Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: June 19, 2019 3:38 PM
Product Diagram (VID2VGATV3)
Front and Side Prole
Rear and Side Prole
Component Function
1Video Input Selection Switch • Select the Source Device Video Signal
2VGA Output Port • Connect a VGA Video Display Device
3Resolution Selection Button • Select the Output Resolution
4Power Port • Connect a Power Source
5Composite Video Input Port • Connect a Composite Video Source Device
6S-Video Input Port • Connect an S-Video Source Device
Composite and S-Video to VGA Video Converter
Requirements
For the latest requirements, please visit . www.startech.com/VID2VGATV3
• Composite Video or S-Video Source Device x 1
• Composite Video or S-Video Cable x 1
• VGA Video Display Device x 1
• VGA Cable x 1
• USB Power Source x 1
Installation and Operation
1. Ensure all of your are powered o.Devices
2. Determine if you are using a or . Toggle the Composite S-Video Source Device
Video Input Selection Switch Source Device to match your video signal.
3. Connect a to the . Composite Video Cable Composite Video Input Port
Or
Connect an to the . S-Video Cable S-Video Input Port
4. Connect the other end of the to the Composite Video Cable Composite Video
Source Device.
Or
Connect the other end of the to the . S-Video Cable S-Video Source Device
5. Connect a to the on the .VGA Cable VGA Output Port Video Converter
6. Connect the other end of the to the .VGA Cable VGA Video Source Device
7. Connect the to an available and to USB-A to USB Mini Cable USB Power Source
the .Power Port
8. Select the output resolution by pressing the until the Resolution Selection Button
desired resolution is met. Each time you press the the Resolution Selection Button
new resolution settings will appear on the in the upper On Screen Display (OSD)
right-hand corner of the screen.
5
6
4
3
2
1
