UNILINE™ CONDENSER QUICK-MOUNT
GOOSENECK MICROPHONE
- Designed for high-quality sound
reinforcement, professional record-
ing and broadcasting.
- UniLine™ polar pattern provides
narrow 90° acceptance angle.
- Superior o-axis rejection for maxi-
mum gain before feedback.
- UniGuard™ RFI-shielding technol-
ogy oers outstanding rejection of
radio frequency interference (RFI).
- Easy-to-adjust, rugged, small-
dimeter, alternating gooseneck with
virtually no “memory” permits quick
positioning into desired shape.
- UniSteep® lter provides a steep
low-frequency attenuation to im-
prove sound pickup without aect-
ing voice quality.
- Self-contained electronics eliminate
need for external power module.
- Accepts interchangeable elements
to permit angle of acceptance from
90° to 360°.
- Two-stage foam windscreen yields
dramatically improved resistance to
P-pops and other breath blasts.
- Quick-mount design with 3-pin XLRM-type connector insert at
base plugs into any standard XLRF-type surface or cable con-
nector.
- Optional shock mount attenuates noise, shock and vibration
transmitted through the mounting surface.
The U857QLU stands 603mm from the table or podium. The
model is require 11V to 52V phantom power for operation.
Output from the microphone's XLRM-type connector is low
impedance (Lo-Z) balanced. The signal appears across Pins
2 and 3; Pin 1 is ground (shield). Output phase is "Pin 2 hot" -
positive acoustic pressure produces positive voltage at Pin 2.
At integral 80 Hz high-pass UniSteep® filter provides easy
switching from a at frequency response to a low-end roll-off.
The roll-o position reduces the microphone's sensitivity to
popping in close vocal use. It also reduces the pickup of low-
frequency ambient noise (such as trafc, air-handling systems,
etc.), room reverberation and mechanically coupled vibrations.
Avoid leaving the microphone in the open sun or in areas where
temperatures exceed 43°C for extended periods. Extremely
high humidity should also be avoided.
SPECIFICATIONS
ELEMENT
POLAR PATTERN
FREQUENCY RESPONSE
LOW FREQUENCY ROLL-OFF
OPEN CIRCUIT SENSITIVITY
IMPEDANCE
MAXIMUM INPUT SOUND LEVEL
DYNAMIC RANGE (TYPICAL)
SIGNAL-TO-NOISE RATIO
PHANTOM POWER REQUIREMENTS
SWITCH
WEIGHT
DIMENSIONS
OUTPUT CONNECTOR
OPTIONAL INTERCHANGEABLE
ELEMENTS
ACCESSORIES FURNISHED
Fixed-charge back plate
permanently polarized condenser
Line Cardioid
30-20,000 Hz
80 Hz, 18 dB/octave
-35 dB (17.7 mV) re 1V at 1 Pa
250 ohms
135 dB SPL, 1 kHz at 1% T.H.D.
115 dB, 1 kHz at Max SPL
74 dB, 1 kHz at 1 Pa
11-52V DC, 2 mA typical
Flat, roll-o
167 g
603 mm - long,
12.2 mm - head diameter
Integral 3-pin XLRM-type
UE-C cardioid (120°)
UE-H hypercardioid (100°)
UE-O omnidirectional (360°)
AT8154 two-stage foam windscreen
10 dB
20k10k5k2k1k50020010050
8 kHz
200 Hz
1 kHz
5 kHz
0°
330°
300°
270°
240°
210°
180°
150°
120°
90°
60°
30°
Optional Accessories:
AT8662 shock mount.
AT8506 four-channel 48V phantom power
supply (AC powered).
AT8615 quick-mount plug-in microphone
desk stand.
AT8801/EU single-channel 48V phantom
power supply (AC powered).
Polar Pattern
Frequency Response
SCALE IS 5 DECIBELS PER DIVISION
LEGEND
Frequency in Hertz
LEGEND 12” or more on axis
Roll-o
Response in dB
FORM No. ATGC-L0167-10-E
Machida • Tokyo • Japan
