S DING Bicycle computer UN
SD-201A (21Functions)
FUNCTION
- SPD CURRENT SP D EE
-
ODO ODOMETER
（0-99999km/m）
-
DST TRIP DISTANCE
- MXS MAXIMUM SP D EE
- AVS AVERAGE SPEED
- TM ELAPSED TIME
- CLK CLOCK 12H/24H（ ）
-
TMP TEMPERTERATURE
（
-10
℃
~70
℃）
- MIN TMP
- MAX TMP
- SCAN
- COMPARATOR
- CAL（0 999Kcal～99 ）
- FAT 0 9999.9kg（ ～ ）
- S TING SP D SCALEET EE （km/h,m/h）
- S TING TYRE CIRCUMFERENCE 0mmET （ ～
9999mm）
- S TIN THE LAST VALUE OF ODOM ER / O ET ET OD
- S TING THE RIDER’S WEIGHT ET
- FR E FRAME MEMORY EEZ
- MAIN NCE ALERTENA T
- AUTO ON/OFF
Battery Installation
Remove the battery cover from the bottom of the computer
by using a flat blade screwdriver, install a CR2032 battery
with the positive(+) pole facing the battery cover and replace
the cover. Should the LCD show irregular digits, take out the
battery and re-install it.
Speedometer Sensor & Magnet
Attach the speedometer sensor bracket to the left fork blade,
using the shims to adjust the diameter, and using the cable
ties (show be w) to tie it withe the fork. Position the sensor lo
and magnet as shows, make sure that the arc of the magnet
intersects the alignment mark on the sensor with 1mm
clearance.
Mounting Shoe
Attach the mounting shoe with the cable
ties to the handlebar, adjust the
mounting shoe on the handlebar with the
shims to hold its position. two type of （
mounting shoes for choices）
Sensor Wiring
Route the sensor wire up the fork
blade, using cable ties to secure it at
the bottom and crown to a d it voi
hinder the movement of the fr t on
wheel.
Computer
Attach the computer to the mounting shoe by s ding the unit li
until it snaps firmly into its position. To remove it, press the
button on it in the opposite direction.
To check for proper speed function and sensor alignment,
spin the front wheel with computer in speed mode. Adjust
the position of the sensor and the magnet when there is no or
weak reaction.
Wheel size input
‘2060’ appears on the screen when the battery has been
installed, and w h one figure flashing, ch se the correct it oo
wheel corcumference from the form below. Press RIGHT
button to advance digits as needed and LEFT button to
confirm and advance to next digit setting. (the circumference
ranges 0mm~ 99mm), press LEFT button to enter into 99
km/m mode.
Tire size CIRC Tire size CIRC
700c x 38mm 2180 26” x 2.25” 2115
700c x 35mm 2168 26” x 2.1” 2095
700c x 32mm 2155 26” x 2.0” 2074
700c x 30mm 2145 26” x 1.9”/1.95” 2055
700c x 28mm 2136 26” x 1.75” 2035
700c x 25mm 2124 26” x 1.5” 1985
700c x 23mm 2105 26” x 1.25” 1953
700c x 20mm 2074 26” x 1.0” 1913
700c Tubulari 2130 24” x 1.9”/1.95” 1916
650c x 23mm 1990 20” x 1-1/4” 1618
650c x 20mm 1945 16” x 2.0” 1253
27” x 1-1/4” 2161 16” x 1.95” 1257
27” x 1-1/8” 2155 16” x 1.5” 1206
26” x 2.3” 2135
Se ing KM/Mile tt
Press the RIGHT button to choose km/h or
m/h. Press the LEFT button to enter into
ride’s weight setting.
Se ing Rider’s weight tt
The default weight is 65kg, press the RIGHT button to
adjust the flashing weight number according to rider’s
weight, press LEFT button to confirm and advance. Weight
ranges : 20~150kg. Press the LEFT bu on to enter into tt
Maintenance Alert setting.
Se ing Maintenance Alert tt
There with the default Maintenance Alert
digit 200km/m flashing, Press the RIGHT
button to choose 20 400/6 /8000/ 00 （ ）km/m .
Press the LEFT button to confirm and enter into Clock mode.
(When the > the Maintenance Alert digit you setted, the ODO
will appear on the screen to alert the rider, press the
LEFT button to cancel it.)
C LK (12H/24H)
In Clock mode, press the LEFT button
for 3 seconds to enter into 1 /24h 2h
selection. Press the LEFT button for
exchanging. Press the RIGHT button to
confirm and with Hour digit flashing,
press the Left button to adjust Hour, press the RIGHT button
to confirm and with Minute di t flashing, press the LEFT gi
button to adjust Minute, press the RIGHT button to finish and
enter into O mode. OD
Se ing the Last Value of Odometer tt
In O mode, press the LEFT button for 2 sec ds with one OD on
digit flashing to setting O value, the OD
initial value is 0000.0km(m), press the
RIGHT button to adjust the digit, press
LEFT button to confirm and
advance.(after re-install the battery, the lastest O value OD
which is before battery re-installed can be inputted).
Reset of Mileage Parameter
In any mode, press b h two buttons simultaneously for 3 ot
seconds to clear the tyre circumference and other records, the
user need to reset the tyre circumference, km/m, the ODO
and CLK will remain.
Speedometer
When riding, speed is shown all the time on the screen, it
ranges : 0~99.9km(m), it is accurate to +/- 0.1km(m).
Comparator
When riding, or display on the screen, indicates the
current speed is higher than average speed, and indicates
the current speed is wer than average speed. lo
Odometer
In O mode, the total distance is OD
indicated on the screen, its mileage
range is 0.001~ 999km(m). The 99
display will be back to 0 when the value
of it exceeds its maximum limit. Press the RIGHT button to
enter DST mode.
Trip Distance
In DST mode, the trip distance for one
trip is indicated on the screen, this
distance is start calculate when DST be
cleared to 0. It ranges: 0~9999km(m),
when exceed the range limit, it will restart from 0
automatically. In DST mode, press LEFT button for 5
seconds to clear the DST, MXS, AVS, TM records. Press the
RIGHT button to enter into MXS mode.
Maximum Speed
In MXS mode, Maximum speed for one
trip is indicated on the
screen. Press the LEFT button for 5
seconds to clear the MXS,
DST, AVS, TM records. Press the RIGHT button to enter into
AVS mode.
Average Speed
In AVS mode, the average speed for one
trip is indicated on the screen. Press the
LEFT button for 5 sec ds to clear the on
AVS, DST, MXS, TM records. Press the
RIGHT button to enter Into TM mode.
Time
In TM mode, the trip time for one trip is
indicated on the screen. TM ranges :
0 :00 :00~9 9 :59, restart from :5
0 :00 :00 when it exceed the range limit. In TM mode, press
the LEFT button for 5 seconds to clear the TM, DST, MXS,
AVS records. Press the RIGHT button to enter into TMP
mode.
TMP (Temperature) MIN（ ）（ ）MAX
In TMP mode, the current outdoor
temperature is indicated on the screen.
Minimum Temperature(MIN TMP)
Maximum Temperature(MAX TMP)
The default display for RPM is , press the LEFT butoon for ℃
3seconds, ℃ is flahing, press the RIGHT button to
exchange ℉/℃,p ress the LEFT button to confirm. TMP
ranges : -10~70 ( ), it is accurate to +/-0.1 . In TMP ℃ ℃
mode, press the LEFT button for 5 seconds to clear TMP
MIN MAX, DST, MXS, AVS. Press the RIGHT button to
enter into CAL mode.
CAL (calory)
In CAL mode, the total heat energy the rider
consumed calculates from the last restoration
of the computer is indicated on the screen. It
ranges: 0~99999Kcal. Press the RIGHT button
to enter into FAT mode.
FAT
In FAT mode, the total FAT the rider
consumed calculates from the last restoration
of the computer is indicated on the screen. It
ranges: 0~9999.9kg. Press the RIGHT button
to enter into Scan mode.
SCAN
In SCAN mode, the DST, MXS, AVS, TM are
indicated in turn every 4 seconds. Press the
RIGHT button to enter into CLK mode.
Menu Hide Function
In any mode except CLK mode, press the RIGHT button for
5 seconds, the computer is going to Menu hide mode, it
hides MIN RPM, MAX RPM, CAL & FAT, which will not
be indicated on the screen but still running without effect.
Also in any mode except CLK mode, press the RIGHT
button for 5 seconds again, these functions are resumed.
Sleep Mode
If no signal has been inputted for 300 seconds, computer
will enter into Sleep mode, CLK remains. It will turn back to
the former mode with all the data collected when any signal
is inputted or any button is pressed.
Freeze Frame Memory
In any mode, press the LEFT button to enter into Freeze
Frame memory mode, flashing TM data will appear on the
screen, press the RIGHT button to view the records of DST,
TM, AVS and MXS. Press the LEFT button to end it.
Malfunctions & Problems
Accessories
Malfunctions problems
No speedometer Improper magnet/sensor alignment
Inaccurate value is
indicated
Improper input, such as wheel
circumference.
Slow display response Temperature exceeds operating
limits (0℃~55℃)
Black display Too long time in sunlight, should
take back to shade for a period.
Weak display Poor battery or dead battery
Displays irregular
figures
Take battery out and reinstall it after
10 seconds.
