Side 1/188
B3D-F8199-7A
YXE70WPAJ
YXE70WPHJ
OWNER’S MANUAL
READ THIS MANUAL CAREFULLY!
It contains important safety information.
EBU33773
Read this manual carefully before operating this vehicle. This manual should stay with this ve-
hicle if it is sold.
ANSI ROHVA 1 - 2016
General Manager
Engineering Division
Recreational Vehicle Business Unit
Vehicle & Solution Business Operations
YAMAHA MOTOR CO., LTD.
1, August, 2017
We, YAMAHA MOTOR CO., LTD. 2500 Shingai, Iwata, Japan,
declare in sole responsibility, that the product
(Make, model)
(If applicable)
and to the other relevant Directives of EEC
2014/30/EU
(Title and/or number and date of issue of the other Directives of EEC)
(If applicable)
YAMAHA MOTOR EUROPE N.V.
Koolhovenlaan 101, 1119 NC Schiphol-Rijk, The Netherlands
Signature
Akihiro Tsuzuki
Date of Issue
to which this declaration applies, conforms to the essential health
and safety requirements of Directive 2006/42/EC
To effect correct application of the essential health and safety requirements
stated in the Directives of EEC, the following-standards and/or technical
specifications were consulted:
(Title and/or number and date of issue of standards and/or specifications)
Authorized Representative
EC Declaration of Conformity
conforming to Directive 2006/42/EC
Manufacturer
YAMAHA MOTOR MANUFACTURING CORPORATION OF AMERICA
1000 GA Highway 34 East, Newnan, Georgia 30265-1320, U.S.A.
YXE700E (YXE70WPAJ) (5Y4AM92W0H0500601–)
YXE700E (YXE70WPHJ) (5Y4AMA4W0H0500411–)
EBU31040
INTRODUCTION
EBU32920
Congratulations on your purchase of the Yamaha YXE70WPAJ / YXE70WPHJ. It represents the
result of many years of Yamaha experience in the production of fine sporting, touring, and pace-
setting racing vehicles. With the purchase of this Yamaha, you can now appreciate the high de-
gree of craftsmanship and reliability that have made Yamaha a leader in these fields.
This manual will provide you with a good basic understanding of the features and operation of
this vehicle. It also includes basic maintenance and inspection procedures. If you have any ques-
tions regarding the operation or maintenance of your vehicle, please consult a Yamaha dealer.
WARNING
EWB03490
Please read this manual carefully before operating this vehicle. Do not attempt to operate
this vehicle until you have attained adequate knowledge of its controls and operating fea-
tures. Regular inspections and careful maintenance, along with good operating techni-
ques, will help ensure that you safely enjoy the capabilities and reliability of this vehicle.
EBU31080
IMPORTANT MANUAL INFORMATION
EBU31070
FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SERI-
OUS INJURY OR DEATH.
Particularly important information is distinguished in this manual by the following notations:
* Product and specifications are subject to change without notice.
This is the safety alert symbol. It is used to alert you to poten-
tial personal injury hazards. Obey all safety messages that fol-
low this symbol to avoid possible injury or death.
A WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
A NOTICE indicates special precautions that must be taken to
avoid damage to the vehicle or other property.
A TIP provides key information to make procedures easier or clear-
er.
WARNING
NOTICE
TIP
EBU31090
IMPORTANT NOTE ABOUT USE
EBU33170
This vehicle is designed and manufactured for use on UNPAVED surfaces only. It is un-
safe to operate this vehicle on any paved surface, paved street, paved road or motorway.
Check the laws and regulations in force before choosing where to operate this vehicle.
It is illegal to operate this vehicle on public lands where vehicles its size are prohibited.
EBU33130
YXE70WPAJ / YXE70WPHJ
OWNER’S MANUAL
©2017 by Yamaha Motor Co., Ltd.
1st edition, August 2017
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Co., Ltd.
is expressly prohibited.
Printed in U.S.A.
EBU31120
CONTENTS
LOCATION OF THE WARNING AND
SPECIFICATION LABELS ....................... 1-1
SAFETY INFORMATION ......................... 2-1
DESCRIPTION......................................... 3-1
Left view ............................................... 3-1
Right view............................................. 3-2
Controls and instruments ..................... 3-3
INSTRUMENT AND CONTROL
FUNCTIONS............................................4-1
Main switch .......................................... 4-1
Indicator lights and warning lights ....... 4-2
Multi-function meter unit ...................... 4-6
Light switch ........................................ 4-11
On–Command drive knob
“2WD/4WD/DIFF LOCK” .................. 4-11
Horn switch ....................................... 4-12
Accelerator pedal ............................... 4-12
Brake pedal ........................................ 4-13
Parking brake lever ............................ 4-13
Drive select lever................................ 4-14
Fuel tank cap...................................... 4-14
Doors.................................................. 4-14
Seats .................................................. 4-15
Adjusting the driver seat position....... 4-16
Seat belts ........................................... 4-17
Glove compartment ........................... 4-18
Storage compartments ...................... 4-18
Cup holders........................................ 4-20
Cargo bed .......................................... 4-20
Front shock absorbers ....................... 4-22
Rear shock absorbers ........................ 4-27
Trailer hitch bracket and receiver....... 4-32
Auxiliary DC jack ................................ 4-33
FOR YOUR SAFETY –
PRE-OPERATION CHECKS.................... 5-1
Front and rear brakes........................... 5-3
Fuel....................................................... 5-3
Engine oil.............................................. 5-5
Coolant................................................. 5-6
Final gear.............................................. 5-6
Differential gear .................................... 5-6
Accelerator pedal ................................. 5-6
Seat belts ............................................. 5-7
Passenger handhold ............................ 5-7
Steering ................................................ 5-7
Fittings and fasteners ........................... 5-7
Instruments, lights and switches.......... 5-8
Control cables ......................................5-8
Tires...................................................... 5-8
OPERATION ............................................ 6-1
Engine break-in .................................... 6-1
Starting the engine ............................... 6-2
Drive select lever operation and
reverse driving .................................... 6-3
On-Command drive knob..................... 6-5
Parking ................................................. 6-7
Loading................................................. 6-7
BASIC GUIDE FOR SAFE USE .............. 7-1
KNOW YOUR VEHICLE........................ 7-1
LEARNING TO OPERATE YOUR
VEHICLE........................................... 7-12
PERIODIC MAINTENANCE AND
ADJUSTMENT .........................................8-1
Owner’s Manual and tool kit.................8-2
Maintenance charts ..............................8-4
Hood ...................................................8-10
Panels .................................................8-11
Engine oil and oil filter cartridge .........8-14
Final gear oil .......................................8-20
Differential gear oil ..............................8-22
Coolant ...............................................8-25
Axle boots...........................................8-29
Spark plug inspection.........................8-30
Cleaning the air filter element .............8-32
Air filter check hoses ..........................8-36
V-belt case drain plug.........................8-37
Cleaning the spark arrester ................8-37
Valve clearance...................................8-39
Brakes.................................................8-39
Checking the front and rear brake
pads ..................................................8-39
Checking the brake fluid level ............8-40
Brake fluid replacement......................8-41
Checking the brake pedal...................8-42
Parking brake ..................................... 8-42
Brake light switch adjustment ............ 8-42
Cable inspection and lubrication........ 8-43
Brake pedal and accelerator pedal
lubrication ......................................... 8-43
Checking the stabilizer bushes .......... 8-44
Rear knuckle upper and lower pivot
lubrication (left and right).................. 8-45
Steering shaft lubrication ................... 8-45
Wheel removal.................................... 8-45
Tire replacement ................................ 8-46
Wheel installation ............................... 8-47
Battery ................................................ 8-47
Jump-starting ..................................... 8-51
Fuse replacement............................... 8-52
Replacing a headlight bulb................. 8-54
Headlight beam adjustment ............... 8-56
Tail/brake light bulb replacement....... 8-57
Troubleshooting ................................. 8-57
Troubleshooting charts ...................... 8-59
CLEANING AND STORAGE.................... 9-1
Cleaning ............................................... 9-1
Storage .................................................9-2
SPECIFICATIONS..................................10-1
CONSUMER INFORMATION ................11-1
Identification number records.............11-1
INDEX ....................................................12-1
1-1
1
EBU33410
LOCATION OF THE WARNING AND SPECIFICATION LABELS
EBU33422
Read and understand all of the labels on your vehicle. They contain important information for safe
and proper operation of your vehicle.
Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a
replacement label is available from your Yamaha dealer.
1-2
1
For Europe
1-3
1
2221 23 24 25
1-4
1
1 2
1-5
1
AVERTISSEMENT
La char e ne doit pas exéder 6.4 k (13.5 lbs).g g
Les vapeurs d’essence peuvent provo uer un icendieq
ou une explosion.
Afin d’éviter tout ris ue de blessure corporelle, voireq
mortelle, ne jamais stocker de carburant ni de liquide
inflammable dans ce compartiment de ran ement.g
2MB-F151F-10
WARNING
Fuel vapors can be a fire or explosion hazard.
To avoid injury or death, never store fuel or
flammable li uids in this storaq ge compartment.
Stora e should not exceed 13.5 lbs (6.4 k )g g
2MB-F151F-00
YAMAHA 2MB-F1568-10
AVERTISSEMENT
PILOTE DE
PILOTE DE
PILOTE DE
PILOTE DE
PILOTE DE
MOINS DE
MOINS DE
MOINS DE
MOINS DE
MOINS DE
16
16
16
16
16
PILOTE DE
MOINS DE
16
Lire le Man el d propriétaire. u u
Lire le G cond cte r d éhic le récréatif hors ro te. uide de conseils à l’intention du u u u v u u
S i re to tes les directi es et to s les au v u v u vertissements.
L’ u u v u utilisation négligente d’ n éhic le hors ro te
pe t ca ser de grau u ves b u vless res, oire la mort.
Les ro lades ont déjà ca sé des u u
b uless res graves et la mort, même
s r terrain plat et sans o stacles.u b
Utilisation igilante d éhic lev u v u
Faire sa part po r préu venir les less res :b u
N u b u u ue pas permettre la cond ite acro atiq e o impr dente .•
S’ass u u u u urer q e le cond cte r est âgé d’a moins 16 ans
et q ’il est tit laire d’ n permis de cond alide.u u u uire v
•
N u v u ue permettre à personne de cond ire le éhic le o
d’y prendre place après a oir consommé alcool o drog es.v u u
•
N u u v u ue pas permettre la cond ite d éhic le s r les chemins
p lics (à moins q e les éhic les hors ro te y soient ub u v u u
a torisés) – les collisions a ec oit res et camions arriu v v u vent en n clin d’œil.u
•
N b be pas dépasser le nom re de places disponi les : 1 passager.•
Être préparé
Attacher la ceint re de sécu urité.
•
Porter n casq e homologu u ué, une protection pour les yeux et une tenue de protection.
•
Le cond cte r doit pou u uvoir rejoindre aisément tou utes les commandes alors q ’il est en
position assise, son dos contre le dossier du siège.
•
Les occ pants doi ent pou v uvoir rejoindre la poignée de maintien centrale alors qu ue le rs
pieds reposent à plat su u ur le plancher et q ’ils sont assis le dos contre le dossier d siège.
•
Demeu brer entièrement dans l’ha itacle d le.u v u éhic
•
Cond ire de façon responsa leu b
Pré enir la perte de contrôle o les ro lades :v u u
É iter les manœ res s ites, glissements latéra x, v uv ub u
dérapages, q e es de poisson et u u
zigzags; ne jamais tenter d’acro aties.b
•
Ralentir a ant d’entamer n irage.• v u v
É iter d’accélérer r sq ement dans les irages, v b u u v
même à partir de l’arrêt.
•
Être prêt po r pentes, terrains inhospitaliers, u
ornières, aspérités d terrain et a tres facte rs u u u
réduisant la traction. É iter les s rfaces asphaltées.v u
•
N u ue pas cond ire s r le flanc des pentes.•
Ne permettre à personne de prendre place dans la caisse de chargement.•
Être pré oyant, être prêtv
Si ne ro lade o le imminent, réd ire le risq e de less res :u u u un capotage semb u u b u
Agripper fermement le olant o la poignée de maintien et se préparer à encaisser le choc.v u
•
N u u u u v u u u u ue mettre a c ne partie d corps hors d éhic le, po r q elq e raison q e ce soit.•
3
4
5
1-6
1
6
8
1-7
1
YAMAHA 2MB-F4897-00
WARNING
• Load or trailer may affect handling and sta ility.b
• Do not exceed the maximum load ratings for the
cargo ed , trailer tong e, or b u vehicle.
• hen loaded ith cargo or to ing a trailer:W w w
• Redu wce speed and allo more room to stop.
• Tu u wrn grad ally and slo ly.
• Av uoid hills and ro gh terrain.
• Secu wre cargo so that it ill not shift - a loose load
co ld change handling nexpectedly or e throu u b wn
forw uard and strike occ pants.
• Keep eight in the cargo ed centered side to side andw b
as lo as possiw ble. Top-heavy loads increase the risk of a
rollover.
• Do not to or p ll o jects from any point other thanw u b
the trailer hitch racket or inch (if installed).b w
• Read Owner’s Manu b w ual efore loading, to ing, or p lling
o jects.b
Improper ed or use of cargo b
cage/fr ame can res ult
in severe injury or
death from loss of
control, overturn or
other accidents.
Maxim m Load in Cargo Bed: 300 l s (136 kg)u b
Maximum Vehicle Load: 721 l s (327 kg)b
N ve er carry
passengers
in cargo bed.
1HP-F2259-21
9 10
1-8
1
11 12
1-9
1
YAMAHA 2MB-F4897-10
AVERTISSEMENT
Charge maximale dans la caisse : 136 kg (300 l s) b
Charge maximale d éhic le : 327 kg (721 l s)u v u b
Une charge o t n ilité et u une remorque peu uire à la maniab
à l’éq ili re d éhic le.u b u v u
Lors d transport d’ ne charge o lors d remorq age :u u u u u
Lire le Man el d propriétaire a ant de charger le u u v v uéhic le,
de tirer o de remorq er ne charge.u u u
– e pas dépasser la limite de charge nominale po r la caisse N u
de chargement, le timon et le éhic le.v u
– Réd ire la itesse et préu v voir ne distance de freinage accru ue.
– égocier les irages progressiN v vement et lentement.
– É iter les pentes et les terrains accidentés.v
– Arrimer solidement to n article mal arrimé ute charge – u
po rrait n ire so dainement à la mania ilité o être projeté u u u b u
vers l’av u u uant et he rter n occ pant.
– Répartir le poids de la charge de façon éq ili rée et le pl s u b u
b bas possi le dans la caisse; ili rée a gmente une charge mal équ b u
le risq e de capotage.u
– er a c tre qNe tirer ni ne remorqu u un objet d’un point au ue la
fixation d timon ou u u le tre il (le cas échéant).
Le ma ais uv usage de la caisse de chargement o de u de l’arceau
protection pe t prou voq er de grau ves bless res ou u la mort par s ite u
d’ ne perte de contrôle, d’ n capotage ou u u d’u u un accident q elconq e.
A c n passager u u
dans la caisse de
chargement
YAMAHA 1XD-K7762-00
WARNING
Any part of your
body (arms, legs,
or head) o tside of u
the e vehicle can b
cr shed u by the
cage/frame.
If you think or feel
that the vehicle
may tip or roll,
b urace yo r feet on
the floor or footrests,
and keep your
hands on the
steering wheel or
handhold.
N ve er hold cage.
Do not try to stop a
vehicle tipover
u using yo r arm or leg.
YA MA H A 1XD-K7762-10
AVERTISSEMENT
To ute partie du corps
(bras, jambes, tête) se
trouvant hors de
l’habitacle risque d’être é
crasée par l’arceau de
protection.
Si une roulade ou un
capotage semble
imminent, caler les pieds
sur le plancher ou sur
les repose-pieds et
agripper le volant ou la
poignée de maintien. e N
jamais agripper l’arceau
de protection.
Ne jamais tenter d’empê
cher un capotage à l’aide
du bras o de la jamu be.
13 14 15
1-10
1
16
18
1-11
1
YAMAHA 5UG-F151J-00
MAX 7.3 INCH
(1 5MM)8
YAMAHA 1XD-F151K-00
WARNING
Improperly loading a trailer
or pulling an object can
affect handling, stability, and
risk of overturn or other
accidents.
• Secure load to prevent it
from shifting.
• Never load more than 490 N
(50 kgf)/110 lbf tongue
weight on towing bracket.
• Do not tow more than
6664 N(6 0 kgf)/1500 lbf8
rolling weight (trailer plus
cargo).
• Tow or pull only from hitch
bracket.
• Read Owner’s Manual
before loading, towing, or
pulling objects.
19 20
1-12
1
21
1-13
1
Liste de vérification
de sécurité intégrale
YAMAHA 1XD-F1558-10
Tête Casque et protection des yeux
Corps Ceinture de sécurité et vêtements de protection
Mains À l’intérieur du véhicule, tenantla
poignée de maintien ou le volant.
Pieds Sur le plancher ou les repose-pieds, prêts à
encaisser le choc; portière fermée.
1XD-F 446-008
Be P repar ed
Adju st, l ock a nd never re move h a ndho l d.
Always use handh old, Nev e r ho l d ca g e.
Always wear seat belt an d he l met.
1XD-F 446-108
Toujours prévoir l’imprévu.
Régler et verrouiller la poignée de maintien; ne jamais la retirer.
Toujours agripper la poignée de maintien, non l’arceau de protection.
Toujours porter la ceinture de sécurité et un cas ue approprié.q
23
24
25
1-14
1
For Oceania
1-15
1
1110 12
1-16
1
1 2
1-17
1
YAMAHA 2MB-F4897-00
WARNING
• Load or trailer may affect handling and sta ility.b
• Do not exceed the maximum load ratings for the
cargo ed , trailer tong e, or b u vehicle.
• hen loaded ith cargo or to ing a trailer:W w w
• Redu wce speed and allo more room to stop.
• Tu u wrn grad ally and slo ly.
• Av uoid hills and ro gh terrain.
• Secu wre cargo so that it ill not shift - a loose load
co ld change handling nexpectedly or e throu u b wn
forw uard and strike occ pants.
• Keep eight in the cargo ed centered side to side andw b
as lo as possiw ble. Top-heavy loads increase the risk of a
rollover.
• Do not to or p ll o jects from any point other thanw u b
the trailer hitch racket or inch (if installed).b w
• Read Owner’s Manu b w ual efore loading, to ing, or p lling
o jects.b
Improper ed or use of cargo b
cage/fr ame can res ult
in severe injury or
death from loss of
control, overturn or
other accidents.
Maxim m Load in Cargo Bed: 300 l s (136 kg)u b
Maximum Vehicle Load: 721 l s (327 kg)b
N ve er carry
passengers
in cargo bed.
1HP-F2259-21
4 5
1-18
1
6 7
1-19
1
YAMAHA 5UG-F151J-00
MAX 7.3 I CHN
(185MM)
YAMAHA 1XD-F151K-00
WARNING
Improperly loading a trailer
or p lling an ou bject can
affect handling, sta ility, andb
risk of overt rn or otheru
accidents.
• Secure load to prevent it
from shifting.
• Nev Ner load more than 490
(50 kgf)/110 l f tongb ue
weight on towing bracket.
• Do not to more thanw
6664 (680 kgf)/1500 lN bf
rolling weight (trailer plus
cargo).
• Tow or p ll only from hitchu
bracket.
• Read Owner’s Manual
before loading, towing, or
pulling o jects.b
8 9
1-20
1
10
2-1
2
EBU31150
SAFETY INFORMATION
SAFETY INFORMATION
EBU33442
Be a responsible owner
As the vehicle’s owner, you are responsible for the safe and proper operation of your Yamaha
Wolverine. While understanding all parts of this manual are important for vehicle ownership, be
sure to read this chapter and the instructions in Chapter 7 before operating your Yamaha
Wolverine. Also use these two chapters and the labels on the vehicle to instruct new operators
and passengers. Do not allow anyone else to operate your vehicle or ride as a passenger if you
are unsure that he/she is willing and able to follow these instructions.
Get to know your vehicle
This off-road vehicle will handle and maneuver differently from cars, ATVs, go-carts, golf-cars
and grounds-keeping vehicles. Follow these instructions to reduce your risk of an accident and
to reduce the risk of serious injury or death in the event of an accident.
2-2
2
Before you operate your Yamaha Wolverine
Prepare yourself and your passenger:
• This vehicle is intended for use only by an operator 16 or older with a valid motor vehicle li-
cense. Check country laws for minimum age requirements.
• This vehicle is designed to carry the driver and one passenger. Never carry passengers in
the cargo bed.
• Both driver and passenger should wear seat belts properly.
• Both driver and passenger must be able to put both feet flat on the floorboard while seated
upright with their backs against the backrests. Passenger must be able to reach and hold
the passenger handhold within the cage/frame.
• Both driver and passenger should wear an approved motorcycle helmet that fits properly.
Both driver and passenger should also wear eye protection (goggles or a face shield), gloves,
over-the-ankle boots, long-sleeved shirt or jacket, and long pants.
DRIVER
UNDER
16
2-3
2
• Do not drive or ride as passenger after using drugs or alcohol.
Prepare your vehicle
Perform the pre-operation checks each time you use the vehicle to make sure it is in safe oper-
ating condition. Failure to inspect or maintain the vehicle properly increases the possibility of an
accident or equipment damage. See page 5-1 for a list of pre-operation checks.
Prepare your load or trailer
Carrying loads, towing a trailer, or pulling objects can affect handling, stability, and cause the risk
of overturns or other accidents.
Read Chapter 6 before loading, towing, or pulling objects.
Do not overload the vehicle or trailer. Refer to label in cargo bed for cargo bed load limit. Refer
to label next to hitch for tongue weight and trailer load limits.
Keep weight in the cargo bed centered side to side, and as low and as far forward as possible.
Secure cargo so that it will not shift – a loose load could change handling unexpectedly or be
thrown forward and strike occupants.
While using your Yamaha Wolverine
Keep your body completely inside the vehicle at all times. Keep both hands on the steering
wheel. Be sure the passenger is seated, belted, and holding onto the passenger handhold.
Close doors before driving. Any part of your body (arms, legs, and head) outside the vehicle
can be struck by objects your vehicle is passing or crushed by the vehicle cage/frame in a roll-
over accident.
Watch for branches, brush, or other hazards that could enter the vehicle.
2-4
2
Abrupt maneuvers or aggressive driving, even on flat, open areas, can cause loss of control,
including rollovers. The Wolverine has higher ground clearance and other features to handle
rugged terrain, and, as a result, can overturn in situations where some other vehicles may not.
Avoid rollovers:
• Use care when turning:
• Turning the steering wheel too far or too fast can result in a rollover.
• Avoid sideways sliding, skidding, or fishtailing (rear-wheel sliding), and never do donuts.
• Slow down before entering a turn and avoid hard braking in a turn.
• When making tight turns from a stop or at slow speeds, avoid sudden or hard acceleration.
• Drive straight up and down inclines, not across them. If crossing a hill is unavoidable, drive
slowly and turn downhill immediately if you feel the vehicle may tip.
• Avoid paved surfaces. Turn gradually and go slowly if you must drive on pavement. This
vehicle is designed for off-road use only.
2-5
2
If you think or feel that the vehicle may tip or roll, keep your body completely inside the protec-
tive structure of the vehicle:
• Brace yourself by pressing your feet firmly on the floorboard and keep a firm grip on the
steering wheel or passenger handhold.
• Do not put your hands or feet outside of the vehicle for any reason. Your arm or leg could be
crushed.
• Do not try to stop a vehicle tipover using your arm or leg.
Do not operate this vehicle on any public street, road, or highway, even if dirt or gravel.
Do not operate the vehicle in fast-flowing water or water deeper than 37 cm (15 in). If you must
cross shallow, slow-moving water, choose your path carefully to avoid sharp drop-offs, large
rocks, or slippery surfaces. Operating this vehicle through deep or fast-flowing water can lead
to loss of control or overturn. To reduce your risk of drowning or other injuries, use care when
crossing through water.
When loaded with cargo or towing a trailer:
• Reduce speed, operate in low gear only, and allow more room to stop.
• Avoid hills and rough terrain. Use extreme caution when towing or carrying a load on inclines.
• Load trailer properly and use extra care when towing or pulling.
Do not tow or pull objects from any part of the vehicle other than the trailer hitch bracket or
winch (if installed).
Avoid carbon monoxide poisoning
All engine exhaust contains carbon monoxide, a deadly gas. Breathing carbon monoxide can
cause headaches, dizziness, drowsiness, nausea, confusion, and eventually death.
2-6
2
Carbon monoxide is a colorless, odorless, tasteless gas which may be present even if you do not
see or smell any engine exhaust. Deadly levels of carbon monoxide can collect rapidly and you
can quickly be overcome and unable to save yourself. Also, deadly levels of carbon monoxide
can linger for hours or days in enclosed or poorly-ventilated areas. If you experience any symp-
toms of carbon monoxide poisoning, leave the area immediately, get fresh air, and SEEK MED-
ICAL TREATMENT.
Do not run engine indoors. Even if you try to ventilate engine exhaust with fans or open win-
dows and doors, carbon monoxide can rapidly reach dangerous levels.
Do not run engine in poorly ventilated or partially enclosed areas such as barns, garages, or
carports.
Do not run engine outdoors where engine exhaust can be drawn into a building through open-
ings such as windows and doors.
Genuine Yamaha Accessories
Choosing accessories for your Wolverine is an important decision. Genuine Yamaha Accesso-
ries, which are available only from a Yamaha dealer, have been designed, tested, and approved
by Yamaha for use on your Wolverine.
Many companies with no connection to Yamaha manufacture parts and accessories or offer oth-
er modifications for Yamaha vehicles. Yamaha is not in a position to test the products that these
aftermarket companies produce. Therefore, Yamaha can neither endorse nor recommend the
use of accessories not sold by Yamaha or modifications not specifically recommended by
Yamaha, even if sold and installed by a Yamaha dealer.
2-7
2
Aftermarket parts, accessories, and modifications
While you may find aftermarket products similar in design and quality to genuine Yamaha Acces-
sories, recognize that some aftermarket accessories or modifications are not suitable because
of potential safety hazards to you or others. Installing aftermarket products or having other mod-
ifications performed to your Wolverine that change any of the vehicle’s design or operation char-
acteristics can put you and others at greater risk of serious injury or death. You are responsible
for injuries related to changes in the vehicle.
Aftermarket tires and rims
The tires and rims that came with your Wolverine were designed to match the performance ca-
pabilities and to provide the best combination of handling, braking, and comfort. Other tires,
rims, sizes, and combinations may not be appropriate. Refer to page 8-46 for tire specifications
and more information on replacing your tires.
3-1
3
EBU31170
DESCRIPTION
EBU31180
Left view
1. Front shock absorber assembly
2. Radiator cap
3. Brake fluid reservoir
4. Air filter
5. Shoulder bolster
6. Driver seat belt
7. Cargo bed
8. Tail/brake light
9. Rear shock absorber assembly
10.Spark plug
11.Driver seat
12.Door
3-2
3
EBU31190
Right view
10 9411 8
3 4 5,61 72
1. Spark arrester
2. Passenger seat belt
3. Engine oil dipstick
4. Storage compartment
5. Battery
6. Fuses
7. Headlight
8. Coolant reservoir
9. Passenger seat
10.Fuel tank cap
11.Oil filter cartridge
3-3
3
EBU31200
Controls and instruments
The vehicle you have purchased may differ slightly from those shown in the figures of this man-
ual.
1. Light switch
2. On-Command drive knob
3. Steering wheel
4. Main switch
5. Helmet indicator light
6. Seat belt indicator light
7. Multi-function meter unit
8. Auxiliary DC jack
9. Passenger handhold
10.Glove compartment
11.Storage compartment
12.Drive select lever
13.Parking brake lever
14.Accelerator pedal
15.Brake pedal
16.Horn switch
4-1
4
EBU31217
INSTRUMENT AND CONTROL
FUNCTIONS
EBU31220
Main switch
Functions of the respective switch positions
are as follows:
EBU31231
On position “ ”
All electrical circuits are supplied with power.
The key cannot be removed.
TIP
The helmet indicator light comes on and stays
on while the key is turned to the on
position “ ”.
EBU31241
Off position “ ”
All electrical circuits are switched off. The key
can be removed.
EBU31251
Start position “ ”
The electric starter is engaged by turning and
holding the key in this position. Release the
key when the engine starts.
1. Main switch
2. Off position “ ”
3. On position “ ”
4. Start position “ ”
1
2
3
4
4-2
4
EBU31268
Indicator lights and warning lights
EBU31270
Low-range indicator light “L”
This indicator light comes on when the drive
select lever is in the “L” position.
EBU31280
High-range indicator light “H”
This indicator light comes on when the drive
select lever is in the “H” position.
1. Differential gear lock indicator light “DIFF. LOCK”
2. Low-range indicator light “L”
3. High-range indicator light “H”
4. Neutral indicator light “N”
5. Reverse indicator light “R”
6. Parking brake indicator light “ ”
7. Drivetrain icon “ / ”
8. Engine trouble warning light “ ”
9. Coolant temperature warning light “ ”
10.Electric Power Steering warning light “EPS”
3
5
6
4
2
1
7
8
10
9
1. Helmet indicator light “ ”
2. Seat belt indicator light “ ”
2
1
4-3
4
EBU31290
Neutral indicator light “N”
This indicator light comes on when the drive
select lever is in the “N” position.
EBU31300
Reverse indicator light “R”
This indicator light comes on when the drive
select lever is in the “R” position.
EBU31310
Parking brake indicator light “ ”
This indicator light comes on when the park-
ing brake is applied.
EBU37220
Differential gear lock indicator light “DIFF.
LOCK”
This indicator light comes on when the front
differential gear is locked.
TIP
When the On–Command drive knob is set to
“DIFF LOCK”, the indicator light will flash until
the differential is locked. Turn the steering
wheel back and forth or drive slowly to help
the differential gear lock to engage.
EBU37171
Drivetrain icon “ / ”
This icon indicates the currently selected
drive mode. When 2WD is selected, the icon
is off. When 4WD is selected, “ ” is dis-
played. And when 4WD with differential lock
is selected “ ” is displayed.
TIP
See pages 4-11 and 6-5 for more informa-
tion on selecting the drive mode.
Due to the synchronizing mechanism in the
differential gear case, the drivetrain icon
may not come on until the vehicle starts
moving.
4-4
4
When the On–Command drive knob is set
to “DIFF LOCK” or “4WD”, the drivetrain
icon will flash until the differential has
locked or unlocked. Turn the steering wheel
back and forth or drive slowly to help the
differential gear lock to engage or disen-
gage.
EBU31333
Coolant temperature warning light “ ”
This light comes on to warn that the coolant
temperature is too hot. If the light comes on
during operation, stop the vehicle as soon as
it is safe to do so and allow the engine to cool
down for about 10 minutes. (See page 8-60.)
TIP
If you continue to drive the vehicle while the
engine is overheating, a buzzer will sound.
NOTICE
ECB03460
Continuous use while this warning light is
on will damage the engine.
The electrical circuit of the warning light can
be checked by turning the key to “ ” (on). If
the warning light does not come on initially
when the key is turned to “ ” (on), or if the
warning light remains on, have a Yamaha
dealer check the electrical circuit.
EBU31341
Engine trouble warning light “ ”
This warning light comes on or flashes if a
problem is detected in the electrical circuit
monitoring the engine. When this occurs, the
display will indicate an error code (see page
4-10). Have a Yamaha dealer check the self-
diagnosis system.
The electrical circuit of the warning light can
be checked by turning the key to “ ” (on). If
the warning light does not come on initially
when the key is turned to “ ” (on), or if the
warning light remains on, have a Yamaha
dealer check the vehicle.
4-5
4
EBU33041
Electric Power Steering warning light
“EPS”
This warning light comes on when the key is
turned to “ ” (on), and then goes off once
the engine is started. If the warning light re-
mains on or comes on after the engine is
started, the EPS system may not be working
correctly. When this occurs, have a Yamaha
dealer check the EPS system.
The electrical circuit of the warning light can
be checked by turning the key to “ ” (on). If
the warning light does not come on, have a
Yamaha dealer check the electrical circuit.
TIP
If the steering load is too heavy (e.g., exces-
sive steering use at slow speed or when op-
erating in deep mud, sand, or snow), the
power assist is reduced to protect the EPS
motor from overheating.
EBU31360
Helmet indicator light “ ”
The indicator light comes on and stays on
while the key is turned to “ ” (on) to remind
the occupants to always wear a helmet. If the
indicator light does not come on when the key
is turned to “ ” (on), have a Yamaha dealer
check the electrical circuit.
EBU31370
Seat belt indicator light “ ”
The indicator light comes on when the key is
turned to “ ” (on) to remind the occupants
to fasten their seat belt. The indicator light
stays on until the driver seat belt is properly
latched. If the indicator light does not come
on when the key is turned to “ ” (on), or if
the indicator light remains on after the driver
seat belt is properly latched, have a Yamaha
dealer check the electrical circuit.
4-6
4
EBU31386
Multi-function meter unit
The multi-function meter unit is equipped with
the following:
 speedometer
 odometer
two tripmeters
 clock
hour meter
voltage display
fuel gauge
error code display
Speedometer
The speedometer shows the vehicle’s travel-
ing speed. The speedometer can be set to
“mph” or “km/h”. This also changes the
odometer and tripmeter units between miles
and kilometers. To change the display be-
tween “mph” and “km/h”, turn the key to “ ”
(off), then while holding the “SELECT” button
pushed, turn the key to “ ” (on).
1. “CLOCK” button
2. “RESET” button
3. “SELECT” button
4. Speedometer
5. Fuel gauge
6. Clock/Hour meter/Voltage display
7. Odometer/Tripmeter A/Tripmeter B
3
2
1
4 5
67
4-7
4
Odometer and tripmeters
The odometer shows the total distance trav-
eled by the vehicle. The odometer can be
used for maintenance and service intervals.
The tripmeters show the distance traveled
since they were last reset. The tripmeters can
be used to record the distance traveled on a
single trip, or to estimate the distance that
can be traveled with a full tank of gas, etc.
Push the “SELECT” button to switch between
the odometer “ODO” and the tripmeters
“TRIP A” and “TRIP B” in the following order:
ODO → TRIP A → TRIP B → ODO
To reset a tripmeter, set the display to the
tripmeter you want to reset, then push the
“RESET” button for three seconds.
TIP
The odometer will lock at 99999.
The tripmeters will reset and continue
counting after 9999.9 is reached.
1. “SELECT” button
2. “RESET” button
3. Odometer/Tripmeter A/Tripmeter B
1
2
3
4-8
4
Clock, hour meter and voltage display
The clock displays time in 12-hour format.
The hour meter shows the total time the en-
gine has been running. The voltage display
shows the battery voltage.
Push the “CLOCK” button to switch between
the clock “CLOCK”, the hour meter mode
“HOUR” and the voltage display
mode “ ” in the following order:
CLOCK → HOUR → → CLOCK
To set the clock
1. Set the display to the clock.
2. Push both the “SELECT” button and
“RESET” button for three seconds. The
hour digits will start flashing.
3. Push the “RESET” button to set the
hours.
4. Push the “SELECT” button, and the mi-
nute digits will start flashing.
5. Push the “RESET” button to set the minu-
tes.
6. Push the “SELECT” button and then re-
lease it to start the clock.
1. “SELECT” button
2. “RESET” button
3. “CLOCK” button
4. Clock/Hour meter/Voltage display
4
1
2
3
4-9
4
Voltage display
This display shows the battery voltage.
“ ” appears for one second when the
voltage display mode is first selected, and
then “ ” appears and the battery voltage is
displayed.
If the battery voltage is less than 10 volts,
“LO” is displayed, and if the voltage is above
16 volts, “HI” is displayed.
NOTICE
ECB02050
If the voltage display indicates “LO” or
“HI”, there may be trouble with the battery
charging circuit or the battery may be
faulty. If this occurs, have a Yamaha dealer
check or repair the vehicle.
Fuel gauge
The fuel gauge indicates the amount of fuel in
the fuel tank. The display segments of the fuel
gauge disappear from “F” (full) towards “E”
4-10
4
(empty) as the fuel level decreases. When the
“E” segment disappears and the “ ” icon
flashes, refuel as soon as possible.
TIP
If the electrical circuit for the fuel gauge is not
working correctly, all display segments
and “ ” will flash repeatedly. Have a Yamaha
dealer check the vehicle.
Error code display
This model is equipped with a self-diagnosis
device for various electrical circuits.
If a problem is detected in any of those cir-
cuits, the engine trouble warning light will
come on or flash, and the display will indicate
an error code.
If the display indicates an error code, note the
code number and have a Yamaha dealer
check the vehicle.
NOTICE
ECB00812
If the multi-function display indicates an
error code, the vehicle should be checked
as soon as possible in order to avoid en-
gine damage.
1. Error code display
2. Engine trouble warning light “ ”
21
4-11
4
EBU31391
Light switch “ / / ”
Set the switch to “ ” to turn on the low
beam and the taillights.
Set the switch to “ ” to turn on the high
beam and the taillights.
Set the switch to “ ” to turn off the head-
lights and taillights.
NOTICE
ECB02061
Do not use the headlights with the engine
turned off for an extended period of time.
The battery may discharge to the point
that the electric starter will not have
enough power to crank the engine. If this
should happen, remove the battery and re-
charge it.
EBU31402
On–Command drive knob
“2WD/4WD/DIFF LOCK”
Stop the vehicle and move the On–Command
drive knob to change the drive mode to two–
wheel drive, four–wheel drive, or four–wheel
1. Light switch “ / / ”
L
H
1
L
H
L
H
1. On-Command drive knob “2WD/4WD/DIFF LOCK”
1
4-12
4
drive with differential lock. Select the appro-
priate drive according to the terrain and driv-
ing conditions.
“2WD” (two–wheel drive): Power is sup-
plied to the rear wheels only.
“4WD” (four–wheel drive): Power is sup-
plied to the front and rear wheels.
“DIFF LOCK” (four–wheel drive with the dif-
ferential gear locked): Power is supplied to
the front and rear wheels with the differen-
tial gear locked. Unlike standard four–wheel
drive, all wheels turn at the same speed re-
gardless of traction.
EBU33192
Horn switch “ ”
Press the switch to sound the horn.
EBU31413
Accelerator pedal
1. Horn switch “ ”
1. Accelerator pedal
1
1
4-13
4
Press the accelerator pedal to increase en-
gine speed and thus vehicle speed. Release
the accelator pedal and spring tension will re-
turn the pedal to idle position.
EBU31421
Brake pedal
Press the brake pedal to slow or stop the ve-
hicle.
EBU35641
Parking brake lever
Setting the parking brake lever will help keep
the vehicle from moving while parked.
To set the parking brake, pull the lever up-
ward firmly.
To release the parking brake, pull slightly up-
ward on the lever, press the release button,
and then push the lever all the way down.
TIP
Spring tension helps return the lever to the
released position.
1. Brake pedal
1
1. Release button
2. Parking brake lever
2
1
4-14
4
If you drive the vehicle with the parking
brake engaged, a buzzer will sound.
EBU31441
Drive select lever
The drive select lever is used to shift the
transmission into the low, high, neutral, and
reverse positions. (See page 6-3.)
EBU31451
Fuel tank cap
Remove the fuel tank cap when refueling. To
open, turn counterclockwise. When finished
refueling, install the fuel tank cap by screwing
it down clockwise.
EBU31460
Doors
To open a door, pull the latch outward. To
close a door, push or pull the door inward un-
til it is securely latched. Be sure the door is
SECURELY LATCHED AFTER CLOSING IT.
1. Drive select lever
1
1. Fuel tank cap
1
4-15
4
EBU33461
Seats
To remove a seat cushion, lift the front of the
cushion, and then pull the cushion off.
To install a seat cushion, insert the projec-
tions on the rear of the seat cushion under the
seat frame, and then insert the projection on
the front of the cushion into the grommet
while pushing the cushion downward. Make
sure the seats are properly secured before
starting off. WARNING! A loose seat could
cause the operator to lose control, or cau-
se the operator or passenger to fall. [EWB03510]
1. Door
2. Latch
21
1. Seat cushion
1
4-16
4
EBU31481
Adjusting the driver seat position
The driver seat can be installed to one of three
positions.
1. Remove the driver seat cushion.
2. Remove the bolts.
3. Move the seat frame to the desired posi-
tion and align the bolt holes in the seat
frame with the bolt holes in the vehicle
frame.
1. Bolt
1
1
4-17
4
4. Install the bolts.
5. Tighten to the specified torque.
6. Install the cushion.
EBU33472
Seat belts
This vehicle is equipped with three-point seat
belts for the driver and passenger.
Always wear the seat belts properly while rid-
ing in the vehicle. (See page 7-5.)
TIP
If the vehicle is driven without the driver
seat belt fastened, a buzzer will sound.
If the vehicle is driven without the driver
seat belt fastened, engine power will be lim-
ited.
Tightening torque:
Driver seat bolt:
23 N·m (2.3 kgf·m, 17 lb·ft)
4-18
4
EBU31502
Glove compartment
Store lightweight or frequently used items,
such as your driving gloves or vehicle docu-
ments, in this compartment.
NOTICE
ECB02071
To protect from damage, do not put metal
items, like tools, or sharply edged items di-
rectly in the glove compartment. If they
must be stored, wrap them in appropriate
cushioning material.
EBU33522
Storage compartments
The storage compartments are located in the
dashboard, between the driver seat and the
passenger seat, and under the passenger
seat. To access the under-passenger seat
storage compartment, remove the passenger
seat cushion (see page 4-15 for more infor-
mation).
When storing any documents in the storage
compartments, be sure to wrap them in a
plastic bag so that they will not get wet. When
washing the vehicle, be careful not to let any
water enter the storage compartments.
1. Unlock.
2. Open.
1
2
4-19
4
NOTICE
ECB02241
To protect from damage, do not put metal
items, like tools, or sharply edged items di-
rectly in the storage compartment. If these
items must be stored, wrap them in appro-
priate cushioning material.
1. Storage compartment
1
1. Storage compartment
1. Storage compartment
1
1
4-20
4
EBU31520
Cup holders
Be sure to tightly close the cap of any plastic
bottle before placing it in a cup holder.
Some plastic bottles may not fit into the cup
holders depending on their size and shape.
WARNING
EWB03240
Never ride with any open or glass con-
tainers in the cup holders; otherwise, the
contents may spill and the glass contain-
ers may be thrown about and break, and
possibly injure people in the vehicle dur-
ing sudden braking or an accident.
Do not place any other items than seal-
able plastic containers in the cup hold-
ers; otherwise, they may be thrown
about and possibly injure people in the
vehicle during sudden braking or an ac-
cident.
EBU33630
Cargo bed
WARNING
EWB03250
Never carry passengers in the cargo
bed.
Maximum load limit:
Storage compartment between the driver
seat and the passenger seat:
6.4 kg (13.5 lb)
1. Cup holder
1
4-21
4
Do not exceed the specified maximum
load limits. Heavier cargo could cause
loss of control because of improper
weight balance.
There are six cargo hooks in the cargo bed.
For additional loading information, see page
6-7.
Removing and installing the tailgate
To remove the tailgate
Unhook the latches, and then pull up the tail-
gate.
1. Cargo hook
1
1. Cargo hook
Maximum load limit: 136.0 kg (300 lb)
1
4-22
4
To install the tailgate
Place the tailgate in the original position, and
then hook the latches.
The tailgate can also be installed at the front
of the cargo bed. Install the tailgate and hook
the latches as shown.
EBU33614
Front shock absorbers
The shock absorber assemblies are equipped
with a spring preload adjusting nut, a rebound
damping force adjusting screw, a fast com-
pression damping force adjusting bolt, and a
slow compression damping force adjusting
screw.
1. Tailgate
2. Latch
2
2
1
1. Tailgate
2. Latch
2 2
1
4-23
4
WARNING
EWB02492
Suspension components become hot
during operation. Never touch the com-
pression damping force adjusting bolt
and screw, the rebound damping force
adjusting screw or the oil reservoir with
your bare hand or skin until suspension
components have cooled.
Always adjust the shock absorber as-
semblies on the left and right side to the
same setting. Uneven adjustment can
cause poor handling and loss of stability,
which could lead to an accident.
NOTICE
ECB00091
Never turn an adjusting mechanism be-
yond the minimum and maximum settings.
TIP
Although the total number of clicks or turns of
a damping force adjusting mechanism may
not exactly match the following specifications
due to small differences in production, the ac-
tual number of clicks or turns always repre-
sents the entire adjusting range. To obtain a
precise adjustment, it would be advisable to
check the number of clicks or turns of each
damping force adjusting mechanism and to
modify the specifications as necessary.
Spring preload
1. Loosen the locknut.
2. Turn the spring preload adjusting nut in
direction (a) to increase the spring pre-
load and thereby harden the suspension,
and in direction (b) to decrease the spring
preload and thereby soften the suspen-
sion.
4-24
4
TIP
A special wrench can be obtained at a
Yamaha dealer to make this adjustment.
The spring preload setting is determined by
measuring distance A, shown in the illustra-
tion. The shorter distance A is, the higher
the spring preload; the longer distance A is,
the lower the spring preload. With each
complete turn of the adjusting nut, distance
A is changed by 1.5 mm (0.06 in).
3. Tighten the locknut to the specified
torque. NOTICE: Always tighten the
locknut against the adjusting nut, and
then tighten it to the specified torque.
[ECB00082]
1. Special wrench
2. Locknut
3. Spring preload adjusting nut
2
1
3
(a)
(b)
Spring preload setting:
Minimum (soft):
Distance A = 313.5 mm (12.34 in)
Standard:
Distance A = 305.5 mm (12.03 in)
Maximum (hard):
Distance A = 298.5 mm (11.75 in)
1. Distance A
1
4-25
4
Rebound damping force
Turn the rebound damping force adjusting
screw in direction (a) to increase the rebound
damping force and thereby harden the damp-
ing, and in direction (b) to decrease the re-
bound damping force and thereby soften the
damping.
Compression damping force
Fast compression damping force
To increase the fast compression damping
force and thereby harden the compression
damping, turn the fast compression damping
force adjusting bolt in direction (a). To de-
crease the fast compression damping force
and thereby soften the compression damp-
ing, turn the adjusting bolt in direction (b).
Tightening torque:
Locknut:
30 N·m (3.0 kgf·m, 22 lb·ft)
1. Rebound damping force adjusting screw
1
(a)
(b)
Rebound damping setting:
Minimum (soft):
30 click(s) in direction (b)*
Standard:
13 click(s) in direction (b)*
Maximum (hard):
1 click(s) in direction (b)*
* With the adjusting screw fully turned in di-
rection (a)
4-26
4
Slow compression damping force
To increase the slow compression damping
force and thereby harden the compression
damping, turn the slow compression damp-
ing force adjusting screw in direction (a). To
decrease the slow compression damping for-
ce and thereby soften the compression
damping, turn the adjusting screw in direction
(b).
1. Fast compression damping force adjusting bolt
Fast compression damping force settings:
Minimum (soft):
2 turn(s) out from the fully turned in posi-
tion
Standard:
1 1/4 turn(s) out from the fully turned in
position
Maximum (hard):
Adjusting bolt fully turned in
1
(a)
(b)
1. Slow compression damping force adjusting screw
1
(a)
(b)
4-27
4
WARNING
EWB00411
These shock absorber assemblies contain
highly pressurized nitrogen gas. Read and
understand the following information be-
fore handling the shock absorber assem-
blies.
Do not tamper with or attempt to open
the cylinder assemblies.
Do not subject the shock absorber as-
semblies to an open flame or other high
heat source. This may cause the unit to
explode due to excessive gas pressure.
Do not deform or damage the cylinders
in any way. Cylinder damage will result in
poor damping performance.
Do not dispose of a damaged or worn
out shock absorber assembly yourself.
Take the shock absorber assembly to a
Yamaha dealer for any service.
EBU33623
Rear shock absorbers
The rear shock absorber assemblies are
equipped with a spring preload adjusting nut,
a rebound damping force adjusting screw, a
fast compression damping force adjusting
bolt, and a slow compression damping force
adjusting screw.
WARNING
EWB02492
Suspension components become hot
during operation. Never touch the com-
pression damping force adjusting bolt
and screw, the rebound damping force
Slow compression damping force settings:
Minimum (soft):
18 click(s) in direction (b)*
Standard:
12 click(s) in direction (b)*
Maximum (hard):
1 click(s) in direction (b)*
* With the adjusting screw fully turned in di-
rection (a)
4-28
4
adjusting screw or the oil reservoir with
your bare hand or skin until suspension
components have cooled.
Always adjust the shock absorber as-
semblies on the left and right side to the
same setting. Uneven adjustment can
cause poor handling and loss of stability,
which could lead to an accident.
NOTICE
ECB00091
Never turn an adjusting mechanism be-
yond the minimum and maximum settings.
TIP
Although the total number of clicks or turns of
a damping force adjusting mechanism may
not exactly match the following specifications
due to small differences in production, the ac-
tual number of clicks or turns always repre-
sents the entire adjusting range. To obtain a
precise adjustment, it would be advisable to
check the number of clicks or turns of each
damping force adjusting mechanism and to
modify the specifications as necessary.
Spring preload
1. Loosen the locknut.
2. Turn the spring preload adjusting nut in
direction (a) to increase the spring pre-
load and thereby harden the suspension,
and in direction (b) to decrease the spring
preload and thereby soften the suspen-
sion.
4-29
4
TIP
A special wrench can be obtained at a
Yamaha dealer to make this adjustment.
The spring preload setting is determined by
measuring distance A, shown in the illustra-
tion. The shorter distance A is, the higher
the spring preload; the longer distance A is,
the lower the spring preload. With each
complete turn of the adjusting nut, distance
A is changed by 1.5 mm (0.06 in).
3. Tighten the locknut to the specified
torque. NOTICE: Always tighten the
locknut against the adjusting nut, and
then tighten it to the specified torque.
[ECB00082]
1. Locknut
2. Spring preload adjusting nut
3. Special wrench
1
3
2
(a) (b)
Spring preload setting:
Minimum (soft):
Distance A = 386.0 mm (15.20 in)
Standard:
Distance A = 378.0 mm (14.88 in)
Maximum (hard):
Distance A = 372.0 mm (14.65 in)
1. Distance A
1
4-30
4
Rebound damping force
Turn the rebound damping force adjusting
screw in direction (a) to increase the rebound
damping force and thereby harden the damp-
ing, and in direction (b) to decrease the re-
bound damping force and thereby soften the
damping.
Compression damping force
Fast compression damping force
To increase the fast compression damping
force and thereby harden the compression
damping, turn the fast compression damping
force adjusting bolt in direction (a). To de-
crease the fast compression damping force
and thereby soften the compression damp-
ing, turn the adjusting bolt in direction (b).
Tightening torque:
Locknut:
30 N·m (3.0 kgf·m, 22 lb·ft)
1. Rebound damping force adjusting screw
1(a)
(b)
Rebound damping setting:
Minimum (soft):
30 click(s) in direction (b)*
Standard:
14 click(s) in direction (b)*
Maximum (hard):
1 click(s) in direction (b)*
* With the adjusting screw fully turned in di-
rection (a)
4-31
4
Slow compression damping force
To increase the slow compression damping
force and thereby harden the compression
damping, turn the slow compression damp-
ing force adjusting screw in direction (a). To
decrease the slow compression damping for-
ce and thereby soften the compression
damping, turn the adjusting screw in direction
(b).
1. Fast compression damping force adjusting bolt
Fast compression damping force settings:
Minimum (soft):
2 turn(s) out from the fully turned in posi-
tion
Standard:
1 1/4 turn(s) out from the fully turned in
position
Maximum (hard):
Adjusting bolt fully turned in
1
(a)
(b)
1. Slow compression damping force adjusting screw
1
(a)
(b)
4-32
4
WARNING
EWB03500
These shock absorber assemblies contain
highly pressurized nitrogen gas. Read and
understand the following information be-
fore handling the shock absorber assem-
blies.
Do not tamper with or attempt to open
the cylinder assemblies.
Do not subject the shock absorber as-
sembly to an open flame or other high
heat source. This may cause the unit to
explode due to excessive gas pressure.
Do not deform or damage the cylinders
in any way. Cylinder damage will result in
poor damping performance.
Do not dispose of a damaged or worn
out shock absorber assembly yourself.
Take the shock absorber assembly to a
Yamaha dealer for any service.
EBU31552
Trailer hitch bracket and receiver
Slow compression damping force settings:
Minimum (soft):
18 click(s) in direction (b)*
Standard:
12 click(s) in direction (b)*
Maximum (hard):
1 click(s) in direction (b)*
* With the adjusting screw fully turned in di-
rection (a)
1. Trailer hitch bracket
2. Receiver
1
2
4-33
4
This vehicle is equipped with a trailer hitch
bracket and a 2" (5 cm) receiver for a stan-
dard trailer hitch. Trailer towing equipment
can be obtained at a Yamaha dealer. See
page 6-7 for loading information.
EBU32952
Auxiliary DC jack
This model has an auxiliary DC jack in the
dashboard. A 12-V accessory with the proper
plug, such as a radio or smartphone charger,
can be used when the engine is running and
the headlights are off.
1. Start the engine. (See page 6-2.)
2. Turn the headlights off. (See page 4-11.)
3. Open the auxiliary DC jack cap.
4. Turn the accessory off.
5. Insert the accessory power plug.
6. Turn the accessory on.
TIP
When inserting or removing the accessory
power plug, turn the accessory off.
When the auxiliary DC jack is not being
used, cover it with the cap.
1. Auxiliary DC jack cap
2. Auxiliary DC jack
2
1
Auxiliary DC jack maximum capacity:
10 A (120 W)
4-34
4
NOTICE
ECB02250
Do not use accessories requiring more
than the stated maximum capacity. Do-
ing so may overload the circuit and cau-
se the fuse to blow.
If accessories are used without the en-
gine running, the battery may discharge.
Do not use an automotive cigarette light-
er or other accessories with a plug that
gets hot, because the jack can be dam-
aged.
5-1
5
EBU31574
FOR YOUR SAFETY – PRE-OPERATION CHECKS
EBU31584
Before starting off, inspect the vehicle to make sure it is in safe operating condition. Use the fol-
lowing checklist and related information as a guide. Also, follow the service intervals in the peri-
odic maintenance chart to keep the vehicle in safe operating condition.
WARNING
EWB00482
Failure to inspect or maintain the vehicle properly increases the possibility of an accident
or equipment damage. Do not operate the vehicle if you find any problem. If a problem can-
not be corrected by the procedures provided in this manual, have the vehicle inspected by
a Yamaha dealer.
Pre-operation checklist
ITEM ROUTINE PAGE
Brakes •Check operation, free play, fluid level, and fluid leakage.
•Fill with DOT 4 brake fluid if necessary. 5-3, 8-39, 8-42
Parking brake •Check for proper operation. 8-42
Fuel •Check fuel level.
•Fill with the recommended fuel if necessary. 5-3
Engine oil • Check oil level.
• Fill with oil to proper level if necessary. 5-5, 8-14
5-2
5
Coolant • Check coolant level in reservoir.
•Fill with coolant if necessary. 5-6, 8-25
Final gear oil/Differen-
tial gear oil •Check for leakage. 5-6, 5-6, 8-20, 8-22
Accelerator pedal •Check free play and for proper operation. 5-6
Seat belts • Check for proper operation and belt wear. 5-7
Passenger handhold •Check for stability and proper fastening. 5-7, 7-8
Steering •Check for proper operation. 5-7
Fittings and fasteners •Check all fittings and fasteners. 5-7
Instruments, lights and
switches •Check for proper operation. 3-3, 4-2, 5-8, 8-54,
8-56, 8-57
Wheels and tires •Check tire pressure and for wear and damage. 5-8, 8-45, 8-47
Axle boots • Check for damage. 8-29
ITEM ROUTINE PAGE
5-4
5
WARNING
EWB02522
Gasoline and gasoline vapors are ex-
tremely flammable. To avoid fires and ex-
plosions and to reduce the risk of injury
when refueling, follow these instructions.
1. Before refueling, turn off the engine and
be sure that no one is sitting in the vehi-
cle.
Never refuel while smoking, or while in
the vicinity of sparks, open flames, or
other sources of ignition such as the pilot
lights of water heaters and clothes dry-
ers.
2. Do not overfill the fuel tank. Because fuel
expands when it heats up, heat from the
engine or the sun can cause fuel to spill
out of the fuel tank.
3. Wipe up any spilled fuel immediately.
4. Be sure the fuel tank cap is closed se-
curely.
WARNING
EWB02532
Gasoline is poisonous and can cause inju-
ry or death. Handle gasoline with care.
Never siphon gasoline by mouth. If you
should swallow some gasoline or inhale a
lot of gasoline vapor, or get some gasoline
in your eyes, see your doctor immediately.
If gasoline spills on your skin, wash with
soap and water. If gasoline spills on your
clothing, change your clothes.
Your Yamaha engine has been designed to
use regular unleaded gasoline with a research
octane number of 91 or higher (95 or higher
for Europe). If knocking or pinging occurs,
use a different brand of gasoline or premium
unleaded gasoline. Unleaded fuel will give
you longer spark plug life and reduced main-
tenance cost.
5-5
5
For Europe
TIP
When refueling, check that the gasoline pump
nozzle has same fuel identification mark.
Portable fuel containers
If you carry a portable fuel container in the
bed of your Yamaha Wolverine, be sure to se-
cure it with the cap tightened before driving
the vehicle.
Always place a portable fuel container on the
ground before filling it. Before removing the
container cap, touch the container with the
fuel dispenser nozzle. Keep fuel dispenser
nozzle in contact with container inlet when fill-
ing. WARNING! Never refill a fuel container
in the bed of any vehicle. Fire may result
from a build-up of static electricity. The
discharge of this build-up while refueling
can cause a spark and ignite the gasoline.
[EWB03270]
EBU31750
Engine oil
Make sure the engine oil is at the specified
level. Add oil as necessary. (See page 8-14.)
Recommended fuel:
Regular unleaded gasoline only
For Europe: Regular unleaded gasoline only
with a research octane number of 95 or
higher
Fuel tank capacity:
36.7 L (9.69 US gal, 8.07 Imp.gal)
1. EN228 fuel identification mark
E10
1
5-6
5
NOTICE
ECB00301
In order to prevent clutch slippage (since
the engine oil also lubricates the clutch),
do not mix any chemical additives. Do
not use oils with a diesel specification of
“CD” or oils of a higher quality than
specified. In addition, do not use oils la-
beled “ENERGY CONSERVING II” or
higher.
Make sure that no foreign material en-
ters the crankcase.
EBU31761
Coolant
Check the coolant level in the reservoir and
replenish if necessary. (See page 8-25.)
EBU36020
Final gear
Make sure there is no oil leaking from the final
gear case.
EBU36030
Differential gear
Make sure there is no oil leaking from the dif-
ferential gear case.
EBU31791
Accelerator pedal
Before starting the engine, confirm that the
accelerator pedal operates correctly. It
should depress smoothly and spring back to
the idle position when released. Also check
the accelerator pedal for excessive free play.
If the accelerator pedal is not in correct work-
ing order, have the vehicle inspected before
starting off.
Recommended engine oil type and quantity:
See page 10-1.
5-7
5
EBU31800
Seat belts
Make sure that the seat belts are not frayed,
torn, stretched, or damaged. The seat belts
must move smoothly when pulled out and re-
tract on its own when released. The seat belts
must also lock up when quickly pulled out.
The latch plate should click securely into the
buckle and release when the release button is
pushed firmly. Wash off any dirt or mud that
could affect operation. Have a Yamaha dealer
repair as necessary for proper operation.
A crash can damage the restraint systems in
your vehicle. A damaged restraint system
may not properly protect the person using it,
resulting in serious injury or death in a crash.
To help make sure your restraint systems are
working properly after a crash, have them in-
spected and any necessary replacements
made as soon as possible.
EBU31810
Passenger handhold
Check that the handhold bar and its supports
are in good condition. Confirm that the lock-
ing pins are securely fastened, and then push
and pull on the handhold to make sure that it
is not loose.
EBU31820
Steering
Park on level ground. Turn the steering wheel
right and left. Check for excessive free play,
abnormal noises, or a rough feeling. Have a
Yamaha dealer repair as necessary for proper
operation.
EBU31832
Fittings and fasteners
Always check the tightness of chassis fittings
and fasteners before starting off. Take the ve-
hicle to a Yamaha dealer or refer to the Servi-
ce Manual for correct tightening torque.
5-8
5
EBU31840
Instruments, lights and switches
Check that all instruments, lights and switch-
es are working properly. Correct if necessary.
EBU31851
Control cables
When driving in cold weather, always make
sure all control cables work smoothly before
starting off. WARNING! Control cables can
freeze in cold weather and you could be
unable to control the vehicle. [EWB03280]
EBU33481
Tires
Check tire pressure regularly to make sure it
is at the recommended specifications. Also
check for wear and damage.
Tire pressure
Use the tire pressure gauge to check and ad-
just tire pressures when the tires are cold. Tire
pressures must be equal on both sides.
WARNING! Operation of this vehicle with
improper tire pressure may cause severe
injury or death from loss of control or roll-
over. Tire pressure below the minimum
specified could also cause the tire to dis-
lodge from the rim under severe driving
conditions. [EWB04120]
Set tire pressures to the following specifica-
tions:
5-9
5
The tire pressure gauge is included as stan-
dard equipment. Make two measurements of
the tire pressure and use the second reading.
Dust or dirt in the gauge could cause the first
reading to be incorrect.
Tire wear limit
When the tire groove decreases to 3 mm
(0.12 in) due to wear, replace the tire.
Recommended tire pressure:
Vehicle load:
0 - maximum
Front:
75.0 kPa (0.750 kgf/cm², 11 psi)
Rear:
75.0 kPa (0.750 kgf/cm², 11 psi)
Minimum tire pressure:
Vehicle load:
0 - maximum
Front:
70.0 kPa (0.700 kgf/cm², 10 psi)
Rear:
70.0 kPa (0.700 kgf/cm², 10 psi)
Maximum vehicle load*:
327.0 kg (721 lb)
* Total weight of operator, passenger, acces-
sories, cargo, and (if applicable) trailer
tongue weight
1. Tire pressure gauge
1
5-10
5
1. Tire wear limit
1
6-1
6
EBU31872
OPERATION
EBU31880
Read the Owner’s Manual carefully to be-
come familiar with all controls. If there is a
control or function you do not understand,
ask your Yamaha dealer.
WARNING
EWB03290
Failure to familiarize yourself with the con-
trols can lead to loss of control, which
could cause an accident or injury.
EBU31890
Engine break-in
There is never a more important period in the
life of your vehicle than the period between 0
and 20 hours.
For this reason, we ask that you read the fol-
lowing material carefully. Because the engine
is brand new, you must not put an excessive
load on it for the first several hours of opera-
tion. During the first 20 hours, the various
parts in the engine wear and polish them-
selves to achieve the correct operating clear-
ances.
During this period, prolonged full-throttle op-
eration or any condition that might result in
excessive engine heating must be avoided.
However, momentary (2–3 seconds maxi-
mum) full-throttle operation under load does
not harm the engine.
Each full-throttle acceleration sequence
should be followed with a substantial rest pe-
riod for the engine, by cruising at lower r/min
so the engine can rid itself of the temporary
build-up of heat. If any abnormality is noticed
during this period, consult a Yamaha dealer.
0–10 hours:
Avoid continuous operation above 1/2-throt-
tle. Allow a cooling-off period of 5 to 10 minu-
tes after every hour of operation. Vary the
speed of the vehicle from time to time. Do not
operate it at one set throttle position.
6-2
6
10–20 hours:
Avoid prolonged operation above three-quar-
ter throttle.
After break-in:
The vehicle may now be operated normally.
EBU33081
Starting the engine
1. Turn the key to “ ” (on).
NOTICE
ECB02291
The coolant temperature warning light and
engine trouble warning light should come
on, then go off.
The EPS warning light should come on,
then go off when the engine is started.
To avoid possible damage, do not operate
the vehicle if a warning light does not work
as described above.
2. Apply the brake pedal.
3. Shift the drive select lever into the neutral
position.
When the drive select lever is in the
neutral position, the neutral indicator
light should come on. If the neutral indi-
cator light does not come on, ask a
Yamaha dealer to inspect the electric
circuit.
The engine can be started in any gear if
the brake pedal is applied. However, it
is recommended to shift into neutral
before starting the engine.
4. With your foot off the accelerator pedal,
start the engine by turning the key to “ ”
(start).
If the engine fails to start, release the key, and
then try starting it again. Wait a few seconds
before the next attempt. Each attempt should
be as short as possible, to preserve battery
energy. NOTICE: Do not crank the engine
more than 5 seconds on each attempt, or
starter damage could occur. Wait at least
5 seconds between each operation of the
electric starter to let it cool. [ECB02140]
6-3
6
Do not turn the key to the “ ” (start) position
with the engine running; otherwise, damage
to the electric starter may result.
TIP
For maximum engine life, never accelerate
hard when the engine is cold!
EBU31912
Drive select lever operation and re-
verse driving
NOTICE
ECB02150
Do not shift without coming to a complete
stop and waiting for the engine to return to
normal idle speed. Damage to the engine
or drive train may occur.
Shifting: neutral to high and high to low
1. Stop the vehicle, and take your foot off
the accelerator pedal.
2. Apply the brake pedal, then shift by mov-
ing the drive select lever along the shift
guide. Make sure that the drive select le-
ver is completely shifted into position.
3. Release the parking brake, if applied.
4. Release the brake pedal and press the
accelerator pedal gradually.
1. Drive select lever
2. L (Low-range)
3. H (High-range)
4. N (Neutral)
5. R (Reverse)
1
2
5
4
3
6-4
6
Shifting: neutral to reverse
WARNING
EWB03300
Before you shift into reverse, make sure
there are no obstacles or people behind
you. When it is safe to proceed, go slowly.
Hitting an obstacle or person could result
in serious injury or death.
1. Stop the vehicle, take your foot off the ac-
celerator pedal, and check behind you.
2. Apply the brake pedal.
3. Shift from neutral to reverse by moving
the drive select lever along the shift gui-
de.
When in reverse, the reverse indicator
light should be on. If the light does not
come on, ask a Yamaha dealer to in-
spect the reverse indicator light electri-
cal circuit.
Due to the synchronizing mechanism in
the engine, the light may not come on
until the vehicle starts moving.
4. Release the parking brake, if applied.
5. Check behind the vehicle for people or
obstacles, and then release the brake
pedal.
6. Press the accelerator pedal gradually and
continue to watch to the rear while back-
ing.
1. Drive select lever
2. L (Low-range)
3. H (High-range)
4. N (Neutral)
5. R (Reverse)
1
2
5
4
3
6-5
6
EBU31922
On-Command drive knob
The vehicle handles differently in each of the drive modes (“2WD”, “4WD” and “DIFF LOCK”). For
example, the vehicle requires more effort to turn in “DIFF LOCK” than in “2WD”. Always stop the
vehicle before changing the position of the On-Command drive knob. The meter display changes
according to the selected drive mode. The different drive indicators, and the differential gear lock
indicator light “DIFF. LOCK” come on as follows:
Knob position Indication Drive mode
No indicator light.
“2WD” (two-wheel drive): Power is supplied to the rear
wheels.
“4WD” (four-wheel drive): Power is supplied to the rear and
front wheels.
“DIFF LOCK” (four-wheel drive with the differential gear
locked): Power is supplied to the rear and front wheels and
the differential gear is locked.
Unlike in four-wheel drive, all wheels turn at the same
speed.
6-8
6
TIP
You can measure tongue weight with a bath-
room scale. Put the tongue of the loaded trail-
er on the scale with the tongue at hitch height.
Adjust the load in the trailer, if necessary, to
reduce the weight on hitch. If you are carrying
cargo and towing a trailer, include the tongue
weight in the maximum vehicle load limit.
Operating when loaded with cargo or tow-
ing a trailer
Drive more slowly than you would without a
load. The more weight you carry, the slower
you should go. Although conditions vary, it is
good practice to keep the vehicle in low gear
whenever you are carrying heavier loads or
when towing a trailer.
WARNING
EWB03320
Carrying loads or towing a trailer can in-
crease the risk of loss of control, an over-
turn, or other accident. To reduce the risk
of an accident:
Reduce speed, operate in low gear only,
and allow more room to stop. A heavier
vehicle takes longer to stop.
Avoid hills and rough terrain. Choose
terrain carefully. Use extreme caution
when towing or carrying a load on in-
clines.
Turn gradually and go slowly.
MAXIMUM LOAD LIMITS
Cargo bed:
136.0 kg (300 lb)
Pulling load (gross trailer weight):
6664 N (680 kgf, 1500 lbf)
Tongue weight (vertical load on hitch):
490 N (50 kgf, 110 lbf)
Vehicle maximum load (all occupants, ac-
cessories, cargo, and tongue weight):
327.0 kg (721 lb)
6-9
6
Pulling something other than a trailer
Yamaha recommends that loads be trans-
ported in the bed or in a trailer. If you need to
move an object a short distance use a winch
and follow the winch manufacturer’s instruc-
tions.
If you choose to use something other than a
winch use extreme caution, follow the manu-
facturer’s instructions for that product, and
only attach to the hitch or hitch bracket of the
Wolverine. WARNING! Improperly pulling
can cause serious injury or death. Never
exceed the pulling load limit of the
Wolverine. Avoid pulling on inclines. [EWB03330]
Pulling objects on the ground can be more
hazardous than pulling a trailer. It may be dif-
ficult to predict how the load will affect vehicle
operation. That effect could also change de-
pending upon terrain or what obstacles might
be in the object’s path.
7-1
7
EBU31950
BASIC GUIDE FOR SAFE USE
EBU31961
As a Wolverine owner you are responsible for
the safe and proper operation of this vehicle.
Read this chapter and review the safety in-
structions in Chapter 2 before operating the
vehicle. Use these chapters and the labels on
the vehicle to instruct new operators and pas-
sengers. Do not allow anyone else to operate
the vehicle or ride as a passenger if you are
unsure that he/she is willing and able to follow
these instructions.
WARNING
EWB03340
Follow these instructions to reduce your
risk of an accident and to reduce the risk
of serious injury or death in the event of an
accident.
EBU33512
KNOW YOUR VEHICLE
This off-road vehicle will handle and maneu-
ver differently from cars, ATVs, go-carts, golf-
cars and grounds-keeping vehicles. The
Wolverine has higher ground clearance and
other features to handle rugged terrain, and,
as a result, can overturn in situations where
some vehicles may not. This would include
vehicles made primarily for pavement, roads,
improved paths, or grounds-keeping. If you
do not use care in maneuvering the
Wolverine, you can cause it to roll over even
on flat, open areas.
Doing things with a Wolverine that some peo-
ple do for thrills in other vehicles [such as
sideways sliding, skidding, fishtailing (rear-
wheel sliding), or donuts] have led to side roll-
overs. These rollovers can result in crushed
limbs and other serious injuries or death to
drivers or passengers.
7-2
7
As the owner/operator, it is your responsibility
to protect yourself and your passenger from
accidents, including rollovers. The Wolverine
has many features, including a protective
structure and seat belts, to help protect occu-
pants, but the best way to avoid injuries is to
avoid accidents. There is a risk of injury or
death in any accident, even with these safety
features.
Driver requirements
This vehicle is intended for use only by an
operator 16 or older with a valid motor ve-
hicle license. Check country laws for mini-
mum age requirements.
The driver must be able to place both feet
flat on the floorboard while seated upright
with his/her back against the backrest.
Do not drive after using drugs or alcohol.
Remove the ignition key when the vehicle is
not in use to prevent unauthorized use of
the machine.
Parents:
Many countries have implemented new mo-
tor vehicle licensing requirements for young
drivers. These requirements are in response
to the disproportionately high rate of crashes
involving youthful drivers. As with automo-
DRIVER
UNDER
16
7-3
7
biles, to promote safe driving behaviors, you
should supervise younger drivers and consid-
er setting rules and putting limits on how,
when, and where the Wolverine can be used.
Passenger requirements
This vehicle is designed for the operator and
one passenger. Allowing passengers to ride
improperly can lead to serious injury or death.
As the operator, you are responsible for your
passenger.
Your passenger must be able to place both
feet on the floorboard while seated upright
with his/her back against the backrest.
Your passenger must be able to reach and
hold the passenger handhold.
Allow only one passenger in the vehicle and
only in the designated passenger seat. Do
not carry any other passengers. Do not car-
ry passengers in the cargo bed.
Do not allow someone to ride as a passen-
ger who has been using drugs or alcohol.
Do not allow children who need child safety
seats or booster seats in the Wolverine. The
seat belt is not designed to restrain auto-
motive child safety seats.
Occupant protection system
WARNING
EWB03350
Do not make changes to the occupant pro-
tection system. If you install aftermarket
products or have your vehicle modified,
you may put yourself and others at greater
risk of serious injury or death. You are re-
sponsible for any such changes to the ve-
hicle.
7-4
7
The Wolverine comes with a variety of fea-
tures to help reduce the risk of driver and pas-
senger injury. These features work together,
and when properly used, these features will
help protect the occupants in the event of an
accident. If these features are not used prop-
erly, they can cause injury.
1. Seat belt
2. Shoulder bolster
3. Door
1
2
3
1
1. Passenger handhold
2. Shoulder bolster
3. Door
1
2
3
7-5
7
Protective structure
The vehicle cage/frame provides a protective
structure that helps limit intrusions by branch-
es or other objects and may reduce your risk
of injury in accidents. The protective structure
will not protect occupants in all rollovers or
accidents.
Body parts outside of vehicle can be struck
by passing objects or crushed during vehicle
rollover. Do not put your hands or feet outside
of the vehicle for any reason. Do not hold onto
the door, cage/frame or shoulder bolster.
Wear your seat belt and helmet.
If you think or feel that the vehicle may tip or
roll, do not put your hands or feet outside the
vehicle for any reason. You will not be able to
stop the vehicle from tipping over using your
body. Any part of your body (arms, legs, or
head) outside of the vehicle can be crushed
by the vehicle cage/frame.
Seat belts
Seat belts should be worn by the driver and
passenger. The driver must be sure that the
passenger is belted before driving.
Be sure the seat belt is not twisted, is close-
fitting across the hips and chest, and is
latched securely.
Do not wear the seat belt across the abdo-
men or stomach.
Do not put the seat belt behind the back.
Failure to use seat belts properly may lead to
an increased likelihood and severity of injury.
An unbelted occupant may strike the interior
of the vehicle, the protective structure, or oth-
er objects in an accident or during operation.
You may also fall completely out or be partial-
ly ejected from the vehicle, which may lead to
being crushed between the ground and the
vehicle. Wearing the seat belt helps you re-
main in the vehicle – the doors and passenger
handhold are not a substitute for using a seat
belt.
7-6
7
A crash can damage the restraint systems in
your vehicle. A damaged restraint system
may not properly protect the person using it,
resulting in serious injury or death in a crash.
To help make sure your restraint systems are
working properly after a crash, have them in-
spected and any necessary replacements
made as soon as possible.
To wear the seat belt properly, do the follow-
ing:
1. Hold the latch plate as you pull the belt
across your lap and chest. Make sure the
belt is not twisted and is not caught on
any portion of the vehicle, your clothing,
or any equipment you are carrying.
2. If the latch plate is not positioned in the
correct location along the seat belt,
squeeze the latch plate ends together
along its long edges in order to more eas-
ily adjust its location up or down along
the length of the belt.
1. Seat belt
2. Latch plate
3. Buckle
1
2
1
2
3
7-7
7
3. Push the latch plate into the buckle until it
clicks. Pull up on the latch plate to make
sure it is secure.
4. Put the lap portion of the belt low on your
hips. Pull up on the shoulder part so the
belt is snug across your hips. Be sure the
seat belt is not caught on the shoulder
bolster or other object.
5. Position the shoulder belt over your
shoulder and across your chest. The
shoulder belt should fit against your
chest. If it is loose, pull the belt out all the
way and then let it retract.
6. Check if the seat belt shoulder position
suits the size of the driver and passenger.
To lower the belt, insert the belt into the
seat belt height adjuster slot as shown.
To raise the belt, remove the belt from the
height adjuster slot.
1. Buckle
2. Latch plate
3. Release button
1
3
2
1. Seat belt height adjuster
2. Seat belt
3. Slot
12
3
7-8
7
7. To release the buckle, firmly press the re-
lease button.
Doors
The doors are designed to reduce the likeli-
hood that you will stick your leg out to stop
the vehicle from tipping over or for any other
reason in a rollover. The doors may also re-
duce intrusion of objects into the occupant
area. Make sure the door is securely latched
before operation. Do not place your arm or
hand on the door during operation. Your hand
or arm may be struck by objects or crushed
against outside objects or the ground during
a rollover.
Passenger handhold
The passenger handhold is provided to grip
during operation to maintain proper position
and balance. Holding onto the handhold
helps to reduce the likelihood that the pas-
senger puts a hand outside the vehicle if the
vehicle begins to tip.
The driver should make sure the passenger is
holding onto the handhold with both hands
before operating the vehicle.
7-9
7
Adjusting the handhold position
The handhold can be adjusted to one of three
positions to suit the passenger’s preference.
Adjust the handhold position as follows.
1. Remove the locking pins.
2. Slide the handhold to the desired position
and align the holes in the handhold bar
with the holes in the handhold supports.
1. Passenger handhold
2. Locking pin
2
1
7-10
7
3. Insert the pins into the holes and secure
them with the wire loops. Make sure that
the handhold is properly secured before
starting off.
Seat and shoulder bolsters
The seats and shoulder bolsters are designed
to help keep you in the vehicle. Do not put
your hand or arm on or outside of the shoul-
der bolster during operation. Your hand or
arm may be struck by objects or crushed
against outside objects or the ground during
a rollover.
1. Handhold support
2. Handhold bar
2
1
1
1. Wire loop
1
7-11
7
Floorboard
The floorboard allows you to brace your feet,
which helps you keep your body in the vehicle
in the event of an accident or rollover. Keep
your feet on the floorboard during operation.
Steering wheel
Keep both hands on the steering wheel. Do
not hold the steering wheel with your thumbs
inside the rim. Keep your palms on the out-
side of the steering wheel. Similar to other off-
road vehicles, if the Wolverine hits a deep rut
or large obstacle, the steering wheel could
briefly jerk in one direction or back and forth
as the tires and vehicle respond to the obsta-
cle. This quick motion could injure your
thumbs or wrist if your thumbs or hand(s) are
inside the steering wheel. Grip the steering
wheel so that your thumbs will not be hit by
the spokes. As an example, see the illustra-
tion.
7-12
7
EBU33543
LEARNING TO OPERATE YOUR VEHI-
CLE
Personal protective equipment
The driver and passenger should wear the fol-
lowing to reduce risk of injury in an accident:
Approved motorcycle helmet that fits prop-
erly
CORRECT GRIP EXAMPLE
I CORRECT GRIP EXAMPLEN
1. Approved motorcycle helmet
2. Eye protection
3. Long-sleeved shirt or jacket
4. Gloves
5. Long pants
6. Over-the-ankle boots
12
3
4
5
6
7-13
7
Eye protection (goggles, helmet face shield,
or protective eyewear)
Over-the-ankle boots, gloves, long-sleeved
shirt or jacket, and long pants
An approved helmet and other personal pro-
tective equipment can help in a variety of
ways, including:
Reduce the severity of injuries if any part of
you is outside the vehicle cage/frame pro-
tective structure during a rollover.
Help protect you if outside objects intrude
inside the vehicle during operation.
Help protect you in the event of vehicle im-
pact with an obstacle.
Wear eye protection when operating or riding
in the vehicle to reduce the risk of a serious
accident or injury. Eye protection, such as a
face shield or goggles, may reduce the risk of
foreign material getting in your eyes and help
prevent loss of vision.
Practice for new Yamaha Wolverine users
You should become familiar with the perfor-
mance characteristics of the vehicle in a lar-
ge, flat area that is free of obstacles and other
vehicles. Practice controlling the accelerator
pedal, brakes, steering, and drive select lever.
Drive at slow speeds with gradual accelera-
tion and turning. Practice smooth throttle ap-
plication. Practice slowing down before
turning. Practice maintaining a steady throttle
through the turn. Avoid higher speeds until
you are thoroughly familiar with the operation
of your vehicle. Remember, driving aggres-
sively or making abrupt maneuvers even on
flat, open areas can cause side rollovers.
7-14
7
Become familiar with the way the vehicle feels
in low and high ranges, first in two-wheel
drive “2WD” and then in four-wheel drive
“4WD” and four-wheel drive with the differen-
tial locked “DIFF LOCK”. Steering may take
more effort in four-wheel drive with the differ-
ential locked “DIFF LOCK”. Also practice
driving in reverse.
Take the time to learn basic operation of the
vehicle before attempting more difficult ma-
neuvers.
Getting ready to ride
Perform the Pre-Operation Checks on page
5-1. Follow the instructions starting on page
6-2 to start the engine.
Turning
Use care in turns – turning the steering wheel
too far or too fast can result in loss of control
or a rollover. Slow down before entering
turns. When making tight turns from a stand-
still or at slow speeds, avoid sudden or hard
acceleration. Driving aggressively or making
abrupt maneuvers even on flat, open areas
can cause side rollovers. Avoid sideways slid-
ing, skidding, or fishtailing (rear-wheel slid-
ing), and never do donuts. If you feel the
Wolverine begin to slide sideways or the rear
wheels begin to slide during a turn, steer into
the direction of the slide, if possible, and
gradually let off the accelerator pedal to re-
gain directional control and avoid rollover. For
example, if you feel the back of the vehicle
start to slide to your right, steer to the right.
7-15
7
If you think or feel that the vehicle may tip or
roll, keep your body completely inside the
protective structure of the vehicle:
Brace yourself by pressing your feet firmly
on the floorboard and keep a firm grip on
the steering wheel or passenger handhold.
Do not put your hands or feet outside of the
vehicle for any reason. Do not try to stop a
tipover using your arm or leg.
Accelerating
With the engine idling in neutral and your foot
on the brake, shift the drive select lever into
low or high. NOTICE: Do not shift from low
to high or vice versa without coming to a
complete stop and waiting for the engine
to return to normal idle speed – damage to
the engine or drive train may occur. Then
release the parking brake. [ECB02160] Press the
accelerator pedal slowly and smoothly. The
centrifugal clutch will engage and the vehicle
will begin to accelerate.
Avoid higher speeds and sudden or hard ac-
celeration until you are thoroughly familiar
with the operation of your vehicle. Avoid sud-
den or hard acceleration in any turn.
Braking
When slowing down or stopping, take your
foot off the accelerator pedal and press the
brake pedal smoothly. Improper use of the
brakes can cause the tires to lose traction, re-
ducing control of the vehicle and increasing
the possibility of an accident.
Braking ability is affected by type of terrain. In
most cases, gradual application of the brakes
is more effective than abrupt braking, partic-
ularly on loose surfaces, such as gravel. Al-
ways allow for greater braking distance on
rough, loose, or slippery surfaces.
Engine braking
Engine compression braking is designed to
assist you when operating your Wolverine off-
road. With this feature, the engine helps slow
7-18
7
to see far enough ahead of you. Use common
sense and remember that some hills are too
steep for you to climb or descend. Use proper
driving techniques to avoid rearward, for-
ward, or sideways rollovers on hills and
slopes.
Drive straight up and down inclines, not
across them. If crossing a hill is unavoidable,
drive slowly. Turn downhill immediately if you
feel the vehicle may tip.
If you think or feel the vehicle may tip or
roll:
Brace yourself by pressing your feet firmly
on the floorboard and keep a firm grip on
the steering wheel or passenger handhold.
Do not put your hands or feet outside of the
vehicle for any reason.
Uphill
Do not attempt to climb hills until you have
mastered basic maneuvers on flat ground.
Drive straight up hills, and avoid crossing the
side of a hill, which increases your risk of roll-
over. Practice first on gentle slopes before at-
tempting steeper hills. Always check the
terrain carefully before attempting any hill.
To climb a hill, you need traction, momentum,
and steady throttle. For more traction and
control for climbing steeper and/or rougher
slopes, shift into low gear and select “4WD”
or “DIFF LOCK”. Travel fast enough to main-
tain momentum, but not so fast that you can-
not react to changes in the terrain as you
climb.
Slow down when you reach the crest of the
hill if you cannot see clearly what is on the
other side – there could be another person, an
obstacle, or a sharp drop-off.
If you start to lose traction or momentum
when climbing, and decide you will be unable
to continue, use the brakes to stop. Do not at-
tempt to turn the vehicle around. With your
foot on the brake pedal, look behind you and
plan your descent. Shift the drive select lever
into reverse so you can use engine braking to
7-19
7
slow your descent. Release the brake and be-
gin to coast down the hill. Use engine braking
as much as possible, gently applying the
brakes when necessary.
Downhill
Check the terrain carefully before going
downhill. When possible, choose a path that
lets you drive your vehicle straight downhill.
Choose your path carefully and drive slowly
enough to be able to react to obstacles that
you encounter.
For more traction and control, before going
down steeper and/or rougher slopes, shift
into low gear and select “4WD” or “DIFF
LOCK”. Engine braking will help you go
downhill slowly. Go as slowly as possible. If
you begin to go too fast, apply the brakes
gently. Avoid hard application of the brakes,
which could cause the vehicle to slide.
If you are sliding or skidding, try to steer in the
direction the vehicle is sliding, to regain con-
trol. For example, if you feel the back of the
vehicle start to slide to your right, steer to the
right.
If you must turn on the hill to avoid an obsta-
cle, do so slowly and carefully. If the vehicle
starts to tip, immediately steer in the downhill
direction if there are no obstacles in your
path. As you regain proper balance, gradually
steer again in the direction you want to go.
Rough terrain
Operation over rough terrain should be done
with caution.
Look for and avoid obstacles that could
cause damage to the vehicle or could lead
to a rollover or accident.
Do not drive in a way that will get the vehicle
airborne, as injury, loss of control, and
damage to the vehicle could occur.
7-20
7
Pavement
This vehicle is designed for off-road use only.
Avoid paved surfaces. Turn gradually and go
slowly if you must drive on pavement.
Water
If you must cross shallow, slow-moving water
up to the depth of the vehicle’s floorboard,
choose your path carefully to avoid sharp
drop-offs, large rocks, or slippery surfaces
that could cause the vehicle to overturn. Nev-
er operate through water deeper than 37 cm
(15 in) or fast-flowing water. Choose a path
where both your entrance into and exit point
from the water is a gradual incline. Determine
the water depth and currents before crossing.
Operating this vehicle through deep or fast-
flowing water can lead to loss of control or
overturn. To reduce your risk of drowning or
other injuries, use care when crossing
through water.
Wet brakes may have reduced effectiveness.
After leaving the water, test the brakes. If nec-
essary, apply the brakes several times to let
friction dry them out.
NOTICE
ECB02170
After driving your vehicle in water, be sure
to drain the trapped water by removing the
check hoses at the bottom of the air filter
case and air duct and the V-belt case drain
plug. Wash the vehicle in fresh water if it
has been operated in salt water or muddy
conditions.
Loose terrain/slippery terrain
When driving on slippery terrain, including
wet, muddy, or icy conditions, as well as
loose gravel, be aware that you could begin
skidding or sliding. To avoid loss of control,
slow down and put the vehicle in four-wheel
drive before driving on a slippery surface and
plan your path to avoid making abrupt ma-
neuvers.
7-21
7
If you feel the vehicle begin to slide sideways
or fishtail (rear-wheel sliding), steer into the di-
rection of the slide if possible, to regain direc-
tional control. For example, if you feel the
back of the vehicle start to slide to your right,
steer to the right.
Brush or wooded areas
When operating in areas with brush or trees,
watch carefully on both sides and above the
vehicle for obstacles such as branches that
the vehicle might hit, causing an accident.
Watch for brush that might enter the vehicle
as you pass and strike you or the passenger.
Never hold onto the cage/frame. The passen-
ger should always hold onto the passenger
handhold with both hands.
The muffler and other engine parts become
extremely hot during operation and remain
hot after the engine has stopped. To reduce
the risk of fire during operation or after leaving
the vehicle, do not let brush, grass and other
materials collect under the vehicle, near the
muffler or exhaust pipe, or next to other hot
parts. Check under the vehicle after operating
in areas where combustible materials may
have collected. Do not idle or park the vehicle
in long dry grass or other dry ground cover.
Encountering obstacles
If you cannot go around an obstacle, such as
a fallen tree or a ditch, stop the vehicle where
it is safe to do so. Set the parking brake and
get out to inspect the area thoroughly. Look
from both your approach side and exit side. If
you believe you can continue safely, choose
the path that will allow you to get over the ob-
stacle and at as close to a right angle as pos-
sible to minimize vehicle tipping. Go only fast
enough to maintain your momentum but still
give yourself plenty of time to react to chang-
es in conditions.
7-22
7
If there is any question about your ability to
maneuver safely over the obstacle, you
should turn around if the ground is flat and
you have the room or back up until you find a
less difficult path.
8-1
8
EBU32005
PERIODIC MAINTENANCE AND
ADJUSTMENT
EBU32010
Periodic inspection, adjustment, and lubrica-
tion will keep your vehicle in the safest and
most efficient condition possible. Safety is an
obligation of the vehicle owner/operator. The
most important points of vehicle inspection,
adjustment, and lubrication are explained on
the following pages.
WARNING
EWB01842
Failure to properly maintain the vehicle or
performing maintenance activities incor-
rectly may increase your risk of injury or
death during service or while using the ve-
hicle. If you are not familiar with vehicle
service, have a Yamaha dealer perform the
service.
WARNING
EWB02563
Turn off the engine when performing main-
tenance unless otherwise specified.
A running engine has moving parts that
can catch on body parts or clothing and
electrical parts that can cause shocks or
fires.
Running the engine while servicing can
lead to eye injury, burns, fire, or carbon
monoxide poisoning - possibly leading
to death. See page 2-5 for more informa-
tion about carbon monoxide.
WARNING
EWB02691
Brake discs, calipers, drums, and linings
can become very hot during use. To avoid
possible burns, let brake components cool
before touching them.
8-2
8
EBU33561
Owner’s Manual and tool kit
You are recommended to put this manual in
the vinyl bag and always carry it in the glove
compartment as shown. Put the tool kit and
tire pressure gauge under the passenger
seat.
The maintenance information included in this
manual is intended to provide you, the owner,
with the necessary information for completing
your own preventive maintenance and minor
repairs.
The tools provided in the tool kit are sufficient
for this purpose, and should be kept on the
vehicle in case of emergency repairs.
Other tools and equipment are required for
certain service items. If you do not have a
torque wrench available during a service op-
1. Owner’s Manual
1
1. Tool kit
2. Tire pressure gauge
1
2
8-3
8
eration requiring one, take your vehicle to a
Yamaha dealer to check the torque settings
and adjust them as necessary.
