Installing the Batteries

Before replacing the batteries, have new ones

ready beforehand.

Slide open the battery compartment and insert two

R6 (size AA) batteries*.

Be sure to line up the + and – on the batteries with

the + and – on the battery compartment.

1 2

* The supplied manganese batteries are for testing

purposes.

When to replace the batteries

Under normal conditions, batteries will last up to

one year. If the Commander does not operate

properly, the batteries might be worn out. Replace

the batteries with new ones.

Notes

•Replace both batteries with new ones.

•Do not take more than 3 minutes to replace the

batteries; otherwise, your setting of the code

numbers will be erased.

Notes on Batteries

•Do not mix old batteries with new ones or mix

different types of batteries together.

•If the electrolyte inside the battery should leak,

wipe the contaminated area of the battery

compartment with a cloth and replace the old

batteries with new ones. To prevent the

electrolyte from leaking, remove the batteries

when you plan not to use the Commander for a

long period of time.

Setting the Code

Follow the steps 1 and 2 below for each component

you plan to use with the Commander.

Step 1: Entering the Code Number

1See the supplied

“Component code

numbers”, and find the

four-digit code number

for the desired

component.

If more than one code

number is listed, use

the number that’s listed

first.

For example, if you’re setting up a Sony

TV, you would use the code number 8201.

If your component isn’t listed, see

“Searching for the Correct Code.”

2 SETPress more than two seconds.

The SET indicator lights up.

3Press the button of the component that you

want to set up.

The SET indicator lights up.

4Press the Number buttons to enter the

four-digit component code number.

5 ENTERPress . The SET indicator

turns off. If the SET indicator

flashes five times before lighting

up, it means that the setup is

incomplete. Confirm the

component code number and start over

from Step 4.

If the code setting is not finished

properly

If you do not input anything into the Commander

within 20 seconds between each step, or if you

press SET while setting the component code, the

setup procedure will be cancelled.

Start over from Step 2.

3-284-977- (1)11

Operating a DVD

2To change the input

mode.

3 qdand

Number buttons : To set

items selected from the

screen.

4To select numbers 10

and above.

8To switch to Teletext.

9To bring up the Master

Guide.

q; To return to the

previous screen.

qd To enter the setting. To

set items selected from

the screen.

qf To switch the audio

mode.

qg PROGRAM+:

Programme up.

PROGRAM–:

Programme

down.

qh To select a deck.

qj To switch the subtitle.

qk To display the DVD

menu.

ql To move the cursor

upward, downward, to

the left, to the right, or

to enter the selection.

w; To call up the setup

menu.

Specifications

Operable distance Approx. 7 m (varies depending of the

component of each manufacturer)

Power requirements Two R6 (size AA) batteries

Battery life Approx. 1 year (varies depending on

frequency of button use - up to

approx. 300 times per day.)

Dimensions Approx. 53 × 220 × 29 mm (w/h/d)

Mass Approx. 143 g (including batteries)

Supplied accessories Operating Instructions (1)

Component code numbers (1)

R6 (size AA) batteries (2)*

* The supplied manganese batteries are for testing purposes.

Design and specifications are subject to change without notice.

The validity of the CE marking is restricted to only

those countries where it is legally enforced, mainly

in the countries EEA (European Economic Area).

Troubleshooting

If you have problems setting up or using the Commander:

• When setting up the Commander, carefully go through the

procedures described in “Setting the Code.” If the code that’s

listed first for your component doesn’t work, try all the codes

for your component - in the order in which they’re listed. If

all the codes fail to work (or if your component is not listed

in this manual), try using the procedures in “Searching for

the Correct Code.”

• Check that you’re aiming the Commander directly at the

component, and that there are no obstructions between the

Commander and the component.

• Make sure the batteries you’re using are not worn out, and

that they’re inserted correctly.

• , , Check that the button of the TV VCR SAT, or DVD is pressed

to choose your desired component.

• Check that the component has infrared remote capability.

For example, if your component didn’t come with a remote

commander, it probably isn’t capable of being controlled by

a remote commander.

• Should any problem persist, reset the Commander to the

factory setting by pressing the 1 2, t and – buttons

simultaneously.

Operating a TV

2To change the input

mode.

3To change the

programme.

4To select double-digit

numbers.

8To switch to Teletext.

9To bring up the Master

Guide.

q; To exit the mode.

qd To select a number

between 20 and 29.

qg PROGRAM+:

Programme up.

PROGRAM–:

Programme

down.

qh To operate JUMP

FLASHBACK or

CHANNEL RETURN

function.

qj To switch to TV.

qk To call up the MENU

display.

ql To move the cursor

upward, downward, to

the left, to the right, or

to enter the selection.

w; To bring up the EPG.

wa N: To play.

m: To rewind.

M: To fast-forward.

zREC: To record, press

N while

pressing .zREC

x: To stop.

X: To pause.

ws Fastext buttons.

wd SERVICE:

To show the

Service screen.

FAVORITE:

To show the Box

Office screen.

wf To show the interactive

screen.

wg To show the Help

screen.

Operating a cable box

ENTER

About tactile dots

The number button, the button and each5NPROGRAM+

have a tactile dot for convenient use.

Note on the – and buttons2 2+, %

The Commander controls or mutes the TV’s volume when you

select a visual component. The Commander outputs the signals

to control or to mute a TV’s own volume when you have set

TV components.

SET

TV VCR SAT DVD

SET

Setting Up the Remote

Commander

About Presetting the Commander

The Commander is preset at the factory to operate

Sony brand components.

If you’re using the Commander with a Sony

component, you won’t need to preset the

Commander before you start using it.

To set up the Commander to use with other (non-

Sony) manufacturers’ components, or to use with a

component that is not preset at the factory, you’ll

need to follow the instructions in this manual to

preset the Commander with the correct code

number for your components. (See the supplied

“Component code numbers” also).

Notes

•The Commander can be set up to operate only

one component per button – unless their code

numbers happen to be the same. For example,

you cannot set up the Commander to operate a

Sony TV and a Panasonic TV simultaneously

(because they use different code numbers).

•You may not be able to operate even a Sony

brand component with the factory presetting. In

such a case, follow the procedure in “Setting the

Code.”

Operating Instructions

Mode d'emploi (au verso)

Component that can be preset

VCR/Satellite receiver/

DVD/TV/Cable box

Button

VCR

SAT

DVD

Factory setting

Sony TV

Sony VHS VCR

Sony satellite

receiver

Sony DVD player

Operating a VCR

2To change the input

mode.

qg PROGRAM+:

Programme up.

PROGRAM–:

Programme

down.

qj To switch the antenna

output.

wa N: To play.

x: To stop.

m: To rewind.

M: To fast-forward.

zREC: To record, press

while pressing

zREC.

X: To pause.

wf To expose the on-screen

display.

Notes

• There may be cases you may turn on/off the cable box by

pressing PROGRAM+ or PROGRAM– on the Commander.

• If your cable box can control volume, be sure to set its

volume control to a medium position. If the volume on the

cable box is turned down completely, you will not be able to

adjust your TV’s volume with the Commander.

Step 2: Checking if the Code Number

Works

1Power on the component you want to set

up.

2Aim the Remote Commander at the

component and press a button to check if

that button works.

For example, press the button to see if it1

works on your component .

3Check that the other buttons of the

Commander are operating the

corresponding functions of the component.

You can write down the code number on the

label inside the battery compartment lid.

If the Commander Doesn’t Seem to Be

Working...

•First, try repeating these setup procedures using

the other codes listed for your component (see

the supplied “Component code numbers”).

•If – after trying all the codes listed for your

component – you still cannot get the Commander

to work properly, try the search method

described in “Searching for the Correct Code.”

Searching for the Correct Code

You can find a code number

available for a component

that doesn’t have one in the

supplied “Component code

numbers.”

Before starting the Search

function

Set each component to the

following status so that the

Search function works

effectively.

TV: Power-on

Other components: Power-off

* If any of these components are

assigned to any of the

Component Select buttons, you

can set a component code using

the Search function.

1 SETPress more than two seconds. The SET

indicator lights up.

2Press the Component Select button for the

desired component. The SET indicator

lights up.

3 PROGRAM+ PROGRAM–Press or and 1

in turn until the component reacts as

follows:

TV: Powers off

Other components: Powers on

Press PROGRAM+ to go to the next code

number.

Press PROGRAM– to go back to the

previous code number.

The SET indicator flashes once after the

numbers have turned one cycle.

One cycle means, for example, that the

commander finishes searching all the

component code numbers allocated to the

component.

4 ENTERPress .

The SET indicator and the Component

button turn off.

If the SET indicator flashes five times

before turning off, it means that the setup

is incomplete. Start over from Step 3.

If the component does not operate properly, repeat

steps 1 to 4 and search for another code.

If you still cannot get the Commander to work

properly, see “Troubleshooting.”

2To change the input

mode.

3To change the

programme.

4To select double-digit

numbers.

8To switch to Teletext.

9To bring up Master

Guide.

q; To exit the menu.

qd To select a number

between 20 and 29.

qf To select DIGITAL.

qg PROGRAM+:

Programme up.

PROGRAM–:

Programme

down.

qh To operate JUMP,

FLASHBACK or

CHANNEL RETURN

function on the TV.

qj To return from Teletext

to TV.

qk To call up the MENU

display.

ql To move the cursor

upward, downward, to

the left, to the right, or

to enter the selection.

w; To call up the option

menu.

wa N: To play.

m: To rewind.

M: To fast-forward.

zREC: To record, press

N while

pressing .zREC

x: To stop.

X: To pause.

.: To proceed to

the previous

location.

>: To proceed to

the next

location.

: To replay.

: To advance

forward.

REC STOP:

To stop

recording, press

x while

pressing .zREC

REC PAUSE:

To pause

recording, press

X while

pressing .zREC

ws Fastext buttons.

wd SERVICE:

Press once to

display a frozen

image.

FAVORITE:

To switch to

Wide Mode.

wf To display the current

programme on TV.

wg To operate the Picture-

in-Picture function.

Operating a satellite receiver

2To change the input

mode.

3To change the

programme.

4To select double-digit

numbers.

8To switch to Teletext.

9To bring up the Master

Guide.

q; To exit the mode.

qd To select a number

between 20 and 29.

qf To switch to Wide

Mode.

qg PROGRAM+:

Programme up.

PROGRAM–:

Programme

down.

qh To operate JUMP

FLASHBACK or

CHANNEL RETURN

function.

qj To switch to TV.

qk To call up the MENU

display.

ql To move the cursor

upward, downward, to

the left, to the right, or

to enter the selection.

w; To bring up the EPG.

wa N: To play.

m: To rewind.

M: To fast-forward.

zREC: To record, press

N while

pressing .zREC

x: To stop.

X: To pause.

ws Fastext buttons.

wd SERVICE:

To show the

Service screen.

FAVORITE:

To show the Box

Office screen.

wf To show the interactive

screen.

wg To show the Help

screen.

Customer Service

If you have any questions or

problems concerning the

Remote Commander that are

not covered in this manual,

please call the customer remote

helpline. The number is

mentioned in the warranty

card.

Remote

Commander

RM-V210T

SET

T V VCR SAT DVD

123

456

789

PROGRAM

DIGITAL

ENT ER

Helpline available

English

Notice for the customer in the

countries applying EU Directives

The manufacturer of this product is Sony

Corporation, 1-7-1 Konan, Minato-ku, Tokyo,

Japan. The Authorized Representative for EMC

and product safety is Sony Deutschland GmbH,

Hedelfinger Strasse 61, 70327 Stuttgart, Germany.

For any service or guarantee matters please refer to

the addresses given in separate service or

guarantee documents.

Disposal of Old Electrical &

Electronic Equipment

(Applicable in the European

Union and other European

countries with separate

collection systems)

This symbol on the product or on its packaging

indicates that this product shall not be treated as

household waste. Instead it shall be handed over to

the applicable collection point for the recycling of

electrical and electronic equipment. By ensuring

this product is disposed of correctly, you will help

prevent potential negative consequences for the

environment and human health, which could

otherwise be caused by inappropriate waste

handling of this product. The recycling of materials

will help to conserve natural resources. For more

detailed information about recycling of this

product, please contact your local Civic Office,

your household waste disposal service or the shop

where you purchased the product.

Disposal of waste batteries

(applicable in the European

Union and other European

countries with separate

collection systems)

This symbol on the battery or on the packaging

indicates that the battery provided with this

product shall not be treated as household waste.

By ensuring these batteries are disposed of

correctly, you will help prevent potentially

negative consequences for the environment and

human health which could otherwise be caused by

inappropriate waste handling of the battery. The

recycling of the materials will help to conserve

natural resources.

In case of products that for safety, performance or

data integrity reasons require a permanent

connection with an incorporated battery, this

battery should be replaced by qualified service

staff only.

To ensure that the battery will be treated properly,

hand over the product at end-of-life to the

applicable collection point for the recycling of

electrical and electronic equipment.

For all other batteries, please view the section on

how to remove the battery from the product safely.

Hand the battery over to the applicable collection

point for the recycling of waste batteries.

For more detailed information about recycling of

this product or battery, please contact your local

Civic Office, your household waste disposal

service or the shop where you purchased the

product.

wa N: To play.

m: To rewind.

M: To fast-forward.

zREC: To record, press

N while

pressing .zREC

x: To stop.

X: To pause.

.: To proceed to

the previous

location.

>: To proceed to

the next

location.

: To replay.

: To advance

forward.

REC STOP:

To stop

recording, press

x while

pressing .zREC

ws Fastext buttons.

wd SERVICE:

Timer on/off.

FAVORITE:

To display the

title menu.

wf To show the current

play status on the

screen.

wg To display the program

explanation.

SET

T V VCR SAT DVD

123

456

789

PROGRAM

DIGITAL

ENT ER

Operating a Component

1Press the button of the desired component

on the Commander.

TV VCR SAT DVD

2Point the Commander directly at the

component.

3Press the button for the function you want

to use.

See “Remote Button Descriptions” for complete

descriptions of the buttons on the Commander.

Notes on Using the Remote Commander

Basically, use this Commander in the same way as

the Commanders supplied with your components.

•Using this Commander will not increase the

functions of your components. The functions of

the Commander are limited to the functions of

the components themselves. For example, if your

TV does not have a MUTING function, % on this

Commander will not function with your TV.

•Some functions of the component may not work

with this Commander.

•If your cable box can control volume, be sure to

set its volume switch to a medium position. If the

volume on the cable box is turned down

completely, you will not be able to adjust your

TV’s volume with the Commander.

Remote Button Descriptions

General

1To set up the

Commander, press

SET more than two

seconds.

62+: Volume up

2–: Volume down

7To mute the volume

on a TV.

qa To turn on and off the

power of the selected

component.

qs Component select

buttons. Press to select

a component to

operate.

SET

T V VCR SAT DVD

123

456

789

PROGRAM

DIGITAL

GUIDE MENU

RETURN

TOOLS

FAVO RITESERVICE

ENT ER

SET

indicator

Produkt Specifikationer

Mærke:	Sony
Kategori:	Fjernbetjening
Model:	RM-V210T
Bredde:	145 mm
Dybde:	220 mm
Højde:	29 mm
Vægt:	53 g
Batterilevetid (maks.):	288 t
Batteritype:	AA
Antal understøttede batterier:	2
Maks. rækkevidde:	7 m
