Side 1/5
![](https://manualstech.ams3.cdn.digitaloceanspaces.com/html/nl/aluratek/abctwskit/html/bg1.png)
Volume upBluetooth
Pairing
Volume down
Optical /
AUX
Select
TX / Bypass / RX
Mode Switch
Optical
(SPDIF)
Ports*
Micro U DC IN PortSB
AUX (3.5mm) Ports
*In SPDIF mode, connect devices through SPDIF IN
for TX mode and SPDIF OUT for RX mode
Warranty
Package Contents Receiver / Transmitter Product Highlights Bluetooth Earbuds and Charging Case - Product Highlights
Charging the True Wireless Earbuds/Battery case
True Wireless Earbuds - Device Operation (using with other devices) True Wireless Earbuds - Device Operation (using with other devices)
Using the Transmitter and Headphones with a TV Using the Transmitter and Headphones with a TV Using the Transmitter and Headphones with a TV
qsg Q10469 Copyright © 2019 Aluratek, Inc. All Rights Reserved.
aluratek.com
model ABCTWSKIT
Qui idc uk Start G e
Bluetooth Wireless TV Streamin itg K w/ Bluetooth 5
Your order has been carefully packaged and inspected. The following accessories should
be included in your package. Please inspect the contents of the package to ensure that
you ha ve it received all ems and that no hing has been damaged ou dist . If y cov a , er problem
please contact us immediately for assistance.
USB Cable
(x2)
Regis rat tion Car d
RCA-Y Cable 3.5 mm Cable
True Wireless Earbud pairing instructions:
Power On:
Press the “Touch Panel” for 3 seconds.
Power Off:
Press the “Touch Panel” for 3 seconds.
Pause/Play music:
During music playback, short press the “Touch Panel”
*
Next song:
During music playback, quickly press the “Touch Panel” twice
*
Answer a call:
Short press the “Touch Panel”
*
Hang up a call:
During a call, short press the “Touch Panel”
*
Refuse a call:
When there is an incoming call, press the “Touch Panel” for 2 seconds
*
No leate: P se kema sure he audio ou t tpu is set t to Blue oot th for audio streaming rom he devi f t ce.
* These features can be done either on the left or right earbuds.
There are three ways to connect the Transmitter:
Connect using the AUX (3.5mm) cable.
Connect the Transmitter to the AUX OUT / headset (3.5mm) port on the back
of your TV.
Connect using the RCA-Y cable.
When using the included RCA cable to connect to a TV or tuner / receiver,
please make sure you connect to the RCA OUT. Some TV’s may not have an
RCA OUT. Connecting to the RCA IN will not work.
1
RCA-IN /
Line-In
RCA-OUT /
Line-Out
AUX OUT /
3.5 mm headset port
2Connect using the Optical (SPDIF) cable.
When using the included Optical cable to connect to a TV or tuner / receiver,
please make sure you connect to the SPDIF OUT on the TV / tuner and
connect the optical cable to the SPDIF IN port on the transmitter.
SPDIF IN /
Line-In
SPDIF OUT /
Line-Out
3
Digital Optical Cable
Left & Right Indicators Silicon Eartips
Charging Pin
Voice Call
Microphone
Touch Button
Indicator
Charging Port
Indicator
Charging the True Wireless Earbuds
Battery Charging Status
Note: ABCTWSKIT will try to reconnect when it is powered ON / OFF again or when it is out of range.
The Transmitter and Headphones are pre-paired and ready for use out of the
box. Simply power on both devices and enjoy!
Connect the larger USB end of the provided cable to your computer/power adapter (not
included). Connect the smaller USB end to the USB port on the back of the True Wireless
Earbud Battery case. Please charge the case for a minimum of 2 hours. The Blue LED will be
flashing while charging. The Blue LED will turn off when it is fully charged.
The battery is not fully charged and it is highly recommended that you charge the headset
before you begin using it. The earbuds feature a rechargeable battery for up to 5 hours of
continuous talk and music play. The case (with built-in battery) holds multiple charges for up
to 15 hours of listening time.
1st LED: Blue means RIGHT earbud is charging. It will turn off when it is fully charged
2nd LED: Blue means LEFT earbud is charging. It will turn off when it is fully charged
When the Earbuds Are in the Case:
1-2 LED on: Case is 25% - 50% charged
2-3 LED on: Case is 50% - 75% charged
3-4 LED on: Case is 75% - 100% charged
When Battery Case is Open:
Indicator
1. Open the charging case, the earbuds will power on and pair to each other automatically.
Please wait until the LED on the left earbud turns off and the LED on the right LED flashing
Red/Blue before paring to your device.
2. Activate your device’s Bluetooth function and set your device to search for Bluetooth
devices. Select ABHTWS01F when it is found.
3. If prompted by your device to connect, please select “Yes”.
4. After connecting successfully, the blue LED will flash every 5 seconds.
Radio and TV Interference Statement
Technical Support
If you need further assistance, please contact the Aluratek support department for troubleshooting
prior to returning this device.
E-mail: support@aluratek.com
Web: www.aluratek.com/helpdesk
Local (Irvine, CA): 714-586-8730
Toll free: 1-866-580-1978
WARNING!!! This equipment has been tested and found to comply with the limits of a Class B digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by whatever measures may be required to correct the interference.
Aluratek warrants this product against defect in material or workmanship for 1 YEAR
from the date of purchase.
This warranty becomes invalid if the factory-supplied serial number or "warranty void" sticker
has been removed or altered on the product.
This warranty does not cover:
A) Cosmetic damage or damage due to acts of God
B) Accident, misuse, abuse, negligence or modification of any part of the product.
C) Damage due to improper operation or maintenance, connection to improper equipment,
or attempted repair by anyone other than Aluratek.
D) Products sold AS IS or WITH FAULTS.
IN NO EVENT SHALL ALURATEK'S LIABILITY EXCEED THE PRICE PAID FOR THE
PRODUCT FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THE PRODUCT, IT'S ACCOMPANYING
SOFTWARE, OR IT'S DOCUMENTATION.
Aluratek makes no warranty or representation, expressed, implied, or statutory, with respect to
it's products, contents or use of this documentation and all accompanying software, and
specifically disclaims it's quality, performance, merchantability, or fitness for any particular
purpose. Aluratek reserves the right to revise or update it's product, software or documentation
without obligation to notify any individual or entity.
