Bicycle computer
SD-546C (24Functions)
FUNCTIONS
- AUTO WAKE UP (SD-546C1)
MANUAL WAKE UP(SD-546C2)
- SPD CURRENT SPEED
- ODO ODOMETER 0.00（１～99999km/m)
- DST TRIP DISTANCE
- MXS MAXIMUM SPEED
- AVS AVERAGE SPEED
- TM ELAPSED TIME .
- CLK CLOCK 12H/24H（ ）
- TMP TEMPERTERATURE(-10 70 )℃～℃
- MIN RPM
- MAX RPM
- SCAN
- “+” “ ” COMPAPATOR－
- CAL CALORIE(0 99999Kcal)～
- FAT (0 9999.9kg)～
- SETTING SPEED SCALE km/h,m/h（ ）
- SETTING TYRE CIRCUMFERENCE : 0mm（ ～
9999mm）
- SETTING THE LAST VALUE OF ODOMETER/ODO
- SETTING RIDER’S WEIGHT
- FREEZE FRAME MEMORY
- MAINTENANCE ALERT
- “ ”LOW POWER REMINDING
- BACK LIGHT
- AUTO ON/OFF
Computer Battery Installation
Remove the battery cover from the bottom of the computer by
using a flat blade screwdriver, install one CR2032 battery with
the positive (+) pole facing the battery cover and replace the
cover. Should the LCD show irregular figures, take out the
battery and reinstall it.
Sensor Transmitter Battery Installation
Remove the battery cover from the
bottom of the computer by using a
flat blade screwdriver, install one
23A 12V battery with the positive
(+) pole facing the battery cover
and replace the cover. Should the
LCD show irregular figures, take
out the battery and re-install it.
Sensor Transmitter
Attach the sensor transmitter to the left fork blade, the distance
between computer and the sensor can not exceed 60cm, the
closer the better. Using the shims to adjust the diameter, and
using the cable ties(show below) to tie it with the fork.
Position the sensor transmitter and magnet as shows, make
sure that the arc of the magnet intersects the alignment mark
on the sensor transmitter with 1mm clearance.
Mounting Shoe
Attach the mounting shoe with the cable
ties to the handlebar, adjust the mounting
shoe on the handlebar with the shims to
hold its position.
Sensor Wiring
Route the sensor wire up the fork blade,
using cable ties to secure it at the bottom and crown to avoid it
hinder the movement of the front wheel.
Computer
Attach the computer to the mounting shoe by sliding the unit
until it snaps firmly into its postion. To remove it, press the
button on it in the opposite direction.
To check for proper speed function and sensor alignment, spin
the front wheel with computer in speed mode. Adjust the
position of sensor and magnet when there is no or weak
reaction.
Wheel Size Input
‘2060’ appears on the screen when the battery has been
installed, with one figure flashing,choose the correct wheel
circumference from the table below.Press RIGHT button to
advance digits as needed and LEFT button to confirm and
advance. (The circumference ranges 0mｍ～9999mm), press
LEFT button to enter KM/M mode.
TIRE SIZE TIRE SIZECIRC CIRC
700c x 38mm 2180 26’’ x 2.25’’ 2115
700c x 35mm 2168 26’’ x 2.1’’ 2095
700c x 32mm 2155 26’’ x 2.0’’ 2074
700c x 30mm 2145 26’’ x
1.9’’/1.95’’ 2055
700c x 28mm 2136 26’’ x 1.75’’ 2035
700c x 25mm 2124 26’’ x 1.5’’ 1985
700c x 23mm 2105 26’’ x 1.25’’ 1953
700c x 20mm 2074 26’’ x 1.0’’ 1913
700cTubulari 2130 24’’ x
1.9’’/1.95’’ 1916
650c x 23mm 1990 20’’ x 1-1/4’’ 1618
650c x 20mm 1945 16’’ x 2.0’’ 1253
27’’ x 1-1/4’’ 2161 16’’ x 1.95’’ 1257
27’’ x 1-1/8’’ 2155 16’’ x 1.5’’ 1206
26’’ x 2.3’’ 2135
Setting（km/h / m/h） （ ）
Press the RIGHT button to choose km/h
or m/h. Press the LEFT button to enter
CLOCK mode.
Setting Rider’s Weight
The default weight is 65kg, press the RIGHT button to adjust
the flashing weight number according to rider’s weight, press
LEFT button to confirm and advance. Weight ranges :
20~150kg. Press the LEFT button to enter into Maintenance
Alert setting.
Setting Maintenance Alert
While the default Maintenance Alert digit
200km/m
is flashing, Press the RIGHT button to choose
200/400/600/800 km/m. Press the LEFT button to confirm（
and enter into Clock mode.(When the ODO>the Maintenance
Alert digit you set, the will appear on the screen to
alert the rider, press the LEFT button to cancel it.)
CLK Mode(12H/24H)
In CLOCK Mode, press the LEFT button for
3 seconds to enter 12/24H selection.
Re-press the LEFT button for 12/24
exchanging. Press the RIGHT button to
enter Hour setting mode, when the figure
indicating HOUR start to flash, press the LEFT button to
adjust it.
the LEFT bu Continue to press the RIGHT button to enter
Minute setting mode, when the figure indicating MINUTE
start to flash, press tton to adjust it and RIGHT button to
confirm, press the RIGHT button again to
ODO mode.
Setting the Last Value of Odometer
In ODO mode, press the LEFT button for
2 seconds to set the ODO value, its
initial value is 0000.0. when one figure flashing, press
RIGHT button to adjust it and LEFT button to confirm
it and start to set the next figure.(after re-install the
battery, latest value can be inputted according to the
value exists before the battery is re-installed).
Reset of Mileage Parameter
In ODO mode, press and hold both RIGHT and LEFT button
simultaneously for 3 seconds to clear the tire circuference and
(km/m) setting, The user need to reset the tire circumference
and (km/m), the original ODO value and CLOCK will remain
unaffected.
Speedometer
Speed is shown all the time on the screen, its maximum
reading is 99.9km/h(m/h), and it’s accurate to +/- 0.1km/h
(m/h).
Speed Comparator
During riding , ¡ø and ¨‹ will dispaly on the
screen , ¡ø indicates the current speed is higher than average
speed. ¨‹ indicates the current speed is
lower than average speed.
Odometer
In ODO mode , the total distance is
indicated on the screen, its mileage range is
0.00１～99999km(m). the display will be back to 0 when value
exceeds its maximum limit, press the RIGHT button to enter
DST mode..
Trip Distance (DST)
In DST mode, the distance for one trip is
indicated on the bottom line. DST ranges
from 0.001 9999km(m), when the value～
exceed the range limit, it restarts from 0
automatically. Both the time and the distance records will be
cleared when the time of one trip exceed the range limits.
press the LEFT button for 5 seconds to clear the records of
DST,MXS,AVS and TM.
Press the RIGHT button to enter MXS mode.
Maximum Speed (MXS)
In MXS mode, maximum speed is
indicated on the bottom line. Press the
LEFT button for 5 seconds to clear the
records of MXS,DST,AVS and TM.
Press the RIGHT button to enter AVS mode.
Average Speed
In AVS mode, average speed is indicated
on the bottom line. Press the LEFT button
for 5 seconds to clear the records of
AVS,DST,MXS and TM.
Press RIGHT button to enter TM mode.
Trip Time
In TM mode, trip time is indicated on the
bottom line.TM ranges 0 :00 :00 ～
99 :59 :59. It will be back to 0 when
value exceed the limits.
Press the LEFT button for 5 seconds to clear the records of
TM, DST,MXS and AVS.
Press the RIGHT button to enter SCAN
mode.
Temperature(RPM)(MIN)(MAX)
In RPM mode, the current outdoor
temperature is indicated on the screen.
Minimum Temperature(MIN RPM)
Maximum Temperature(MAX RPM)
flahing, press the RIGHT button to
confirm. RPM ranges : -
accurate to +/-
the LEFT button for 5 seconds to clear RPM MIN MAX, DST,
MXS, AVS. Press the RIGHT button to enter into CAL mode.
CAL (Calory)
In CAL mode, the total heat energy the rider consumed is
calculated from the last restoration of the computer is
indicated on the screen. It ranges: 0~99999Kcal. Press the
RIGHT buttonto enter into FAT mode.
FAT
In FAT mode, the total FAT the
riderconsumed is calculated from the last
restoration of the computer is indicated
on the screen. It ranges: 0~9999.9kg.
Press the RIGHT button to enter into
Scan mode.
SCAN
In Scan mode , DST, MXS, AVS and TM
mode are indicated in turn every 4
seconds.Press the RIGHT button to enter CLOCK Mode.
Menu Hide Function
In any mode except CLK mode, press the RIGHT button for5
seconds, the computer is going to Menu hide mode, ithides
MIN RPM, MAX RPM, CAL & FAT, which will notbe
indicated on the screen but still running without effect.Also in
any mode except CLK mode, press the RIGHTbutton for 5
seconds again, these functions are resumed.
Sleep Mode
If no signal has been inputted for 300 seconds, computer will
enter into Sleep Mode, and CLK value remains. It will turn
back to the former mode with all the data collected when any
signal is inputted or any button is pressed.
Freeze Frame Memory
Press the LEFT button in any time will enter into freeze frame
memory mode. Flashing TM data will appear on the screen.
Press the RIGHT button to view the records of DST, MXS,
AVS and TM.
Press the LEFT button to end it
Back Light
The back light function is switched on or off when you press
any button during PM:18 00 8 00. It will not work at any： ～ ：
other time.
Low Power Reminding
When the battery is low power, the symbol “ ”will be
shining, which reminds the rider to change into a new battery.
Malfunctions and Problems
Malfunctions Problems
No speedometer
Improper magnet/sensor alignment
Distance between computer and
sensor transmitter exceed 60cm
Low battery voltage of sensor
transmitter or computer.
Short distance of
the transmitter or
no receiving
Lower battery voltage, need to change
for a new one.
Display
Abnormal
figures
Too much Electromagnetic
interference around
Inaccurate value
is indicated Improper input, such as wheel
circumference.
Slow display
respons
Temperature exceeds operating
limits(0 55 ).℃～℃
Black display
Temperature too high, or put in direct
sunlight for too long time. Need take
back to shadow place for a period.
Weak display Poor battery contact or dead battery
Display shows
irregular figures
Take out battery and re-install it after
10 seconds.
Sensor without
reaction Put off the insulation film of the
sensor transmitter
Accessories
Create PDF with GO2PDF for free, if you wish to remove this line, click here to buy Virtual PDF Printer
Produkt Specifikationer
| Mærke: | Sunding |
| Kategori: | Cykel computer |
| Model: | SD-546C |
Har du brug for hjælp?
Hvis du har brug for hjælp til Sunding SD-546C stil et spørgsmål nedenfor, og andre brugere vil svare dig
Cykel computer Sunding Manualer
21 August 2024
20 August 2024
20 August 2024
20 August 2024
20 August 2024
20 August 2024
19 August 2024
19 August 2024
19 August 2024
19 August 2024
Cykel computer Manualer
- Cykel computer Bosch
- Cykel computer Pioneer
- Cykel computer Garmin
- Cykel computer Polar
- Cykel computer Crivit
- Cykel computer Mio
- Cykel computer Navman
- Cykel computer Rawlink
- Cykel computer Batavus
- Cykel computer Bell
- Cykel computer Sigma
- Cykel computer Trelock
- Cykel computer BBB
- Cykel computer Bontrager
- Cykel computer Bryton
- Cykel computer BTwin
- Cykel computer Cateye
- Cykel computer CicloSport
- Cykel computer Contec
- Cykel computer Echowell
- Cykel computer Mavic
- Cykel computer Pro
- Cykel computer VDO
- Cykel computer Vetta
- Cykel computer Timex
- Cykel computer Vogue
- Cykel computer Wahoo Fitness
- Cykel computer Shimano
- Cykel computer Hema
- Cykel computer Lezyne
- Cykel computer Asaklitt
- Cykel computer Trek
- Cykel computer IGPSport
- Cykel computer Magene
- Cykel computer Oregon Scientific
- Cykel computer Ascot
- Cykel computer Prophete
- Cykel computer Ciclo
- Cykel computer Kogan
- Cykel computer Kayoba
- Cykel computer Knog
- Cykel computer Maxxus
- Cykel computer Union
- Cykel computer QT Cycle Tech
- Cykel computer Ascent
- Cykel computer Filzer
- Cykel computer Conrad
- Cykel computer Halfords
- Cykel computer XLC
- Cykel computer Assize
- Cykel computer Stella
- Cykel computer Cannondale
- Cykel computer Powertap
- Cykel computer Bikemate
- Cykel computer VDO Dayton
- Cykel computer Key Disp
- Cykel computer SmartHalo
- Cykel computer Sigma Sport
- Cykel computer BBB Cycling
- Cykel computer Osynce
- Cykel computer MCP
- Cykel computer Cube
- Cykel computer Stamm
- Cykel computer Dresco
- Cykel computer Bafang
- Cykel computer Silent Force
- Cykel computer Cordo
- Cykel computer Falk Outdoor
- Cykel computer Matrabike
- Cykel computer Speedmaster
- Cykel computer Wahoo
- Cykel computer Decathlon
- Cykel computer Axiom
- Cykel computer Kellys
- Cykel computer Filmer
- Cykel computer Walfort
- Cykel computer Stels
- Cykel computer Stages Cycling
Nyeste Cykel computer Manualer
12 Oktober 2024
3 Oktober 2024
2 Oktober 2024
2 Oktober 2024
30 September 2024
29 September 2024
23 September 2024
23 September 2024
23 September 2024
19 September 2024
