Drayton MiTime T720R Manual
Læs nedenfor 📖 manual på dansk for Drayton MiTime T720R (2 sider) i kategorien Termostat. Denne guide var nyttig for 3 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere
Side 1/2
Step 1: Keys and Display - MiTime
RF Packs: T710R, T720R, T720M, T740R, T 740M
Single Channel: MiTime T710R Dual Channel: MiTime T720R, T720M Multi Channel: MiTime T740R, T740M
Step 2: Home Screens
→
What is a programmer?
... an explanation for householders
Programmers allow you to set ‘On’ and ‘Off’ time
periods. Some models switch the central heating and
domestic hot water on and off at the same time, while
others allow the domestic hot water and heating to
come on and go off at different times.
Set the ‘On’ and ‘Off’ time periods to suit your own
lifestyle. On some programmers you must also set
whether you want the heating and hot water to run
continuously, run under the chosen ‘On’ and ‘Off’
heating periods, or be permanently off.
The time on the programmer must be correct. Some
types have to be adjusted in spring and autumn at the
changes between Greenwich Mean Time and British
Summer Time.
You may be able to temporarily adjust the heating
programme, for example, ‘Override’, ‘Advance’ or
‘Boost’. These are explained in the manufacturer’s
instructions.
The heating will not work if the room thermostat has
switched the heating off. Also, if you have a hot-water
cylinder, the water heating
will not work if the cylinder
thermostat detects that the
hot water has reached the
correct temperature.
What is a room thermostat?
... an explanation for householders
A room thermostat simply switches the heating
system on and off as necessary. It works by sensing
the air temperature, switching on the heating when
the air temperature falls below the thermostat setting,
and switching it off once this set temperature has
been reached.
Turning a room thermostat to a higher setting will not
make the room heat up any faster. How quickly the
room heats up depends on the design of the heating
system, for example, the size of boiler and radiators.
Neither does the setting affect how quickly the room
cools down. Turning a room thermostat to a lower
setting will result in the room being controlled at a
lower temperature, and saves energy.
The heating system will not work if a time switch or
programmer has switched it off.
The way to set and use your room thermostat is to
find the lowest temperature setting that you are
comfortable with, and then leave it alone to do its job.
The best way to do this is to set the room thermostat
to a low temperature – say 18ºC – and then turn it up
by one degree each day until you are comfortable
with the temperature. You won’t have to adjust the
thermostat further. Any adjustment above this setting
will waste energy and cost you more money.
If your heating system is a boiler with radiators, there
will usually be only one room thermostat to control the
whole house. But you can have different temperatures
in individual rooms by installing thermostatic radiator
valves (TRVs) on individual radiators. If you don’t
have TRVs, you should choose a temperature that is
reasonable for the whole house. If you do have TRVs,
you can choose a slightly higher setting to make sure
that even the coldest room is comfortable, then prevent
any overheating in other rooms by adjusting the TRVs.
Room thermostats need a free flow of air to sense
the temperature, so they must not be covered by
curtains or blocked by furniture. Nearby electric
fires, televisions, wall or table lamps may prevent the
thermostat from working properly.
What is a cylinder thermostat?
... an explanation for householders
A cylinder thermostat switches on and off the heat
supply from the boiler to the hot-water cylinder. It
works by sensing the temperature of the water inside
the cylinder, switching on the water heating when the
temperature falls below the thermostat setting, and
switching it off once this set temperature has been
reached.
Turning a cylinder thermostat to a higher setting will
not make the water heat up any faster. How quickly the
water heats up depends on the design of the heating
system, for example, the size of boiler and the heat
exchanger inside the cylinder.
The water heating will not work if a time switch or
programmer has switched it off. And the cylinder
thermostat will not always switch the boiler off,
because the boiler sometimes needs to heat the
radiators.
Cylinder thermostats are usually fitted between one
quarter and one third of the way up the cylinder. The
cylinder thermostat will have a temperature scale
marked on it, and it should be set at between 60C and
65C, then left to do its job. This temperature is high
enough to kill off harmful bacteria in the water, but
raising the temperature of the stored hot water any
higher will result in wasted energy and increase the
risk of scalding.
If you have a boiler control thermostat, it should
always be set to a higher temperature than that of the
cylinder thermostat. In most boilers, a single boiler
thermostat controls the temperature of water sent
to both the cylinder and radiators, although in some
there are two separate boiler thermostats.
MiT ime
MiStat
MiTimeTM Programmer Series
RF Packs
Single Channel: MiTime T710R
Dual Channel: MiTime T720R, T720M
Multi Channel: MiTime T740R, T740M
Invensys
Customer Service Tel: 0845 130 5522
Customer Service Fax: 0845 130 0622
Technical Helpline: 0845 130 7722
Website: www.draytoncontrols.co.uk
E-mail: customer.care@invensys.com
l @DraytonControls
x /DraytonControls
EU Design Regs:- 002180638-1/2/3
User Guide 06490193001 Iss F
MiTime
MiS tat
HOMEOWNER Guide
Zone = Heating
Current status: the programme is On
until 12:00 am
Link to zone details, see Step 3.
Link to Settings
See further details in Step 6.
Zone = Hot Water
Current status: the programme is
Off until 12:00 am
Link to zone details, see Step 3.
Press Select ( ) to view or edit zonePress Select ( ) to change mode Press Select ( ) to view or edit zone
Zone = Heating
Current status: the programme is On
until 12:00 am
Link to zone details, see Step 3.
Link to Settings
See further details in Step 6.
Zone = Hot Water
Current status: the programme is Off until
12:00 am. Link to zone details, see Step 3.
Zone = Zone 3
Current status: the programme is Always Off
Link to zone details, see Step 3.
HOMEOWNER Guide
Step 3: Zone Details
(not Single Channel) →→
Link to Settings
See further details in Step 6.
Now: describes the current status,
e.g. programme is On until 12:00 am.
Link to Programme timetable - see
further details in Step 4.
Temp: describes the current status
of the zone temperature, e.g.
Temperature in zone is 21.0C and the
setpoint is 21.5C
Link to modify the zone temperature.
Current mode: Auto
Options: see table in Step 3.
Temp: describes the current status of the
zone temperature, e.g. Temperature in
zone is 21.0C and the setpoint is 21.5C.
Link to modify the zone temperature.
Press Select ( ) to change mode
Link to Programme timetable
See further detail in Step 4.
MiTime
Home key: Press to go back
to the home screen at any
time
Date
Time
Back key: Press to return to
the previous screen
Help text to prompt for
next action. It relates to the
highlighted line
Arrow keys: Press to move
the highlight on screen, and
to change field values
Advance key: Press from
the home or zone details
screens to advance to the
next on or off period
+hr key: Press from the
home or zone details
screens to add up to 3 hours
to the current period
Select key: Press to select highlighted
options, and to open and save editor screens
This icon used
throughout these
instructions refers
to this button
LED: Illuminates when any
zone is scheduled to be ON
Note:
See help in product menu for quick
button description.
: Indicates an RF transmission issue or
Service warning.
: Indicates that holiday is enabled
Home screen, depending on
model - see Step 2
Zone = Heating Current mode: Auto
Options: see table below.
Now: describes the current status, e.g. programme
is On until 12:00 am. Link to Programme timetable
- see further details in Step 4.
Mode: Description:
Auto The programmer will control the
ON & OFF times in line with the
programmed timetable
Always Off The selected zone will be OFF
Always On The selected zone will be ON
All Day
(first on / last
off)
The programme will control the
ON & OFF times in line with the
programmed timetable, but using
only the first ON event and the last
OFF event - it will remain ON in
between these two periods.
