Sunding Bicycle Computer
Sd-565A
FUNCTIONS
- SPD CURRENT SPEED
- ODO ODOMETER（0-99999 km/m）
-
DST TRIP DISTANCE
- MXS MAXIMUM SPEED
- AVS AVERAGE SPEED
- TM ELAPSED TIME
- CLK CLOCK 12H/24H （ ）
- RPM TEMPERATURE (-10 ~70 ℃ ℃)
- MIN RPM MINIMUM TEMPERATURE
- MAX RPM MAXIMUM TEMPERATURE
- SCAN
- COMPARATOR
- CAL Calory （0~99999Kcal ）
- FAT (0~9999.9kg)
- SETTING SPEED SCALE km.m （ ）
- SETTING TYRE CIRCUMFERENCE 0mm （ ～
9999mm ）
- SETTIN THE LAST VALUE OF ODOMETER / ODO
（ ）km/m
- SETTING RIDER’S WEIGHT
- FREEZE FRAME MEMORY
- MAINTENANCE ALERT
- AUTO ON/OFF
- P (CURRENT / MAXIMUM / AVERAGE) HEART
RATE / MINUTE
Battery Installation
Remove the battery cover by using a flat blade screwdriver,
install a CR2032 battery with the (+) pole facing the battery
cover and replace the cover.
Speedometer Sensor & Magnet
Attach the speedometer sensor bracket to the left fork blade,
using the shims to adjust the diameter, and using the cable ties
(show below) to tie it withe the fork. Position the sensor and
magnet as shows, make sure that the arc of the magnet
intersects the alignment mark on the sensor with 1mm
clearance.。
Mounting Shoe
Attach the mounting shoe with the cable
ties to the handlebar, adjust the
mounting shoe on the handlebar with the
shims to hold its position.
Sensor Wiring
Route the sensor wire up the fork blade, using cable ties to
secure it at the bottom and crown to avoid it hinder the
movement of the front wheel.
Computer
Attach the computer to the mounting
shoe by sliding the unit until it snaps
firmly into its position. To remove it,
press the button on it in the opposite
direction.
To check for proper speed function
and sensor alignment,
spin the front wheel with computer in speed mode. Adjust the
position of the sensor and the magnet when there is no or weak
reaction.
Wheel Size Input
‘2060’ appears on the screen when the battery has been
installed, and with one figure flashing, choose the correct
wheel corcumference from the form below. Press RIGHT
button to advance digits as needed and LEFT button to confirm
and advance to next digit setting. (the circumference ranges
0mm~9999mm), press LEFT button to enter into km/m mode.
Tire size CIRC
Tire size CIRC
700c x 38mm 2180 26” x 2.25” 2115
700c x 35mm 2168 26” x 2.1” 2095
700c x 32mm 2155 26” x 2.0” 2074
700c x 30mm 2145 26” x 1.9”/1.95”
2055
700c x 28mm 2136 26” x 1.75” 2035
700c x 25mm 2124 26” x 1.5” 1985
700c x 23mm 2105 26” x 1.25” 1953
700c x 20mm 2074 26” x 1.0” 1913
700c Tubulari 2130 24” x 1.9”/1.95”
1916
650c x 23mm 1990 20” x 1-1/4” 1618
650c x 20mm 1945 16” x 2.0” 1253
27” x 1-1/4” 2161 16” x 1.95” 1257
27” x 1-1/8” 2155 16” x 1.5”
1206
26” x 2.3” 2135
Setting KM/Mile
Press the RIGHT button to choose km/h or m/h.
Press the LEFT button to enter into ride’s weight
setting.
Setting Rider’s Weight
The default weight is 65kg, press the RIGHT button to adjust
the flashing weight number according to rider’s
weight, press LEFT button to confirm and
advance. Weight ranges : 20~150kg. Press the
LEFT button to enter into Maintenance Alert
setting.
Setting Maintenance Alert
There with the default Maintenance Alert digit 200km/m
flashing, Press the RIGHT button to choose
200/400/600/800 km/m . Press the LEFT （ ）
button to confirm and enter into Clock mode.
(When the ODO> the Maintenance Alert digit
you setted, the will appear on the screen to alert the
rider, press the LEFT button to cancel it.)
CLK (12H/24H)
In Clock mode, press the LEFT button for 3
seconds to enter into 12h/24h selection. Press
the LEFT button for exchanging. Press the
RIGHT button to confirm and with Hour digit flashing, press
the Left button to adjust Hour, press the RIGHT button to
confirm and with Minute digit flashing, press the LEFT button
to adjust Minute, press the RIGHT button to finish and enter
into ODO mode.
Setting the Last Value of Odometer
In ODO mode, press the LEFT button for 2
seconds with one digit flashing to setting ODO
value, the initial value is 0000.0km(m), press
the RIGHT button to adjust the digit, press
LEFT button to confirm and advance.(after
re-install the battery, the lastest ODO value which is before
battery re-installed can be inputted).
Reset of Mileage Parameter
In any mode, press both two buttons simultaneously for 3
seconds to clear the tyre circumference and other records, the
user need to reset the tyre circumference, km/m, the ODO and
CLK will remain.
Speed
When riding, speed is shown all the time on the screen, it
ranges : 0~99.9km(m), it is accurate to +/- 0.1km(m).
Comparator
When riding, or display on the screen, indicates the
current speed is higher than average speed, and indicates
the current speed is lower than average speed.
Odometer
In ODO mode, the total distance is indicated
on the screen, its mileage range is
0.001~99999km(m). The display will be back
to 0 when the value of it exceeds its maximum limit. Press the
RIGHT button to enter DST mode.
DST (Trip distance)
In DST mode, the trip distance for one trip is indicated on the
screen, this distance is start calculate when DST be cleared to 0.
It ranges: 0~9999km(m), when exceed the range limit, it will
restart from 0 automatically. In DST mode, press LEFT button
for 5 seconds to clear the DST, MXS, AVS, TM records. Press
the RIGHT button to enter into MXS mode.
MXS (Maximum speed)
In MXS mode, Maximum speed for one trip is indicated on the
screen. Press the LEFT button for 5 seconds to clear the MXS,
DST, AVS, TM records. Press the RIGHT button to enter into
AVS mode.
AVS (Average speed)
In AVS mode, the average speed for one trip is indicated on the
screen. Press the LEFT button for 5 seconds to clear the AVS,
DST, MXS, TM records. Press the RIGHT button to enter into
TM mode.
TM
In TM mode, the trip time for one trip is indicated on the
screen. TM ranges : 0 :00 :00~9 :59 :59, restart from 0 :00 :00
when it exceed the range limit. In TM mode, press the LEFT
button for 5 seconds to clear the TM, DST, MXS, AVS records.
Press the RIGHT button to enter into RPM mode.
RPM (Temperature)（
（（
（ ）（MIN）（）（
）（ ）MAX））
）
In RPM mode, the current outdoor temperature is indicated on
the screen.
Minimum Temperature(MIN RPM)
Maximum Temperature(MAX RPM)
The default display for RPM is , press the ℃
LEFT butoon for
3seconds, is flahing, press the RIGHT ℃
button to exchange
℉/ ℃,press the LEFT button to confirm. RPM ranges :
-10~70 ( ), it is accurate to +/-0.1℃ ℃ . In RPM mode, press the
LEFT button for 5 seconds to clear RPM MIN MAX, DST,
MXS, AVS. Press the RIGHT button to enter into CAL mode.
CAL (Calory)
In CAL mode, the total heat energy the rider
consumed calculates from the last restoration
of the computer is indicated on the screen. It
ranges: 0~99999Kcal. Press the RIGHT
button to enter into FAT mode.
FAT
In FAT mode, the total FAT the rider
consumed calculates from the last
restoration of the computer is indicated on
the screen. It ranges: 0~9999.9kg. Press the
RIGHT button to enter into Scan mode.
SCAN
In SCAN mode, the DST, MXS, AVS, TM
are indicated in turn every 4 seconds. Press
the RIGHT button to enter into CLK mode.
Menu Hide Function
In any mode except CLK mode, press the RIGHT button for 5
Seconds, the computer is going to Menu hide mode, it hides
MIN RPM, MAX RPM, CAL & FAT, which will not be
indicated on the screen but still running without effect. Also in
any mode except CLK mode, press the RIGHT button for 5
seconds again, these functions are resumed.
Sleep Mode
If no signal has been inputted for 300 seconds, computer will
enter into Sleep mode, CLK remains. It will turn back to the
former mode with all the data collected when any signal is
inputted or any button is pressed.
Freeze Frame Memory
In any mode, press the LEFT button to enter into Freeze frame
memory mode, flashing TM data will appear on the screen,
press the RIGHT button to view the records of DST, TM,
AVS and MXS. Press the LEFT button to end it.
Heart Rate Function
* P current heart rate times/minute （ ）
* AVS average heart rate （ ）times/minute
* MAX Maximum heart rate (times/minute)
Accessories
Heart Rate Elastic manual
*
Remove the battery cover, install a CR2032 battery with the
(+) pole facing the cover, and replace the cover.
*
Install the buckle of the elastic
*
Tie the elastic to the rider(show below),with the battery
cover side touch the skin.
Attention
1, wireless transfer heart rate with the frequency of 5.3KHz
2, the heart rate conductor should be approach the heart
position, close to the skin, should without cloth or any other
object between the skin and the conductor.
3, with dry or cold weather, it is possible that the conductor not
transfer signal well, it will get steady after minutes. The user
also can spill drops of clean water to wet the conductor for
soon signal transferring.
Malfunctions and Problems
Malfunctions problems
No speedometer Improper magnet/sensor alignment
Inaccurate value is
indicated Improper input, such as wheel
circumference.
Slow display response Temperature exceeds operating
limits ( ~50℃ 5℃)
Black display Too long time in sunlight, should
take back to shade for a period.
Weak display Poor battery or dead battery
Displays irregular
figures Take battery out and reinstall it after
10 seconds.
