LB-CA50 Rechargeable Li-ion
Battery Pack
Ver:A Tel:+86-25-85805753
Fax:+86-25-85805296
http://www.swit.cc
E-mail: contact@swit.cc
USER MANUAL
S W I T E l e c t r o n i c s Co. , LT D.
Congratulations on your purchase of this product. Please read this user manual carefully.
Charging
Features
Description of appearance
Keep in mind the following precautions to avoid fire and other safety hazards！
Warning
Do not use battery in fire or hot places to prevent overheating, cracking and other hazards.
Please do not pierce the battery shell or try to open the shell and decompose the battery.
Do not use battery beyond charge, discharge and storage environment temperature.
Do not charge the battery in the car or in direct sunlight.
Do not use damaged battery.
Do not squeeze the battery shell which may cause physical damage.
Make sure the power-consuming equipment(s) meet the battery specifications.
Use SWIT charger or SWIT recommended charger to charge the battery to avoid overheating or break.
Keep out of the reach of children.
① 4-level LED power indicators
② USB output socket
③ Power check button/
USB output button
④ D-TAP input/output socket
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
The battery is charged only
through type D-TAP socket,
and the maximum charging
current is 3A. It is recommend-
ed to charge by the SWIT
S-3010B, SWIT PC-U130B and
SWIT PC-U130B×2.
Please pay attention to the
positive and negative of the
D-TAP socket. Do not reverse
the connection.
The battery can be charged at a temperature range of 0~40℃, but we
recommend charging at a temperature range of 10~30℃ to ensure
the best performance of the battery.
Discharging
Specification
The battery needs to use with
PA-BL4 cable (additional purchase)
to power Canon EOS C300 MarkII,
EOS C200.ect through D-TAP socket.
It is recommended to be used in the
temperature range of 0~40℃ to
ensure the best performance of the
battery.
Four LEDS show the battery
remaining capacity (25%, 50%, 75%,
and 100%), when the battery lasts
less than 15 minutes on the
equipment, 25% LED indicator will
flash red to alert, and please change
battery asap.
◆
◆
◆
◆
◆
◆
Caution
Fully charged battery will discharge naturally and please use it as
soon as it gets charged.
The battery may become warm in use or while being charged. This
is normal.
Never expose the battery to temperature above 60℃.
Keep the battery terminals clean and never short-circuit the battery
terminals.
When stored for a long time, please keep the battery power
capacity beyond 50%.
Battery will automatically enter the sleep mode if rest in 10 days,
the output will be shut off. Press the button to restore output.
The battery pack is applicable with Canon EOS C300 MarkII, EOS C200
.etc.
Power supply to camera DC input from battery D-TAP output.
5V/1A USB output.
4-level LED power indicator to display the battery remaining capacity
percentage and low-voltage alarm warning.
High performance rechargeable lithium ion battery, no memory effect.
Build-in multiple protective circuit design.
Fig 2.Battery charging diagram
Fig 3.Battery power
supply diagram
①Battery
②PA-BL4 cable
Model
Voltage
Capacity
D-TAP socket
USB socket
In total
Dimension
Net weight
LB-CA50
14.4V
73Wh/ 5.1Ah
50W,3.5A
5W,5V/1A
50W,3.5A
69.6*41.5*95.5mm
0.414KG
Output
Fig 1.Battery appearance
◆
