AC-E15A/E30A/E45A

AC-E60A/E90A

3-048-456-11 (1)

AC Power

Adaptor

Operating Instructions

Mode d’emploi

WARNING

To prevent fire or shock hazard, do not

expose the unit to rain or moisture.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference,

and (2) This device must accept any interference

received, including interference that may cause

undesired operation.

You are cautioned that any changes or modifications

not expressly approved in this manual could void

your authority to operate this equipment.

“IMPORTANT SAFETY INSTRUCTIONS - SAVE

THESE INSTRUCTIONS”

”DANGER - TO REDUCE THE RISK OF FIRE OR

ELECTRIC SHOCK, CAREFULLY FOLLOW THESE

INSTRUCTIONS”

“For connection to a supply not in the U.S.A., use an

attachment plug adaptor of the proper configuration

for the power outlet.”

English

Using your AC power adaptor

abroad

You can use your AC power adaptor in any country or

area that uses 100 V to 240 V AC, 50/60 Hz, by

connecting a plug adaptor. If the country you visit

employs a different shaped socket, use the correct

plug adaptor.

Please consult your nearest travel bureau for the type

of the plug adaptor needed in your travels.

Precautions

Installation

Do not place the AC power adaptor in a location

where it is:

• Subject to extreme high temperature

(E.g., in a car with its windows closed)

• Subject to direct sunlight or near a heat source

• Subject to mechanical vibration or shock

• Subject to a magnetic field

(E.g., near a magnet, speaker, or TV)

• Subject to excessive dust.

Operation

• Make sure the current and voltage of the equipment

matches that of the outlet.

• For safety, if the input current is too high, the unit

will automatically shut down.

• Do not connect this unit to a radio or equipment

with a radio tuner as it may cause noise.

• Do not use the unit near a TV set, radio, or

equipment with a radio tuner. If you place

equipment too close to the unit while they are being

used, you may experience some interference.

• To prevent damage, be careful not to drop or

otherwise cause a mechanical shock to the unit.

• After using, disconnect the unit from the wall outlet

and the equipment.

• Disconnect the unit from the AC outlet by pulling on

the plug. Do not pull on the cord.

• To avoid short-circuiting, do not allow the terminals

of the unit or connector to touch any metal object.

Cleaning

• Clean the unit with a soft, dry cloth. If the unit is

very dirty, wipe it off with a soft cloth lightly

moistened with a mild detergent solution, and then

wipe with a soft dry cloth.

• Do not use any type of solvent such as alcohol,

thinner, or benzine as it may damage the finish of

the cabinet.

• If you use any chemical cleaner, observe the

instructions provided with the product.

• If the cabinet of the unit is splashed with any type of

solvent such as insecticide, or remains in contact for

a long time with rubber or vinyl, the finish of the

cabinet may be damaged.

Specifications

Input voltage 100 – 240 V, 50/60 Hz

Rated output voltage AC-E15A DC 1.5 V

AC-E30A DC 3.0 V

AC-E45A DC 4.5 V

AC-E60A DC 6.0 V

AC-E90A DC 9.0 V

Rated output current 1,000 mA

Power consumption AC-E15A 3.8 W

AC-E30A 6.0 W

AC-E45A 7.5 W

AC-E60A 9.0 W

AC-E90A 15.0 W

Dimensions Approx. 1 5/ 8×13/ 16 × 3 5/8 in.

(Approx. 40 × 20 × 90 mm)

(w/h/d)

Mass Approx. 3.46 oz (108 g)

Design and specifications are subject to change

without notice.

How to Use

Plug’s polarity

6 ft. 6 in. (2 m)

to the DC power input jack

2 to an AC outlet

Note on the DC plug of the AC power adaptor

This AC power adaptor uses a unified polarity type

plug (EIAJ standard). Damage will occur if it is

connected to a DC power input jack without the

polarity symbol or with another symbol. If the jack of

your audio equipment does not match the AC power

adaptor, consult your dealer.

Symbol of unified polarity type jack

DC plug diameter

AC-E15A ø3/ mm)32 in. (ø2.35

AC-E30A ø3/ mm)32 in. (ø2.35

AC-E45A ø3/ mm)16 in. (ø4.0

AC-E60A ø3/ mm)16 in. (ø4.0

AC-E90A ø7/ mm)32 in. (ø4.75
