Side 1/2
Charge the battery before use
The parent unit runs on rechargeable battery or AC power.
To continuously monitor your baby, keep the parent
unit connected to AC power. With the battery alone, the
parent unit can cordlessly run for a short time only.
• Before using the baby monitor for the first time, charge the
parent unit battery for 12 hours. When the parent unit battery
is fully charged, the battery icon becomes solid .
• It takes longer to charge when the parent unit is turned on.
To shorten the charging time, turn the parent unit off while
charging.
• The standby time varies depending on your actual use.
After the parent unit is fully charged, press POWER until the
welcoming screen appears.
The battery icon indicates the battery status (see the following table).
Battery indicators Battery status Action
The screen displays and
. The light flashes.
The battery has very little
charge and may be used
for only a short time.
Charge
without interruption
(about
30 minutes).
The battery icon becomes
solid .
The battery is fully
charged.
To keep the battery charged, connect
it to AC power when not in use.
Overview
What’s in the box
Connect, charge and power on the baby monitor
Protect your privacy and online security
How the system works
VTech cares about your privacy and peace of mind. That’s why we’ve put together a list of
industry-recommended best practices to help keep your wireless connection private and
your devices protected when online. We recommend you carefully review and consider
complying with the following tips.
Ensure your wireless connection is secure.
• Before installing a device, ensure your router’s wireless signal is encrypted by selecting
the “WPA2-PSK with AES” setting in your router’s wireless security menu.
Change default settings.
• Change your wireless router’s default wireless network name (SSID) to something unique.
• Change default passwords to unique, strong passwords. A strong password:
- Is at least 10 characters long.
- Is complex.
- Does not contain dictionary words or personal information.
- Contains a mix of uppercase letters, lowercase letters, special characters and numbers.
Keep your devices up to date.
• Download security patches from manufacturers as soon as they become available. This
will ensure you always have the latest security updates.
• If the feature is available, enable automatic updates for future releases.
Disable Universal Plug and Play (UPnP) on your router.
• UPnP enabled on a router can limit the effectiveness of your firewall by allowing other
network devices to open inbound ports without any intervention or approval from you.
A virus or other malware program could use this function to compromise security for the
entire network.
For more information on wireless connections and protecting your data, please review the
following resources from industry experts:
1. Federal Communications Commission: Wireless Connections and Bluetooth Security Tips
–
www.fcc.gov/consumers/guides/how-protect-yourself-online.
2. U.S. Department of Homeland Security: Before You Connect a New Computer to the
Internet –
www.us-cert.gov/ncas/tips/ST15-003.
3. Federal Trade Commission: Using IP Cameras Safely –
https://www.consumer.ftc.gov/articles/0382-using-ip-cameras-safely.
4. Wi-Fi Alliance: Discover Wi-Fi Security –
http://www.wi-fi.org/discover-wi-fi/security.
Parent unit icons
For mobile access:
MyVTech Baby HD mobile app
Network Wi-Fi
Wi-Fi router 2.4GHz 802.11 b/g/n
Internet connection 1.5 Mbps @ 720p or 2.5 Mbps @1080p upload
bandwidth per baby unit
Requirements
Connect and charge the parent unit
Install the parent unit battery
The parent unit runs on rechargeable battery or AC power. To continuously monitor your
baby, keep the parent unit connected to AC power. With the battery alone, the parent unit can
cordlessly run for a short time only.
• Use only the battery supplied with this product.
• If the parent unit will not be used for a long time, disconnect and remove the battery to prevent
possible leakage.
Connect and power on the baby unit
1. Connect the power adapter to the baby unit and a
power supply.
2. Slide the switch leftward to power on ON/OFF
your baby unit.
• When powering up, the baby unit’s status LED turns on. It
will turn off after a while and keeps off.
• The status LED is set to off by default. If you want to keep
the LED on, press MENU, then go to
> and turn it on.Status LED
Main
Menu Options
Monitoring mode (* For pairing with
RM9011HD only)
• View baby unit 1 or 2 in Single
mode.
• View both baby units in Patrol
mode.
• View both baby units in Split
screen.
Melodies and soothing sounds
• Select play all melodies, or play
one of the five melodies and
four soothing sounds.
• You can also set the timer to
stop playing after 15, 30 or 60
minutes, or playing non-stop.
Alerts - Sound, motion and temperature
• Select the sound and motion
sensitivity level.
• Turn on/off sound and motion
detection alerts.
• Select maximum and minimum
temperature for alert range.
• Turn on/off temperature alert.
• Turn on/off Auto Wake Up
function.
Parent unit settings
• Adjust parent unit screen
brightness.
• Turn on/off dim mode.
Baby unit settings
• Turn on/off .Night Vision
• Turn on/off baby unit’s status LED.
• Adjust baby unit’s speaker
volume.
• Update baby unit’s security key.
Main
Menu Options
General settings
• Connect to home Wi-Fi network.
• Turn on/off Parent unit Wi-Fi
Connection.
• Connect mobile phone.
• Turn on/off Low Battery Alert Tone.
• Turn on/off No Link Alert Tone.
• Add/remove baby unit.
Direct mode
The parent unit and the baby unit of your video monitor connect to each others in Direct mode
by default, which allows you to stream live video right out of the box. connection Direct mode
lets you stream live video from parent unit only.
• You may experience reduced signal strength if your parent unit and baby unit are far apart, or there are
obstructing factors, such as internal walls, between them. Move the parent unit closer to the baby unit to
improve the signal strength. You can also set up Router mode to connect via your home Wi-Fi network to
improve the connection between your parent unit and baby unit.
Router mode
You can continue using your video monitor
with connection, or you can set Direct mode
up your monitor in Router mode connection.
Router mode uses your home Wi-Fi network
to connect your video monitor. It supports
streaming live video through parent unit and
smartphone app.
We recommend that you set up your
monitor in to enjoy streaming Router mode
live video via your parent unit with better
connection.
If you want to stream live video remotely with your mobile device, download and install the
MyVTech Baby HD mobile app. With the mobile app, your Wi-Fi router (not included) provides
Internet connectivity to your HD video monitor system. It serves as a communicating channel
between your baby unit and mobile device, allowing you to monitor and/or control your baby
unit wherever you are. For detail, see Download app for mobile access section in this quick start
guide.
• Your parent unit detects the connection signal strength. If you have connected your video monitor with
your home Wi-Fi network, your parent unit automatically switches to direct or router mode - the one that
has stronger signal strength.
• When both parent unit and app are viewing the camera simultaneously, the video quality will be
optimised to deliver the best possible viewing result.
NOTE:
Camera lens and surface may get
warm during normal operation.
WARM
WARM
WARM
WARM
WARM
x 2
x 2
Quick start guide
Your HD video monitor package contains the following items. Save your sales receipt and
original packaging in the event warranty service is necessary.
ESTE LADO HACIA ARRIBA
CE CÔTÉ VERS LE HAUT
model: IS057
modèle: IS057
Recharageable Li-ion Battery
3.7V 1900mAh 7.03Wh
Pile au lithium-ion rechargeable
3,7V 1900mAh 7,03Wh
1ICP5/54/57
Limited charge voltage: 4.2V
Tension de charge limitée: 4,2V
Battery Pack: BT290865
Bloc-piles:BT 290865
MANUFACTURER:
ICON ENERGY SYSTEM (SHENZHEN) CO.,LTD.
FABRICANT:
ICON ENERGY SYSTEM (SHENZHEN) CO., D.LT
1
6
12
11
10
2
3
5
7
8
9
4
Baby unit overview Parent unit overview
1 LED light
• On when the parent unit is connected to
AC power, or the battery is charging.
• Flashes when the parent unit battery is
low and needs charging.
• Off when the parent unit is disconnected
from AC power.
2LINK LED light
• On when the parent unit is linked to the
baby unit.
• Flashes when the link to the baby unit is
lost.
3 LED light
• On when the parent unit speaker volume
is set to off.
• On when the parent unit is talking to the
baby unit.
4TALK LED light
• On when the parent unit is talking to the
baby unit.
5LCD display
6Microphone
7LCD ON/OFF
8POWER
9 Lullaby
• Press to enter the lullaby menu.
10 TALK
• Press and hold to talk to the baby unit.
• While in a submenu, press to exit.
11 Arrow keys
, , or
• Press to move the selection box
leftward, upward, rightward or
downward.
• While viewing image from the baby
unit, press and hold to pan the baby
unit leftward, upward, rightward or
downward.
• While viewing zoomed image,
press and hold to move the zoomed
image leftward, upward, rightward or
downward.
12 MENU/SELECT
• Press to enter the menu.
• While in a menu, press to choose an
item, or save a setting.
13 Zoom in
14 Zoom out
15 - VOL/ VOL +
16 Power jack
17 Antenna
18 Speaker
19 Battery compartment cover
20 Stand
1Microphone
2Camera lens
3Light sensor
4LED indicators
• Flash orange and green alternately
when the baby unit is in pairing
mode.
• Orange is steady on when the baby
unit is not connecting to the Internet
and is idle.
• Green is steady on when the baby
unit is connecting to the Internet and
is idle.
• Flash orange slowly when the baby
unit is not connecting to the Internet
and is streaming with the parent unit.
• Flash green slowly when the baby
unit is connecting to the Internet and
streaming with the parent unit or
mobile app.
• Flash orange and green quickly and
alternately when the baby unit is
updating its firmware.
5Infrared LEDs
Allow you to see clearly in a dark
surrounding.
6 ON/OFF switch
7Antenna
Connect to router with Wi-Fi.
8Speaker
9Temperature sensor
10 Power jack
11 Threaded socket
12 Pair/reset button
• Press and hold for three seconds to
enter pairing mode.
20
11
12
13
14
15
17
10
8
9
18
16 19
7
6
2
3
4
5
1
Local access
63
o
F
Mobile access Enhanced local access
63ē
Connect the baby monitor
• Use only the power adapters supplied with this
product.
• Make sure the parent unit and the baby unit are not
connected to the switch controlled electric outlets.
• Connect the power adapters in a vertical or floor
mount position only. The adapters’ prongs are not
designed to hold the weight of the parent unit and
the baby unit, so do not connect them to any ceiling,
under-the-table, or cabinet outlets. Otherwise, the
adapters may not properly connect to the outlets.
• Make sure the parent unit, the baby unit and the
power adapter cords are out of reach of children.
2
1
3
1
Press down on the battery
compartment cover to pull
it out.
2
Make sure the label is THIS SIDE UP
facing up while inserting the battery.
THIS SIDE UP
1
2
Replace the battery
To replace the battery, press down on
the battery compartment cover and pull
it out, then follow the steps above to
install the battery.
Raise the parent unit
antenna for better reception Status icons
Direct mode
Parent unit, baby unit 1 and baby unit 2
(*For pairing with RM9011HD only) are
connected to each others directly.
Router mode
Parent unit, baby unit 1 and baby unit 2
(*For For pairing with only) RM9011HD
are connected to home Wi-Fi network.
Baby unit 1 and 2 are being viewed
in Patrol mode (*For For pairing with
RM9011HD only).
Baby unit 1 and 2 are being viewed
in mode (*For For pairing with Split
RM9011HD only).
Night vision is turned on.
Motion alert is turned on.
Sound detection alert is turned on.
Melodies and soothing sounds are
turned on.
6-level sound indicator
• indicates low sound level
detected by the baby unit.
• indicates moderate sound level
detected by the baby unit.
• indicates high sound level
detected by the baby unit.
Parent unit speaker is muted.
Temperature alert is turned on.
Technical specifications
Android TM and Google Play TM are trademarks of Google Inc.
App Store is a trademark of Apple Inc., registered in the U.S. and other countries.
IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license.
UL STD.
62368-1
CERTIFIED TO
CSA STD.
C22.2 NO.62368-1
CO ORMS TO NF
RM901HD
Smart Wi-Fi 1080p
HD Pan & Tilt Monitor
What does HD Video Monitor do?
VTech Smart Wi-Fi 1080p HD Pan & Tilt Monitor allows you to stay close to your baby when you
are on the move or away.
This monitor is Wi-Fi enabled, which uses your home wireless network to stream live video and
audio through the HD baby unit and 5-inch color screen parent unit. It allows you to maintain a
constant connection to your baby.
You can also monitor from your smartphone and mobile tablet.
VTech Smart Wi-Fi 1080p HD Pan & Tilt Monitor uses MyVTech Baby HD app to let you instantly
see and hear what’s happening with your baby from anywhere in the world.
The app can be downloaded from the App Store or the Google PlayTM Store, directly from your
smartphone or mobile tablet.
Specifications are subject to change without notice.
© 2020 VTech Communications, Inc. All rights reserved.
10/20. RM901HD_AU_QSG_V1.
Frequency Baby unit: 2412 - 2462 MHz
Channels 13
LCD 5’’ Color LCD
(IPS 1280x720 pixels)
Nominal effective range Actual operating range may vary according to environmental conditions
at the time of use.
Power requirement 1. Parent unit power adapter:
Output: 5V DC 1A
2. Parent unit: 3.8V Polymer battery Lithium-ion
Baby unit power adapter:
Output: 5V DC 1A
Quick start guide
For more support information
Go to auphones.vtech.com
to register your product for
warranty support and latest
VTech product news.
Congratulations
on purchasing your new VTech product. Before using this HD video monitor, please read
Important safety instructions.
Basic operation
After powering up your video monitor, the parent unit streams live video in local mode.
We recommend you follow the instructions on screen to set up home Wi-Fi network
with your monitor for functionality enhancements and mobile access. See Auto software
and firmware update Download app for mobile access and in this quick start guide.
Use the menu
Press MENU/SELECT to enter the
menu, choose a menu item, or save
a setting. You can use the parent
unit menu for advanced settings or
operations, such as to play or stop the
baby unit lullaby, or adjust the sound
detection setting.
While in the menu:
• Press , , to scroll among or
the menu options.
• Press to select an MENU/SELECT
item.
• Press TALK to return to the live video
• Press page. to go to Help & Info
Zoom
Press to zoom in or out. or
Muted
63ē
10:25 AM
10:25 AM
10:25 AM
10:25 AM
10:25 AM
Adjust speaker volume
Press / -VOL VOL+ to adjust your parent unit
speaker volume. It determines the volume of
sound transmitted from your baby unit.
63ē
10:25 AM
10:25 AM
10:25 AM
10:25 AM
10:25 AM
Talk to your baby via the baby unit
1. Press and hold the TALK key.
2. When the LED turns on, TALK
speak to your parent unit.
Your voice is transmitted to
the baby unit.
3. When finish talking, release
the TALK key.
Press and hold
63ē
10:2 5 AM
10:2 5 AM
10:2 5 AM
10:2 5 AM
10:2 5 AM
Turn off the screen
Press LCD ON/OFF to switch
off the screen. You can still hear
sound from the baby unit.
Turn on/off baby unit's status LED
You may set the status LED indicator of
your baby unit on or off. Go to
> .Status LED
Produkt Specifikationer
| Mærke: | Vtech |
| Kategori: | Babyfoon |
| Model: | RM901HD |
Har du brug for hjælp?
Hvis du har brug for hjælp til Vtech RM901HD stil et spørgsmål nedenfor, og andre brugere vil svare dig
Babyfoon Vtech Manualer
14 September 2024
12 September 2024
30 August 2024
22 August 2024
13 August 2024
2 August 2024
30 Juli 2024
22 Juli 2024
20 Juli 2024
20 Juli 2024
Babyfoon Manualer
- Babyfoon Amplicomms
- Babyfoon Denver
- Babyfoon Beurer
- Babyfoon Philips
- Babyfoon Medisana
- Babyfoon Gigaset
- Babyfoon Motorola
- Babyfoon Hyundai
- Babyfoon TriStar
- Babyfoon Sanitas
- Babyfoon Topcom
- Babyfoon Uniden
- Babyfoon Medion
- Babyfoon EZVIZ
- Babyfoon König
- Babyfoon Elro
- Babyfoon Geemarc
- Babyfoon Babymoov
- Babyfoon Beaba
- Babyfoon Withings
- Babyfoon Terraillon
- Babyfoon Angelcare
- Babyfoon Fisher-Price
- Babyfoon Neonate
- Babyfoon Chicco
- Babyfoon Lindam
- Babyfoon Reer
- Babyfoon Alcatel
- Babyfoon Tommee Tippee
- Babyfoon Alecto
- Babyfoon Olympia
- Babyfoon Ansmann
- Babyfoon Foscam
- Babyfoon Binatone
- Babyfoon Eufy
- Babyfoon Albrecht
- Babyfoon Nova
- Babyfoon Bébétel
- Babyfoon Manhattan
- Babyfoon Switel
- Babyfoon GoClever
- Babyfoon Duux
- Babyfoon Audioline
- Babyfoon Lionelo
- Babyfoon Oricom
- Babyfoon Oregon Scientific
- Babyfoon SereneLife
- Babyfoon Duronic
- Babyfoon TrueLife
- Babyfoon Kogan
- Babyfoon Summer
- Babyfoon BabyOno
- Babyfoon Safety 1st
- Babyfoon Luvion
- Babyfoon Hartig And Helling
- Babyfoon NUK
- Babyfoon Tomy
- Babyfoon Babysense
- Babyfoon Jablotron
- Babyfoon Modern-Electronics
- Babyfoon Levana
- Babyfoon IBaby
- Babyfoon Oretti
- Babyfoon Neno
- Babyfoon LeamsiQ
- Babyfoon Philips-Avent
- Babyfoon Heimvision
- Babyfoon Peekyboo
Nyeste Babyfoon Manualer
18 September 2024
16 September 2024
15 September 2024
9 September 2024
8 September 2024
7 September 2024
5 September 2024
5 September 2024
5 September 2024
5 September 2024
