SuperServer 110P-FWTR Quick Reference Guide
Caution
SAFETY INFORMATION
!
WARNING:
IMPORTANT: See installation instructions and safety warning before connecting system
to power supply.
http://www.supermicro.com/about/policies/safety_information.cfm
!
To reduce risk of electric shock/damage to equipment, disconnect power from server by
disconnecting all power cords from electrical outlets.
If any CPU socket empty, install protective plastic CPU cap
WARNING:
!
Always be sure all power supplies for this system have the same power output. If mixed
power supplies are installed, the system will not operate.
For more information go to : http://www.supermicro.com/support
Board Layout
Rear View
Front View and Features
System Overview BMC ADMIN User Password
P s Both Notches res
S a ht D n into the tr ig ow
Memory Slot
Notches
Rel e Tabseas
DI nMM Install ioat
Memory
BIOS
LICENSE
1
BAR CODEIPMI CODEMAC CODESAN MAC
DESIGNED IN USA
X12SPW-TF/F
REV: 2.00
JNCSI1
JBT1
S-SGPIO1
JPWR2
JSD2
JSD1
S-S A1AT
JSTBY1
JRK1
S-S A0AT
JPWR3 JPWR1
JF1
JVRM2
JVRM1
JPFR3
JPFR2
JPFR1
JL1
JD1
JPRG1
JWD1
P4
FAN6
FAN7
FAN4
FAN3
FAN5
FAN1
BT1
NVME0/1
NVME2/3
MH16MH15
JP 2C1
JIPMB1
JNVI2C
JI2C_EXP1
MH4
MH6
MH1
MH9
MH5
MH3
MH2
JPME1
JPL2
JMP2
JMP1
JPL1
JPL3
SXB2: PCI-E 4.0 X16
SXB1A SXB1B: PCI-E 4.0 X 6 + X16
SXB1C
COM2
M.2-H
COM1
DIMMG1
I-S A4~7AT
DIMMH1
DIMME1
DIMMF1
DIMMA1
DIMMB1
DIMMD1
DIMMC1
CPU
USB6/7(3.0)
USB4/5 (3.0)
USB2/3
LAN2 LAN1
CMOS CLEAR
TPM/PORT80
I-S A0~3AT
UID-SW
UID-LED
VGA
USB0/1
IPMI_LAN
USB8(3.0)
LE3
LEDBMC
LE4
FAN2
7910
CPU Installation and Removal
123Supports a single Intel Xeon Ice Lake Scalable Processor (LGA 4189)
4 6 75
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Item
1
Description
2
3
VGA Port
4
Two 10GbE(-TF)/1GbE(-F) LAN Ports
5
USB 3.2 G 1 Porten
6
7
Dedicated LAN for IPMI
USB 2.0 Port
8
COM Port (S l Port)eria
9
COM Port r (S l Port)Heade eria
10
M.2 PCI- A InterfaceE/SAT
11
12
USB 2.0 erHead
13
TPM erHead
S-SATA0/1: SATA 3.0 Ports with SATA
DOM P erow
I-SATA 7: Int l SATA Ports4- erna
Item
14
Description
15
USB 3.2 G 1 eren Head
16
Intel RAID Key erHead
17
18
USB 3.2 G 1 Ty -A Porten pe
F nt nt l P el Headerro Co ro an
19 CPU
20
DIMM A 1 Slots1-H
21
NVME0/1: PCI-E 4.0 x8 S e SAS limlin
Connector
22
23
NVME2/3: PCI-E 4.0 x8 S e SAS limlin
Connector
24
S- O erSGPI Head
JIPMB1 n BMC Ext l I2C 4-pi erna
Header
25
I-SATA 3: Int l SATA Ports0- erna
O d CMOS Batterynboar
Rev. 1.0MNL-2406-QRG http://www.supermicro.com
6
8
43 51 2
1. Insert the desired number of DIMMs into
the memory slots based on the recommended
DIMM population table.
2. Push the release tabs outwards on both
ends of the DIMM slot to unlock it.
3. Align the key of the DIMM module
with the receptive point on the
memory slot.
4. Align the ends of the module against the
receptive points on the ends of the slot.
5. Press the ends of the module straight down
into the slot until the module snaps into place.
6. Press the release tabs to the lock positions
to secure the DIMM module into the slot.
1 CPU, 8-DIMM Slots
Number of DIMMs Memory Population Sequence
1 DIMMA1
2
4
6
8
DIMMA1 / DIMME1
DIMMA1 / DIMME1 / DIMMC1 / DIMMG1
DIMMA1 / DIMME1 / DIMMC1 / DIMMG1 / DIMMB1 / DIMMF1
DIMMA1 / DIMME1 / DIMMC1 / DIMMG1 / DIMMB1 / DIMMF1 / DIMMD1 / DIMMH1
Type Ranks Per DIMM
and Data Width
DIMM Capacity (GB)
1DPC
8 Gb
Speed (MT/s); Voltage (V);
Slot Per Channel (SPC) and DIMM Per
Channel (DPC)
*Data below assumes 2 SPC unless other-
wise noted.
16 Gb 1.2V
RDIMM
SRx8 8 GB 16 GB
3200
SRx4 16 GB 32 GB
DRx8 16 GB 32 GB
DRx4 32GB 64 GB
RDIMM-3DS (4R/8R) x4 2H-64F GB
4H-128 GB
2H-128 GB
4H 256 GB 3200
LRDIMM QRx4 64 GB 128 GB 3200
LRDIMM-3DS (4R/8R) X4 4H-128 GB 2H-128 GB
4H-256 GB 3200
Item Description
Two redundant power supply modules
Serial port
Dedicated IPMI LAN
Two USB 3.2 Gen 1 ports and two USB 2.0 ports
VGA Port
LAN port; 2x 10GbE BaseT port(s)
PCIe 4.0 p1-x16 Full-height full-length slot for PCIe expansion card
1
2
3
4
5
6
7
8
9
10 Power Button with Status LED
PCIe 4.0 p1-x16 Full-height full-length slot for PCIe expansion card
PCIe 4.0 p1-x16 low-profile slot for PCIe expansion card
Chassis CSE-515B-R801W with PWS 800w
CSE-515B-R601W with PWS 600w
Motherboard X12SPW-TF
Processor Support 3rd Gen Intel® Xeon® Scalable processors up to 205W
Memory Eight DIMM slots, up to 2TB ECC LRDIMM,
DDR4-3200 MHz
Drive Support Two internal 2.5" SATA3 drive bays
Expansion Slots
I/O Ports
One PCIe 4.0 p1-x16 LP slot
Two PCIe 4.0 p1-x16 FHFL slots
System Cooling
Two LAN 10GbE ports
One dedicated IPMI/KVM LAN port
One VGA port
One serial port
Two USB 3.2 Gen 1 ports
Two USB 2.0 ports
Six (4cm x 4cm x 5.6cm) counter-rotating fans
Passive Heatsink for 1U System
One air shroud for CPU
One optional air shroud for PCIe cards
Power Redundant DC 600W
Redundant AC 800W
Form Factor 1U rackmount,
(WxHxD) 17.2 x 1.7 x 16.9 in. (437 x 43 x 429 mm)
Each system comes with a unique default password for the ADMIN user.
This can be found on a sticker on the motherboard and a sticker
underneath the service tag on chassis. If necessary, the password
can be reset by the Supermicr IPMICFG tool.
For more information, please visit:
https://www.supermicro.com/en/solutions/management-software/bmc-
resources
BMC: XXXXXXXXXXXX
PWD: XXXXXXXXXX
A the i y. ing Creat In l Ite ce Lake Carr er Assembl
A
B
Pin 1
A
lat
llo
ch o n
w ca r
t
r
o C PU
ier to
A
lat
llo
ch o n
w ca r
t
r
o C PU
ier to
A
lat
llo
ch o n
w ca r
t
r
o C PU
ier to
ca r
t
r
o C PU
ier to A
lat
llow
ch o n
1. Locate small gold t in 1 on p andriangle (P ) rocessor
co ierresponding hollo ed t iangle on caw r rr r.
2. U r r sing the t iangles as a guide, ca efully align and place
Point A of the p into the ca . Gently snap intorocessor rrier
place to fasten onto Point B.
B the ro or ts k. bling Assem P cess Hea in
M e (P )odul HM
tr r iangle cutout of the heatsink and p“A” ess into place
such that the clips lock in.
1. Tur w n the heatsink upside do n, and hold the
pr r r w ocesso carrie assembly ith the gold contacts facing
up.
2. A r ) w lign the t iangle (Pin 1 on the assembly ith the
Pin1
A
C p the CPU for. Pre aring Socket
In ll iosta at n
Gently pull o f the plastic p otective covef r r
by one co to emove it f om the rner r r CPU
socket.
Remove the plastic protective
cover from the CPU socket.
Do not touch or bend the socket
pins.
Socket Pins
D the ro or k M e. Installing P cess Heatsin odul
1. A r ) r r w r r lign the golden t iangle (Pin 1 of the p ocesso ith the p inted t iangle
on the socket. A r .ll fou holes should be aligned
2. nsu otating up unlockedE r r re that the fou wir r “es a e in an ” ( ) . position
3. Mount the M onto the socket on the mothe d and gentlyPH CPU rboar
pr F r wir .ess into place. lip the otating es to the sides to a locked position
4. 30W Tith a Torx- rewdr r - r r bit sc ive , gently tighten peek nuts 1 4 in the o de
descr .ibed on the heatsink label
#1
#2
#3
#4
Rem cess Heatsov the roing P or in odulk M e
Gently lift the module up to emove it f om the socketr r .3.
4. M Flip the PH w U ith the gold contacts facing up. nlock the
lever r . and gently emove the CPU
1. 30U Tsing a Torx- rewdr r r bit sc ive , loosen the fou peek nuts in
a back d sequence of 4, 3, 2, 1war .
2. nsu otating up unlockedE r r re that the fou wir r “es a e in an ” ( )
position. #1
#2
#3
#4
1 2
Item Description
6 Heavy Duty Fans with Optimal Fan Speed Control
Service Tag
1
2
PULL
Pull-out tag with BMC unique
password underneath.
