Side 1/1
Specications
Carrier Frequency Range ........ UHF band 540 – 570MHz
Oscillator.................................. PLL synthesized
Modulation ............................... FM
Frequency Stability .................. ±0.005%
S/N Ratio ................................. More than 94dB, at 20kHz deviation
................................................. and 60dBmV antenna input
Maximum Deviation ................. ±48kHz
Image and Spurious Rejection ... 80dB minimum
Receiving Sensitivity................ At 10uV over 80dB S/N ratio
Selectivity ................................ More than 50dB
AF Response ........................... 80Hz – 16kHz (±3dB)
T.H.D. ....................................... More than 1% (at 1kHz)
IF Frequency ........................... 1st: 243.95MHz 2nd:10.7MHz
Dynamic Range ....................... More than 96dB
Tone Signal .............................. 32.768kHz
Audio Output............................ Balanced and unbalanced audio outputs
Power Supply .......................... 12VDC (power supply included)
Current Consumption .............. Single Channel: about 260mA
Dimensions .............................. 7.9” (W) x 1.7” (H) x 4.8” (D)
Specications
Carrier Frequency Range ....UHF band 540 – 570MHz
RF Power Output ...............10mW (max.)
Oscillator............................PLL synthesized
Frequency Stability ............±0.005%
Maximum Deviation ...........±48KHz
Spurious Emission .............More than 60dB below carrier frequency
T.H.D. .................................More than 1% (at 1kHz)
Microphone Cartridge ........(Handheld) uni-directional dynamic or
uni-directional electret condenser unit.
(Lavalier) uni-directional electret condenser unit
Operating Voltage ..............DC1.5V x 2 AA size dry or rechargeable batteries
Current Consumption ........120mA (max.)
Speco Technologies’ UHF 700 frequency-selectable single channel
receiver, handheld and lapel microphone transmitters allow the user
to select and match desired frequencies on each unit. This eliminates
the need to maintain high inventory levels of similar units with locked
frequencies. They provide clear, interference-free channels of
communication for roaming distances in excess of 150 feet.
• Up to 700 selectable pre-programmed frequencies make it easy to set up
multiple system congurations and avoid interference
• Auto-scan function can locate interference-free channels easily
• True Diversity technology ensures quality reception
• Constructed from durable plastic with a ½ rack design
• Squelch adjustment
• Balanced XLR connector and unbalanced ¼” jack audio output
• FCC, CE, RoHS compliant
UHF 700 Frequency-Selectable
Professional Microphone Line
MUHF101 UFH 700 Frequency-selectable single channel true
MUHFHH UFH 700 Frequency-selectable handheld microphone
MUHFLP UFH 700 Frequency-selectable lapel microphone
Features
Speco Technologies is constantly developing and improving products.
We reserve the right to modify product design and specications without notice
and without incurring any obligation. Spec Rev. 2/23/22
800-645-5516 • Fax: 631-957-9142 or 631-957-3880 • specotech.com
*Products are in compliance with NDAA Section 889 Part B Guidelines
