Quick Installation Guide
Turret IPC & PoE+ NVR KIT
Note: VIGI NVR1008H-8MP and VIGI C445 are used as an example throughout the Guide. Images may dier from the actual
product.
Hardware Overview
1
Install the NVR
3
Mount the Camera
2
VIGI NVR1008H-8MP
VIGI C445
*The camera’s standard power supply is 12V DC or PoE (802.3af/at). The power source should comply with
Power Source Class 2 ( PS2) or Limited Power Source(LPS) of IEC 62368-1.
*Some models do not have the power supply interface. You can check the detailed specications on the
product page at https://www.tp-link.com/.
Front Panel
Back Panel
Power PoE PortUSB Port
VGA
HDMI
LAN Port
AUDIO OUT
AUDIO IN
USB
Interface Description
2 USB ports for additional devices such as USB
mouse, USB storage device, and USB keyboard.
Output port for analog video signals.
Connect your monitor to this port if it uses VGA
connection.
Designed to connect to the device with a
bandwidth of 100/10 Mbps. The port can also
provide power for PoE PDs (recommended for
PoE cameras).
PoE
RJ45 10/100Mbps self-adaptive Ethernet port.
Connect to an Ethernet device (eg. router and
switch).
AUDIO IN /
AUDIO OUT
VGA
HDMI
Power Connector for power input.
LAN
Output port for high-denition audio and
video signals. Connect your monitor to this
port if it uses HDMI connection.
Connector for audio input and output.
Note: Audio input only supports microphones
with power supply.
LED USB Port
On: A device is linked to the port but no activity.
Flashing: Transmitting or receiving data.
O: No device is linked to the corresponding port.
Link / Act
On: The port is supplying power normally.
Flashing: Overload or short circuit is detected.
O: Not providing PoE power on the port.
PoE
On: The total PoE power reaches the warning threshold.
Flashing: The total PoE power has reached the warning
threshold for more than 2 minutes.
O: The total PoE power does not reach the warning
threshold.
PoE Max
On: The HDD is normal.
O: No HDD or the HDD is malfunctioning.
HDD
On: Network is working properly.
Flashing: Data is being transmitted or received.
O: Network is malfunctioning.
LAN
On: System is running normally.
O: System is running abnormally.
SYS
LED Indication
Kensington
Security Slot
Grounding Terminal
Kensington Security Slot: Secure the lock (not provided)
into the security slot to prevent the device from being
stolen.
Grounding Terminal: The device comes with lightning
protection mechanism.
3. Secure the Camera
Insert anchors into the holes and use screws to ax the camera base. Identify
the groove and alignment ridge on the camera. Begin by aligning the base's rim
with the camera's groove, attaching the ridge side rst for a correct t. Once
aligned, proceed to snap the rest of the camera onto the base to secure it.
Stick the mounting template to the desired mounting place. Drill 4 screw holes
and 1 cable hole (for the cable through wall/ceiling) according to the template.
1. Drill Holes
2. Open the Camera Case
Use the L-shaped hex metal screwdriver to loosen the hex screw,
and use a screwdriver to gently pry open the camera case.
4. Adjust the Surveillance Angle
Use the L-shaped hex metal screwdriver to loosen the hex screw
on the base, and adjust the surveillance angle as needed.
Through the wall/ceiling Through the side outlet
Or
Camera Base
Speaker
7
IR LED × 4
6
White LED × 4
5
Built-in Microphone
1
2
Reset
3
microSD Card Slot
Unfasten the two xed screws to remove the cover.
Insert a microSD card for local storage. Initialize the SD
card via VIGI app or other management tools before
recording videos.
Power Supply Interface
(12V DC) *
9
RJ45 Network Interface
(supports PoE) *
8
4
1
3
2
56
4
89
Unfasten the two xed screws to remove the cover. Press
for 5 seconds to reset the camera to factory settings.
7
56
Cable Hole
(For the cable through wall/ceiling)
When installing with anchors
Φ = 6 mm (15/64 in.)
When installing with screws only
Φ = 3 mm (1/8 in.)
Appropriate drilling size (Φ)
Hex screw
Side Outlet
Rim
Alignment Ridge
Rim
Alignment Ridge
Tilt: 0° to 85°
Pan: 0° to 360°
Rotate: 0° to 360°
L-shaped Hex Metal
Screwdriver
Mounting
Template
Anchors & ScrewsNetwork Camera
Φ6 mm Φ3.5 mm
Waterproof Cable
Attachments
Waterproof
Seal
5. Tighten the Hex Screw
Tighten the hex screw to secure the camera to the camera base. Hold the
camera and ensure the camera and base are as close together as possible
when tightening.
Network Video Recorder Rubber Feet
One hard disk drives (HDD) is already installed in the NVR. You can also
follow the steps below to reinstall the HDD.
1. Remove the xing screws on the side and back panels to open the
cover of the NVR.
2. Attach the 4 included HDD screws to your hard drive. Do not fasten.
Hard Disk Drive (HDD)
Install Waterproof Cable Attachments
Install the waterproof cable attachments for the network interface if needed.
Note: Make sure each part is securely attached and the waterproof rings are ush to keep out water.
1. Route the network cable through the following components in order: x
nut, waterproof ring, and then the waterproof jacket.
2. Fix the O-ring to the network interface of the camera and connect the
network cables.
3. Attach the network interface with the waterproof jacket, then twist to lock.
4. Insert the waterproof ring into the waterproof jacket. Rotate the x nut to
secure it to the waterproof jacket.
Fix Nut Waterproof
Ring
O-ring Network
Interface
Waterproof
Jacket
Install the waterproof seal for the power connectors when using a power
adapter to power the camera.
Install Waterproof Seal for Power Connectors
Male Power Connector Waterproof Seal Female Power Connector
