Side 1/2
GB Operating instruction
The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by
SANGEAN ELECTRONICS INC. is under
license.
Important Safety Instructions
● Do not install near any heat sources such
as radiators, heat registers, stoves or
other apparatus (including amplifiers) that
produce heat.
●Only use attachments / a ccessorie s
specified by the manufacturer.
● To reduce the risk of fire or electric shock,
do not expose this appliance to rain or
moisture.
● Apparatus shall not be exposed to dripping
or splashing and no objects filled with liquids,
shall not be placed on the apparatus.
● The batteries shall not be exposed to
excessive heat such as sunshine, fire or
the like.
● Any changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate the equipment and warranty.
● CAUTION: “Risk of explosion if the battery
is replaced by an incorrect type.”
● Do not allow your radio to be exposed to
water, steam or sand.
● Do not leave your radio
where excessive heat
could cause damage.
● If safety relevant, the following information
should be included as far as applicable:
»m i n i m u m d i s t a n c e s a r o u n d t h e
apparatus for sufficient ventilation;
» the ventilation should not be impeded by
covering the ventilation openings with
items, such as newspaper, table-cloths,
curtains, etc.;
» no naked flame sources, such as lighted
candles, should be placed on the
apparatus;
»at tenti on s ho uld be dr awn to th e
en vir on me nta l a spe cts of b atter y
disposal;
»the use of apparatus in tropical and / or
moderate climates.
● CAUTION: Danger of explosion if battery is
incorrectly replaced. Replace only with the
same or equivalent type.
● If an apparatus is provided with a replaceable
lithium battery, the following applies:
» if the battery is intended to be replaced by
the user, there shall be a warning close to
the battery or in both the instruction for use
and service instructions;
» i f the battery is not intended to be replaced
by the user, there shall be a warning close
to the battery or in the service instructions.
For United States:
Cautions to the user
The changes or modifications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the
equipment.
RF exposure statements
IMPORTANT NOTE:
To comply with the FCC RF exposure compliance
requirements, the antenna(s) used for this transmitter
must be installed to provide a separation distance of
at least 20cm (8 inches) from all persons and must
not be co-located or operating in conjunction with
any other antenna or transmitter. No change to the
antenna or the device is permitted. Any change to
the antenna or the device could result in the device
exceeding the RF exposure requirements and void
user's authority to operate the device.
Note:
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guaranty that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of the
following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment
and receiver.
● Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
●Consult the dealer or an experienced radio / TV
technician for help.
CAUTION:
These servicing instructions are for use by
qualified service personnel only. To reduce the
risk of electric shock, do not perform any servicing
other than that contained in the operating
instructions unless you are qualified to so.
VERY IMPORTANT PLEASE READ
Sangean suggest that you keep your AC Adapter
at least 12 inches away from the radio while
listening to the AM Band.
Your Sangean Radio is powered by an AC adapter
which is a “switching” or “switch-mode” type.
The DOE (Department Of Energy) has a Federal
mandate; requiring all manufactures to use this
type of power supply.
This newer power saving technology has the
unfortunate side effect of causing interference to
the AM radio band.
Therefore, we recommend that customers keep
at least a 1 foot distance between the AC adapter
and the radio. This interference will not affect
the FM Band. If you have any questions please
contact customer service at (888)726-4326,
(562)941-9900 or service@sangean.com
If an AC adapter isn’t included in this model and if
you wish to purchase an AC Adapter separately,
please refer to the specifications for the AC
Adapter stated on the final page of the manual,
or please contact Sangean for the correct AC
Adapter and specifications.
To learn more about the DOE mandate please visit:
http://www1.eere.energy.gov/buildings/appliance_
standards/product.aspx/productid/23
Please note not all AC adapters are alike.
The AC adapter that is included with this radio is
designed to be used exclusively with this device.
Do not use an AC adapter that differs from the
specifications on the AC adapter that is included.
If an AC adapter is NOT included with your radio
and in order not to damage the unit and void
your warranty, specifications for the AC Adapter
are stated on the final page of the manual, or
please contact Sangean for the correct AC
Adapter and specifications. For customers in
the US and Canada, please call 562-941-9900
or 888-726-4326. For all other areas, please
contact us via contact@sangean.com
Do not use an AC adapter that does not meet the
correct specifications.
CP-100
Controls and functions
1 2 3 4
6
5
7 8 9 10
1. Mode knob: Power off / FM / AM / Bluetooth /
Aux in
2. Volume control knob
3. LED indicator
Green: Tune to a stable FM / AM station (Note:
Some products show an amber indicator.)
Blue blinking: The radio is discoverable for
pairing in Bluetooth mode.
Solid blue: The radio is already connected to a
Bluetooth device.
4. Tuning control knob
5. Bass reflex tube
6. Speaker
7. LED indicator
Lighted: The radio is in power on mode.
Off: The radio is in power off mode.
8. 3.5mm external antenna socket
9. 3.5mm auxiliary input socket
10. DC IN socket
Listening to music via Bluetooth
streaming
Pairing and playing your Bluetooth device
for the first time
1. Rotate the Mode knob to select the Bluetooth
mode. The LED indicator will flash a fast blue to
show the radio is discoverable.
2. Activate Bluetooth on your device according to
the device's user manual to link to the radio.
Locate the Bluetooth device list and select the
device named ‘SANGEAN CP-100’. With some
mobile devices (which are equipped with earlier
versions than BT2.1 Bluetooth device), you may
need to input the pass code “0000”.
3. Once connected, there will be a confirmation
tone sound and the LED indicator will turn a
solid blue. You can simply select and play any
music from your source device. Volume control
can be adjusted from your source device, or
directly on CP-100.
4. Use the controls on your Bluetooth-enabled
device to play / pause and navigate tracks.
Disconnecting your Bluetooth device
Rotate the Mode knob to select any mode other
than Bluetooth mode to disconnect with your
Bluetooth device or turn off Bluetooth function on
your Bluetooth device to disable the connection.
Supplied accessories
●External antenna
●AC power adaptor
Specifications
AC Power adaptor: DC 9V 1.2A center pin
positive
Frequency Coverage:
FM 87.5-108 MHz
AM 520-1710 kHz
Antenna System:
FM external antenna
AM built-in ferrite
antenna
FM / AM Band Output
Power:
4 W T. H . D 1 0 % @
400Hz
B l u e t o o t h O u t p u t
Power:
4 . 8 W T.H . D 1 0 % @
110Hz
AUX Input sensitivity: 4. 8 W T. H . D 1 0 % @
110Hz
Operating temperature
range: 0°C to +35°C
Bluetooth
Bluetooth specification Bluetooth® Ver 4.1
Profile Support A2DP
Bluetooth Audio
CODEC SBC
Transmitting Power Sp ecificatio n Power
Class 2
Line of sight range 10meters / 30feet
※
The barcode label on the product is defined as
below:
Serial number
Production month
Production year
Product code
Sangean reserves the right to amend the
specifications without notice.
If at any time in the future you should need
to dispose of this product please note that:
Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check with
your Local Authority or retailer for recycling
advice. (Waste Electrical and Electronic
Equipment Directive)
3A81d00S10020
F Mode d’emploi
La marque et les logos Bluetooth® sont des
marques déposées appartenant à Bluetooth
SIG, Inc. et toute utilisation de ces marques
par SANGEAN ELECTRONICS INC. est
soumise à une licence.
Instructions I m p o r ta n te s
Concernant La Sécurité
● N’installez pas à proximité de sources
de chaleur telles que radiateurs, grille de
convecteur de chaleur, poêle ou autres
appareils (y compris les amplificateurs) qui
produisent de la chaleur.
● N’utilisez que les extensions / accessoires
spécifiés par le fabricant.
● Pour réduire le risque d’incendie ou de
choc électrique, n’exposez pas cet appareil
à la pluie ou l’humidité.
● L’appareil ne doit pas être exposé aux
égouttements ou aux éclaboussures et
aucun objet rempli de liquide ne doit être
placé dessus.
● Les piles ne doivent pas être exposées à
des températures excessives telles que le
soleil, le feu ou autres.
● Tout changement ou modification non
approuvée expressément par la partie
r es p on s ab l e de l a con f or m it é p eut
entraîner l’annulation de l’autorisation pour
l’utilisateur d’utiliser l’équipement et la
garantie.
●
ATTENTION: ''Risque d’explosion en cas
de remplacement des piles par des piles
de type incorrect.
● N’exposez pas la radio à l’eau, la vapeur
ou au sable.
● Ne l ais sez pa s vo tr e
radio dans un endroit où une chaleur
excessive pourrait causer des dommages.
●
Pour d es m esu re s de sé cur ité p lus
importantes, les informations suivantes
doivent être incluses dans la mesure du
possible :
» les distances minimales autour de
l'appareil pour une ventilation efficace;
» la ventilat ion ne do ive nt pas êtr e
entravée en couvrant les ouvertures de
ventilation avec des articles tels que des
journaux, des nappes, des rideaux, etc.

Produkt Specifikationer

Mærke: Sangean
Kategori: Hi-Fi system
Model: CP-100

Har du brug for hjælp?

Hvis du har brug for hjælp til Sangean CP-100 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Hi-Fi system Sangean Manualer

Sangean

Sangean HDR-15X Manual

20 Januar 2025
Sangean

Sangean HDR-19 Manual

20 Januar 2025
Sangean

Sangean WR-16 Manual

20 Januar 2025
Sangean

Sangean DDR-53BT Manual

20 Januar 2025
Sangean

Sangean CP-100 Manual

20 Januar 2025
Sangean

Sangean WFT-4 Manual

22 August 2024
Sangean

Sangean DDR-75BT Manual

20 Juli 2024

Hi-Fi system Manualer

Nyeste Hi-Fi system Manualer

Soundmaster

Soundmaster NADEL05 Manual

15 Januar 2025
Samsung

Samsung MAX-L45 Manual

15 Januar 2025
Morel

Morel SUB-8X Manual

14 Januar 2025
Morel

Morel BEAT-X Manual

14 Januar 2025
Morel

Morel Sopran 634 Manual

14 Januar 2025
Klipsch

Klipsch HD Theater 500 Manual

14 Januar 2025
OSD Audio

OSD Audio Nero Stream ARC Manual

14 Januar 2025
Philips

Philips TAM3205M2 Manual

13 Januar 2025
Philips

Philips TAM3505M2 Manual

13 Januar 2025
Lenco

Lenco MC-129 MP3 Manual

12 Januar 2025
