BICYCLE COMPUTER
SUNDING -568
（
（
（
（（SD ）
）
）
））
（
（
（
（（21Functions
）
）
）
））
FUNCTIONS
- SPD CURRENT SPEED
- ODO ODOMETER 0.001 99999km/m) （ ～
- DST TRIP DISTANCE
- MXS MAXIMUM SPEED
- AVS AVERAGE SPEED
- TM ELAPSED TIME .
- CLK CLOCK 12H/24H （ ）
- PRM TEMPERATURE - ~70 （10℃ ℃）
- MIN PRM
- X PRM MA
- CAL 0 99999Kcal （ ～ ）
- FAT 0 9999.9kg （ ～ ）
- SCAN
- + COMPARATOR “ ” “ ”－
- SETTING SPEED SCALE km/h,m/h （ ）
- SETTING TYRE CIRCUMFERENCE : 0mm 9999mm （ ～ ）
- SETTING THE LAST VALUE OF ODOMETER/ODO
- FREEZE FRAME MEMORY
- SETTING THE RIDER S WEIGHT ’
- MAINTENANCE ALERT
- AUTO ON/OFF
Computer Battery Installation
Remove the battery cover from the bottom of the computer by using a
flat blade screwdriver, install one CR2032 battery with the positive
(+)pole facing the battery cover and replace the cover. Should the LCD
show irregular figures, take out the battery and reinstall it.
Speedometer Sensor&magnet
Attach the speedometer sensor bracket to the left fork blade, using the
shims to adjust the diameter, and using the cable ties (as shown below)
to tie it with the fork. Position the sensor and magnet as show; make sure
that the arc of the magnet intersects the alignment mark on the sensor
with 1mm clearance.
Mounting Shoe
Attach the mounting shoe with the cable ties to the handlebar, adjust the
mounting shoe the handlebar with the shims to hold its position. on
(three type of mounting shoes for choices )
Sensor Wiring
Route the sensor wire up the fork blade, using cable
ties to secure it at the bottom and crown to avoid it
hinder the movement of the front wheel.
Computer
Attach the computer to the mounting
shoe by sliding the unit until it snaps
firmly into its postion. To remove it,
press the button on it in the opposite
direction.
To check f proper speed function and or
sensor alignment, spin the front wheel
with computer in speed mode. Adjust the
position of sensor and magnet there is if
no or weak reacti .on
Wheel Size Input
‘ ’2060 appears on the screen when the battery has been installed, with
one figure flashing, choose the correct wheel circumference from the
table below. Press RIGHT button to advance digits as needed and LEFT
button to confirm and advance.
(The circumference ranges 0mm 9999mm),press LEFT button to ～
enter KM/M mode
Setting KM/mile
Press the RIGHT button to choose km/h or m/h. Press the LEFT button
to enter into ride’s weight setting.
Setting rider’s weight
The default weight is 65kg, press the RIGHT
button to adjust the flashing weight number according to rider’s weight,
press LEFT button to confirm and advance. Weight ranges : 20~150kg.
Press the LEFT button to enter into Maintenance Alert setting.
Setting maintenance alert
While the default Maintenance Alert digit
200km/m is flashing, Press the RIGHT button
to choose 200/400/600/800 km/m ）
（Press the LEFT button to confirm and enter
into Clock mode.(When the ODO>the
Maintenance Alert digit you setted the ,
will appear on the screen to alert the rider, press the LEFT button to
cancel it.)
C Mode(12H/24H) LK
In Clock mode, press the LEFT button
for 3 seconds to enter into 12h/24h
selection.Press the RIGHT button until Hour
digit flashes,thenpress the LEFT button to
adjust Hour .Press the RIGHT button
, until Minute digit flashes, then press the LEFT
button to adjust Minute .Press the RIGHT button twice to finish and
enter into ODO mode.
Setting the Last value of Odometer
In ODO mode, press th e LEFT for 2 button
seco nds set the ODO val ue, its init ial to
value is 0000.0 . when one figure flashing,
press RIGHT but ton to adjust and LEFT it
butt on t o con fir m it, and start to set the next
fi gure.(a fter re- install the battery, lat est
value can be inp ut ted accordin g to the value exist s before th e
battery -instal led). is re
Reset of Mileage Parameter
In ODO mode, s and hold both RIGHT and LEFT button Pres
simultaneously for 3 seconds to clear the circumference value and cancel
(km/m) & Maintenance Alert setting. The user need to reset the tyre
circumference, (km/m) & Maintenance Alert the original ODO value ,
and CLOCK will remain unaffected.
Speedometer
When riding speed is shown all the time on the screen, ranges - it :0
99.9km/h(m and accurate to - 0.1km/h (m/h). /h), it is +/
Speed Comparator
During riding , and will dispaly on the screen , indicates the ▲ ▼ ▲
current speed is higher than average speed indicates the current speed . ▼
is lower than average speed.
Odometer
In ODO mode , the total distance is indicated on
the screen, its mileage ranges : 0.001 ～
99999km(m). The display will be back to 0
when value exceeds its maximum limit, press
the RIGHT button to enter DST mode.
Trip Distance (DST)
In DST mode, the distance for one trip is
indicated on the screen This distance is start to .
be calculated when DST becleared to 0. It
ranges: 0~9999km(m), when exceed the range
limit, it will restart from 0 automatically. In
DST mode, press LEFT button for 5 seconds to clear the DST, MXS,
AVS, TM records. Press the RIGHT button to enter into MXS mode.
Maximum Speed (MXS)
In MXS mode, maximum speed indicated on is
the bottom line. Press the LEFT button for 5
seconds to clear the records MXS,DST,AVS of
and TM. Press the RIGHT button to enter AVS
mode.
Average Speed
In AVS mode, the average speed for one
trip is indicated on the screen. Press the
LEFT button for 5 seconds to clear the
AVS, DST, MXS, TM records. Press the
RIGHT button to enter Into TM mode.
Trip Time
In TM mode, the trip time for one trip is
indicated on the screen. TM ranges :
0 :00 :00~9 :59 :59,restartfrom0 :00 :00 when it
exceed the range limit. In TM mode, press the
LEFT button for 5 seconds to clear the TM, DST,
MXS, AVS records. Press the RIGHT button to enter into RPM mode.
Temperature (PRM)
In RPM mode, the current outdoor
temperature is indicated on the screen.
Minimum Temperature(MIN RPM)
Maximum Temperature(MAX RPM)
The default display for RPM is , press the ℃
LEFT butoon for 3seconds, is flahing, press the RIGHT button to ℃
exchange / ,press the LEFT button to confirm. RPM ranges : -10~70 ℉ ℃
( ), it is accurate to +/-0.1 . In RPM mode, press the LEFT button for ℃ ℃
5 seconds to clear RPM MIN MAX, DST, MXS, AVS. Press the RIGHT
button to enter into CAL mode.
CAL (Calory)
In CAL mode, the total heat energy the rider consumed is calculated
from the last restoration of the computer is indicated on the screen. It
ranges: 0~99999Kcal. Press the RIGHT buttonto enter into FAT mode.
FAT
In FAT mode, the total FAT the rider
consumed is calculated from the last restoration of
the computer is indicated on the screen. It ranges:
0~9999.9kg. Press the RIGHT button to enter into
Scan mode.
SCAN
In SCAN mode, the DST, MXS, AVS, TM are
indicated in turn every 4 seconds. Press the
RIGHT button to enter into CLK mode.
Menu Hide Function
In any mode except CLK mode, press the RIGHT button for
5 seconds, the computer is going to Menu hide mode, it
hides MIN RPM, MAX RPM, CAL & FAT, which will not
be indicated on the screen but still running without effect.
Also in any mode except CLK mode, press the RIGHT
button for 5 seconds again, these functions are resumed.
Sleep Mode
If no signal has been inputted for 300 seconds, computer
will enter into Sleep mode, CLK remains. It will turn back to
the former mode with all the data collected when any signal
is inputted or any button is pressed.
FREEZE FRAME MEMORY
In any mode, press the LEFT button to enter into Freeze
Frame memory mode, flashing TM data will appear on the
screen, press the RIGHT button to view the records of DST,
TM, AVS and MXS. Press the LEFT button to end it.
Malfunctions and Problems
Malfunctions
Problems
No speedometer
Improper magnet/sensor alignment
Inaccurate value is
indicated
Improper input, such as wheel
circumference.
Slow display
response
Temperature exceeds operating
limits(0 ). ℃～55℃
Black display
Temperature too high, or put in direct
sunlight for too long time. Need back to
shadow place for a period.
Weak display
Poor battery contact or dead battery.
Display shows
Irregular figures
Take out battery and reinstall it after 10
seconds.
Accessories
TIRE SIZE
CIRC
TIRE SIZE
CIRC
700c x 38mm
2180
26’’ x 2.25 ’’
2115
700c x 35mm
2168
26’’ x 2.1 ’’
2095
700c x 32mm
2155
26’’ x 2.0 ’’
2074
700c x 30mm
2145
26’’ x 1.9 /1.95 ’’ ’’
2055
700c x 28mm
2136
26’’ x 1.75 ’’
2035
700c x 25mm
2124
26’’ x 1.5 ’’
1985
700c x 23mm
2105
26’’ x 1.25 ’’
1953
700c x 20mm
2074
26’’ x 1.0 ’’
1913
700cTubulari
2130
24’’ x 1.9 /1.95 ’’ ’’
1916
650c x 23mm
1990
20’’ x 1-1/4 ’’
1618
650c x 20mm
1945
16’’ x 2.0 ’’
1253
27’’ x 1-1/4 ’’
2161
16’’ x 1.95 ’’
1257
27’’ x 1-1/8 ’’
2155
16’’ x 1.5 ’’
1206
26’’ x 2.3 ’’
2135
