Display panel / ButtonsProgramme selector / Off

Empty the condensate container

If the condensation drain is installed, it is not necessary to empty the

condensate container. a separate Instructions for condensation drain.

Empty the container after each drying cycle, but not during

the cycle.

1. Remove the container, holding it level.

2. Pour out the condensate.

3. Always push the container back in until it clicks into

place.

IfüÈ (Condensate container) flashes in the display panel

despite the container having been emptied a clean filter

in condensate container, page 8/12.

Do not pull out/empty the condensate container

when drying is in progress.

Clean fluff filter

The fluff filter consists of two parts. Clean the inner and outer filter after every

drying cycle:

1. Open the door. Remove fluff

from the door/door area.

2. Pull out both parts of the

fluff filter.

3. Remove fluff from the edge of the shaft. Fluff should

not fall into the open shaft.

4. Open the filter and remove

all the fluff.

5. Rinse both parts under

running water and dry thoroughly

6. Close the inner and outer filter, put them back

together and reinsert them into the appliance.

Programmes / Fabrics

Detailed overview of the programmes and fabrics

aProgramme overview, page 7.

Observe the care instructions on the care label.

algodón/algodão

(cottons)

Hard-wearing fabrics.

sintéticos (easy-care) Fabrics made from synthetic or

blended fabrics.

Dryness levels to select with the cottons and easy-care

programmes:

extra seco

(cupboard dry extra)

Thick and multi-layered fabrics.

seco para guardar

(cupboard dry)

Single-layered laundry.

Ô seco para (iron dry) Laundry suitable for ironing after

drying.

microfibras (outdoor) Functional clothing made of

microfibre.

toallas/toalhas (towels) Terry-towelling laundry e.g. towels

and bathrobes.

mix A mixed load of fabrics made of

cotton and synthetic fabrics.

caliente/quente

(warm) All types of fabric; time

programme.

frío (cold)

camisas (shirts) Cotton or linen fabrics that are still

damp and easy-care fabrics.

express 40 min.

(super 40’)

Synthetics, cotton or blended fabrics.

acabado lana/lã

(woollen finish)

Woollen fabrics that are suitable

for use in washers.

lenceria/lingerie

(lingerie)

Lingerie made of synthetic fibres,

cotton or blended fabric.

Remove the laundry and switch off

the dryer

Your new dryer

Congratulations - You have chosen a modern, high-quality

Siemens domestic appliance.

The condensation dryer with heat pump and automatic cleaning

of the heat exchanger is outstanding in terms of efficient energy

consumption and low maintenance requirements a page 6.

Every dryer which leaves our factory is carefully checked to

ensure that it functions correctly and is in perfect condition.

Should you have any questions, our after-sales service will be

pleased to help.

Disposal in an environmentally-responsible manner 

This appliance is labelled in accordance with European Directive 

2012/19/EU concerning used electrical and electronic

appliances (waste electrical and electronic equipment - WEEE).

The guideline determines the framework for the return and

recycling of used appliances as applicable throughout the EU.

For further information about our products, accessories,

spare parts and services, please visit: www.siemens-home.com

Intended use Preparation

Set and adjust the

programme individually 1

Drying

ʋexclusively for domestic use,

ʋonly for drying fabrics which have been washed using water.

Keep children younger than 3 years old away from

the dryer.

Do not let children make the cleaning and

maintenance work on the dryer without supervision.

Do not leave children unsupervised near the dryer.

Keep pets away from the dryer.

The dryer may be operated by children from 8 years

of age, by persons who have limited physical, sensory

or mental abilities and by persons who have

inadequate experience or knowledge, provided they

are supervised or have been instructed by

a responsible person.

This appliance is intended for use up to a maximum

height of 4000 metres above sea level.

Drying

Display panel and settings

ʑDisplay panel (status indicators)

(Fluff filter) Clean the fluff filter a page 4/12.

È÷

(Condensate

container)

Empty the condensate container a page 4,8/12.

SELF CLEANING Automatic cleaning of the heat exchanger a page 8.

ÕüÔ]+- -Æ §Ê

(Programme

sequence)

These indicators show the programme progress in the next steps

of the drying cycle:

Õ Drying;

Ô] Iron Dry;

+Cupboard Dry;

- - ÆProgramme pause aif required;

§ÊProgramme end.

(Childproof lock)

You can lock the dryer to prevent the functions you have set from being

changed inadvertently. To activate/deactivate s(Childproof lock) start

the programme and then press and hold the inicio/pausa (start/pause)

button for 5 seconds until a long acoustic signal is heard. The option

activated/deactivated as(Childproof lock) indicator light on/off.

[h:min]

(Remaining time)

When a programme is selected, the anticipated drying time (remaining time)

for the recommended load is displayed. While drying, the moisture sensors

detect the actual load and correct the programme length. This is shown by

jumps in the remaining time in the display panel.

ʑSettings (indicators lights and buttons)

Selected option activated/deactivated aindicator light on/off.

See the separate Energy-saving mode instructions.



(Drying time)

Drying time, available only for timed programmes, can be selected

from min. 0:20 h to max. 3:00 h, in 10-minute steps.



(Fine adjust)

The dryness levels (e.g. Cupboard Dry) can be increased in three levels.

The laundry is made drier. Default = 0. Selectable values: 0, 1, 2, 3. After

setting the level of the fine adjustment for a programme, it is also retained for

other programmes, until  (Fine adjust) is changed again.

³¤- ¤ 

 (Finished in)

The time when the programme has to end can be set by selecting

the (Finished in) time. The  (Finished in) time can be selected in

one-hour steps, up to a maximum of 24 hours. Select the  (Finished in)

button repeatedly until the required number of hours is displayed. Then press

the inicio/pausa (start/pause) button to activate the  (Finished in)

option. The programme ends after the selected number of hours.

Several minutes after activating  (Finished in) option the display switches

off to save energy. To switch it on select any button, close/open the door or

turn the programme selector.



delicado (gentle dry)

Reduced temperature for delicate fabrics, e.g. polyacrylic, polyamide

or elastane, with a longer drying time.

â menos

(wrinkle guard plus)

After the programme finishes, the drum moves at regular intervals to prevent

creases. Laundry remains loose and fluffy.

The standard setting for each programme is 60 min. Automatic anti-crease

function can be extended by up to 60 min.

ü

(Buzzer)

For switching the buzzer on and off. ü(Buzzer) indicates program end if it

is activated. Other sounds are not influenced by this option.

Close the door

Contents Page

ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2

ʋControl panel . . . . . . . . . . . . . . . . . . . . . 2

ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . .3/4

ʋDisplay panel and settings . . . . . . . . . . . 5

ʋNotes on laundry . . . . . . . . . . . . . . . . . . 6

ʋImportant information . . . . . . . . . . . . . . . 6

ʋOverview of programmes . . . . . . . . . . . . 7

ʋCare and cleaning . . . . . . . . . . . . . . . . . 8

ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . 9

ʋFrost protection / Transport . . . . . . . . . . 9

ʋOptional accessories . . . . . . . . . . . . . . 10

ʋTechnical data . . . . . . . . . . . . . . . . . . . 10

ʋConsumption rates . . . . . . . . . . . . . . . . 10

ʋNormal noises . . . . . . . . . . . . . . . . . . . 11

ʋWhat to do if ... . . . . . . . . . . . . . . . . 11/12

ʋAfter-sales service . . . . . . . . . . . . . . . 13

ʋSafety instructions. . . . . . . . . . . . . . . . . 13

Never start the dryer if it is damaged!

Inform your after-sales service! Inspect the dryer

Sort the laundry

Remove all items from pockets,

especially cigarette lighters.

The drum must be empty prior to loading.

See also separate instructions for “Woollens basket”

(depending on model).

Make sure your hands are dry.

Only grasp the plug by the plug

body.

Connect the

mains plug

End of the programme...

Interrupt the programme

1. Open the door or press the inico/pausa (start/pause) button;

the drying cycle is interrupted.

2. Add or remove laundry and close the door.

3. If required, select a new programme and additional functions. Select the

inico/pausa (start/pause) button. The remaining time is updated after

a few minutes.

The drum and door may be hot!

Notes on laundry ...

Labelling of fabrics

Follow the manufacturer's care instructions.

hcSuitable for tumble drying.

(cDry at normal temperature.

'cDry at low temperature a in addition, select delicado (gentle dry).

)cDo not tumble dry.

Do not tumble dry the following fabrics:

– Non-breathable fabrics (e.g. rubber-coated).

– Delicate materials (silk, curtains made from synthetic material) a these may crease.

– Oil-stained laundry.

Drying tips

– To ensure a consistent drying result, sort the laundry by fabric type and drying programme.

– Always dry very small fabrics (e.g. baby socks) together with large items of laundry (e.g. towels).

– Close zips, hooks and eyelets, and button up covers. Tie cloth belts, apron strings, etc. together or use a laundry bag.

– Do not over-dry easy-care laundry a risk of creasing. Allow laundry to finish drying in the air.

– Do not dry woollens in the dryer. They may, however, be refreshed in the dryer a page 7, acabado lana/lã

(woollen finish) Programme (depending on model).

– Do not iron laundry immediately after drying; fold items up and leave for a while a residual moisture will then be

distributed evenly.

– Knitted fabrics (e.g. T-shirts, jerseys) often shrink slightly the first time they are tumble-dried. a Do not use the extra

seco (cupboard dry extra) programme.

– Starched laundry is not always suitable for dryers a starch leaves behind a coating that reduces the drying effect.

– When washing laundry that is to be tumble dried afterwards, use the correct amount of fabric softener as specified in the

manufacturer's instructions.

– For pre-dried, multi-layered fabrics or small, individual items of laundry, use the timed programme. Also suitable for

subsequent drying.

Environmental protection / Energy-saving tips

– Before drying, spin the laundry in the washing machine a higher spin speeds minimise the drying time and reduce

energy consumption.

– Use the maximum recommended capacity, but do not exceed it a Programme overview page 7.

– Make sure the room is well ventilated during drying.

– Do not cover or seal the air inlet on the dryer.

Control panel

Two-part

fluff filter

Select

inicio /pausa

(start/pause)

Door

Installation a page 9.

Condensate

container

with filter

Air inlet

Programme selector for setting

the programme and switching the appliance

on/off. Can be turned in both directions.

Important information ...

Your dryer is designed to be particularly energy efficient. Its technical features include a refrigeration circuit, which uses

energy efficiently in a similar way to a refrigerator.

The dryer's heat exchanger is cleaned automatically during drying.

The fluff filters and filter in the condensate container must be cleaned regularly.

Never operate the dryer without the fluff filters and without filter in condensate container!

Fluff filters

During drying, fluff and hair from the laundry is trapped by the fluff filter. Blocked fluff filters may impair the heat exchange

process.

The fluff filters must therefore be cleaned after every drying cycle. Rinse regularly under running water a page 4/12.

Filter in the condensate container

The filter in the condensate container cleans the condensation. This condensation is required for the automatic cleaning

process. The filter should be cleaned regularly under running water. Empty the condensate container before cleaning the

filter a page 4,8/12.

Fabrics

Do not dry any fabrics that have come into contact with solvents, oil, wax, grease or paint: e.g. hair styling products, nail

varnish remover, stain remover, cleaning solvent etc.

Empty all pockets.

Do not dry non-breathable fabrics.

Avoid drying items that produce a lot of fluff.

Woollens should be refreshed only, using the woollens programme.

Further information

can be found

on page 5

Clean fluff filters reduce energy consumption.

Programme sequence ÕüÔ]+

- Æ-§Ê

Childproof lock s

Condensate container È

Fluff filter ¡

Automatic cleaning of the

heat exchanger

SELF

CLEANING

`  (Drying Time) Setting the drying time available only for timed programmes.

(Fine adjust) Fine adjustment of dryness level.

³¤- ¤  (Finished in) Setting the programme end.

delicado (gentle dry) Low-heat drying  reduced temperature.

Îâümenos (wrinkle guard plus) Extends the anti-crease function.

(Buzzer) Buzzer on/off.

inicio/pausa (start/pause) Starts, pauses and continues the programme;

activates or deactivates s(Childproof lock).

Programme overview see also page 6.

Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying.

After drying, laundry is to be ... cironed  lightly ironed @cnot ironed cmangled

PROGRAMMES TEXTILE TYPE AND INFORMATION

*algodón/algodão (cottons) max. 8 kg Hard-wearing fabrics, boil-proof fabrics made of cotton or linen.

*sintéticos (easy-care) max. 3.5 kg Non-iron laundry made of synthetic fibres and mixed fabric, easy-care cotton.

Ô seco para (iron dry) c÷@c The condition of the laundry means it is suitable for ironing (iron clothes in order to avoid creases).

seco para guardar

(cupboard dry) @Single-layered laundry.

extra seco

(cupboard dry extra) @Laundry with thick, multi-layered parts.

microfibras (outdoor) max. 1.5 kg Fabrics with membrane coating, water-repellent fabrics, functional clothing, fleece fabrics (dry jackets/trousers with removable

internal lining separately).

toallas/toalhas (towels) max. 6 kg Terry-towelling laundry e.g. towels and bathrobes.

mix max. 3 kg Mixed items of laundry made of cotton and synthetics (Mix).

caliente/quente (warm) max. 3 kg

All types of fabric; time programme. Suitable for pre-dried or slightly damp laundry and for drying off multi-layered, thick laundry.

Only dry wool, sports shoes and soft toys with the basket for woollens aOptional Accessories, page 10.

In the time programme, the laundry's residual moisture is not automatically detected. If the laundry is still too damp after the drying

programme, repeat the programme and, if required, extend the programme length.

frío (cold) max. 3 kg All types of fabrics. For freshening up or airing of items of laundry that have been worn for a short period of time.

camisas (shirts) max. 1.5 kg Cotton or linen fabrics that are still damp and easy-care fabrics. Creasing in fabrics is reduced. Fabrics are not dried completely.

Hang up fabrics!

express 40 min. (super 40’) max. 1 kg Laundry made of synthetic fibres, cotton or blended fabrics (for example) that needs to be dried quickly. The values may differ from the

those specified depending on the type of fabric, mixture of laundry to be dried, residual moisture in the fabric and loading capacity.

acabado lana/lã (woolen finish) max. 3 kg Woollen fabrics suitable for washing machines. Fabrics become fluffier but not dry. Remove fabrics once the programme has ended

and allow to dry.

lenceria/lingerie (lingerie) max. 1 kg Lingerie made of synthetic fibres, cotton or blended fabric.

*Dryness levels can be selected individually a cupboard dry extra, cupboard dry and Ø iron dry (depending on the model).

Degree of dryness can be finely adjusted; multi-layered textiles require a longer drying time than single-layered items of clothing. Recommendation: Dry separately.

9608 / 9001060296

*1060296*

BSH Hausgeräte GmbH

Carl-Wery-Straße 34

81739 München/GERMANY

WT45W230EE

Manufactured by BSH Hausgeräte GmbH under Trademark License of Siemens AG

Produkt Specifikationer

Mærke:	Siemens
Kategori:	Tørretumbler
Model:	WT45W230EE
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	598 mm
Dybde:	652 mm
Højde:	842 mm
Vægt:	53000 g
Produktfarve:	Hvid
Kontroltype:	Buttons,Rotary
Indbygget skærm:	Ja
Strøm:	10 A
Ledningslængde:	1.45 m
Årligt energiforbrug:	232 kWh
Strømforbrug (standby):	0.5 W
Strømforbrug (slukket):	0.1 W
Placering af apparat:	Fritstående
Dørhængsel:	Højre
Tilsluttet belastning:	1000 W
Støjniveau:	65 dB
Ilægningstype:	Front-læsning
Tromlekapacitet:	8 kg
Forsinket start-timer:	Ja
Certificering:	CE, VDE
Cyklustid:	203 min.
Forsinket start (maks.):	24 t
Tørringsklasse:	B
Selvrensende:	Ja
Energieffektivitetsklasse:	A++
Tørreprogrammer:	Wool,Mix,Delicate/silk,Microfiber,Blouse/shirt,Lingerie,Towel
Tørresystem:	Kondensering
Nominel strømstyrke:	10 A
Energiforbrug:	1.8 kWh
Varmekilde:	Elektrisk
