USER'S MANUAL
Revision 1.0
SuperStorage®
1029P-NEL32R
The information in this user’s manual has been carefully reviewed and is believed to be accurate. The vendor assumes
no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update
or to keep current the information in this manual, or to notify any person or organization of the updates. Please Note:
For the most up-to-date version of this manual, please see our website at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual
at any time and without notice. This product, including software and documentation, is the property of Supermicro and/
or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except
as expressly permitted by the terms of said license.
IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT
OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER
MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED
OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the
State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution
of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual,
may cause harmful interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only
to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply.
See ”.www.dtsc.ca.gov/hazardouswaste/perchlorate
The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment,
nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical
systems whose failure to perform be reasonably expected to result in signicant injury or loss of life or catastrophic
property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products
for use in such ultra-hazardous applications, it does so entirely at its own risk. Furthermore, buyer agrees to fully
indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and
proceedings of any kind arising out of or related to such ultra-hazardous use or sale.
Manual Revision 1.0
Release Date: May 16, 2019
Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this
document. Information in this document is subject to change without notice. Other products and companies referred
to herein are trademarks or registered trademarks of their respective companies or mark holders.
Copyright © 2019 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!
3
SuperServer 1029P-NEL32R User's Manual
Preface
About this Manual
This manual is written for professional system integrators and PC technicians. It provides
information for the installation and use of the SuperStorage 1029P-NEL32R Installation and
maintenance should be performed by experienced technicians only.
Please refer to the 1029P-NEL32R server specications page on our website for updates on
supported memory, processors and operating systems (http://www.supermicro.com).
Notes
For your system to work properly, please follow the links below to download all necessary
drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: https://www.supermicro.com/wftp/driver
• Product safety info: http://www.supermicro.com/about/policies/safety_information.cfm
If you have any questions, please contact our support team at:
support@supermicro.com
This manual may be periodically updated without notice. Please check the Supermicro website
for possible updates to the manual revision level.
Warnings
Special attention should be given to the following symbols used in this manual.
Warning! Indicates high voltage may be encountered when performing a procedure.
Warning! Indicates important information given to prevent equipment/property damage
or personal injury.
4
Preface
Contents
Chapter 1 Introduction
1.1 Overview ...............................................................................................................................8
1.2 Unpacking the System .........................................................................................................8
1.3 System Features ..................................................................................................................9
1.4 System Chassis Features ..................................................................................................10
Control Panels ...................................................................................................................10
Front Features ...................................................................................................................11
Rear Features ...................................................................................................................12
1.5 Motherboard Layout ...........................................................................................................13
Quick Reference Table ......................................................................................................14
Chapter 2 Server Installation
2.1 Overview .............................................................................................................................17
2.2 Preparing for Setup ............................................................................................................17
Choosing a Setup Location ...............................................................................................17
Rack Precautions ..............................................................................................................17
Server Precautions ............................................................................................................18
Rack Mounting Considerations .........................................................................................18
Ambient Operating Temperature ....................................................................................18
Airow ............................................................................................................................18
Mechanical Loading .......................................................................................................18
Circuit Overloading ........................................................................................................19
Reliable Ground .............................................................................................................19
2.3 Installing the System into a Rack.......................................................................................20
Identifying the Sections of the Rack Rails ........................................................................20
Releasing the Inner Rails ..................................................................................................21
Installing the Inner Rails on the Chassis ..........................................................................22
Installing the Outer Rails on the Rack ..............................................................................23
Installing the Chassis onto the Rack ................................................................................25
Chapter 3 Maintenance and Component Installation
3.1 Powering On the System ...................................................................................................26
3.2 Removing Power ................................................................................................................26
3.3 Accessing the System ........................................................................................................26
5
SuperServer 1029P-NEL32R User's Manual
3.4 Processor and Heatsink Installation ...................................................................................28
The Intel® Xeon® Scalable Series Processor ..................................................................28
Overview of the Processor Carrier Assembly ...................................................................29
Overview of the CPU Socket ............................................................................................29
Overview of the Processor Heatsink Module ....................................................................30
Creating the Non-F Model Processor Carrier Assembly...................................................31
Assembling the Processor Heatsink Module ....................................................................32
Preparing the CPU Socket for Installation ........................................................................33
Installing the Processor Heatsink Module (PHM) ............................................................34
Removing the Processor Heatsink Module (PHM) from the Motherboard .......................35
Memory Installation ...........................................................................................................36
ESD Precautions ...........................................................................................................36
Precautions ....................................................................................................................36
Introduction to Intel® Optane DC Persistent Memory ...................................................36
Memory Support ............................................................................................................36
Memory Population Sequence ......................................................................................37
General Memory Population Requirements ..................................................................38
DIMM Population Guidelines for Optimal Performance ................................................38
DIMM Installation ...........................................................................................................42
DIMM Module Removal .....................................................................................................42
PCI Expansion Card Installation .......................................................................................43
Motherboard Battery .........................................................................................................43
3.5 Chassis Components .........................................................................................................44
EDSFF Long (E1.L). Drives ..............................................................................................44
Removing a Drive Using Linux ......................................................................................44
Removing a Drive Using Windows ................................................................................47
Cable Connections ............................................................................................................50
IPMI ..............................................................................................................................50
PCI-E Slots ....................................................................................................................50
References .....................................................................................................................50
Removing and Installing a Ruler Drive ..........................................................................51
System Fans .....................................................................................................................52
Power Supply ...................................................................................................................53
6
Preface
Chapter 4 Motherboard Connections
4.1 Power Connections ............................................................................................................54
4.2 Rear I/O Ports ....................................................................................................................55
Dedicated IPMI Port ......................................................................................................56
4.3 Headers and Connectors ...................................................................................................57
4.4 Jumpers ..............................................................................................................................60
Explanation of Jumpers .................................................................................................60
4.5 LED Indicators ....................................................................................................................62
Chapter 5 Software
5.1 Microsoft Windows OS Installation .....................................................................................64
5.2 Driver Installation ................................................................................................................66
5.3 SuperDoctor® 5 ...................................................................................................................67
5.4 IPMI ....................................................................................................................................67
Chapter 6 UEFI BIOS
6.1 Introduction .........................................................................................................................68
Starting the Setup Utility ...................................................................................................68
6.2 Main Menu ..........................................................................................................................69
6.3 Advanced Setup Congurations .........................................................................................71
6.4 Event Logs .........................................................................................................................98
6.5 IPMI ..................................................................................................................................100
6.6 Security Settings ..............................................................................................................103
6.7 Boot Settings ....................................................................................................................106
6.8 Save & Exit .......................................................................................................................108
Appendix A BIOS Error Codes
Appendix B Standardized Warning Statements for AC Systems
Appendix C System Specications
Appendix D UEFI BIOS Recovery
Appendix E CPU-Based RAID for NVMe
7
Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: +1 (408) 503-8000
Fax: +1 (408) 503-8008
Email: marketing@supermicro.com (General Information)
support@supermicro.com (Technical Support)
Website: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: +31 (0) 73-6400390
Fax: +31 (0) 73-6416525
Email: sales@supermicro.nl (General Information)
support@supermicro.nl (Technical Support)
rma@supermicro.nl (Customer Support)
Website: www.supermicro.nl
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: +886-(2) 8226-3990
Fax: +886-(2) 8226-3992
Email: support@supermicro.com.tw
Website: www.supermicro.com.tw
Preface
8
SuperServer 1029P-NEL32R User's Manual
Chapter 1
Introduction
1.1 Overview
This chapter provides a brief outline of the functions and features of the 1029P-NEL32R. The
1029P-NEL32R is based on the X11DPS-RE motherboard and the SC136HTS-R1K69P-E2
chassis. The SC136HTS-R1K69P-E2 chassis features two front mounted sleds, with the right
side having a control panel, and space for 32 drive bays for EDSFF Long (E1.L).
In addition to the motherboard and chassis, several important parts that are included with
the system are listed below.
Main Parts List
Description QuantityPart Number
SC136 16-bay E1.L sled (without bezel) MCP-220-13602-0N 2
40x40x56 mm, 23.3K-20.3K RPM, counter-rotating fan FAN-0163L4 8
SC136H power supply air shroud MCP-310-13601-0N 1
Drive backplane 1U EDSFF NVMe supports 16x Ruler Gen-2 PCI-E p8-x4
devices BPN-EDS3-136P1-1 2
1U Passive CPU heat sink for equipped with a Narrow Retention
Mechanism SNK-P0067PS 2
Riser Card RSC-R1U-E16R 2
Rail set MCP-290-11809-0N 1
AC-DC 1600W at high and 1000W at low line, Platinum level PWS-1K69P-1R 2
1.2 Unpacking the System
Inspect the box the SuperStorage 1029P-NEL32R was shipped in and note if it was damaged
in any way. If any equipment appears damaged, please le a damage claim with the carrier
who delivered it.
Decide on a suitable location for the rack unit that will hold the server. It should be situated
in a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical noise and
electromagnetic elds are generated. It will also require a grounded AC power outlet nearby.
Be sure to read the precautions and considerations noted in Appendix B.
9
Chapter 1: Introduction
1.3 System Features
The following table provides you with an overview of the main features of the 1029P-NEL32R.
Please refer to Appendix C for additional specications.
System Features
Motherboard
X11DPS-RE
Chassis
SC136HTS-R1K69P-E2
CPU
Dual Intel 81xx/61xx/51xx/41xx/31xx or 82xx/62xx/52xx/42xx/32xx series up to 165W
Socket Type
Socket P
Memory
The X11DPS-RE supports up to 3 TB of RDIMM/NVDIMM DDR4 ECC 2933*/2666/2400/2133 MHz speed
memory in 24 memory slots.
*Notes 1.: 2933 MHz memory is supported by the 82xx/62xx series processors only. Up to 9TB memory is 2.
supported with DCPMM modules installed.
Chipset
Intel® C627
Expansion Slots
Two PCI-E 3.0 x16 slots with riser card support
Hard Drives
Up to 32 hot-swappable 9.5mm EDSFF Long (E1.L) drive bays in two 16-bay sleds
Power
Two redundant 1600W power supplies
Form Factor
1U rackmount server
Dimensions
(WxHxD) 17.26 x 1.7 x 35.95 in. (438.4 x 43 x 913-mm) (without power supply bracket extortion)
10
SuperServer 1029P-NEL32R User's Manual
Figure 1-1. Control Panel View
1.4 System Chassis Features
Control Panels
The switches and LEDs located on the control panels are described below. One control panel
is located on the front of the chassis on the right side.
Control Panel Features
Item Feature Description
1 Power Button
The main power button is used to apply or remove power from the power supply
to the system. Turning o󰀨 system power with this button removes the main power
but maintains standby power. To perform many maintenance tasks, you must also
unplug system before servicing.
Note: Before applying power to the system, refer to Section 2.4, "Powering On the
System."
2 Reset Button The reset button is used to reset the system.
3 LAN LED Indicates activity from the LAN ports.
4 UID LED Illuminates when the UID button is activated. Use this to easily identify the system
in a rack environment.
5Power Fail LED/
Info LED
Indicates a power supply module has failed when solid red. The second power
supply module will take the load and keep the system running but the failed module
will need to be replaced. Refer to Chapter 3 for details on replacing the power
supply. This LED should be o󰀨 when the system is operating normally.
After the server powers on, this LED will blink at 4Hz until initialization is complete,
upon which time it will turn o󰀨 and become the Power Fail LED.
1
5
4
3
2
11
Chapter 1: Introduction
Front Chassis Features
Item Feature Description
1 Control Panel Front control panel with LEDs and buttons (see preceding page)
2 Drive Bays Hot-swappable Ruler SSDs (Drive IDs: 0 to 7 left to right)
3 Drive Bays Hot-swappable Ruler SSDs (Drive IDs: 8 to 15 left to right)
4 Drive Bays Hot-swappable Ruler SSDs (Drive IDs: 16 to 23 left to right)
5 Drive Bays Hot-swappable Ruler SSDs (Drive IDs: 24 to 31 left to right)
6 Latch Latch for releasing and extending the chassis from the rack
Figure 1-2. Chassis Front View
Front Features
The SC136HTS-R1K69P-E2 is a 1U chassis. See the illustration below for the features
included on the front of the chassis.
1
6
62 3 4 5
EDSFF Long (E1.L) Drive LEDs
LED Description
Activity LED This upper (away from latch) Green LED indicates the combined power and activity
of the SSD.
Fault LED This lower (close to the latch) Amber LED indicates a Fault or Error if there is a
drive failure.
12
SuperServer 1029P-NEL32R User's Manual
Figure 1-3. Chassis Rear View
Rear Features
The illustration below shows the features included on the rear of the chassis.
Rear Chassis Features
Item Feature Description
1 Power Supply This is the 1600W power supply module with LED and there are two modules
for power redundancy. (See Power Supply LED table.)
2 UID Button Press this button to activate the UID LED, which allows you to quickly identify
the system in a rack.
3 Expansion Card Slots Slots for expansion cards.
4 I/O Ports Rear I/O ports (see Section 4.3).
Power Supply LED
Status Description
Solid green Power supply is providing power to the system.
Solid amber Power supply is plugged in and deactivated, or the system is powered o󰀨 but in an abnormal state.
Blinking amber Power supply temperature has reached 63 °C. The system automatically powers o󰀨 if the
temperature rises to 70 °C, and automatically resets when the temperature falls below 60 °C.
1 1 2
33
4
13
Chapter 1: Introduction
Figure 1-4. Motherboard Layout
1.5 Motherboard Layout
Below is a layout of the X11DPS-RE with jumper, connector and LED locations shown. See
the table on the following page for descriptions. For detailed descriptions, pinout information
and jumper settings, refer to Chapter 4.
AC
BIOS LICENSE
X11DPS-RE
REV:1.01
DESIGNED IN USA
IPMI CODE BAR CODE
JF1
JCOM1
JLAN2 JLAN1
LE1
LED4
LED3
JCOM2
JRK1
BT1
JIPMILAN
JPWR1
JPWR2
JUSB1
LEDM1
LED1
JP2
JSD2JSD1
SP1
FAN7FAN8 FAN5FAN6 FAN3FAN4 FAN1FAN2
JP6JP5
JWD1
JPB1
JPQAT
JPME1
JP1
JPME2
PSU2 PSU1
JUIDB2
JL1
JBT1
JSDCARD1
JTPM1
JP_BSCAN_BMC
M.2
JIPMB1
CN6 CN5
CN4
M.2
B37
A37
A1
B1
A1 A37
CN3
CN2
CN1
J30 J31
J30
LE2
S-SATA4S-SATA5
VGA
CPU2 SLOT2 PCIe 3.0X16
CPU1 SLOT1 PCIe 3 0X16
P2-DIMMF 1 P2-DIMME 1P2-DIMMF 2 P2-DIMME 2 P2-DIM MD1 P2-DIMMD2
CPU2
P2-DIMMA2 P2-DIM MB2P2-DIMMA1 P2-DIMMB1 P2-DIMMC2 P2-DIMM C1P1-DIMMF 1 P1-DIMMF2 P1-DIMME 1 P1-DIMMD1P1-DIMME2 P1-DI MMD2
CPU1
P1-DIMMA1P1-DIMMA2 P1-DIM MB2 P1-DIMMB1 P1-DI MMC2 P1-DIM MC1
USB12/13(3.0)
JPL1
IPMI_LAN
VGA JLAN1JUSB1
LED1
JUIDB2
JCOM1
JIPMB1
JP1
JPME2
PSU1
PSU2
JF1
FAN1
FAN2
FAN3
FAN4
FAN5
FAN6
FAN7
FAN8
JPQAT
JSDCARD1 JLAN2
JCOM2
JP6
JP5 JPWR2
J31 LED3
SP1
JRK1
JPWR1
JTPM1
LEDM1
JSD2
JSD1
S-SATA5
S-SATA4
JWD1
JPB1
LED4
J30
JPME1
JBT1
BT1
LE1
LE2
JL1
JPL1
14
SuperServer 1029P-NEL32R User's Manual
Notes:
• See Chapter 4 for detailed information on jumpers, I/O ports, and JF1 front panel connec-
tions.
• " " indicates the location of Pin 1.
• Jumpers/LED indicators not indicated are used for testing only.
• To avoid causing interference with other components, please be sure to use an add-on
card that is fully compliant with the PCI-standard on a PCI slot.
• Use only the correct type of onboard CMOS battery as specied by the manufacturer. Do
not install the onboard battery upside down to avoid possible explosion.
Quick Reference Table
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JP1 BIOS Advance Function Pins 2-3 (Normal)
JP5 BMC Power Button Ready Test Header Pins 1-2 (Normal)
JPB1 BMC Enable/Disable Pins 1-2 (Enabled)
JPL1 GLAN Enable/Disable Pins 1-2 (Enabled)
JPME1 ME Recovery Pins 1-2 (Normal)
JPME2 Manufacturing Mode Pins 1-2 (Normal)
JPQAT QAT (QuickAssist Technology) Enable/Disable Pins 1-2 (Enabled)
JWD1 Watch Dog Timer Enable Pins 1-2 (Reset)
LED Description Status
LE1 CPLD Heartbeat LED Blinking Green: Normal
LE2 Onboard Power LED Solid Green: Power on
LED1 UID LED Solid Blue: Unit Identied
LED3 PCI-E/SATA Hybrid M.2 SLOT 1 LED Blinking Green: M.2 Active
LED4 PCI-E/SATA Hybrid M.2 SLOT 2 LED Blinking Green: M.2 Active
LEDM1 BMC Heartbeat LED Blinking Green: Normal
15
Chapter 1: Introduction
Connector Description
BT1 Onboard CMOS battery
FAN1 ~ FAN8 System/CPU fan headers (FAN1: CPU Fan)
J30 PCI-E/SATA Hybrid M.2 Slot 1
J31 PCI-E/SATA Hybrid M.2 Slot 2
JCOM1/JCOM2 COM ports
JF1 Front control panel header
JIPMB1 4-pin external I²C header (for an IPMI card)
JIPMILAN Dedicated IPMI LAN port
JL1
Chassis intrusion header Please connect a cable from the Chassis Intrusion header at JL1 (Note:
to the chassis to receive an alert via IPMI.)
JLAN1/JLAN2 10G LAN ports 1 and 2
JPWR1/JPWR2 Backplane power connectors
JRK1 Intel VROC RAID key header for NVMe Solid State Devices (SSD)
JSDCARD1 SD card socket
JSD1 - JSD2 SATA Disk-On-Module (DOM) power connectors
JTPM1 TPM/PORT80 Port 80 connector for Trusted Platform Module (TPM)
JUIDB2 Unit Identier (UID) switch
JUSB1 (3.0) USB 3.0 rear ports (USB12/13)
PSU1 Power Supply Unit 1
PSU2 Power Supply Unit 2
S-SATA4~5 (Powered) SATA connectors with power-pins built-in with support of SuperDOMs
VGA VGA port
Note: To avoid causing interference with other components, please be sure to use an
add-on card that is fully compliant with the PCI-standard on a PCI slot.
16
SuperServer 1029P-NEL32R User's Manual
Note: This is a general block diagram and may not exactly represent the features on
your motherboard. See the previous pages for the actual specications of your moth-
erboard.
Figure 1-5. System Block Diagram
UPI0
CPU 1
DMI
PE1 2 PE3PE
DDR4 DIMM
CPU 0
Polarity Inversion
10.4G/11.2G T/s
UPI
UPI1
PE1 2 I0PE UP
PE3 I1UP
32GB/s
32GB/s
32GB/s
32GB/s
32GB/s
32GB/s
8GB/s
PCH
S-SATA5
S-SATA4
sSATA Gen3 [4, 5]
DMI
USB3.0 [1,2]
USB2.0 [ , ]12 13
SPI
LPC/eSPI
USB2.0 [7]
TPM
Header
HWM
USBSPI
MUX
LPC/eSPI
PE
PE[5]
SPI
FLASH
32MB
BMC
SPI
FLASH
64MB
BIOS
IPMI LAN
RJ45
COM1
PHY
RTL F8211
VGA
NCSI DDR4
SPI
BMC
AST2500
DDR4
VGA NLA
UART
UPI
port 0,1
REAR
A
DDR4 DIMM
#1
#2
#1
#2
DDR4 DIMM
DDR4 DIMM
DDR4 DIMM
#1
#2
DDR4 DIMM
#1
#2#2
#1
#2
#1
DDR4 DIMM
#1
#2
DDR4 DIMM
#1
#2
DDR4 DIMM
#1
#2
B
C
D
E
F
H
J
G
#2
#1
#2
#1
K
L
M
DDR4 DIMM
#1
#2
DDR4 DIMM
DDR4 DIMM
M.2
PE[0..3]
HSSI
2IPU2IPU
DMI
x8
x16
x16
x8
UPLINK[0:7]
LAN1
LAN2 PE[6-7]/sSATA[0] M.2
PCI-E
MUX
PCI-E
X32
CABLE
PCI-E
CABLE
X32
Intel 50X5
x16
PCI-E x1 slot6
x8
x8
x16
PCI-E x1 slot6
PCI-E
MUX
FX_UPLINK[0:7]
PE[8-9]/sSATA[2]
x8
x16
x16 x8
x8
x8
x8x8
x8
COM2
CN1/2/3
CN4/5/6
Chapter 2: Server Installation
17
Chapter 2
Server Installation
2.1 Overview
This chapter provides advice and instructions for mounting your system in a server rack.
If your system is not already fully integrated with processors, system memory etc., refer to
Chapter 4 for details on installing those specic components.
Caution: Electrostatic Discharge (ESD) can damage electronic components. To prevent such
damage to PCBs (printed circuit boards), it is important to use a grounded wrist strap, handle
all PCBs by their edges and keep them in anti-static bags when not in use.
2.2 Preparing for Setup
The box in which the system was shipped should include the rackmount hardware needed to
install it into the rack. Please read this section in its entirety before you begin the installation.
Choosing a Setup Location
• The system should be situated in a clean, dust-free area that is well ventilated. Avoid areas
where heat, electrical noise and electromagnetic elds are generated.
• Leave enough clearance in front of the rack so that you can open the front door completely
(~25 inches) and approximately 30 inches of clearance in the back of the rack to allow
su󰀩cient space for airow and access when servicing.
• This product should be installed only in a Restricted Access Location (dedicated equipment
rooms, service closets, etc.).
• This product is not suitable for use with visual display workplace devices according to §2
of the German Ordinance for Work with Visual Display Units.
Rack Precautions
• Ensure that the leveling jacks on the bottom of the rack are extended to the oor so that
the full weight of the rack rests on them.
SuperServer 1029P-NEL32R User's Manual
18
• In single rack installations, stabilizers should be attached to the rack. In multiple rack in-
stallations, the racks should be coupled together.
• Always make sure the rack is stable before extending a server or other component from
the rack.
• You should extend only one server or component at a time - extending two or more simul-
taneously may cause the rack to become unstable.
Server Precautions
• Review the electrical and general safety precautions in Appendix B.
• Determine the placement of each component in the rack you install the rails.before
• Install the heaviest server components at the bottom of the rack rst and then work your
way up.
• Use a regulating uninterruptible power supply (UPS) to protect the server from power
surges and voltage spikes and to keep your system operating in case of a power failure.
• Allow any drives and power supply modules to cool before touching them.
• When not servicing, always keep the front door of the rack and all covers/panels on the
servers closed to maintain proper cooling.
Rack Mounting Considerations
Ambient Operating Temperature
If installed in a closed or multi-unit rack assembly, the ambient operating temperature of
the rack environment may be greater than the room's ambient temperature. Therefore,
consideration should be given to installing the equipment in an environment compatible with
the manufacturer’s maximum rated ambient temperature (TMRA).
Airow
Equipment should be mounted into a rack so that the amount of airow required for safe
operation is not compromised.
Mechanical Loading
Equipment should be mounted into a rack so that a hazardous condition does not arise due
to uneven mechanical loading.
Chapter 2: Server Installation
19
Circuit Overloading
Consideration should be given to the connection of the equipment to the power supply circuitry
and the e󰀨ect that any possible overloading of circuits might have on overcurrent protection
and power supply wiring. Appropriate consideration of equipment nameplate ratings should
be used when addressing this concern.
Reliable Ground
A reliable ground must be maintained at all times. To ensure this, the rack itself should be
grounded. Particular attention should be given to power supply connections other than the
direct connections to the branch circuit (i.e. the use of power strips, etc.).
To prevent bodily injury when mounting or servicing this unit in a rack, you must take
special precautions to ensure that the system remains stable. The following guidelines
are provided to ensure your safety:
• This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
• When mounting this unit in a partially lled rack, load the rack from the bottom to the top
with the heaviest component at the bottom of the rack.
• If the rack is provided with stabilizing devices, install the stabilizers before mounting or
servicing the unit in the rack.
Warning: do not pick up the server with the front handles. They are designed to pull
the system from a rack only.
Slide rail mounted equipment is not to be used as a shelf or a work space.
SuperServer 1029P-NEL32R User's Manual
24
Figure 2-6. Adjusting the Middle Rail
Figure 2-7. Installing Outer Rails to a Rack
2. Push the middle rail back into the outer rail. An audible click indicates that the rail is fully
inserted.
3. Insert the pegs on the rear of the outer rail into the rear rack holes. An audible click
indicates that the rail is locked into place.
4. Press upward on the locking tab near the rear end of the middle rail, and extend the
outer rail until the length ts within the posts of the rack.
5. On the front end of the outer rail, turn the latch to the open position and push the pegs
into the front rack holes.
6. Turn the latch to the locked position.
7. Repeat steps 1-6 for the remaining outer rail.
1 2
1 2
3 4
27
Chapter 3: Maintenance and Component Installation
Warning: Except for short periods of time, do not operate the system without the cover in place.
The chassis cover must be in place to allow for proper airow and to prevent overheating.
Figure 3-1. Removing the Chassis Cover
31
Chapter 3: Maintenance and Component Installation
Creating the Non-F Model Processor Carrier Assembly
To install a Non-F model processor into the processor carrier, follow the steps below:
1. Hold the processor with the LGA lands (gold contacts) facing up. Locate the small, gold
triangle in the corner of the processor and the corresponding hollowed triangle on the
processor carrier. These triangles indicate pin 1. See the images below.
2. Using the triangles as a guide, carefully align and place Point A of the processor into
Point A of the carrier. Then gently ex the other side of the carrier for the processor to t
into Point B.
3. Examine all corners to ensure that the processor is rmly attached to the carrier.
Processor Carrier Assembly (Non-F Model)
A
A
B
B
Pin 1
Align CPU Pin 1
CPU (Upside Down)
with CPU LGA Lands up
Processor Carrier
(Upside Down)
Align Point B of the CPU and
Point B of the Processor Carrier
Align Point A of the CPU and
Point A of the Processor Carrier
Pin 1
A
B
Allow carrier to
latch onto CPU
Allow carrier to
latch onto CPU
