GREAT BRITAIN - CUSTOMER SERVICE contact number: 020 8247 9300 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.co.uk
English
1
2
7 8 9
3 4 5 6
Ver. 20150512
Bluetooth Speaker
Art.no 38-6984 Model BX55
Please read theentire instruction manual before using theproduct
and then save it for future reference. We reserve theright for any
errors in text or images and any necessary changes made to
technicaldata. In theevent of technical problems or other queries,
please contact our Customer Services.
Things to consider:
• Other wireless equipment using thesame frequency band can
reduce thetransmissionrange.
• Therange of all wireless equipment depends on thetype of
obstacles located between thetransmitter and thereceiver
(e.g. aconcrete wall will interfere with thesignal more than
aplasterboard wall).
If you experience problems, try thefollowing:
• Turn off any other existing wireless equipment to check whether
this is thecause of theproblem.
• Reposition thewireless equipment, shorten thedistance between
thetransmitter and thereceiver or reduce thenumber of
obstacles (walls, furniture,etc.) betweenthem.
Safety
• Do not place thespeaker where it could fall into water or other
liquid. Donot place any objects which contain liquid onto
thespeaker.
• Never subject thespeaker to high temperature, dust, heavy
vibration, impacts, damp or moisture.
• Do not disassemble or modify thespeaker in anyway.
• Never place any heavy objects on top of thespeaker.
• Air must always be allowed to circulate freely around thespeaker,
never cover it duringuse.
Care and maintenance
• Thespeaker should be cleaned by wiping it with adrycloth.
• If thespeaker is not to be used for along time, thebattery should
be charged every thirdmonth.
Disposal
This product should be disposed of in accordance with local
regulations. Ifyou are unsure how to proceed, contact your
localcouncil.
Specifications
Range Approx. 10m
Battery 1300mAh
Charginginput USB, 5 V DC
Power 3W×2
Operating temperature Max 35°C
Size 3×6.8×18.5cm
Weight 283g
Buttons and functions Note: Ifyou are prompted to enter aPIN code on your device, you
should enter (four zeroes). Certain devices may also require 0000
you to approve theconnection.
If you have connected amobile phone to thespeaker via Bluetooth
and receive acall whilst you are listening to music, themusic will be
switched off automatically and thespeaker will emit aring signal.
Oncethecall has been ended, music playback will be resumed
(ifyour phone settings enable this).
If no connection has been established after 15 minutes,
theBluetooth mode will switch off automatically. Inorder to make
thespeaker detectable for other Bluetooth devices once more,
holdin [ ˃ll ] for approximately 3 seconds.
Changing to another Bluetooth device
1. Turn off Bluetooth on thefirst device.
2. Hold in [ ˃ll ] for 3 seconds in order to make thespeaker
detectable for other Bluetooth devices.
3. Activate Bluetooth on thenew device to be paired with thespeaker.
4. Follow theinstructions in the sectionabove.Bluetooth connection
Connecting an external device via the 3.5 mm
AUX IN jack
1. Connect a3.5 mm audio cable between theexternal audio
device and the3.5mm AUX-IN (8) jack on thespeaker.
2. Turn thespeaker on and begin playback on theexternal device.
Note:
Thespeaker starts in Bluetooth mode (refer to point 1 in
the section above) even if a3.5mm audio Bluetooth connection
cable has been connected. Playback from theAUX IN jack is not
affected bythis.
• Thespeaker can be connected to one device via Bluetooth
and to another via theAUX IN jack at thesametime. Press
[ ˃ll ] to toggle between devices. Ittakes 6–7 seconds Note:
for thespeaker to change from Bluetooth playback to AUX IN
playback.
• Thespeaker prioritises theBluetoothinput. Ifthespeaker is
connected via Bluetooth to amobile phone and to another
device via theAUX IN jack, theplayback from theAUX IN jack
will be interrupted when theplayback from theBluetooth device
begins.
• Thespeaker will then automatically switch to AUX IN playback if
theplayback from theBluetooth device is stopped.
Handsfree function
If your mobile phone is connected to thespeaker via Bluetooth,
thespeaker can be used as ahandsfree device.
Press [ ˃ll ] to answer anincomingcall. Press [ ˃ll ] again to end thecall.
LOCK feature
If [ LOCK-ON-OFF ] is set to the position, thebuttons of LOCK
thespeaker will be locked and calls can only be controlled from
themobilephone.
Volume limit
Thevolume can only be raised to acertain level using the [ + ] button
on thespeaker. Anaudible signal will be emitted when thespeaker
has reached its maximum volume setting. Thevolume can only be
raised further by using themobilephone.
Troubleshooting guide
TheBluetooth
speaker will not
switchon.
Thebattery might beflat. Recharge
thebattery.
No sound from
theexternal
device connected
via Bluetooth.
• Check thevolume and that play/pause
has been activated on thedevice.
• Make sure that theBluetooth connection
has been properly established.
• Test theplayback of thefile on thedevice
itself before connecting it to thespeaker.
• Try using anotherfile. Thefile may be
incompatible or damaged.
• Make sure that no other wireless devices
are disrupting thecurrent Bluetooth
connection.
• Is thespeaker in AUX INmode? Press
[ ˃ll ] to switch to Bluetoothmode.
No sound from
theexternal
device connected
via the3.5 mm
AUX IN socket.
• Check thevolume and that play/pause
has been activated on thedevice.
• Check that thecable connecting
thedevice and thespeaker is
undamaged and securely connected.
• Test theplayback of thefile on thedevice
itself before connecting it to thespeaker.
• Try using anotherfile. Thefile may be
incompatible or damaged.
1. Bluetooth indicator
2. Charging indicator
3. Microphone
4. [ ˃ll ] Play/pause, controlcalls
5. [ - ] Lower thevolume
6. [ + ] Raise thevolume
7. [ LOCK-ON-OFF ] Speaker button lock, on/off
8. AUX IN: 3.5 mmjack
9. DC 5V: Micro-USB port for chargercable
Operating instructions
Charging
1. Connect theincluded charge lead to thecharging port (9) on
thespeaker and to acomputer or other USB charger.
2. Thecharging indicator shines orange while thebattery is
charging and goes out when thebattery is fully charged.
3. Thecharging indicator shines red when thebattery needs to be
charged.
Bluetooth connection
1. Turn thespeaker on by setting the [ LOCK-ON-OFF ] switch to
the position. Thespeaker will emit anaudible signal and ON
theBluetooth indicator will flash red/blue.
2. Activate Bluetooth on thedevice to be paired with thespeaker.
3. Thespeaker will appear on your device as , select it and BX55
pair it with your device.
4. Once connection has been established theblue LED indicator on
thespeaker will flash slowly.
5. Start playback on your device. Setthedesired volume levels
both on your device and thespeaker. Control theother playback
settings on theexternal device and on thespeaker.
Declaration of Conformity
Hereby, Clas Ohlson AB declares that following product(s):
38-6984
BX55
is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC and 2006/95/EC.
Article 3.1a (Health): EN 62479
Article 3.1a (Safety) EN 60065
Article 3.1b (EMC): EN 301489-1
EN 301489-17
Article 3.2 (Radio): EN 300328
Insjön, Sweden, May 2015
Klas Balkow
President
Clas Ohlson, 793 85 Insjön, Sweden
1797
