SWIT S-8210S Manual
SWIT
Accus kamera
S-8210S
Læs nedenfor 📖 manual på dansk for SWIT S-8210S (1 sider) i kategorien Accus kamera. Denne guide var nyttig for 10 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere
Side 1/1
High Load Rechargeable Li-ion Battery Pack
Tel: +86-25-85805753
Fax: +86-25-85805296
http://www.swit.cc
E-mail: contact@swit.cc
Characteristics
1. High power output Li-ion battery pack, rechargeable.
2. 4-step LED power indicator.
3. D-tap DC output and charging socket.
4. Build-in multiple protective circuit design.
Caution
1. Never attempt to open the battery pack.
2. Use SWIT charger or the chargers recommended by SWIT.
3. Please make sure the battery mount on camera could endure
high current, otherwise it might damage the mount or battery.
4. Keep the battery pack terminals clean.
5. Never short-circuit the battery pack terminals.
6. Never expose the battery pack to rain, fire or moisture.
7. Never expose the battery pack to temperature above 60 .
8. Avoid strong mechanical shock.
9. The battery pack may become warm in use or while being
charged. This is normal.
Charging
1. The battery pack is not fully charged when it is purchased.
Charge the battery before use.
2. Use SWIT charger or the chargers recommended by SWIT.
3. The battery pack should be charged within a temperature
range of 0-40
Discharging
1. Fully charged battery pack will discharge naturally and please
use it as soon as it gets charged.
2. At low temperature, the running time of battery pack usually
decreases.
3. The internal impedance of battery pack will be greater at low
temperature, which may cause the automatically circuit cutting.
4. According to the using conditions, please set the camera low
battery warning voltage at 13-14V, cut off voltage at 12-13V.
LED indicator
1. The four-step LEDs indicate the remaining capacity when
press the “CHECK” button.
2. The indicator may not be accurate when the battery is
powering on the camera.
3. When only one LED indicates, please charge the battery as
soon as possible.
DC socket
The D-tap DC socket can be used as 14.4V DC output or SWIT
S-3010B charging input.
1. Open the rubber cover and plug in D-tap lead to DC output or
charge.
2. Close the rubber cover when disconnected, to keep the socket
away from dust.
Self-protection and Re-activate
The battery pack has multiple protective circuits and will cut off
power automatically when overload or any abnormal detected.
Mount the battery pack to any SWIT charger, it will be re-
activated and get charging normally.
Storage
Please keep in cool, dry and clean place.
Specifications
Model Mount Type Nominal
voltage Capacity Max output Dimension Mass
S-8210A Gold Mount 14.4V 115Wh 8Ah 150W 12A 165×90×53mm 900g
S-8210S V-mount 14.4V
115Wh 8Ah 150W 12A 165×90×51mm 900g
S-8260A Gold Mount 14.4V
172Wh 12Ah 180W 15A 165×90×68mm 1300g
S-8260S V-mount 14.4V
172Wh 12Ah 180W 15A 165×90×66mm 1300g
12-05
Produkt Specifikationer
| Mærke: | SWIT |
| Kategori: | Accus kamera |
| Model: | S-8210S |
