EN:

Important Product Information – Limited Version

Warranty statement

Warranty: 3 years in USA, Canada, Central America, South America, the

Caribbean, Europe, Africa, and the Middle East. 1 year in Asia Pacific.

LIMITED WARRANTY

(USA AND CANADA)

Valid for and only applies to products purchased and used inside the United

States and its territories and in Canada.

WHO MAY USE THIS WARRANTY?

Wacom Co., Ltd. (“Wacom”) extends this limited warranty to the original

consumer purchaser only. It does not extend to any subsequent owner or other

transferee of the product.

WHAT DOES THIS WARRANTY COVER?

This limited warranty covers defects in materials and workmanship of Wacom

products, except for excluded products described below, for a period of three (3)

years from the date of original retail purchase (the “Warranty Period”), as

evidenced by a copy of the receipt and registration with Wacom within 30 days

of purchase.

WHAT IS EXCLUDED FROM THIS WARRANTY?

Software and consumable items such as the battery, pen cartridges, tablet

surface sheet and nibs are excluded from this limited warranty. In addition, this

limited warranty does not cover any damage due to accident, abuse, misuse,

negligence, or unauthorized modification or repair of the product, or if it has been

handled or stored other than in accordance with Wacom’s storage instructions.

WHAT ARE THE REMEDIES UNDER THIS WARRANTY?

Wacom’s sole obligation and entire liability under this limited warranty shall be,

at Wacom’s option, either the repair or replacement of the defective product or

parts thereof of which Wacom is notified during the Warranty Period; provided,

however, that you are responsible for (i) the cost of transportation of the product

to the designated service location and (ii) any loss or damage to the product

resulting from such transportation. Wacom will pay for return shipping by United

Parcel Service or by an equivalent service as chosen by Wacom.

HOW CAN YOU OBTAIN WARRANTY SERVICES?

Upon discovery of a defect in a covered product within the Warranty Period, you

should contact Wacom Technical Support via telephone, email, or fax to obtain

an RMA (Return Merchandise Authorization) number and instructions for shipping

the product to a service location designated by Wacom.

To obtain Warranty service, contact:

Wacom Customer Care Center

1-503-525-3100

www.wacom.com

You should send the product, shipping charges prepaid, to the designated

service location, accompanied by the RMA, your name, address and telephone

number, proof of purchase date, and a description of the defect.

DISCLAIMER; LIMITATION OF LIABILITY

Any descriptions, drawings, specifications, samples, models, bulletins, or similar

material, used in connection with the sale of the product shall not be construed

as an express warranty that the product will conform or comply with your

requirements.

EXCEPT FOR THE LIMITED WARRANTY DESCRIBED ABOVE, THERE ARE NO

OTHER WARRANTIES MADE BY WACOM ON ANY COVERED PRODUCT. NO

ORAL OR WRITTEN INFORMATION OR ADVICE GIVEN BY WACOM, ITS

DEALERS, DISTRIBUTORS, AGENTS, OR EMPLOYEES SHALL CREATE A

WARRANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY,

AND YOU MAY NOT RELY ON ANY SUCH INFORMATION OR ADVICE. THIS

WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO

HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE AND COUNTRY

TO COUNTRY. WACOM LIMITS THE DURATION OF ANY LEGALLY IMPLIED

WARRANTIES INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY OR

FITNESS FOR A PARTICULAR PURPOSE, TO THE DURATION OF WACOM’S

EXPRESS WARRANTY. SOME STATES AND COUNTRIES DO NOT ALLOW

LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE

ABOVE LIMITATION MAY NOT APPLY TO YOU. NEITHER WACOM NOR

ANYONE ELSE WHO HAS BEEN INVOLVED IN THE CREATION, PRODUCTION,

OR DELIVERY OF THIS PRODUCT SHALL BE LIABLE FOR ANY DIRECT,

CONSEQUENTIAL, OR INCIDENTAL DAMAGES (INCLUDING DAMAGES FOR

LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF

BUSINESS INFORMATION AND THE LIKE) ARISING OUT OF THE USE OF OR

INABILITY TO USE SUCH PRODUCT, EVEN IF WACOM HAS BEEN ADVISED

OF THE POSSIBILITY OF SUCH DAMAGES. SOME STATES AND COUNTRIES

DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR

CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION

MAY NOT APPLY TO YOU.

In the event that any of the above limitations are held unenforceable, Wacom’s

liability for any damages to you or any party shall not exceed the purchase price

you paid, regardless of the form of any claim. This limited warranty is governed

by the laws of the United States of America and the State of Oregon. This limited

warranty is valid for and only applies to products purchased and used inside the

United States (and its territories or possessions) or Canada.

Should you have any questions about this limited warranty, or if you desire to

contact Wacom for any reason, please contact us in writing at:

Wacom Technology Corporation

1455 NW Irving Street, Suite 800

Portland OR 97209

USA

LIMITED WARRANTY

(CENTRAL AMERICA, SOUTH AMERICA AND THE CARIBBEAN)

Wacom warrants the product, to the original consumer purchaser, except for the

Software and consumable items such as the battery, pen cartridges, tablet

surface sheet and nibs, to be free from defects in materials and workmanship

under normal use and service for a period of three (3) years, from the date of

original retail purchase, as evidenced by a copy of the receipt and registration

with Wacom within 30 days of purchase.

The Software is licensed “as is.” Wacom makes no warranty with respect to its

quality or performance. Wacom cannot guarantee you uninterrupted service or

the correction of any errors.

Upon discovery of a defect in the product, except in the Software, within the

Warranty Period, you should contact Wacom Technical Support via telephone,

email, or fax to obtain an RMA (Return Merchandise Authorization) number and

instructions for shipping the product to a service location designated by Wacom.

You should send the product, shipping charges prepaid, to the designated

service location, accompanied by the return authorization number, your name,

address and telephone number, proof of purchase date, and a description of the

defect. Wacom will pay for return shipping by United Parcel Service or by an

equivalent service as chosen by Wacom.

Wacom’s sole obligation and entire liability under this warranty shall be, at

Wacom’s option, either the repair or replacement of the defective product or

parts thereof of which Wacom is notified during the Warranty Period; provided,

however, that you are responsible for (i) the cost of transportation of the product

to the designated service location and (ii) any loss or damage to the product

resulting from such transportation.

Wacom shall have no responsibility to repair or replace the product if the failure

of the product has resulted from accident, abuse, misuse, negligence, or

unauthorized modification or repair, or if it has been handled or stored other than

in accordance with Wacom’s storage instructions. Any descriptions, drawings,

specifications, samples, models, bulletins, or similar material, used in connection

with the sale of the product, shall not be construed as an express warranty that

the product will conform or comply with your requirements.

EXCEPT FOR THE LIMITED WARRANTY DESCRIBED ABOVE, THERE ARE NO

OTHER WARRANTIES MADE BY WACOM ON THIS PRODUCT. NO ORAL OR

WRITTEN INFORMATION OR ADVICE GIVEN BY WACOM, ITS DEALERS,

DISTRIBUTORS, AGENTS, OR EMPLOYEES SHALL CREATE A WARRANTY OR

IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY, AND YOU MAY

NOT RELY ON ANY SUCH INFORMATION OR ADVICE. THIS WARRANTY

GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER

RIGHTS WHICH VARY FROM COUNTRY TO COUNTRY.

WACOM LIMITS THE DURATION OF ANY LEGALLY IMPLIED WARRANTIES

INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR

A PARTICULAR PURPOSE, TO THE DURATION OF WACOM’S EXPRESS

WARRANTY. SOME COUNTRIES DO NOT ALLOW LIMITATIONS ON HOW

LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT

APPLY TO YOU.

NEITHER WACOM NOR ANYONE ELSE WHO HAS BEEN INVOLVED IN THE

CREATION, PRODUCTION, OR DELIVERY OF THIS PRODUCT SHALL BE

LIABLE FOR ANY DIRECT, CONSEQUENTIAL, OR INCIDENTAL DAMAGES

(INCLUDING DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS

INTERRUPTION, LOSS OF BUSINESS INFORMATION AND THE LIKE) ARISING

OUT OF THE USE OF OR INABILITY TO USE SUCH PRODUCT, EVEN IF

WACOM HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

SOME COUNTRIES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF

INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION

OR EXCLUSION MAY NOT APPLY TO YOU.

In the event that any of the above limitations are held unenforceable, Wacom’s

liability for any damages to you or any party shall not exceed the purchase price

you paid, regardless of the form of any claim. This Limited Warranty is governed

by the laws of the United States of America and the state of Oregon. This Limited

Warranty is valid for and only applies to products purchased and used inside

Central America, South America or the Caribbean.

WARRANTY SERVICE

To obtain Warranty service within Central America, South America or the

Caribbean contact your local dealer or distributor.

Wacom Customer Care Center

Spanish: http://www.wacom.com/sp/productsupport/email.cfm

Portuguese: http://www.wacom.com/pr/productsupport/email.cfm

Should you have any questions about this Agreement, or if you desire to contact

Wacom for any reason, please contact in writing:

Wacom Technology Corporation

1455 NW Irving Street Suite 800

Portland OR 97209

USA

LIMITED WARRANTY

(EUROPE, AFRICA AND MIDDLE EAST)

WACOM warrants to you, as the initial purchaser, (hereinafter referred to as

“you” or “the customer”) that the product hardware will remain free from defects

in materials and workmanship under normal use and service for a warranty

period of THREE (3) YEARS, commencing from the purchase date and provided

that the product was unused at the time of purchase. Defects in wear parts (e.g.,

pen nibs, tablet surfaces and batteries) resulting from normal wear and tear are

exempt from the warranty. Furthermore, WACOM warrants that the data carriers

delivered with the product are free from defects in materials and workmanship

under normal use for a period of SIX (6) MONTHS from the date of purchase.

If during the applicable warranty period the product, excluding any software, is

discovered to be defective, it should be returned immediately to the place of

purchase in its original packaging together with your name, address, and

telephone number, a description of the problem, and a copy of the original

receipt. The customer shall be liable for any possible damage or loss of the

product during transit to the place of purchase for this purpose.

WACOM’s sole obligation and entire liability under this warranty shall be, at

WACOM’s option, either the repair or the replacement of the product or parts

thereof that prove defective and that were returned within the applicable

warranty period.

WACOM does not warrant to repair or replace the product if: (a) the damage to

the product results from accident, misuse, improper use, negligence or

unauthorised alteration or repair; (b) the product was not handled or stored

according to the instructions provided by WACOM; (c) the damage resulted from

normal wear and tear of product parts; or d) the serial number affixed by

WACOM has been removed or rendered unintelligible.

Any descriptions, drawings, specifications, samples, models, notifications or

similar material provided in connection with the purchase of the product cannot

be taken as an explicit guarantee that the product corresponds to or fulfils your

requirements.

The warranty guaranteed by law remains unaffected. You can claim defects of

the product in accordance with the relevant legal provisions.

WACOM shall only be liable for itself and its vicarious agents if a material

contractual obligation has been culpably breached in a manner jeopardising the

purpose of the contract or the damage is due to intentional acts or omissions or

gross negligence. A material contractual obligation is an obligation which is

essential to the proper performance of the contract on which the other party will

typically rely. In case that the culpable infringement of such a material

contractual obligation is not due to intention or gross negligence, the liability of a

party shall be limited to such damages being typical for the contract and which

were reasonably foreseeable at the time of the closure of the contract. Where

these Terms and Conditions preclude or limit liability, this also applies to the

personal liability of the executive officers of the party concerned, its employees,

agents and subcontractors. The provisions of the product liability law

(Produkthaftungsgesetz) remain unaffected.

If, when a claim made under this warranty is checked, it emerges that it is

outside the permitted time period or is not covered by the warranty or that the

product is not defective, the customer will reimburse WACOM for associated

costs.

This limited warranty shall apply if the registered office of the vendor is situated

in the EU or Iceland, Norway, Jersey, Switzerland, Russia, the Ukraine, Croatia,

Serbia, Tunisia, Turkey, Syria, Lebanon, Jordan, Israel, Egypt, the United Arab

Emirates, Iran or South Africa.

This warranty is subject to German law. However, the applicability of the United

Nations Convention on Contracts for the International Sale of Goods is explicitly

excluded. The city of Düsseldorf, Germany, is the sole place of jurisdiction for all

claims arising from this contractual relationship and all disputes between the

parties resulting from the formation, handling or termination of the contractual

relationship, provided that the customer is a trader, a legal entity or fund under

public law. The jurisdiction agreement shall also apply for customers who do not

have a general place of jurisdiction in Germany. The jurisdiction agreement shall

not apply if, due to legal provisions, a different sole place of jurisdiction must be

established for the case.

Furthermore, WACOM is authorised to file a lawsuit against the headquarters of

the customer. Should one of the provisions of this limited warranty be or become

void, the validity of the other provisions shall not be affected, in full or in part.

Should a provision be invalid, the legally permissible regulation most closely

resembling the invalid regulation shall apply in its place. If you have any

questions about this agreement, or would like to contact WACOM for another

reason, please write to us at this address:

WACOM Europe GmbH

Völklinger Straße 1

40219 Düsseldorf

Germany

LIMITED WARRANTY

(ASIA PACIFIC REGION)

Wacom Co., Ltd. warrants the product, to the original consumer purchaser, to be

free from defects in materials and workmanship under normal use and service for

a period of one year, from the date of original retail purchase, as evidenced by a

copy of the receipt (proof of purchase).

The Software is licensed “as is.” Wacom makes no warranty with respect to its

quality or performance or others. Wacom cannot guarantee you uninterrupted

service or the correction of any errors. Wacom also makes no warranty for

consumable items such as pen cartridges, glass panel and nibs.

Upon discovery of a defect in the product, except in the Software, within the

Warranty Period, the warranty holder must contact the original place of purchase

to obtain instructions for returning the product for repair or replacement. Wacom

and its partners are not obligated to reimburse unauthorized prepaid shipment.

The warranty holder is under no obligation to pay for shipment charges between

the original place of purchase and the place of repair or replacement.

Wacom’s sole obligation and entire liability under this warranty shall be, at

Wacom’s option, either the repair or replacement of the defective product or

parts thereof of which Wacom is notified during the Warranty Period.

Wacom shall have no responsibility to repair or replace the product if the failure

of the product has resulted from force majeure including but not limited to fire,

natural disasters, accident, and act of God; intentional or accidental abuse,

misuse, negligence, unauthorized modification or repair, usage of this product in

a fashion other than as explained in the document, or if the product has been

handled or stored other than in accordance with Wacom’s storage instructions.

Any descriptions, drawings, specifications, samples, models, bulletins, or similar

material, used in connection with the sale of the product, shall not be construed

as an express warranty that the product will conform or comply with your

requirements.

EXCEPT FOR THE LIMITED WARRANTY DESCRIBED ABOVE, THERE ARE NO

OTHER WARRANTIES MADE BY WACOM ON THIS PRODUCT. NO ORAL OR

WRITTEN INFORMATION OR ADVICE GIVEN BY WACOM, ITS DEALERS,

DISTRIBUTORS, AGENTS, OR EMPLOYEES SHALL CREATE A WARRANTY OR

IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY, AND YOU MAY

NOT RELY ON ANY SUCH INFORMATION OR ADVICE.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO

HAVE OTHER RIGHTS WHICH VARY FROM COUNTRY TO COUNTRY. WACOM

LIMITS THE DURATION OF ANY LEGALLY IMPLIED WARRANTIES INCLUDING

IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE, TO THE DURATION OF WACOM’S EXPRESS

WARRANTY.

SOME COUNTRIES DO NOT ALLOW LIMITATIONS ON HOW LONG AN

IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY

TO YOU. NEITHER WACOM NOR ANYONE ELSE WHO HAS BEEN INVOLVED

IN THE CREATION, PRODUCTION, OR DELIVERY OF THIS PRODUCT SHALL

BE LIABLE FOR ANY DIRECT, CONSEQUENTIAL, OR INCIDENTAL DAMAGES

(INCLUDING DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS

INTERRUPTION, LOSS OF BUSINESS INFORMATION AND THE LIKE) ARISING

OUT OF THE USE OF OR INABILITY TO USE SUCH PRODUCT, EVEN IF

WACOM HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

SOME COUNTRIES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF

INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION

OR EXCLUSION MAY NOT APPLY TO YOU.

In the event that any of the above limitations are held unenforceable, Wacom’s

liability for any damages to you or any party shall not exceed the purchase price

you paid, regardless of the form of any claim.

This Limited Warranty is valid for and only applies to products purchased and

used inside the countries and territories of Asia Pacific excluding Japan, the

People’s Republic of China, Hong Kong, and countries in the Middle East.

This Limited Warranty is a statement of the current warranty policy of the Asia

Pacific Division of Wacom Co., Ltd. and takes precedent over all other warranty

statements contained in packaging, brochures, manuals, etc.

This Limited Warranty is governed by the laws of Japan and is subject to change

without prior notice.

Australian Consumer law

Our goods come with guarantees that cannot be excluded under the Australian

Consumer Law. You are entitled to a replacement or refund for a major failure

and for compensation for any other reasonably foreseeable loss or damage. You

are also entitled to have the goods repaired or replaced if the goods fail to be of

acceptable quality and the failure does not amount to a major failure. Our

hardware products come with a one year warranty given by Wacom Co., Ltd.

with a subsidiary located at Wacom Australia Pty. Ltd. Ground Floor, Building 1,

3 Richardson Place, North Ryde, NSW, 2113, Australia. If your products do not

provide the general features and functions described in the User Documentation

in the one (1) year period after delivery to you please contact Wacom Australia

Pty. Ltd. Contact us via http://support.wacom.asia/customer-care with details of

your product, serial number, and proof of purchase. You may be required to

return the hardware product to the address we provide to you at the time. The

benefits under this warranty are in addition to other rights and remedies that you

may have at law.

Warranty Service/Wacom Technical Support in Asia Pacific (except Japan, the

People’s Republic of China, Hong Kong, and countries in the Middle East), the

detailed Asia Pacific Limited Warranty policy and product registration may be

found online at http://support.wacom.asia/.

To obtain technical support or Warranty service within Southeast and South Asia,

Oceania and Taiwan, please contact the Wacom Customer Support Service via

https://support.wacom.asia/. Should you have any questions about this

Agreement, or if you desire to contact Wacom for any reason, please contact

through this website : https://support.wacom.asia/

Precaution

For the full version of the DTK-2451, DTH-2452 Important Product Information

document, go to www.wacom.com and click on Support.

- To ensure the safe operation of the device, be sure to follow all instructions,

cautions, and warnings found within this document. Failure to do so could void

your warranty, in which case Wacom shall have no responsibility to repair or

replace the device.

- The device should be used in normal office environments. It can also be used

as a center console in climate-controlled environments. The device was tested

by Wacom for usage in a normal office environment only and was not tested for

compatibility in medical and military environments.

- Only use the cables specified for use with the device. If you ignore this warning,

you might create a fire hazard, experience electrical shock, or cause device

failure. If you use a different cable, you will void your warranty.

- To protect the health of your eyes when using the device:

• Use the device in a well-lit room only, and do not sit too close to the display

screen.

• Take regular breaks when using the device for extended periods of time.

- Do not open or disassemble the device. If you ignore this warning, you might

experience electrical shock when the casing is open, you will void your warranty,

and Wacom shall have no responsibility to repair or replace the device.

- Choking hazard. Prevent children from swallowing the pen tip. Prevent children

from playing with any packing materials or wrapping, as a choking or suffocation

hazard may exist.

- Touching the device (LCD panels and other areas) repeatedly for extended

periods of time may cause low temperature burns.

- Dispose of devices properly, according to your local ordinances and laws.

- Handle the display stand carefully. When lifting the stand, hold the body of the

stand. Do not use excessive force when opening or closing the stand.

Specifications

General Specifications

Dimensions (W × H × D) 601 x 356 x 46 mm, 23.6 x 14 x 1.8 inch

(e×cluding the Stand)

Weight 7.2kg, 254 oz (including the Stand)

Operating temperature &

humidity 5 to 40 degrees C, Humidity: 30% to 80% RH

(non-condensing)

Storage temperature &

humidity -20 to 60 degree C, Humidity: 30% to 90% RH

(non-condensing)

(Maximum storage humidity is 38% at a temperature

of 60 degree C, and maximum strage temperature is

42 degree C at a humidity of 90%.)

Power Consumption

(with AC adaptor) 45 W(110VAC) or less (Full load)

0.5W or less in sleep mode (USB non-connected)

0.5 W or less in OFF mode

USB HUB Up stream: 1 Down stream: 3 (internal; 2, external; 1)

Load current is Maximum 0.5A per port.

Display

Display Panel VA Mode, Normally Black

Screen Size 23.8inch (527.04(H) x 296.46 (V) mm)

Aspect ratio 16:9

Number of pixels 1920 × 1080

Input Video Connector DVI-I (29 pin)

Input Video Signal DVI 1.0 compliance

Analog RGB

Output Video Connector DVI-I (29 pin)

Output Video Signal DVI 1.0 compliance

Analog RGB

Supported Resolution 1920×1080, 1680×1050, 1366×768, 1280×1024,

1024×768, 1280×800,

800×600, 640×480 pi×els

Pixel Pitch 0.2745 (H) x 0.2745 (V) mm

Viewing Angles @ CR>10

(horizontal/vertical) 178(89/89) / 178(89/89) (typ.)

Display Colors 16,7M colors (Depends on display card used.)

Contrast Ratio 1000:1 (typ.)

Luminance 210 cd/m2 (typ.)

LCD quality Each LCD panel is produced under very stringent

quality standards. Production techniques cannot

guarantee an absolutely perfect TFT display.

Wacom does not allow any pixel to be always

whiteor always black. A small number of pixels

areallowed to show a wrong color for some

parts of the color spectrum. This does not mean

thedisplay is defective.

Pen tablet

Reading Technology Electro-magnetic resonance technology

Active area 479.2 x 271.3 mm

Resolution 0.01 mm/point (2540 lpi)

Accuracy ± 0.5mm (center), the edge area 1 (20mm wide from

edge of display area) to be ± 2.0mm, the edge area 2

(3mm wide from edge of dsplay area) to be ± 4.0mm

Reading Height 10 mm or more (Center)

Maximum Report Rate 187 points/sec

Pressure levels 2048 levels

Communication Interface USB

Power adapter

Input voltage 100 to 240 VAC, 50/60Hz

Output voltage 12 VDC, 5 A (max)

Pen

Physical size (L × D) 156.5 x 11.5 mm

Weight 17 g, approximate

Touch DTH-2452

Technology type Projected capacitive

Resolution 0.03 mm/point

Coordinate Accuracy ±1mm (contact location is greater than 3.5mm from

digitizer edge)

Maximum Report Rate 100 point/sec

DE:

Wichtige Produktinformationen – Kurzversion

Garantieerklärung

Garantie: 3 Jahre in Europa, Afrika und im Nahen Osten.

Für Garantieinformationen für den DTK-2451, DTH-2452 gehen Sie zu

www.wacom.com und klicken auf Support.

Vorsichtsmaßnahme

Für die vollständige Version des Dokuments „Wichtige Produktinformationen”

für den DTK-2451, DTH-2452 gehen Sie zu www.wacom.com und klicken auf

Support.

- Beachten Sie alle Anweisungen, Vorsichtshinweise und Warnungen in diesem

Dokument, damit der sichere Betrieb des Geräts gewährleistet ist. Bei Nicht-

beachtung erlischt Ihr Garantieanspruch und Wacom übernimmt keine

Verantwortung für die Reparatur oder den Ersatz des Geräts.

- Das Gerät ist für den Gebrauch in einer normalen Büroumgebung konzipiert.

Es kann aber auch als Mittelkonsole in klimatisierten Umgebungen verwendet

werden. Das Gerät wurde von Wacom nur für den Gebrauch in einer normalen

Büroumgebung getestet und es wurde keine Überprüfung hinsichtlich des

Gebrauchs in medizinischen und militärischen Einrichtungen durchgeführt.

- Verwenden Sie nur die für dieses Gerät angegebenen Kabel. Wenn Sie diese

Warnung ignorieren, besteht die Gefahr eines Brands, eines Stromschlags

oder eines Gerätefehlers. Wenn Sie ein anderes Kabel verwenden, erlischt der

Garantieanspruch.

- So schonen Sie Ihre Augen bei Verwendung des Geräts:

• Verwenden Sie das Gerät nur in einem gut beleuchteten Raum und setzen

Sie sich nicht zu nah an den Bildschirm.

• Machen Sie regelmäßige Pausen, wenn Sie das Gerät länger verwenden.

- Öffnen bzw. zerlegen Sie das Gerät nicht. Wenn Sie diese Warnung ignorieren,

besteht die Gefahr eines Stromschlags. Ihr Garantieanspruch erlischt und

Wacom übernimmt keine Verantwortung für die Reparatur oder den Ersatz des

Geräts.

- Erstickungsgefahr. Bewahren Sie die Stiftspitze außerhalb der Reichweite von

Kindern auf. Halten Sie Verpackungsmaterial und Umhüllungen von Kindern fern,

da sie ein Erstickungsrisiko darstellen.

- Wenn das Gerät (LCD-Bildschirm und andere Teile) über einen längeren

Zeitraum wiederholt berührt wird, können Verbrennungen die Folge sein.

- Entsorgen Sie Geräte ordnungsgemäß entsprechend den lokalen Bestimmungen

und Gesetzen.

- Behandeln Sie den Display-Standfuß sorgfältig. Wenn Sie den Standfuß

anheben, halten Sie ihn an seinem Gehäuse fest. Wenden Sie beim Öffnen oder

Schließen des Standfußes keine übermäßige Kraft an.

Technische Daten

Allgemeine technische Daten

Abmessungen

(B × H × T) 601 x 356 x 46 mm (ohne Standfuß)

Gewicht 7,2kg (inklusive Standfuß)

Betriebstemperatur und

Luftfeuchtigkeit 5 bis 40°C, relative Luftfeuchtigkeit: 30 bis 80%

(nicht kondensierend)

Temperatur &

Luftfeuchtigkeit bei

Lagerung

-20 bis 60°C, relative Luftfeuchtigkeit: 30 bis 90%

(nicht kondensierend)

(Maximale Luftfeuchtigkeit bei Lagerung: 38 % bei

einer Temperatur von 60 °C. Maximale

Lagertemperatur: 42°C bei einer Luftfeuchtigkeit von

90 %.)

Leistungsaufnahme

(mit Netzadapter) max. 45 W (110 VAC) (Volllast)

maximal 0,5W im Standby-Modus

(USB nicht angeschlossen)

maximal 0,5W im AUS-Modus

USB-Hub Upstream: 1, Downstream: 3 (intern: 2, extern: 1)

Der Ladestrom beträgt maximal 0,5A pro Anschluss.

Display

Display VA-Modus, Normally Black

Bildschirmmaße 23,8 Zoll (527,04 (B) x 296,46 (H)mm)

Seitenverhältnis 16:9

Anzahl der Pixel 1920 × 1080

Videoeingang DVI-I (29Pin)

Eingehendes Bildsignal DVI1.0-Kompatibilität

Analoger RGB-Eingang

Videoausgang DVI-I (29Pin)

Ausgehendes Bildsignal DVI1.0-Kompatibilität

Analoger RGB-Eingang

Unterstützte Auflösungen 1920×1080, 1680×1050, 1366×768, 1280×1024,

1024×768, 1280×800,

800×600, 640×480 Bildpunkte

Punktabstand 0,2745x0,2745mm (HxV)

Blickwinkel bei

Kontrastverhältnis >10

(horizontal/vertikal)

178 (89/89)/ 178 (89/89) (typisch)

Anzeigefarben 16,7 Mio. Farben (in Abhängigkeit von der

verwendeten Display-Karte.)

Kontrastverhältnis 1000:1 (typ.)

Helligkeit 210 cd/m2 (typ.)

LCD-Qualität Jeder LCD-Bildschirm wird unter Einhaltung strenger

Qualitätsstandards hergestellt. Herstellungsbedingt

kann kein absolut perfektes TFT-Display garantiert

werden. Wacom lässt nicht zu, dass ein einzelnes

Pixel immer weiß oder immer schwarz ist. Eine

geringe Anzahl von Pixeln darf für bestimmte Teile

des Farbspektrums jedoch eine falsche Farbe

aufweisen. Dies bedeutet nicht, dass die Anzeige

fehlerhaft ist.

Stifttablett

Lesetechnik Elektromagnetische Resonanztechnologie

Aktive Fläche 479,2 x 271,3mm

Auflösung 0,01mm/Punkt (2540lpi)

Genauigkeit ± 0,5mm (Mitte), im Randbereich 1 (20mm vom

Rand der Displayfläche) voraussichtlich ± 2,0 mm, im

Randbereich 2 (3mm vom Rand der Displayfläche)

voraussichtlich ± 4,0 mm

Lesehöhe 10mm oder mehr (Mitte)

Maximale

Übertragungsrate 187Punkte/Sek.

Druckstufen 2048Stufen

Kommunikations-

schnittstelle USB

Netzadapter

Eingangsspannung 100 bis 240V Wechselstrom, 50/60Hz

Ausgangsspannung 12 VDC, max. 5 A

Stift

Abmessungen (L × T) 156,5 x 11,5 mm

Gewicht ca. 17 g

Touch-Eingabe DTH-2452

Technologietyp Projiziert-kapazitiv

Auflösung 0,03mm/Punkt

Koordinatengenauigkeit ±1mm (Kontaktpunkt mehr als 3,5 mm vom Rand

des Digitalisierers entfernt)

Maximale

Übertragungsrate 100 Punkte/Sek.

NL:

Belangrijke productinformatie – korte versie

Garantieverklaring

Garantie: 3 jaar in Europa, Afrika en het Midden-Oosten.

Voor informatie over garantie voor DTK-2451, DTH-2452, ga naar www.wacom.

com en klik op Support.

Voorzorgsmaatregel

Voor de volledige versie van het document Belangrijke productinformatie over de

DTK-2451, DTH-2452, ga naar www.wacom.com en klik op Support.

- Voor een veilig gebruik van het apparaat moet u alle instructies,

voorzorgsmaatregelen en waarschuwingen in dit document volgen. Als dit wordt

nagelaten kan het recht op garantie vervallen. In dat geval is Wacom niet

verplicht het apparaat te vervangen of te repareren.

- Het apparaat is bestemd voor gebruik in normale kantooromgevingen. Het kan

ook worden gebruikt als centrale console in omgevingen met klimaatbeheersing.

Het apparaat is door Wacom alleen getest voor gebruik in een normale

kantooromgeving en er is niet getest op de toepasbaarheid in medische en

militaire omgevingen.

- Gebruik alleen de kabels die worden aangegeven voor gebruik met het

apparaat. Als u deze waarschuwing negeert, kunt u brandgevaar veroorzaken,

een elektrische schok krijgen of een storing in het apparaat veroorzaken.

Als u een andere kabel gebruikt, vervalt uw recht op garantie.

- Ter bescherming van de gezondheid van uw ogen bij het gebruik van het

apparaat:

• Gebruik het apparaat uitsluitend in een goed verlichte kamer en ga niet te

dicht bij het scherm zitten.

• Neem regelmatig pauze wanneer u het apparaat langere tijd achtereen

gebruikt.

- Open of demonteer het apparaat niet. Als u deze waarschuwing negeert, kunt

u een elektrische schok krijgen als de behuizing open is, vervalt uw recht op

garantie en is Wacom niet verplicht het apparaat te repareren of te vervangen.

- Verstikkingsgevaar. Let erop dat kinderen de penpunt niet in de mond nemen.

Zorg dat kinderen niet met verpakkingsmateriaal kunnen spelen. Dit met het

oog op verstikkingsgevaar.

- Als een lichaamsdeel vaker langere tijd met het apparaat (LCD-scherm of ander

onderdeel) in aanraking komt, kan dit tot eerstegraads brandwonden leiden.

- Gooi dit product op de juiste wijze weg en houd u bij het weggooien aan de

lokale regel- en wetgeving.

- Ga voorzichtig om met de displaystandaard. Als u de standaard optilt, houd

dan het lichaam van de standaard vast. Gebruik niet buitensporig veel kracht bij

het openen of sluiten van de standaard.

Specificaties

Algemene specificaties

Afmetingen (B × H × D) 601 x 356 x 46 mm (exclusief de standaard)

Gewicht 7,2 kg (inclusief de standaard)

Bedrijfstemperatuur

enluchtvochtigheid 5°C tot 40°C, Luchtvochtigheid: 30% tot 80%

relatieve luchtvochtigheid (niet-condenserend)

Opslagtemperatuur

enluchtvochtigheid -20°C tot 60°C, Luchtvochtigheid: 30% tot 90%

relatieve luchtvochtigheid (niet-condenserend)

(Maximale luchtvochtigheid tijdens opslag bedraagt

38% bij een temperatuur van 60 °C en de maximale

opslagtemperatuur bedraagt 42 °C bij een

luchtvochtigheid van 90%.)

Stroomverbruik

(met AC-adapter) 45 W (110 V AC) of minder (max. belasting)

0,5 W of minder in slaapstand (USB niet aangesloten)

0,5 W of minder indien uitgeschakeld

USB-HUB Upstream: 1 Downstream: 3 (intern; 2, extern; 1)

Laadspanning is maximaal 0,5 A per poort.

Display

Display VA-modus, normaal zwart

Schermafmetingen 23,8 inch (527,04 (H) x 296.46 (V) mm))

Verhouding 16:9

Aantal pixels 1920 × 1080

Invoervideoaansluiting DVI-I (29-pins)

Invoervideosignaal voldoet aan DVI 1.0

RGB analoog

Uitvoervideoaansluiting DVI-I (29-pins)

Uitvoervideosignaal voldoet aan DVI 1.0

RGB analoog

Ondersteunde resolutie 1920×1080, 1680×1050, 1366×768, 1280×1024,

1024×768, 1280×800,

800×600, 640×480 pixels

Pixel Pitch 0,2745 (h) x 0,2745 (v) mm

Kijkhoeken bij CR>10

(horizontaal/verticaal) 178(89/89) / 178(89/89) (standaard)

Weergavekleuren 16,7M kleuren (hangt af van gebruikte videokaart.)

Contrastverhouding 1000:1 (standaard)

Helderheid 210 cd/m2 (standaard)

LCD-kwaliteit Elk LCD-beeldscherm wordt onder zeer strenge

kwaliteitsnormen geproduceerd. De productie-

technieken garanderen echter geen absoluut

perfecte TFT-weergave. Wacom staat niet toe

dateen pixel altijd wit of altijd zwart is. Een klein

aantal pixels mag een onjuiste kleur hebben

voorsommige delen van het kleurenspectrum.

Ditbetekent niet dat het beeldscherm defect is.

Pentablet

Leestechnologie Elektromagnetische resonantietechnologie

Actief venster 479,2 x 271,3 mm

Resolutie 0,01 mm/punt (2540 lpi)

Nauwkeurigheid ± 0,5 mm (midden), het randgebied 1 (20 mm brede

rand vanaf de rand van het weergavegebied) wordt ±

2,0 mm, het randgebied 2 (3 mm breed vanaf de

rand van weergavegebied) wordt ± 4,0 mm

Leesafstand 10 mm of meer (midden)

Maximale

overdrachtsnelheid 187 punten/sec

Drukniveaus 2048 niveaus

Communicatie-interface USB

Stroomadapter

Ingangsspanning 100 tot 240 V AC, 50/60 Hz

Uitgangsspanning 12 V DC, 5 A (max.)

Pen

Afmetingen (l x d) 156,5 x 11,5 mm

Gewicht Circa 17 g

Aanraakinvoer DTH-2452

Soort technologie Capacitief

Resolutie 0,03 mm/punt

Coördinaatnauwkeurigheid ±1 mm (contactlocatie is groter dan 3,5 mm vanaf de

rand van de digitizer)

Maximale

overdrachtsnelheid 100 punten/sec

FR:

Informations importantes sur le produit –

Version abrégée

Déclaration de garantie

Garantie: 3ans en Europe, en Afrique et au Moyen-orient.

Pour tout renseignement sur la garantie du produit DTK-2451, DTH-2452,

rendez-vous sur www.wacom.com, puis cliquez sur Support.

Précautions

Pour obtenir la version complète du document «Informations importantes sur le

produit» DTK-2451, DTH-2452, rendez-vous sur www.wacom.com, puis cliquez

sur Support.

- Pour garantir une utilisation sûre de l’appareil, respectez les avertissements et

les instructions contenus dans ce document. Le non-respect de ces indications

pourrait entraîner l’annulation de votre garantie. Si cela se produit, Wacom ne

sera en aucun cas tenue de réparer ou de remplacer l’appareil.

- L’appareil doit être utilisé dans un environnement de bureau normal. Il peut

également être utilisé en tant que console centrale dans des environnements

climatisés. Cet appareil a été testé par Wacom pour une utilisation dans un

environnement de bureau normal uniquement. Aucun test n’a été mené quant

àson compatibilité aux environnements médicaux ou militaires.

- N’utilisez que les câbles spécifiés pour l’utilisation avec cet appareil. Si vous

ignorez cet avertissement, vous risquez de causer un incendie, de subir une

décharge électrique ou d’occasionner une panne du dispositif. Ce faisant, vous

perdriez votre droit à la garantie.

- Pour protéger vos yeux lors de l’utilisation de l’appareil:

• Manipulez l’appareil dans une pièce bien éclairée uniquement. Évitez de vous

asseoir trop près de l’écran.

• Faites régulièrement des pauses lorsque vous utilisez l’appareil de manière

prolongée.

- N’ouvrez et ne démontez en aucun cas l’appareil. Si vous ignorez cet

avertissement, vous risquez de subir une décharge électrique quand le boîtier

est ouvert, auquel cas vous perdrez votre droit à la garantie. Si cela se produit,

DTK-2451, DTH-2452

Wacom ne sera en aucun cas tenue de réparer ou de remplacer l’appareil.

- Risque d’étouffement. Veillez à ce que les enfants n’avalent pas la pointe du

stylet. Veillez à ce que les enfants ne jouent pas avec l’emballage, car ils risquent

de s’étouffer.

- Le contact avec l’appareil (panneaux LCD et autres parties) de manière prolongée

peut entraîner des brûlures à basse température.

- Éliminez les appareils conformément aux lois et règlements locaux en vigueur.

- Manipulez le socle de l'écran avec précaution. Lorsque vous soulevez le socle,

tenez-le par le corps. N'appliquez pas de force excessive pour ouvrir ou fermer

le socle.

Caractéristiques

Spécifications générales

Dimensions (l × H × P) 601 x 356 x 46 mm (sans le socle)

Poids 7,2 kg (support inclus)

Température et humidité

de fonctionnement 5 à 40°C, humidité: 30% à 80% HR

(sans condensation)

Température et humidité

de stockage -20 à 60°C, humidité: 30% à 90% HR

(sans condensation)

(L'humidité maximale de stockage est de 38% à une

température de 60°C et la température maximale de

stockage est de 42°C pour une humidité de 90%)

Consommation

électrique (avec

adaptateur secteur)

45 W (110 V CA) ou moins (charge complète)

0,5W max. en mode veille (USB non connecté)

0,5W ou moins à l'arrêt

CONCENTRATEUR USB Flux supérieur: 1 Flux inférieur: 3 (interne: 2;

externe: 1)

Le courant de charge est de 0,5A maximum par port.

Écran

Écran Mode VA, normalement noir

Dimensions de l'écran 23,8 pouces (527,04 (h) x 296,46 (v) mm)

Rapport largeur/hauteur 16:9

Nombre de pixels 1920 × 1080

Connecteur d'entrée

vidéo DVI-I (29broches)

Signal d'entrée vidéo DVI 1.0

RVB analogique

Connecteur de sortie

vidéo DVI-I (29broches)

Signal de sortie vidéo DVI 1.0

RVB analogique

Résolutions prises

encharge 1920×1080, 1680×1050, 1366×768, 1280×1024,

1024×768, 1280×800,

800×600, 640×480 pixels

Pas du pixel 0,2745mm (H) x 0,2745mm (V)

Angles de vue @ CR>10

(horizontal/vertical) 178(89/89) / 178(89/89) (typ.)

Couleurs d'affichage 16,7 millions de couleurs (selon la carte graphique

utilisée.)

Rapport de contraste 1000:1 (typ.)

Luminosité 210 cd/m2 (typ.)

Qualité LCD Chacun des panneaux LCD répond à des normes

dequalité extrêmement rigoureuses. Les techniques

de production ne peuvent pas garantir la perfection

absolue de votre écranTFT. Wacom n'accepte pas

de pixels toujours blancs ou toujours noirs. Un petit

nombre de pixels peuvent afficher une couleur

incorrecte pour certaines parties du spectre lumineux.

Cela ne signifie pas que l’affichage est défectueux.

Tablette à stylet

Technologie de lecture Technologie de résonance électromagnétique

Zone active 479,2 x 271,3 mm

Résolution 0,01mm/point (2540lpi)

Précision ± 0,5 mm (au centre), la bordure 1 (20 mm de large à

partir du bord de la zone d'écran) de ± 2,0 mm, la

bordure 2 (3 mm de large à partir du bord de la zone

d'écran) de ± 4,0 mm

Hauteur de lecture 10mm ou plus (centre)

Vitesse maximale

delecture 187points/seconde

Niveaux de pression 2048niveaux

Interface de

communication USB

Adaptateur secteur

Tension d’entrée De 100 à 240VCA, 50/60Hz

Tension de sortie 12 V CC, 5 A (max.)

Stylet

Dimensions physiques

(LxD) 156,5 x 11,5 mm

Poids 17g, environ

Saisie tactile DTH-2452

Type de technologie Technologie capacitive projetée

Résolution 0,03mm/point

Précision des

coordonnées ± 1 mm (point de contact plus élevé de 3,5 mm par

rapport au bord numériseur)

Vitesse maximale

delecture 100points/seconde

IT:

Importanti informazioni sul prodotto –

Versione breve

Dichiarazione di garanzia

Garanzia: 3 anni in Europa, Africa, e Medio Oriente.

Per informazioni sulla garanzia di DTK-2451, DTH-2452 accedere a www.wacom.

com efare clic su Assistenza.

Precauzioni

Per la versione completa della documentazione riguardante le importanti

informazioni sul prodotto DTK-2451, DTH-2452 accedere a www.wacom.com e

fare clic su Assistenza.

- Per garantire un funzionamento sicuro del dispositivo, seguire le istruzioni, le

avvertenze e gli avvertimenti riportati nel presente documento. In caso contrario,

la garanzia perderebbe validità e Wacom non si assume alcuna responsabilità

relativa alla riparazione o sostituzione del dispositivo.

- Il dispositivo deve essere utilizzato in normali ambienti di ufficio. Può inoltre

essere utilizzato come console centrale in ambienti a temperatura controllata.

Il dispositivo è stato testato da Wacom per essere utilizzato solo in normali

ambienti di ufficio e non sono stati eseguiti controlli specifici relativamente alla

sua conformità alle attrezzature mediche e militari.

- Utilizzare esclusivamente i cavi specificati per l’utilizzo con il dispositivo.

La mancata osservanza di questa avvertenza potrebbe essere causa di incendi,

scosse elettriche, oppure guasti al dispositivo. L’utilizzo di un cavo diverso

rende non valida la garanzia.

- Per proteggere la salute degli occhi durante l’uso del dispositivo:

• Utilizzare il dispositivo solamente in un ambiente bene illuminato, e non

sedere troppo vicino allo schermo del display.

• Effettuare pause regolari quando si utilizza il dispositivo per lunghi periodi.

- Non aprire o smontare il dispositivo. La mancata osservanza di questa

avvertenza può essere causa di scosse elettriche quando il corpo del dispositivo

è aperto, la garanzia perderebbe validità e Wacom non si assume alcuna

responsabilità relativa alla riparazione o sostituzione del dispositivo.

- Pericolo di soffocamento. Impedire ai bambini di ingerire la punta della penna.

Impedire ai bambini di giocare con i materiali utilizzati per l’imballaggio al fine di

scongiurare il pericolo di soffocamento.

- Toccare a lungo e ripetutamente il dispositivo (pannelli LCD e altre aree) può

essere causa di ustioni da bassa temperatura.

- Smaltire i dispositivi correttamente secondo i regolamenti e le normative vigenti.

- Maneggiare con cautela il supporto per display. Durante il sollevamento del

supporto tenerne fermo il corpo. Non esercitare forza eccessiva quando viene

chiuso o aperto il supporto.

Specifiche

Specifiche generali

Dimensioni (L x A x P) 601 x 356 x 46 mm (escluso il supporto)

Peso 7,2 kg (incluso il supporto)

Temperatura e umidità

operative Da 5° a 40°C, umidità: dal 30 all'80%

(umidità relativa) senza formazione di condensa

Temperatura e umidità

diconservazione Da -20° a 60°C, umidità: dal 30 al 90% (umidità

relativa) senza formazione di condensa

(L'umidità massima di conservazione è del 38% a

una temperatura di 60 °C, mentre la temperatura

massima di conservazione è di 42 °C a un'umidità

del 90%).

Consumo energetico

(con adattatore CA) 45 W (110VAC) o inferiore (pieno carico)

0,5 W o inferiore in modalità Standby

(non connesso via USB)

0,5 W massimi a dispositivo spento

HUB USB A monte: 1 A valle: 3 (interno; 2, esterno; 1)

Corrente di carico di massimo 0,5 A per porta.

Display

Pannello display Modalità VA, normalmente nero

Dimensioni schermo 23,8 pollici (527,04 (orizzontale) x 296,46 (verticale)

mm)

Rapporto delle

proporzioni 16:9

Numero di pixel 1920 × 1080

Connettore video

diingresso DVI-I (29 pin)

Segnale di ingresso

video Conformità DVI 1.0

RGB analogico

Connettore di uscita

video DVI-I (29 pin)

PRN-B151 (B)

Segnale di uscita video Conformità DVI 1.0

RGB analogico

Risoluzione supportata 1920 × 1080, 1680 × 1050, 1366 × 768, 1280 × 1024,

1024 × 768, 1280 × 800,

800×600, 640×480 pixel

Passo dei pixel 0,2745 (H) x 0,2745 (V) mm

Angoli di visualizzazione

con rapporto di

contrasto >10

(orizzontale/verticale)

178 (89/89) / 178 (89/89) (tipico)

Colori del display 16,7 milioni di colori (a seconda della scheda video

utilizzata.)

Rapporto contrasto 1000:1 (tipico.)

Luminosità 210 cd/m2 (tipico.)

Qualità LCD Ciascun pannello LCD viene prodotto secondo

norme di qualità molto rigorose. Le tecniche di

produzione non garantiscono un display TFT

assolutamente privo di difetti. I pixel di Wacom non

sono mai solo bianchi o solo neri. Un piccolo numero

di pixel può essere di un colore errato per alcune

parti dello spettro del colore. Questo non significa

che il display sia difettoso.

Tavoletta con penna

Tecnologia di lettura Tecnologia basata su risonanza elettromagnetica

Area attiva 479,2 x 271,3 mm

Risoluzione 0,01 mm/punto (2540 lpi)

Precisione ± 0,5 mm (al centro), area al bordo 1 (larghezza 20

mm dal bordo dell'area di visualizzazione) ± 2,0 mm,

area al bordo 2 (larghezza 3 mm dal bordo dell'area

di visualizzazione) ± 4,0 mm

Altezza di lettura Almeno 10 mm (centro)

Velocità massima

ditrasmissione 187 punti/sec.

Livelli di pressione 2048 livelli

Interfaccia di

comunicazione USB

Adattatore di alimentazione

Voltaggio di entrata Da 100 a 240 VCA, 50/60 Hz

Voltaggio di uscita 12 VCC, 5 A (max)

Penna

Dimensioni (L × P) 156,5 x 11,5 mm

Peso circa 17 g

Input tattile DTH-2452

Tipo di tecnologia Tecnologia tattile capacitiva

Risoluzione 0,03v mm/punto

Precisione coordinate ±1 mm (il punto di contatto è maggiore di 3,5 mm dal

bordo del digitalizzatore)

Velocità massima

ditrasmissione 100 punti/sec.

ES:

Información importante sobre el producto –

Versión breve

Condiciones de la garantía

Garantía: 3 años en Europa, África y Oriente Medio.

Para ver la información sobre la garantía de DTK-2451, DTH-2452,

vaya a www.wacom.com y haga clic en Soporte.

Precaución

Para ver la versión completa del documento Información importante sobre el

producto de DTK-2451, DTH-2452, vaya a www.wacom.com y haga clic en

Soporte.

- Para garantizar el uso seguro del dispositivo, asegúrese de respetar todas las

instrucciones, precauciones y advertencias del presente documento. Si no las

respeta, podría anularse la garantía, en cuyo caso Wacom no asumirá

responsabilidad alguna sobre la reparación o sustitución del dispositivo.

- El dispositivo debe utilizarse en entornos de oficina habituales. También se puede

utilizar a modo de consola central en entornos de temperatura controlada. Wacom

ha probado el dispositivo únicamente para su uso en un entorno de oficina

habitual, y no ha probado su compatibilidad en entornos médicos y militares.

- Utilice solamente los cables especificados para el uso con el dispositivo. Si pasa

por alto esta advertencia, podría originar un riesgo de incendio, sufrir descargas

eléctricas o provocar fallos en el dispositivo. Si utiliza un cable diferente, anulará

su garantía.

- Para proteger su salud visual cuando utilice el dispositivo:

• Utilice el dispositivo únicamente en una habitación bien iluminada y no se

siente demasiado cerca de la pantalla.

• Realice pausas con regularidad cuando utilice el dispositivo durante largos

periodos de tiempo.

- No abra ni desmonte el dispositivo. Si pasa por alto esta advertencia, podría

sufrir una descarga eléctrica cuando la carcasa esté abierta; esto anulará

su garantía y Wacom no tendrá responsabilidad alguna sobre la reparación

osustitución del dispositivo.

- Peligro de asfixia. No permita que los niños se traguen la punta del lápiz.

No permita que los niños jueguen con los materiales del embalaje, p1-ya que puede

existir riesgo de asfixia.

- El contacto con el dispositivo (paneles LCD y otras zonas) repetidamente

durante periodos de tiempo prolongados puede causar quemaduras leves.

- Deseche los dispositivos correctamente, de acuerdo con las ordenanzas

yleyes locales.

- Manipule el soporte de la pantalla con cuidado. Cuando levante el soporte,

sujete el cuerpo del mismo. No emplee demasiada fuerza para abrir o cerrar

elsoporte.

Especificaciones

Especificaciones generales

Dimensiones

(An. x Al. x Pr.) 601 x 356 x 46mm (sin el soporte)

Peso 7,2 kg (soporte incluido)

Temperatura y humedad

de funcionamiento De 5 a 40°C, Humedad: del 30% al 80% de

humedad relativa (sin condensación)

Temperatura y humedad

de almacenamiento De -20 a 60°C, Humedad: del 30% al 90% de

humedad relativa (sin condensación)

(La humedad máxima de almacenamiento es del

38% a una temperatura de 60°C y, con una

humedad del 90%, la temperatura máxima de

almacenamiento es de 42°C).

Consumo de energía

(con adaptador de CA) 45W (110VAC) o menos (carga completa)

0,5W o menos en modo inactivo

(USB no conectado)

0,5 W o menos en modo OFF

CONCENTRADOR USB Ascendente: 1 Descendente: 3 (interno; 2, externo; 1)

La corriente de carga es de un máximo de 0,5A por

puerto.

Pantalla

Pantalla Modo VA, normalmente negro

Tamaño de pantalla 23,8 pulgadas [527,04 (H) x 296,46 (V) mm]

Relación de aspecto 16:9

Número de píxeles 1920 × 1080

Conector de entrada

devídeo DVI-I (29 pines)

Señal de vídeo

deentrada Conformidad con DVI 1.0

RGB analógico

Conector de salida

devídeo DVI-I (29 pines)

Señal de vídeo de salida Conformidad con DVI 1.0

RGB analógico

Resolución admitida 1920×1080, 1680×1050, 1366×768, 1280×1024,

1024×768, 1280×800,

800×600, 640×480 píxeles

Paso de píxel 0,2745 (H) x 0,2745 (V)mm

Ángulos de visualización

a CR>10

(horizontal/vertical)

178 (89/89)/178 (89/89) (típ.)

Colores de pantalla 16,7 M colores

(en función de la tarjeta de vídeo utilizada).

Relación de contraste 1000:1 (típ.)

Luminancia 210cd/m2 (típ.)

Calidad de LCD Cada uno de los paneles LCD se ha fabricado según

unos estándares de calidad muy exigentes. Las

técnicas de producción no pueden garantizar una

pantalla TFT absolutamente perfecta. Wacom no

permite que ningún píxel quede siempre blanco

osiempre negro. Se permite que un pequeño

número de píxeles muestre un color incorrecto

enalgunas partes del espectro de color. Esto no

significa que la pantalla sea defectuosa.

Pen tablet

Tecnología de lectura Tecnología de resonancia electromagnética

Área activa 479,2 x 271,3 mm

Resolución 0,01mm/punto (2540 lpi)

Precisión ± 0,5 mm (centro), la zona del borde 1 (20 mm de

ancho desde el borde de la pantalla) es de ± 2 mm,

la zona del borde 2 (3 mm de ancho desde el borde

de la pantalla) es de ± 4 mm

Altura de lectura 10 mm o más (centro)

Velocidad máxima

delectura 187 puntos/s

Niveles de presión 2048 niveles

Interfaz de

comunicaciones USB

Adaptador de corriente

Voltaje de entrada 100 a 240VAC, 50/60Hz

Voltaje de salida 12VCC, 5A (máx.)

Lápiz

Dimensiones (L × Pr) 156,5 x 11,5 mm

Peso 17 g, aproximadamente

Entrada táctil DTH-2452

Tipo de tecnología Capacitiva proyectada

Resolución 0,03 mm/punto

Precisión de

coordenadas ±1 mm (el punto de contacto es superior a 3,5 mm

desde el borde del digitalizador)

Velocidad máxima

delectura 100 puntos/s

PT:

Informações importantes sobre o produto –

Versão resumida

Declaração de garantia

Garantia: 3 anos na Europa, África e Oriente Médio.

Para informações sobre a garantia DTK-2451, DTH-2452 vá para www.wacom.

com eclique em Suporte.

Precaução

Para a versão completa do com as Informações importantes sobre o produto

DTK-2451, DTH-2452, vá para www.wacom.com e clique em Suporte.

- Para garantir a operação segura do dispositivo, siga todas as instruções,

cuidados e avisos encontrados neste documento. O descumprimento dessas

recomendações pode anular a garantia; nesse caso, a Wacom não se

responsabilizará pelo reparo ou substituição do dispositivo.

- O dispositivo deve ser usado em ambientes de escritório padrão. Ele também

pode ser usado como console central em ambientes climatizados. Este dispositivo

foi testado pela Wacom para uso somente em ambientes de escritório padrão

enão foi testado quanto à sua compatibilidade em ambientes de aplicações

médicas e militares.

- Utilize somente cabos especificados para uso com o dispositivo. Ignorar esta

advertência pode criar um perigo de incêndio, choque elétrico ou causar uma

falha no dispositivo. O uso de outro cabo anulará a garantia.

- Para proteger a saúde dos seus olhos ao utilizar o dispositivo:

• Use o dispositivo somente em uma sala bem iluminada e não se sente muito

próximo à tela do monitor.

• Faça intervalos regulares ao usar o dispositivo por períodos longos.

- Não abra nem desmonte o dispositivo. Se ignorar esta advertência, poderá

ocorrer choque elétrico quando a carcaça for aberta, a garantia será anulada

e a Wacom não será responsável por consertar ou substituir o dispositivo.

- Risco de asfixia. Tome cuidado para não deixar que crianças engulam a ponta

da caneta. Evite que as crianças brinquem com partes de embalagem, já que

podem existir riscos de choques ou sufocamento.

- Encostar no dispositivo (telas LCD ou outras áreas) repetidamente por períodos

longos pode causar queimaduras por baixa temperatura.

- Descarte os dispositivos corretamente, de acordo com as normas e leis locais.

- Manuseie o suporte da tela com cuidado. Ao levantar o suporte, segure toda a

estrutura do suporte. Não exerça muita força ao abrir ou fechar o suporte.

Especificações

Especificações gerais

Dimensões (L × A × P) 601 x 356 x 46 mm (exceto o suporte)

Peso 7,2 kg (incluindo suporte)

Temperatura e umidade

operacionais 5°C a 40°C, umidade: 30% a 80% de umidade

relativa (não condensada)

Temperatura e umidade

de armazenamento -20°C a 60°C, umidade: 30% a 90% de umidade

relativa (não condensada)

(A umidade máxima de armazenamento é de 38%

em temperatura de 60° C, e a temperatura máxima

de armazenamento é de 42° C a 90% de umidade.)

Consumo de energia

(com adaptador CA) 45 W (110 Vac) ou menos (carga completa)

0,5 W ou menos no modo de hibernação

(USB não conectado)

0,5 W ou menos no modo DESLIGADO

HUB USB Fluxo montante: 1 Fluxo jusante: 3 (interno; 2,

externo; 1)

A corrente de carga é de, no máximo, 0,5 A por porta.

Tela

Painel de exibição Modo VA, normalmente preto

Tamanho da tela 23,8 pol (527,04 (H) x 296,46 (V) mm)

Relação de aspecto 16:9

Número de pixels 1920 × 1080

Conector de entrada

devídeo DVI-I (29 pinos)

Sinal de vídeo

deentrada Conformidade com DVI 1.0

RGB analógico

Conector de saída

devídeo DVI-I (29 pinos)

Sinal de vídeo de saída Conformidade com DVI 1.0

RGB analógico

Resolução das

coordenadas 1920×1080, 1680×1050, 1366×768, 1280×1024,

1024×768, 1280×800,

800×600, 640×480 pixels

Distância entre pixels 0,2745 (H) x 0,2745 (V) mm

Ângulos de visão

aCR>10

(horizontal/vertical)

178(89/89) / 178(89/89) (típico)

Cores da tela 16,7 M cores (Depende do cartão de tela usado.)

Relação de contraste 1000:1 (típico)

Brilho 210 cd/m2 (típico)

Qualidade da tela LCD Cada tela LCD é produzida de acordo com padrões

extremamente rigorosos de qualidade. As técnicas

de produção não podem assegurar uma exibição

TFT absolutamente perfeita. A Wacom não permite

que nenhum pixel seja sempre branco nem sempre

preto. Um pequeno número de pixels pode exibir

acor incorreta em algumas partes do espectro de

cores. Isso não significa que há defeito na tela.

Mesa gráfica com caneta

Tecnologia de leitura Tecnologia de ressonância eletromagnética

Área ativa 479,2 x 271,3 mm

Resolução das

coordenadas 0,01 mm/ponto (2540 lpi)

Precisão ± 0,5 mm (centro), área da borda 1 (20 mm de

largura da borda da área da tela) a ser ± 2,0 mm,

área da borda 2 (3 mm de largura da borda da área

da tela) a ser ± 4,0 mm

Altura de leitura 10 mm ou mais (centro)

Velocidade de leitura

máxima 187 pontos/seg

Níveis de pressão 2.048 níveis

Interface de

comunicação USB

Adaptador de energia

Tensão de entrada 100 a 240 VAC, 50/60 Hz

Tensão de saída 12 Vcc, 5 A (máx.)

Caneta

Dimensões (C x D) 156,5 x 11,5 mm

Peso 17 g, aproximadamente

Entrada de toque DTH-2452

Tipo de tecnologia Capacitivo projetado

Resolução das

coordenadas 0,03 mm/ponto

Precisão das

coordenadas ±1 mm (local de contato é maior que 3,5 mm da

borda do digitalizador)

Velocidade de leitura

máxima 100 pontos/seg

RU:

Важная информация о продукте –

Краткая версия

Гарантийные обязательства

Гарантия: 3 года в странах Европы, Африки и Ближнего Востока.

Для получения гарантийной информации по DTK-2451, DTH-2452,

перейдите по ссылке www.wacom.com и нажмите «Поддержка».

Меры предосторожности

Для получения полной версии документа «Важная информация о продукте»

DTK-2451, DTH-2452 пройдите по ссылке www.wacom.com и нажмите

«Поддержка».

- Для безопасного использования данного устройства рекомендуется

следовать всем инструкциям, мерам предосторожности и

предупреждениям, приведенным в настоящем документе. Неисполнение

данных требований может привести к аннулированию гарантии, а компания

Wacom не будет нести ответственности за ремонт или замену устройства.

- Устройство следует использовать в обычных офисных условиях. Его

также можно использовать как центральную консоль в помещениях с

климат- контролем. Данное устройство было протестировано компанией

Wacom

для использования только в обычных офисных условиях, но не проходило

тестирования на совместимость с медицинским и военным оборудованием.

- Используйте только кабели, предназначенные для данного устройства.

Неисполнение данного требования может привести к возникновению

пожара, поражению электрическим током или вызвать отказ устройства.

Использование кабелей другого типа приведет к аннулированию гарантии.

- Во избежание повреждения глаз при работе с устройством:

• Используйте устройство только в хорошо освещенном помещении.

Не сидите слишком близко к экрану дисплея.

Produkt Specifikationer

Mærke:	Wacom
Kategori:	Tegnetablet
Model:	DTH-2452

Har du brug for hjælp?

Hvis du har brug for hjælp til Wacom DTH-2452 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Tegnetablet Wacom Manualer

Wacom Intuos5 Touch S Manual

13 Oktober 2024

Wacom Cintiq Pro 13 Manual

2 Oktober 2024

Wacom PTH450 Manual

1 Oktober 2024

Wacom DTK-2451 Manual

1 September 2024

Wacom DTH-2452 Manual

1 September 2024

Wacom One M Manual

1 September 2024

Wacom One 13 Touch Manual

1 September 2024

Wacom One S Manual

1 September 2024

Wacom DTU-2231 Manual

1 September 2024

Wacom Graphire MAC Manual

25 August 2024

Tegnetablet Manualer

Nyeste Tegnetablet Manualer

Iskn the Slate 2+ Manual

18 December 2024

Medion Life P82012 (MD 85637) Manual

8 December 2024

Huion Inspiroy H420X Manual

8 December 2024

Lenovo ThinkPad 1838 Manual

9 Oktober 2024

Archos T101 HD3 Wifi Manual

24 September 2024

Huion Inspiroy HS64 Manual

22 September 2024

Archos 116 Neon Manual

20 September 2024

Archos 80 G9 Manual

15 September 2024

Huion H642 Manual

14 September 2024

Rocketbook Fusion Letter Manual

8 September 2024
