PLEASE READ CAREFULLY BEFORE PROCEEDING

* Please keep this manual in a safe place for future reference.

WARNING

Always follow the basic precautions listed below to avoid the

possibility of serious injury or even death from electrical shock, short-

circuiting, damages, fire or other hazards. These precautions inc lude,

but are not limited to, the following:

• This device contains no user-serviceable parts. Do not open the device

or attempt to disassemble the internal parts or modify them in any way. If

it should appear to be malfunctioning, discontinue use immediately and

have it inspected by qualified Yamaha service personnel.

• Do not expose the device to rain, use it near water or in damp or wet

conditions, or place on it any containers (such as vases, bottles or

glasses) containing liquids which might spill into any openings. If any

liquid such as water seeps into the device, have the device inspected by

qualified Yamaha service personnel.

CAUTION

Always follow the basic precautions listed below to avoid the

possibility of physical injury to you or others, or damage to the device

or other property. These precautions include, but are not limited to,

the following:

• Do not place the device in an unstable position where it might

accidentally fall over.

• Do not place the device in a location where it may come into contact with

corrosive gases or salt air. Doing so may result in malfunction.

• Construction work should be carried out in accordance with construction-

related law and always by a professional constructor. If the device

installation requires construction work, make sure to observe the

following precautions.

- Choose mounting hardware and an installation location that can

support the weight of the device.

- Avoid locations that are exposed to constant vibration.

- Use the required tools to install the device.

- Inspect the device periodically.

• Before connecting the device to a power amplifier, turn off the power for

all devices. Before turning the power on or off for all devices, set all

volume levels to minimum.

• Use only speaker cables for connecting speakers to the speaker jacks.

Use of other types of cables may result in fire.

• Do not wipe the outer packaging with benzine, thinner, or synthetic

detergent and do not use electrical contact cleaner. These may damage

the outer packaging and dissolve the parts.

• Do not insert your fingers or hands in any gaps or openings on the device

(ports).

• Avoid inserting or dropping foreign objects (paper, plastic, metal, etc.)

into any gaps or openings on the device (ports). If this happens, have the

device inspected by qualified Yamaha service personnel.

PRECAUTIONS

Do not open

Water warning

Location

Connections

Maintenance

Handling caution

• Do not operate the device if the sound is distorting. Prolonged use in this

condition could cause overheating and result in fire.

• When choosing a power amplifier for use with this device, make sure that

the output power of the amplifier is lower than the power capacity of this

device (see SPECIFICATIONS).

Even if the output power of the amplifier is lower than the power capacity

of this device (program), use of excessive input signals resulting in

clipping may cause damage to the device.

Malfunction or fire may occur especially when the following sounds or

noises are generated:

- feedback, when using a microphone

- continuous and extreme volume sound from a musical instrument

- extreme continuous distorted sound

- noise caused by plugging/unplugging the cable while the amplifier is

turned on

NOTICE

To avoid the possibility of malfunction/damage to the product, damage to

data, or damage to other property, follow the notices below.

ƔHandling and Maintenance

• Do not place vinyl, plastic or rubber objects on the device, since this

might discolor the panel.

• When cleaning the device, use a dry and soft cloth. Do not use paint

thinners, solvents, cleaning fluids, or chemical-impregnated wiping

cloths.

• Condensation can occur in the device due to rapid, drastic changes in

ambient temperature-when the device is moved from one location to

another, or air conditioning is turned on or off, for example. Using the

device while condensation is present can cause damage. If there is

reason to believe that condensation might have occurred, leave the

device for several hours until the condensation has completely dried out.

• Be sure to observe the amplifier’s rated load impedance (see

SPECIFICATIONS), particularly when connecting speakers in parallel.

Connecting an impedance load outside the amplifier’s rated range can

damage the amplifier.

• When connecting the speakers with high impedance, be sure that the

total rated input capacity of the speakers does not exceed the output

power of the amplifier.

• When using a high-impedance speaker connection, make sure the audio

signal is passed through an 80 Hz or above high-pass filter before being

input to the speakers.

• ABOUT THE PROTECTION CIRCUIT

This speaker system has an internal protection circuit that shuts off the

speaker unit when an excessive input signal is applied.

If the speaker unit emits no sound, reduce the volume level of the

amplifier immediately.

The sound will return automatically in several seconds.

• Do not swing the speaker by its strap.

• Do not place the speaker face down with the grille attached, as

deformation of the grille may result.

• When placing the speaker face down, always place it on a flat and

smooth surface.

• Do not touch the speaker driver unit.

ƔAbout This Manual

The illustrations as shown in this manual are for instructional purposes only,

and may appear somewhat different from those on your device.

The contents of this manual apply to the latest specifications as of the

printing date. Since Yamaha makes continuous improvements to the

product, this manual may not apply to the specifications of your particular

product. To obtain the latest manual, access the Yamaha website then

download the manual file. Since specifications, equipment or separately

sold accessories may not be the same in every locale, please check with

your Yamaha dealer.

Yamaha cannot be held responsible for damage caused by improper use

or modifications to the device.

UNPACKING

Unpack the contents and confirm that all the following items are included.

* Speaker cable and safety wire are not included.

SPECIFICATIONS

*1: Half-space (2π)

*2: Calculated based on power rating and sensitivity, exclusive of power compression.

*3: 30 mm or less for the Anti-Drop Tab.

DIMENSIONS

• Speaker × 2 • Grille × 2 • O-ring × 2 • Tile Rail × 4

• Screw × 4 • Cutout Template × 1 • Owner’s Manual (this manual)

Type Full Range with Back Can, Bass-reflex

Component 4" (10 cm) Full Range

Coverage Angle (500 Hz – 4 kHz on average) 130° conical

Nominal Impedance 8 Ω

Power Rating NOISE 30 W

PGM 60 W

MAX 120 W

Sensitivity (1W, 1m) *187 dB SPL

Maximum SPL (Calculated, 1m) *2108 dB SPL

Frequency Range (-10 dB) *180 Hz – 20 kHz

Connector Euroblock (4 pin) × 1 (input: +/-, loop-thru: +/-)

Max. wire size 12 AWG (2.5 mm2)

Transformer Taps 70 V 30 W, 15 W, 7.5 W, 3.8 W

100 V 30 W, 15 W, 7.5 W

Overload Protection PolySwitch

Magnetically Shielded No

Enclosure Shape Back Can

Back Can Material Steel 1mm, Black

Baffle Material HIPS

Grille Material Powder coated perforated steel (t=0.6 mm)

Trim Ring: ABS

Aperture ratio: 51%

Finish VXC4 : Black painting (approximate value: Munsell N3)

VXC4W : White painting (approximate value: Munsell 9.3)

Dimensions (Speaker only) Ø225 × 194H mm (Ø8 7/8" × 7 5/8"H)

Net Weight (Speaker only, 1 piece) 2.6 kg (5.7 lbs)

Cutout Size Ø186 mm (Ø7 5/16")

Required ceiling board thickness 5 mm – 35 mm *3

Conduit Tube Up to 1/2"

Packaging Packaged in pair

243

164

Ø243

Ø183

608

644

O-ringVXC4/VXC4W

Unit: mm

Tile Rail

INSTALLING THE SPEAKERS

Install the speakers onto the ceiling with the supplied hardware. Ensure that

the strength of the ceiling rail is sufficiently strong.

Pre-installation (Preparation of the Cable)

Use stranded wire for cables attached to the Euroblock connector. Strip

their insulation as shown in the figure and connect them.

NOTE

Do not plate stranded wires by solder. Doing so will cause the wire to break.

1Put the supplied cutout template to the ceiling and draw a circle by

tracing it.

Make sure to use the cutout template so that hole is the correct

diameter.

NOTE

If you use a circular cutter, set the diameter with the cutout template.

2Cut the hole by tracing the circle.

Be careful to prevent chips or powder entering your eyes while

cutting the hole.

1Insert the two tile rails through the cut hole and place them on the

ceiling surface within your reach. Be sure that each tile rails are

oriented as shown below.

2Insert the folded O-ring through the cut hole and open it in the ceiling.

3Secure the O-ring and tile rails with supplied two screws through

either slot of both O-ring brackets.

1Pull the wiring from the amplifier through the cut hole.

2Loosen the screw at the right of the terminal cover to open the

terminal cover and remove the Euroblock connector.

3After loosening the terminal screws of the Euroblock connector with a

flat-blade screwdriver, insert the cable into each terminal and tighten

the screws. Make sure that cables cannot be pulled out.

NOTE

Use a flat-blade screwdriver with a blade less than 3 mm (0.1 in.).

1CUT OUT A HOLE IN THE CEILING

2INSTALL THE TILE RAILS AND O-RING

3CONNECT THE WIRING TO THE CONNECTOR AND FIX

THE CABLE

About 7 mm (0.3 in.)

Terminal cover

Euroblock connector

Less than 3 mm (0.1 in.)

There are two acceptable wiring methods.

CAUTION

When connecting with low impedance, take note of the combined

resistance.

Using Loop-Through Terminals

For this method, cables are connected from terminals 1 and 4 to the

subsequent speaker. If the Euroblock connector is disconnected from

a speaker, all subsequent speakers will not work. This can be useful

to identify which speaker has a problem.

Paralleling Input Terminals

For this method, cables are connected to terminals 2 and 3 of each

speaker. Since the cables are connected via Euroblock connectors,

subsequent speakers can work even if a problem occurs with a

speaker.

4Plug the connected Euroblock connector into the socket in the

speaker.

5Loosen the screw A of the strain relief clamp.

6Remove the screw B of the strain relief clamp.

If the cable is not to be held, remove the screw A and remove the

strain relief fitting, then proceed to step 8.

From amplifier or

previous speakers To subsequent

speakers

subsequent

speakers

Euroblock

connector

Power

amplifier

Speaker

From amplifier or

previous speakers

To subsequent

speakers

Power

amplifier

Speaker

Euroblock

connector

subsequent

speakers

7Hold the cable in the strain relief clamp, then tighten screws A and B.

8Close the terminal cover and tighten the screw.

1Attach the safety wire to the safety wire ring, and connect the wire to

an independent support point, such as a joist.

CAUTION

Always take measures to prevent the speaker falling down.

If the safety wire is too short, prepare another wire appropriate for th e

speaker weight and installation conditions. If the wire is too long,

should the speaker fall, the wire may break as a result of too much

strain.

2Push up the speaker slowly into the ceiling, taking care not to trap the

cable.

4FIX THE SPEAKERS ONTO THE CEILING

Screw

Safety wire ring

Anti-Drop Tab

When all the Anti-Drop Tabs

cross over the O-ring, the

speaker is held temporarily. You

can release your hands from the

speaker.

To release the speaker from the

O-ring, press the Anti-Drop Tabs.

These are located above the U

mark near the edge of the

cabinet’s face.

3Turn the screwdriver a half turn counterclockwise to loosen the

attachment screw. This makes the clamp easier to align in the

channel.

4Turn the screwdriver clockwise to tighten the attachment screw.

The first turn of the attachment screw aligns the clamp with the

channel. Further turns move the clamp down the channel to pull the

speaker up into the ceiling.

CAUTION

• Do not over-tighten the attachment screw. Otherwise, the

attachment screw and clamp will break.

• Do not turn any screws that do not have a guide sleeve in the screw

hole. Otherwise, the speaker may fall or malfunction.

Select the line voltage/impedance (100V/70V/8Ω) and power tap for 100V/

70V line distributed system, by rotating the tap selector switch on the front

side of the speaker with a flat-blade screwdriver.

CAUTION

The “X” position should not be selected. The 8Ω position should be selected

for 8Ω audio systems only. If the setting is incorrect, it may cause

malfunction of the speaker and amplifier.

Fit the grille to the cabinet front and turn it clockwise.

CAUTION

The grille may fall down if it is attached inadequately. Attach it firmly.

5SET THE LINE VOLTAGE/IMPEDANCE AND POWER

6ATTACH THE GRILLE

Clamp

Owner’s Manual

Ceiling Speaker

English

ZE19530

Produkt Specifikationer

Mærke:	Yamaha
Kategori:	Højttaler
Model:	VXC4
Bredde:	- mm
Dybde:	195 mm
Højde:	- mm
Vægt:	2600 g
Produktfarve:	Sort
Udgangseffekt (RMS):	30 W
Frekvensområde:	80 - 20000 Hz
Impedens:	8 ohm (Ω)
Forbindelsesteknologi:	Ledningsført
Højttaler, type:	Fuld interval
Lyd-output kanaler:	- kanaler
Højttaler, placering:	I væggen/i loftet
Diameter:	225 mm
Antal drivere:	1
Peak Music-Udgangseffekt (PMPO):	120 W
Sensitivitet:	87 dB
Mid-range driver diameter (britisk mål):	4 "
Antal Euroblock input stikforbindelser:	1
