MEETS OR EXCEEDS THE
ASTM 1625-00 STANDARDS
Sportfi x
Carefully read the instructions before using this child seat. Keep them in a safe place for future
reference.
Before using the product, consult the Highway Code for the country of use.
WARNING: failure to comply with the manufacturer’s instructions may compromise the safety of the
child and of the cyclist and may result in serious injury or death.
NOTICE
WARNING: Do not add any extra loads to the child seat. For additional loads, use a rear parcel rack.
WARNING: All modifi cations to the child seat and supports are prohibited. The manufacturer,
distributor or retailer will not be held responsible for any damages caused by such modifi cations.
WARNING: When a child is on the seat, the bike may handle differently from normal conditions,
especially in terms of balance, steering and brakes.
WARNING: The child seat may reduce the maneuverability of the handlebar. Replace the handlebar
if the child seat reduces the steering angle to less than 45° on each side.
WARNING: Never leave the bike parked with the child unattended in the child seat.
WARNING: Never leave the child in the seat when the bike is only supported by the kick-stand.
WARNING: Do not use the child seat if any parts of the seat and/or bike are broken or missing.
Contact the manufacturer or dealer to order spare parts for the seat.
In case of accident, replace the seat completely even when there is no visible damage.
GENERAL INFORMATION
Front child seat for children weighing a maximum of 15 kg – 33 lb; periodically check that the child
does not exceed the weight limit.
Only use if the child is capable of sitting straight, unassisted, for a long period of time (from 9/12
months approx.). Consult a pediatrician before carrying a child less than 12 months old.
Use on bikes with 26”-28” diameter wheels that can carry additional loads equal to at least 18 kg – 40
lb. Refer to the bike manual or consult with your retailer.
Make sure that the bicycle is in good conditions, and especially ensure that brakes, lights and tires
are all in perfect working order.
Make sure that the size of the bike is suitable for the cyclist and that it allows all and any necessary
adjustments to ensure maximum safety for the cyclist.
Consult the bicycle’s manual, or the bicycle dealer, for any further information.
Do not install the child seat so that it leans forwards. Lean it slightly backwards in order to hold the
child more effectively.
Install the child seat facing front.
Do not use the child seat on motorcycles, scooters, mopeds, racing bikes or bikes with suspensions.
Do not use the child seat on electric bikes. It is possible to use the child seat on electric pedal
assisted cycles.
Check that none of the child or cyclist limbs or clothing might be caught in the moving parts of the
bike (wheels, brake mechanism and saddle springs) or of the child seat.
Check that the child cannot poke his/her fi ngers or feet into the spokes of the bike wheel. We
recommend the use of a wheel guard.
Ensure that the child cannot reach sharp or cutting edges (e.g. frayed brake cables)
Always fasten the child with the harness and the straps on their ankles.
Check that the child is always dressed warmly enough, more than the cyclist and that he/she is
protected in the event of rain.
It is mandatory for the child to use an approved helmet suitable for his/her head size.
Never carry two children at the same time.
The cyclist must be at least 16 years old.
Always fasten any harness or straps, even when there is no child on the seat.
Ensure that the straps do not interfere with the wheels or other moving parts of the bike, both with
and without the child on board.
Never leave the child seat in the sun: when seating the child, the heated plastic cold burn the child’s
skin or cause other injuries.
Remove the child seat from the bike each time the latter is transported on the outside of a vehicle
(e.g. on a car roof, on a towed trailer or behind a motorhome).This is necessary because the wind
force could affect or damage the child seat to the extent that it might compromise the seat’s reliability
when being re-used.
Periodically check the bike: tires, brakes, lights, etc.
Periodically check the seat’s anchoring system.
Periodically wash the child seat with soap and water. Do not use aggressive substances.
INSTALLING THE CHILD SEAT
Do not install the product on the bike with the child in the seat.
Ensure you have all the components before proceeding with assembly (fi g. A).
Installing the support block
Install the support block on the bicycle frame as illustrated in fi g. B.
WARNING: the two half brackets can be positioned according to four different combinations (fi g. C).
Choose the one most suited to your bike frame.
WARNING: Install the block according to the direction that the bicycle travels in (yellow button facing
front).
WARNING: do not install the support block on the handlebar
WARNING: make sure that the brake and gear cables do not get in the way of the block.
Tighten all nuts evenly (fi g. D). Slide the brackets in the protective plastic tubes.
WARNING: periodically check that the nuts are properly tightened. They may loosen with use.
Fixing the support fork to the child seat
Turn the seat over.
Position the support fork beneath the base of the child seat (fi g. E).
Insert the screws into the base of the child seat (fi g. F).
Position the fi xing plate beneath the child seat (fi g. G).
Tighten the nuts in order to fasten the support fork (fi g. H).
WARNING: periodically check that the nuts are properly tightened. They may loosen with use.
Fixing the child seat to the bike
Hold down the yellow button on the bracket- Insert the support fork into the upper part of the block
(fi g. I).
WARNING: once inserted, ensure that the yellow button pops out. If it doesn’t, the fork is not
inserted correctly: repeat the operation.
Determine the best position for the child seat:
• There must be suffi cient room for the cyclist to steer ad pedal comfortably.
• Check that the cyclist’s knees do not knock against the child seat when pedaling
• Check that the bicycle handlebar does not get caught in the child seat when steering
• Leave suffi cient room to be able to move the child in and out of the child seat comfortably.
• The child must have suffi cient leg room during the ride.
• Make sure that the child seat does not get in the way of the pedals, brakes, gears and other
moving parts of the bicycle.
Taking the child seat off the bike
Hold down the yellow button on the block and pull up the support fork up and off.
Installing and/or replacing the footrests
Take the left footrest (marked L on the back).
Push it into the vertical slot on the left side.
Push up as far as.
Take the blocking lever of the left footrest (marked SX on the back).
Push the blocking lever into the hole behind the footrest. Insert from the outside and push in (fi g. L).
Close the blocking lever by pushing downwards until you hear a click.
Repeat the same operation for the right footrest.
ADJUSTING THE CHILD SEAT
Before using the seat, ensure that the child’s feet rest completely on the footrests.
To adjust the height of the footrests:
Turn the blocking lever behind the bracket in the upward position (fi g. M).
Move the footrest up or down to the desired position.
Block the lever by pushing downwards until you hear a click.
FINAL CHECK
WARNING: do not run the fi nal check with the child in the seat.
Push the bicycle for several meters by hand to ensure that no moving parts touch the child seat,
that none of the harness or straps interferes with the wheel, and that the bicycle brakes and pedals
work properly.
Repeat the check every time you take out the bike for a ride.
PLACING THE CHILD IN THE SEAT
Press the button on the large central buckle until you hear a click indicating that the hook has been
released (fi g. N).
Pull upwards to extract the buckle.
Seat the child.
Pull the harness down over the child’s head (fi g. O).
Fasten the large central buckle into the opening (fi g. P). Push the buckle all the way into the slot
until you hear a click.
Adjust the holders on the harness so that the harness will adhere to the child’s body (fi g. Q).
Place the child’s feet in the footrests.
Lock the ankle strap and fasten it to the pin on the back of the footrest (fi g. R).
WARNING: always fasten and tighten all safety straps used to hold the child (both harness and
ankle straps).
WARNING: when cycling, periodically check that the child is properly fastened at all times.
WARNING: fasten the footrest straps even when a child is not being carried, so that they do not
hang loose from the seat.
REMOVING THE CHILD FROM THE SEAT
Release the straps on the child’s ankles.
Press the button on the large central buckle until you hear a click indicating that the hook has been
released.
Pull upwards to extract the buckle.
Pull the harness over the child’s head.
GUARANTEE
The conditions of the guarantee can be found on our web site: www.bellelli.com and www.
mammacangura-na.com.
03ISSPFBELNA00
1 FE
2 PA
3 FE
4 FE
5 PE
6 PA
7 FE
8 FE
9 FE
10 FE
11 PP
12 PP
13 FE
14 FE
15 PU
16 PP
17 POM
18 PE
19 PP
20 PP
21 PA
22 PA
23 PC
24 PP
QDBXB
K
@A
K
D
1
23
4
5
6
7
8910 11
12
13
16
15
14
24
17
18
19
21
20 22
23
max 15 kg
max 33 lb
Ergonomic Handle • Poignée Ergonomique
2
1
3
ONLY FOR FRECCIA SEAT
