Side 1/2
Frequency Baby unit: 2412 - 2462 MHz
Channels 11
LCD 2.8’’ Color LCD
(IPS 320x240 pixels)
Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may
vary according to environmental conditions at the time of use.
Power requirement Parent unit/Baby unit power adapters:
VTech, VT05EUS05100
Rated output: 5V DC, 1000mA.
Parent unit battery: 3.6V 2600mAh, 9.36Wh Lithium-ion battery
Specifications are subject to change without notice.
© 2022 VTech Communications, Inc.
All rights reserved. 10/22. RM2751_CA_QSG_V1
Technical specications
Android TM and Google Play TM are trademarks of Google Inc.
App Store is a trademark of Apple Inc., registered in the U.S. and other countries.
IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license.
RM2751
2.8 inch Smart Wi-Fi 1080p
Video Monitor
What does Video Monitor do?
VTech 2.8 inch Smart Wi-Fi 1080p Video Monitor allows you to stay close to your baby when
you are on the move or away.
This monitor is Wi-Fi enabled, which uses your home wireless network to stream live video and
audio through the baby unit and 2.8 inch color screen parent unit. It allows you to maintain a
constant connection to your baby.
You can also monitor from your smartphone and mobile tablet.
VTech 2.8 inch Smart Wi-Fi 1080p Video Monitor uses MyVTech Baby Pro app to let you
instantly see and hear what’s happening with your baby from anywhere in the world.
The app can be downloaded from the App Store or the Google PlayTM Store, directly from your
smartphone or mobile tablet.
Quick start guide
(Canada version)
For more support information
UL STD.
62368-1
CERTIFIED TO
CSA STD.
C22.2 NO.62368-1
CO ORMS TO NF
Direct mode
The parent unit and the baby unit of your video monitor connect to each others in Direct mode
by default, which allows you to stream live video right out of the box. Direct mode connection
lets you stream live video from parent unit only.
• You may experience reduced signal strength if your parent unit and baby unit are far apart, or there are
obstructing factors, such as internal walls, between them. Move the parent unit closer to the baby unit to
improve the signal strength. You can also set up Router mode to connect via your home Wi-Fi network to
improve the connection between your parent unit and baby unit.
Router mode
You can continue using your video monitor
with connection, or you Direct mode
can set up your monitor in Router mode
connection.
Router mode uses your home Wi-Fi
network to connect your video monitor.
It supports streaming live video through
parent unit and smartphone app.
We recommend that you set up your
monitor in Router mode to enjoy streaming
live video via your parent unit with better
connection.
If you want to stream live video remotely with your mobile device, download and install the
MyVTech Baby Pro mobile app. With the mobile app, your Wi-Fi router (not included) provides
Internet connectivity to your video monitor system. It serves as a communicating channel
between your baby unit and mobile device, allowing you to monitor and/or control your baby
unit wherever you are. For detail, see Download app for mobile access section in this quick start
guide.
Notes
• Your parent unit detects the connection signal strength. If you have connected your video monitor with
your home Wi-Fi network, your parent unit automatically switches to direct or router mode - the one that
has stronger signal strength.
• When both parent unit and app are viewing the camera simultaneously, the video quality will be
optimised to deliver the best possible viewing result.
What’s in the box
Connect, charge and power on the baby monitor
x 2 x 2
Quick start guide
Your video monitor package contains the following items. Save your sales receipt and original
packaging in the event warranty service is necessary.
How the system works
For mobile access:
MyVTech Baby Pro mobile app
Network Wi-Fi
Wi-Fi router 2.4GHz 802.11 b/g/n
Internet connection 1.5 Mbps @ 720p or 2.5 Mbps @1080p upload
bandwidth per baby unit
Requirements
Connect the baby monitor
Fully insert the provided power adapters into the parent unit and baby unit power jack, then plug
into a power source. You can hear a clicking sound if it plugs correctly, and the battery LED light on the
parent unit turns on.
Notes
• The rechargeable battery in the parent unit is built-in.
• Use only the power adapters supplied with this product.
• Make sure the parent unit and the baby unit are not connected to an electronically controlled electric
outlet.
• Connect the power adapters in a vertical or floor mount position only. The adapter prongs are not
designed to hold the weight of the parent unit and the baby unit, so do not connect them to any ceiling,
under-the-table, or cabinet outlets. Otherwise, the adapters may not properly connect to the outlets.
• Make sure the parent unit, the baby unit and the power adapter cords are out of reach of children.
• To maintain compliance with the FCC’s RF exposure guidelines, place the baby unit at least 20cm from
nearby persons.
Charge the parent unit battery before use
The parent unit runs on an internal rechargeable battery or AC power. To continuously monitor
your baby, keep the parent unit connected to AC power. With the battery alone, the parent unit
can cordlessly run for a short time only.
Notes
• Before using the baby monitor for the first time, charge the parent unit battery for 12 hours. When the
parent unit battery is fully charged, the battery icon becomes solid .
• The standby time varies depending on your actual use.
The battery icon indicates the battery status (see the following table).
Battery indicators Battery status Action
alert displays on the parent
unit screen, the battery icon
becomes empty , with the
LED light flashes.
The battery has very little
charge and may be used
for only a short time.
Charge
without interruption
(about 30 minutes).
The battery icon becomes solid
.
The battery is fully
charged.
To keep the battery charged,
connect it to AC power.
The parent unit turns on automatically after
it connects to the power socket, and the
welcome screen appears. You can press and
hold to turn it on or off.
NOTE:
Camera lens and surface may get
warm during normal operation.
WARM
WARM
WARM
WARM
WARM
Parent unit overview
Local access
Mobile access Enhanced local access
Press and hold
The applied nameplate is located at the bottom of the baby unit’s base.
When using your equipment, basic safety precautions should
always be followed to reduce the risk of fire, electric shock and
injury, including the following:
1. Follow all warnings and instructions marked on the product.
2. Adult setup is required.
3. CAUTION: Do not install the baby unit at a height above 6.5
feet (2 meters).
4. This product is intended as an aid. It is not a substitute for
responsible and proper adult supervision and should not be
used as such.
5. This product is not intended for use as a medical monitor.
6. Do not use this product near water, for example, near to a
bath, sink, swimming pool or shower.
7. CAUTION: Use only the battery provided. There may be a risk
of explosion if a wrong type of battery is used for the parent
unit. The battery cannot be subjected to high or low extreme
temperature and low air pressure at high altitude during
use, storage or transportation. Disposal of battery in fire or
a hot oven, mechanically crushing or cutting the battery can
result in an explosion. Leaving the battery in an extremely
high temperature surrounding environment can result in an
explosion or the leakage of flammable liquid of gas. Battery
subjected to extremely low air pressure may result in an
explosion or the leakage of flammable liquid or gas. Dispose
of used battery according to the information in The RBRC seal.
8. Use only the adapters included with this product. Incorrect
adapter polarity or voltage can seriously damage the product.
Power adapter information:
Baby Unit Output: 5V DC 1A
VTech Telecommunications Ltd.
Model: VT05EUS05100
Parent Unit Output: 5V DC 1A
VTech Telecommunications Ltd.
Model: VT05EUS05100
Rechargeable battery information:
Zhuhai Great Power Energy Co., Ltd.
Li-ion battery, 3.6V, 2600mAh, 9.36Wh;
Model:
ICR18650-2.6Ah-3.6V-1S1P
9. The power adapter is intended to be correctly oriented in a
vertical or floor mount position. The prongs are not designed
to hold the plug in place if it is plugged into a ceiling, under-
the-table or cabinet outlet.
10. For pluggable equipment, the socket-outlet (power adapter)
should be installed near the equipment and should be easily
accessible.
11. Unplug this product from the wall outlet before cleaning.
Do not use liquid or aerosol cleaners. Use a damp cloth for
cleaning.
12. Do not modify the power adapters or replace with other
power adapters, as this causes a hazardous situation.
13. Do not allow anything to rest on the power cords. Do not install
this product where the cords may be walked on or crimped.
14. This product should be operated only from the type of power
source indicated on the marking label. If you are not sure of
the type of power supply in your home, consult your dealer or
electricity supply provider.
15. Do not overload wall outlets or use an extension cord.
16. Do not place this product on an unstable table, shelf, stand or
other unstable surfaces.
17. This product should not be placed in any area where proper
ventilation is not provided. Slots and openings in the back or
bottom of this product are provided for ventilation. To protect
them from overheating, these openings must not be blocked
by placing the product on a soft surface such as a bed, sofa
or rug. This product should never be placed near or over a
radiator or heat source.
18. Never push objects of any kind into this product through
the slots because they may touch dangerous voltage points
or create a short circuit. Never spill liquid of any kind on the
product.
19. To reduce the risk of electric shock, do not disassemble
this product, but take it to an authorized service facility.
Disassembling or removing parts of the product other than
via the battery door may expose you to dangerous voltages
or other risks. Incorrect reassembling can cause electric shock
when the product is subsequently used.
20. You should test the sound reception every time you turn on
the units or move one of the components.
21. Periodically examine all components for damage.
22. There is a very low risk of privacy loss when using certain
electronic devices, such as baby monitors, cordless
telephones, etc. To protect your privacy, make sure the
product has never been used before purchase, reset the baby
monitor periodically by powering off and then powering
on the units, and power off the baby monitor if you are not
intending to use it for some time.
23. Children should be supervised to ensure that they do not play
with the product.
24. The small parts of this monitor can be swallowed by babies or
small children. Keep these parts out of reach of children.
25. The product is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
SAVE THESE INSTRUCTIONS
Cautions
• Use and store the product at a temperature between 32 oF
(0oC) and 104oF (40oC).
• Batteries should not be exposed to excessive heat such as
bright sunshine or fire.
• Mishandling batteries can cause burn, fire or explosion
hazards.
• Do not expose the product to extreme cold, heat or direct
sunlight. Do not put the product close to a heating source.
• Strangulation Hazard—Children have STRANGLED
in cords. Keep this cord out of the reach of children
(more than 3 ft (0.9m) away). Do not remove
warning label on the adapter cord.
• Never place the baby unit(s) inside the baby’s
crib or playpen. Never cover the baby unit(s) or
parent unit with anything such as a towel or a blanket.
• Other electronic products may cause interference with your
baby unit. Try installing your baby unit as far away from these
electronic devices as possible: wireless routers, radios, cellular
telephones, intercoms, room monitors, televisions, personal
computers, kitchen appliances and cordless telephones.
Precautions for users of implanted cardiac pacemakers
Cardiac pacemakers (applies only to digital cordless devices):
Wireless Technology Research, LLC (WTR), an independent
research entity, led a multidisciplinary evaluation of the
interference between portable wireless devices and implanted
cardiac pacemakers. Supported by the U.S. Food and Drug
Administration, WTR recommends to physicians that:
Pacemaker patients
• Should keep wireless devices at least six inches from the
pacemaker.
• Should NOT place wireless devices directly over the
pacemaker, such as in a breast pocket, when it is turned ON.
WTR’s evaluation did not identify any risk to bystanders with
pacemakers from other persons using wireless devices.
Electromagnetic elds (EMF)
This VTech product complies with all standards regarding
electromagnetic fields (EMF). If handled properly and according
to the instructions in this user’s manual, the product is safe to be
used based on scientific evidence available today.
Important safety instructions
Basic operation
Talk to your baby via the baby unit
1. Press and hold the key.
2. icon displays on When the
screen, speak to your parent unit.
Your voice is transmitted to the
baby unit.
3. When finished talking, release
the key and hear your baby
again.
Adjust speaker volume
Press to adjust your parent or
unit speaker volume level received from
the baby unit.
After powering up your video monitor, the parent unit streams live video in direct mode.
We recommend you follow the instructions on screen to set up home Wi-Fi network
with your monitor for functionality enhancements and mobile access. See Auto software
and rmware update and Download app for mobile access in this quick start guide.
Use the menu
Press on the parent unit to enter the
main menu, choose a menu item, or
save a setting. You can use the parent
unit menu for advanced settings or
operations, such as to play or stop
lullaby, or adjust the motion and sound
detection settings.
While in the menu:
• Press or to scroll among the
menu options.
• Press to select an item.
• Press to return.
• Press to exit the menu.
To restore to the default settings or reset the
Wi-Fi connection, you can reset the parent
unit by pressing the key at the back of RESET
the unit.
Use a pin and insert it into the hole on the
back of the parent unit, and then gently press
the button inside.
Turn on/off the parent unit screen
You can turn on or off the parent unit screen
without powering off the parent unit. You
can still hear sound from the baby unit.
• Press on the parent unit to turn off
the screen.
• Press any keys on the parent unit to turn
on the screen again.
Muted
Press and hold
Press
Protect your privacy and online security
VTech cares about your privacy and peace of mind. That’s why we’ve put together a list of
industry-recommended best practices to help keep your wireless connection private and
your devices protected when online. We recommend you carefully review and consider
complying with the following tips.
Ensure your wireless connection is secure.
• Before installing a device, ensure your router’s wireless signal is encrypted by selecting
the “WPA2-PSK with AES” setting in your router’s wireless security menu.
Change default settings.
• Change your wireless router’s default wireless network name (SSID) to something unique.
• Change default passwords to unique, strong passwords. A strong password:
- Is at least 10 characters long.
- Is complex.
- Does not contain dictionary words or personal information.
- Contains a mix of uppercase letters, lowercase letters, special characters and numbers.
Keep your devices up to date.
• Download security patches from manufacturers as soon as they become available. This
will ensure you always have the latest security updates.
• If the feature is available, enable automatic updates for future releases.
Disable Universal Plug and Play (UPnP) on your router.
• UPnP enabled on a router can limit the effectiveness of your firewall by allowing other
network devices to open inbound ports without any intervention or approval from you.
A virus or other malware program could use this function to compromise security for the
entire network.
For more information on wireless connections and protecting your data, please review the
following resources from industry experts:
1. Federal Communications Commission: Wireless Connections and Bluetooth Security Tips
–
www.fcc.gov/consumers/guides/how-protect-yourself-online.
2. U.S. Department of Homeland Security: Before You Connect a New Computer to the
Internet –
www.us-cert.gov/ncas/tips/ST15-003.
3. Federal Trade Commission: Using IP Cameras Safely –
https://www.consumer.ftc.gov/articles/0382-using-ip-cameras-safely.
4. Wi-Fi Alliance: Discover Wi-Fi Security –
http://www.wi-fi.org/discover-wi-fi/security.
Overview
Baby unit overview
1Light sensor
2Camera lens
3Infrared LEDs
Allow you to see clearly in a dark surrounding.
4Microphone
5 Night light touch key
(for model with Serial Number starts
with 0KW)
• Tap to turn the night light on or off.
• Tap and hold to adjust night light
brightness.
6Night light
7Speaker
8 Night light control key
• Press to turn the night light on or off.
• Press and hold to adjust night light
brightness.
9PAIR
• The parent unit and baby unit(s) provided
are already paired.
• Reset the baby unit to factory default.
Press and hold PAIR key and Night light
control key at the same time, until you
hear a beep sound.
10 Power jack
11 Temperature sensor
12 Slots for wall mounting
• Wall mount bracket is included in your
package.
13 Product label
• Here show the product Serial Number
(S/N) and other specification. If the serial
number starts with 0KW, the product
comes with a night light touch key
feature.
3
4
5
6
2
1
10
11
9
8
7
12
WIFI M AC: XXXXXX
Mad e in China
For produ ct su pport ple as e
cal l: 1300 369 193
Mo del :RM275 -2 BU
S/N: XXXXXXXXXXX
13
Go to www.vtechcanada.com
for the latest VTech product news.
Str ang ul atio n
Haz a rd
Keep this cord out of reach of children.
The cord ne eds to be at lea s t thre e feet
away from t he child at all tim es . Do not
use with an e xtens ion cord. Do not
rem ove t his t ag.
Éloignez ce cordon des en fants. Le
cordon doit s e tro uve r à a u moins trois pieds d’un enfant e t ce, en tou t te mps .
N’utilisez pa s de ra llonge. Ne re tirez pa s cette é tiquett e.
Manten ga e st e cable fuera de la alcan ce
de los niños . Este cable deb e es ta r por
lo meno s t res pies fuer a de la alcance
del niño en to do m ome nto. No lo us e
con una exte ns ión inalá mbr ica. No quite es ta e tiquet a.
Ri s q u e
d’é tr an g le men t
Ri e sg o de
e str a n gu la ci ó n
Str ang ul atio n
Haz a rd
Keep th is cord out of reach of children.
The cord ne eds to be at lea s t thre e feet
away from t he child at all tim es . Do not
use with an e xtens ion cord. Do not
rem ove t his t ag.
Éloignez ce cordon des en fants. Le
cordon doit s e tro uve r à a u moins trois
pieds d’un enfant e t ce, en tou t te mps .
N’utilisez pa s de ra llonge. Ne re tirez pa s cette é tiquett e.
Manten ga e st e cable fuera de la alcan ce
de los niños . Este cable deb e es ta r por
lo meno s t res pies fuer a de la alcance
del niño en to do m ome nto. No lo us e
con una exte ns ión inalá mbr ica. No quite
es ta e tiquet a.
Ri s q u e
d’é tr an g le men t
Ri e sg o de
e str a n gu la ci ó n
1 / Menu/Select
• Press to enter the main menu.
• While in a menu, press to choose an
item, or save a setting.
2
/ Talk/Return
• Press and hold to talk to the baby unit.
• While in a submenu, press to go back.
3 / Power / LCD on/off / Exit
• Press and hold to power on/off the
parent unit.
• Press to screen on/off.
• While in a submenu, press to exit.
4 / / /
• Increase or decrease parent unit’s
volume.
• While in a submenu, press to navigate
leftward or rightward.
5Microphone
6 LED light
• On when the parent unit is connected
to AC power, and the battery is
charging.
• Flashes when the parent unit battery is
low and needs charging.
7LINK LED light
• On when the parent unit is linked to
the baby unit.
• Flashes when the link to the baby unit
is lost.
8Antenna
9Power jack
10 RESET
• Force reboot the parent unit.
11 Speaker
2
1
3
4
5
6
7
11
8
9
10
Raise the parent unit
antenna for better
reception.
Produkt Specifikationer
| Mærke: | Vtech |
| Kategori: | Babyalarm |
| Model: | RM2751 |
Har du brug for hjælp?
Hvis du har brug for hjælp til Vtech RM2751 stil et spørgsmål nedenfor, og andre brugere vil svare dig
Babyalarm Vtech Manualer
15 December 2024
13 December 2024
13 December 2024
13 December 2024
13 December 2024
13 December 2024
13 December 2024
7 Oktober 2024
2 Oktober 2024
14 September 2024
Babyalarm Manualer
- Babyalarm SilverCrest
- Babyalarm Amplicomms
- Babyalarm Denver
- Babyalarm Sencor
- Babyalarm Beurer
- Babyalarm Philips
- Babyalarm Concept
- Babyalarm Medisana
- Babyalarm Gigaset
- Babyalarm Emos
- Babyalarm Technaxx
- Babyalarm Grundig
- Babyalarm D-Link
- Babyalarm Motorola
- Babyalarm Kodak
- Babyalarm Tefal
- Babyalarm Hama
- Babyalarm Hyundai
- Babyalarm Belkin
- Babyalarm TriStar
- Babyalarm TRENDnet
- Babyalarm Sanitas
- Babyalarm Fysic
- Babyalarm Topcom
- Babyalarm Uniden
- Babyalarm Medion
- Babyalarm EZVIZ
- Babyalarm König
- Babyalarm Ariete
- Babyalarm Elro
- Babyalarm Geemarc
- Babyalarm Babymoov
- Babyalarm Beaba
- Babyalarm Withings
- Babyalarm Terraillon
- Babyalarm Angelcare
- Babyalarm Fisher-Price
- Babyalarm Graco
- Babyalarm Neonate
- Babyalarm PADWICO
- Babyalarm Chicco
- Babyalarm Lindam
- Babyalarm Reer
- Babyalarm Alcatel
- Babyalarm Tommee Tippee
- Babyalarm Jane
- Babyalarm Alecto
- Babyalarm Olympia
- Babyalarm Ansmann
- Babyalarm HQ
- Babyalarm Niceboy
- Babyalarm Marmitek
- Babyalarm Basetech
- Babyalarm Tesla
- Babyalarm Foscam
- Babyalarm Lorex
- Babyalarm Cobra
- Babyalarm Xblitz
- Babyalarm Joblotron
- Babyalarm Binatone
- Babyalarm Eufy
- Babyalarm Overmax
- Babyalarm Albrecht
- Babyalarm Nova
- Babyalarm Trebs
- Babyalarm Bébétel
- Babyalarm Manhattan
- Babyalarm Switel
- Babyalarm Brondi
- Babyalarm GoClever
- Babyalarm Lupilu
- Babyalarm Duux
- Babyalarm Audioline
- Babyalarm BT
- Babyalarm CAPiDi
- Babyalarm Tigex
- Babyalarm Lionelo
- Babyalarm Pabobo
- Babyalarm Oricom
- Babyalarm Oregon Scientific
- Babyalarm SereneLife
- Babyalarm Stabo
- Babyalarm Duronic
- Babyalarm TrueLife
- Babyalarm Kogan
- Babyalarm Cresta
- Babyalarm Chipolino
- Babyalarm Summer
- Babyalarm BabyOno
- Babyalarm Safety 1st
- Babyalarm Esscom
- Babyalarm Luvion
- Babyalarm Hartig And Helling
- Babyalarm NUK
- Babyalarm Tomy
- Babyalarm Babysense
- Babyalarm Jablotron
- Babyalarm Modern-Electronics
- Babyalarm Hartig Helling
- Babyalarm Levana
- Babyalarm Summer Infant
- Babyalarm IBaby
- Babyalarm Fischer Price
- Babyalarm Mobi
- Babyalarm MicroTalk
- Babyalarm Oretti
- Babyalarm Neno
- Babyalarm LeamsiQ
- Babyalarm Philips-Avent
- Babyalarm Heimvision
- Babyalarm BabySafe
- Babyalarm Chillax Baby
- Babyalarm Hubble Connected
- Babyalarm Peekyboo
Nyeste Babyalarm Manualer
10 December 2024
4 December 2024
30 November 2024
30 November 2024
22 November 2024
17 November 2024
16 November 2024
16 November 2024
12 November 2024
11 November 2024
