INSTALLATION OF STI-9110 LOCKABLE THERMOSTAT COVER
All specifications and information shown were current as of publication and are subject to change without notice.
9110IS AUG2018
INSTALLATION INSTRUCTIONS
1. Do not remove thermostat. Prior to drilling anchor holes, cover thermostat
with a damp cloth to prevent dust from penetrating the sensor.
2. Center frame over existing thermostat. Mark and drill (4) anchor holes using
a in. (6.3mm) drill bit. Insert the anchors and complete installation 1/4 (4)
as shown.
NOTE: The (3) tabs on the frame must face upward ( iew A).V
3. Insert the (3) slots on the cover over tabs on the top surface of frame.
Rotate cover downward onto the frame and turn key to lock.
CLEANING INSTRUCTIONS
To clean cover, remove from wall. Rinse with water to remove abrasive dust and
.)BURCS TON OD( htolc tfos a gnisu tnegreted dlim ro paos htiw hsaW .trid
Rinse once more, then dry with a soft cloth or chamois. To remove grease or
wet paint, rub gently with a cloth wetted thoroughly with naphtha. Then wash
and rinse. DO NOT USE RAZOR BLADES.
COVER AND
L SEMBLOCK AS Y
STI- AR)9110 (CLE
9110 FRAME
DRILL (4) HOLES .25"
EXISTING FLUSH
MOUNT THERMOSTAT
(6.3 mm) DIAMETER
FLUSH MOUNT
(STI-9110)
THE THREE (3) COVER TABS
MUST FACE UPWARD AS SHOWN
VIEW A
91101 COVER
9110 FRAME
FRAME TABS
FOR SURFACE MOUNT
STI-9110 AND STI-900
FOR ADEQUATE CLEARANCE
A 2 in. (50mm) DEEP SPACER
MUST BE USED
(ORDER STI-900)
AS EE VIEW A
19013 SCREW
#10 x 1/2 PHILIPS PAN HEAD
(4) PROVIDED
19033 ANCHOR
(4) PROVIDED
Three year warranty or a one year limited warranty (from
date of purchase) on most products. See website for details.
Electronic warranty form at www.sti-usa.com/wc14.
Toll Free: 800-888-4784 • E-mail: info@sti-usa.com
Web: www.sti-usa.com
USA - Headquarters
2306 Airport Road • Waterford, Michigan 48327-1209
Phone: 248-673-9898 • Fax: 248-673-1246
Tel: 44 (0) 1527 520 999 Fax: 44 (0) 1527 501 999
E-mail: info@sti-emea.com • Web: www.sti-emea.com
European Office
Taylor House • • 34 Sherwood Road Bromsgrove
Worcestershire • B60 3DR • England
9.5 in.
(241mm)
8.45 in.
(215mm)
3.9 in.
(99mm)
3.75 in.
(95mm)
5.3 in.
(135mm) 7.6 in.
(193mm)
