
BACKLIGHT OFF OFF WDR OFF OFF
WDR -----
WEIGHT Custom Setting Custom Setting MEDIUM Custom Setting Custom Setting
WDR LEVEL Custom Setting Custom Setting 0 Custom Setting Custom Setting
WHITE BAL Custom Setting Custom Setting Custom Setting Custom Setting Custom Setting
PROFILE
STANDARD
ITS
BACKLIGHT
DAY/NIGHT
GAMING
CUSTOM
00885A-NA_SCC-C6455N-ENG.indb 22 2009-08-05 오후 2:43
English _23
English
CAMERA SETUP MENU
STANDARD ITS BACKLIGHT DAY/NIGHT GAMING
Parent Menu Sub-menus
MOTION (F.FAST)
---
(F.FAST)
--- NORM (F.FAST)
--- SLOW
DNR MEDIUM MEDIUM MEDIUM MEDIUM MEDIUM
SHUTTER OFF OFF OFF OFF OFF
SENSE UP AUTO X4 AUTO X2 AUTO X4 AUTO X4 AUTO X4
XDR MEDIUM MEDIUM MEDIUM MEDIUM MEDIUM
DAY/NIGHT
AUTO AUTO DAY AUTO DAY
NIGHT -----
BURST OFF ON OFF OFF OFF
EXT -----
BURST OFF ON OFF OFF OFF
WHITE BAL
DAY DAY/NIGHT DAY DAY/NIGHT DAY
DAY -----
MODE ATW2 ATW1 ATW1 ATW1 ATW1
RED 00000
BLUE 00000
NIGHT -----
BRIGHTNESS
Custom Setting MEDIUM Custom Setting MEDIUM Custom Setting
MODE OFF ATW2 OFF ATW2 OFF
RED Custom Setting 0 Custom Setting 0 Custom Setting
BLUE Custom Setting 0 Custom Setting 0 Custom Setting
DETAIL 22222
00885A-NA_SCC-C6455N-ENG.indb 23 2009-08-05 오후 2:43
24_ setup
setup
CAmERA SET
You can configure the general settings of the camera module.
For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 20)
Select <mAIN mENU> - <CAmERA SET>.
The Camera Setup menu appears.
Change the settings as necessary, or select
an item to check.
CAmERA ID
Provide the ID and location for a camera that displays on the screen.
For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 20)
Select <CAmERA SET> - <CAmERA ID>.
Use the joystick to select a desired character,
then press [ENTER].
In the lower input box of the screen, the
selected character will be entered.
You can enter up to 54 characters including
alphabets, numbers and special characters.
LOCATION : Specify the display position
of the camera ID.
When done, press [ ]. ENTER
The camera ID will be displayed in the specified position.
vPS
If you set it to <ON>, the camera images will be displayed in progressive mode.
1.
2.
1.
2.
3.
CAMERA SET
CAMERA ID OFF
VPS OFF
IRIS ALC
MOTION (F.FAST)
---
DNR MID
SHUTTER (OFF)
---
SENS-UP AUTO X4
FLICKERLESS OFF
XDR MID
CAMERA ID
ABCDEFGHIJKLMNOPQRSTUVWXYZO
123456789
: ?_+()/
SP SP LOCATION
-
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
00885A-NA_SCC-C6455N-ENG.indb 24 2009-08-05 오후 2:43
English _25
English
IRIS
The IRIS menu is useful if you set to adjust the
intensity of radiation incoming to the camera.
ALC : Adjust the open and close of the iris.
- LEVEL : Select an overall brightness level.
- BLC : With <BACKLIGHT> set to
< >, you can specify the BLC area. BLC
With AREA set to < >, you can USER
specify the position and size.
- WDR : If you set < > to BACKLIGHT
< >, you will see a menu where you WDR
can set the WDR options.
Specify the shutter speed in WDR LEVEL,
and, the composition level in < >. WEIGHT
Select OUTDOOR, or INDOOR in
< >. WHITE BAL
The WDR feature provides an extension of
the gain range, which is useful, especially
if you work on pictures both indoors and
outdoors from inside of a building.
Namely, it improves the sharpness of the picture in outdoor scenery as well as
indoor.
As long as you use the VPS function, the WDR will not be available as the CCD read
method differs accordingly. If you set VPS to ON, WDR will be set to < > OFF
accordingly.
MANUAL : Adjust the iris level manually.
The overall brightness target of a camera
will be set to ALC level 0, while the iris
can be adjusted manually.
M
M
ALC
LEVEL [ 00]
----
I
----
BACKLIGHT BLC
AREA USER
<SIZE>
<LOCATION>
ALC
LEVEL [ 00]
----
I
----
BACKLIGHT WDR
WEIGHT MID
WDR LEVEL [ 0]
----
I
----
WHITE BAL INDOOR
MANUAL
LEVEL [ 00]
----
I
----
00885A-NA_SCC-C6455N-ENG.indb 25 2009-08-05 오후 2:43
26_ setup
setup
AGC
With this, you can adjust the AGC level of a
camera.
With AGC active, if the signal strength falls
below the standard level, AGC will amplify the
video signal to automatically improve the
sensitivity.
If <SENS-UP> is set to <OFF>, or <FIx>
mode, the <mOTION> menu will switch to
<AGC>.
With the USER
( )
submenu selected, press
[ENTER] to display the corresponding screen.
In this mode, you can select from VERY LOW
to VERY HIGH in 16 levels, enabling deeper, wider choices to your convenience.
With the FIX
( )
submenu selected, press [ENTER] to display the corresponding
screen. In this mode, you can select an individualized mode in 16 levels, regardless of
the brightness.
As long as the DAY/NIGHT menu is set to AUTO in Camera Setup, the AGC menu is
not available.
As long as FLICKERLESS is set to ON, the AGC mode is not available.
If you set BACKLIGHT to WDR, the AGC fix mode is not available.
mOTION
You can specify a level of AGC for controlling the camera motion.
This is available only of the SENSE UP menu is set to AUTO.
Select F.FAST if you want to monitor a very fast moving object in a low contrast
scene, and S.SLOW if monitoring a very slow moving, inanimate object in the same
condition.
As long as DAY/NIGHT is set to <AUTO>, the < > menu is not available.MOTION
DNR
Reduces the noise on the camera image.
The higher the level is, the greater the effect is.
Set it to <USER> to specify the level.
M
CAMERA SET
CAMERA ID OFF
VPS OFF
IRIS ALC
AGC (VERY HIGH)
---
DNR MID
SHUTTER OFF
SENS-UP OFF
FLICKERLESS OFF
XDR MID
00885A-NA_SCC-C6455N-ENG.indb 26 2009-08-05 오후 2:43
English _27
English
SHUTTER
You can select a fixed fast electronic shutter
speed in 7 options ranging from 1/100 to 1/10k,
which is mostly used to take a picture of a fast
moving object.
As long as SENSE UP is set to AUTO, FIXED /
FLICKERLESS to ON / BACKLIGHT to WDR, the
SHUTTER menu is not available.
SENS-UP
Automatically senses the darkness level at night or in a low contrast scene, and
extends the accumulation time accordingly; you can select <AUTO> or <FIx> for a
bright and sharp image.
If the SHUTTER menu is set to fixed electronic shutter mode, the SENSE UP menu
will not be available.
If FLICKERLESS is set to ON, or BACKLIGHT to WDR, the FIX mode of the SENSE UP
menu is not available.
FLICKERLESS
This will prevent possible screen distortion due to a mismatch between the vertical
sync frequency and the blinking frequency of the lighting; if set to <ON>, the shutter
speed will be fixed to 1/100 second.
If SHUTTER is set to FIX, SENSE UP to FIX, and AGC to FIX, the < > menu is FLICKERLESS
not available.
xDR
This will correct a brightness difference between different scenes for the optimal
visibility by calculating the ambient luminance contrast in a certain unit of pixels.
The higher the value is, the higher the correction level is.
M
CAMERA SET
CAMERA ID OFF
VPS OFF
IRIS ALC
AGC (VERY HIGH)
---
DNR MID
SHUTTER 1/100
SENS-UP (OFF)
---
FLICKERLESS (OFF)
---
XDR MID
00885A-NA_SCC-C6455N-ENG.indb 27 2009-08-05 오후 2:43
28_ setup
setup
DAY/NIGHT
You can specify a recording mode according to the scene.
For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 20)
Select < > - <CAMERA SET DAY/NIGHT>.
Select a screen transition mode according
to the illumination, and set options as
appropriate.
DAY : Fixed to DAY mode, regardless of
the scene.
NIGHT : Fixed to NIGHT mode,
regardless of the scene.
If BURST is set to < >, the burst ON
signal will be output along with the
black-and-white composite video signal.
AUTO : According to the luminance, this
will switch DAY to NIGHT mode, or vice
versa.
BURST : If set to < >, the burst OFF
signal will not be output in NIGHT mode.
DAY
NIGHT BRIGHTNESS : Specify
the brightness level switching from
COLOR to BW filter.
Adjusting from HIGH to LOW will cause
to switch the filter in a darker screen.
DAYNIGHT DWELL TIME : Time
required to determine the filter switch.
NIGHTDAY BRIGHTNESS : Specify the brightness level switching from
BW to COLOR filter. Adjusting from HIGH to LOW will cause to switch the
filter in a darker screen.
NIGHTDAY DWELL TIME : Time required to determine the filter switch.
MASK AREA : If there exists a bright
spot light source in a night scene, you
can specify the size and position as
needed.
This will prevent an error in switching
filter, or failure to determine the filter
switch in a night scene where a bright
spot light source exists.
Any excessively bright area in a night
scene will be MASKed.
1.
2.
-
-
-
-
-
-
AUTO
BURST OFF
DAY
NIGHT
BRIGHTNESS MID
DWELL TIME 2SEC
NIGHT
DAY
BRIGHTNESS MID
DWELL TIME 5SEC
MASK AREA
1 2
MASK AREA
<SIZE>
<LOCATION>
DAY/NIGHT AUTO
WHITE BAL
FOCUS MODE ONEAF
ZOOM SPEED [2]
DISPLAY ZOOM OFF
DISPLAY P/T OFF
DIGITAL ZOOM OFF
DETAIL [2]
V-SYNC INT
00885A-NA_SCC-C6455N-ENG.indb 28 2009-08-05 오후 2:43
English _29
English
You can specify MASK 1 and 2 simultaneously.
If < > is set to < >, the MASK AREA function is not available.BACKLIGHT BLC
EXT : The interface to an external alarm enables an automatic switch between
DAY and NIGHT mode.
If you set <DAY/NIGHT> to EXT, and alarm #1 to NO/NC in ALARM SET-
ALARM IN SET, the alarm can be used for an input signal in EXT mode of
<DAY/NIGHT>.
If an alarm signal occurs, the mode will switch to NIGHT.
If <DAY/NIGHT> is set to EXT, ALARM1 in ALARM OUT SET, and ALARM1 in ALARM
SET-AUTO SET are not available.
If you use an infrared light source while in AUTO mode, this may cause a failure in
AUTO SWITCH or AUTO FOCUS.
WHITE BAL
If you need to adjust the color according to the ambient illumination, you can use
the <WHITE BAL> function.
For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 20)
Illumination is generally referred to as color temperature, which is represented in a
measurement of kelvin (K). Color temperatures for ordinary lighting are as follows:
In the <WHITE BAL> menu, you
can set a mode for correcting the
<WHITE BAL>.
- ATW1,2 : If you set the <
WHITE
BAL> menu to <ATW1> or
<ATW2> mode, this will monitor
the change of the color temperature
to correct the <WHITE BAL> as
needed.
The following color temperature
ranges are assured in individual
modes:
ATW1 : 2500K ~ 9300K (1)
ATW2 : 2000K ~ 10000K
(suitable to sodium light source) (
2)
1 :
With <ATW1> mode active in a color temperature environment ranging
beyond between 2500K and 9300K, a proper white balance value may not be
produced; if this is the case, you are recommended to use <ATW2> mode.
2 : With <ATW2> mode active in a mostly single color environment, the display
color and the actual one may differ; so select a mode as appropriate to your
color temperature environment.
M
Blue sky
Rainy
Cloudy
Sunny
Partly Cloudy
Fluorescent lamp
Halogen lamp
Tungsten lamp
Candlelight
10000K
9000K
8000K
7000K
6000K
5000K
4000K
3000K
2000K
1000K
00885A-NA_SCC-C6455N-ENG.indb 29 2009-08-05 오후 2:43
30_ setup
setup
Select < > - < >.CAmERA SET WHITE BAL
Select a mode where you set the < >.WHITE BAL
DAY : You can set the RED, and BLUE
value in DAY mode.
The screen will be displayed in colors
according to your settings.
You can set the R-GAIN, and B-GAIN value
only in < > mode.AWC
If AGC is set to < > or < >, the NIGHT OFF FIX
menu can not be accessed.
NIGHT : You can set the <WHITE BAL>
according to the ambient illumination.
If NIGHT mode is set to < >, the OFF
<WHITE BAL> will operate in a mode
specified in DAY mode at all times;
otherwise, the screen will switch to a
mode specified in <DAy/NIGHT>.
You can set the RED, BLUE and
BRIGHTNESS value in DAY mode.
The screen will be displayed in colors
according to your settings.
According to the specified recording mode, select a <WHITE BAL> mode with
necessary options.
ATW1,2 : The camera can automatically adjust the color temperature in real
time, according to the ambient conditions.
(Color temperature range 1: 2500K ~ 9300K, 2 : 2000K ~ 10000K)
AWC : Pressing [ENTER] on a desired item will perform ATW once.
You can set the R-GAIN/B-GAIN value.
3200K : Set the color temperature to 3200K.
5600K : Set the color temperature to 5600K.
BRIGHTNESS : Specify a brightness level switching from DAY mode to
NIGHR mode setting.
RED : Adjust the strength of the red color.
BLUE : Adjust the strength of the blue color.
R-GAIN/B-GAIN : Specify the current color temperature manually.
1.
2.
3.
-
-
-
-
WHITE BAL
DAY/NIGHT NIGHT
BRIGHTNESS MID
MODE AWC
RED [ 00]
----
I
----
BLUE [ 00]
----
I
----
R-GAIN [0064
]
B-GAIN [0064
]
WHITE BAL
DAY/NIGHT DAY
MODE AWC
RED [ 00]
----
I
----
BLUE [ 00]
----
I
----
R-GAIN [0064]
B-GAIN [0064
]
00885A-NA_SCC-C6455N-ENG.indb 30 2009-08-05 오후 2:43

Produkt Specifikationer

Mærke: Samsung
Kategori: Overvågningskamera
Model: SCC-C6455

Har du brug for hjælp?

Hvis du har brug for hjælp til Samsung SCC-C6455 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Overvågningskamera Samsung Manualer

Samsung

Samsung XNV-8080R Manual

27 August 2024
Samsung

Samsung XND-8080RV Manual

27 August 2024
Samsung

Samsung XNO-6080R Manual

27 August 2024
Samsung

Samsung SNZ-5200 Manual

23 August 2024
Samsung

Samsung SCO-2080R Manual

13 August 2024
Samsung

Samsung SCB-2001 Manual

6 August 2024
Samsung

Samsung SmartCam SNH-1011N Manual

5 August 2024
Samsung

Samsung Techwin iPOLiS SNF-7010VM Manual

5 August 2024
Samsung

Samsung Techwin SRD-854D Manual

2 August 2024
Samsung

Samsung SDS-P3022 Manual

30 Juli 2024

Overvågningskamera Manualer

Nyeste Overvågningskamera Manualer

Wisenet

Wisenet PNM-9022V Manual

8 Marts 2025
Wisenet

Wisenet TNV-8010C Manual

8 Marts 2025
Wisenet

Wisenet PNM-7002VD Manual

8 Marts 2025
Wisenet

Wisenet QNE-8021R Manual

8 Marts 2025
Wisenet

Wisenet PNM-8082VT Manual

8 Marts 2025
Wisenet

Wisenet XNF-9010RV Manual

8 Marts 2025
Wisenet

Wisenet TNU-6321 Manual

8 Marts 2025
Wisenet

Wisenet QNV-6024RM Manual

8 Marts 2025
Wisenet

Wisenet PNM-9085RQZ Manual

8 Marts 2025
Wisenet

Wisenet LNV-6022R Manual

8 Marts 2025
