Kogan SmarterHome Manual
Kogan
Luftfugter
SmarterHome
Læs nedenfor 📖 manual på dansk for Kogan SmarterHome (17 sider) i kategorien Luftfugter. Denne guide var nyttig for 7 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere
Side 1/17
www.HunterFan.com 1.888.830.1326
PA G E
7
PA G E
11
PA G E
5
PA G E
6
30 inches
7 feet
PA G E
2
What to Expect with
Your Installation Ceiling Bracket
Ladder
PA G E
3
Tools Needed
Wiring Canopy
Maintenance
& Cleaning Troubleshooting
Downrod
Switch Housing
& Light Kit
Blades
Table of Contents
PA G E
12
PA G E
4
Mounting Options
PA G E
13
PA G E
16
?
?
?
PA G E
17
Congratulations on purchasing
your new Hunter® ceiling fan! It will
provide comfort and performance
in your home or ofce for many
years. This installation and operation
manual contains complete
instructions for installing and
operating your fan.
We are proud of our work and
appreciate the opportunity to
supply you with the best ceiling fan
available anywhere in the world.
To register your fan, please visit:
www.HunterFan.com/register
Save your receipt for proof of purchase.
1
M3548-01 • 12/19/13 • © Hunter Fan Company
www.HunterFan.com
1.888.830.1326
M3548-01 • 12/19/13 • © Hunter Fan Company
1.888.830.13261.888.830.1326
What to Expect with Your Installation
Know your wiring
If you are unfamiliar
with wiring, use a
qualied electrician.
You may need a
friend to help you.
Check box to see
fan weight
Assess location
30 inches
from blade tip
to nearest wall
or obstruction 7 feet
from bottom
edge of blade
to the oor
Select a downrod length
w.1 - To reduce the risk of re, electrical shock, or
personal injury, mount fan directly from building
structure and/or an outlet box marked acceptable for
fan support of 70 lbs (31.8 kg) and use the mounting
screws provided with the outlet box.
w.2 - To avoid possible electrical shock, before installing
or servicing your fan, disconnect the power by turning
off the circuit breakers to the outlet box and associated
wall switch location. If you cannot lock the circuit
breakers in the off position, securely fasten a prominent
warning device, such as a tag, to the service panel.
w.3 - To reduce the risk of re, electrical shock, or motor
damage, use only Hunter Solid State Speed Controls.
w.4 - To reduce the risk of personal injury, do not bend the
blade brackets when installing the blade brackets, balancing
the blades, or cleaning the fan. Do not insert foreign objects
in between rotating fan blades.
c.1 - All wiring must be in accordance with national and
local electrical codes ANSI/NFPA 70. If you are unfamiliar
with wiring, use a qualied electrician.
c.2 - Use only Hunter replacement parts.
Assess ceiling angle
Read and Save These Instructions
This product conforms to UL Standard 507.
WARNINGS
CAUTIONS
Must be able to
secure the fan to
building structure or
fan-rated outlet box
1
2
3
Standard Downrod
for ceilings 8-10 feet high
Shorter Downrod
for fans installed close to ceiling
Longer Downrod
for ceilings 10 feet or higher
2
Ceiling angles greater
than 34° will require an
Angled Mounting Kit.
See page 4 for details.
www.HunterFan.com
1.888.830.1326
Tools Needed
Ladder ScrewdriversPliers Wire Strippers
Power Drill
(optional)
9/64” Drill Bit
(optional)
If mounting to a support structure, you will also need these tools.
Allen Wrench
(included)
If you are installing multiple remote-controlled
fans on the same circuit breaker,
you may need to perform a few extra steps to
prevent interference or faulty operation of your
remote controls.
Go to www.HunterFan.com/FAQs and click
“How do I properly install multiple remote-
controlled fans?” for more information.
3
M3548-01 • 12/19/13 • © Hunter Fan Company
www.HunterFan.com
1.888.830.1326
4
M3548-01 • 12/19/13 • © Hunter Fan Company
1.866.268.1936
If you have an angled ceiling:
1. You will need a longer downrod . (sold separately)
2. If your ceiling angle is greater than 34°, you will
also need an Angled Mounting Kit .(sold separately)
Guide Touches
BOTH Ceiling & Wall
S
I
T
U
A
T
I
O
N
1
Guide Touches Wall
but
NOT Ceiling
S
I
T
U
A
T
I
O
N
2
You need BOTH
a Longer
Downrod &
an Angled
Mounting Kit
You need ONLY
a Longer
Downrod
*most common
If you have a at ceiling:
Hang your fan by a standard downrod .(included)
Mounting Options
Use Standard Mounting
or Low-Prole Mounting
to hang the fan from a at ceiling.
Use Angled Mounting
to hang the fan from a
vaulted or angled ceiling.
4
34OCEILING
WALL
OPTION 1
Standard
Mounting
OPTION 2
Angled
Mounting
2 3
SLIDE
toward ceiling
PLACE
against wall
1
FOLD
on dotted line
34°
Use the three steps below to determine if your ceiling angle is greater than 34°
Support
Structure
Ceiling
Outlet Box
(required)
Angled
Mounting
Style
Standard
Mounting
Style
Support
Structure
Ceiling
Outlet Box
(required)
M3548-01 • 12/19/13 • © Hunter Fan Company
www.HunterFan.com
1.888.830.1326
www.HunterFan.com
Ceiling Bracket
5
M3548-01 • 12/19/13 • © Hunter Fan Company
Refer to warning w.1 on pg. 2
To avoid possible electrical shock, before
installing your fan, disconnect the power by
turning off the circuit breakers to the outlet
box associated with the wall switch location.
For angled ceilings, point
opening toward peak.
If you are unable to do this,
call Technical Support at
1-888-830-1326.
Make sure all four bumpers are
still attached.
Use wood screws
(included) when securing
to support structure with
approved electrical outlet
box. Drill 9/64” pilot holes
in support structure to aid
in securing ceiling bracket
with hardware found in
the hardware bag.
Use machine screws
(provided with outlet
box) when securing to
existing ceiling fan-rated
outlet box. Make sure
it is securely installed
and is acceptable for fan
support of 31.8 kg (70 lbs)
or less.
OFF
Turn Power
www.HunterFan.com
1.888.830.1326
M3548-01 • 12/19/13 • © Hunter Fan Company
Blades
Your blades are shielded with Dust Armor® which
is a nanotechnology coating that repels dust. For
cleaning the fan, use soft brushes or cloths to prevent
scratching. Cleaning agents may damage the nishes.
6
Using the included Allen wrench, secure
each blade to a blade iron as shown using
the blade nuts, found in the hardware
bag, and the blade assembly screws, found
in the hardware bag.
Lightly attach the blade irons to the
motor with the blade iron armature
screws, found in the hardware bag,
then securely tighten after all screws are
attached.
1.888.830.1326
Downrod
S l i d e
S l i d e
1 2 3 4 5
678910
Sold Separately
Included
Longer
Downrod
for angled
ceilings or
ceilings 10’ or
higher
Shorter
Downrod
for fans installed
close to ceiling
Standard
Downrod
for ceilings 8-10’ high
Option 1Option 2
Option 3
skip to next page
If you need a different downrod length follow these steps:
Steps 1-5 to remove standard downrod pipe
Steps 6-10 to reassemble with pipenew
Included
(pre-assembled)
www.HunterFan.com
7
M3548-01 • 12/19/13 • © Hunter Fan Company
www.HunterFan.com
1.888.830.1326
Downrod (continued)
Hand tighten the downrod (at
least 4-5 full turns) until it stops.
KEEP!
Remove the pre-installed setscrew so that
the downrod can be inserted.
K
E
E
P
!
1.888.830.1326
www.HunterFan.com
Slide the adapter cover onto the downrod
until it rests against the hanger ball.
Adapter
Cover
Hanger
Ball
Note: Fan style may vary.
8
M3548-01 • 12/19/13 • © Hunter Fan Company
8
www.HunterFan.com
1.888.830.1326
8”
3/8”
C
U
T
&
S
T
R
I
P
(not to scale)
The wires can be cut, but leave at least 8”
extending from the top of the downrod.
Downrod (continued)
8” 3/8”
Tighten the setscrew with pliers.
DO NOT HAND TIGHTEN.
If the setscrew is not tightened
securely, the fan may fall.
1.888.830.1326
www.HunterFan.com
Lower the adapter cover until it rests ush
against the motor housing. Install the adapter
cover screws, found in the hardware bag,
and tighten them securely.
9
M3548-01 • 12/19/13 • © Hunter Fan Company
9
www.HunterFan.com
1.888.830.1326
10
M3548-01 • 12/19/13 • © Hunter Fan Company
www.HunterFan.com
Downrod (continued)
DO NOT PICK THE FAN UP BY THE
CANOPY OR WIRES. Place the downrod
ball into the slot in the ceiling bracket.
Put the wires and downrod through the
canopy. Let the canopy sit loosely on top
of the fan.
www.HunterFan.com
1.888.830.1326
Wiring
F
R
O
M
F
A
N
F
R
O
M
C
E
I
L
I
N
G
B
R
A
C
K
E
T
F
R
O
M
F
A
N
Using an orange wire
connector from
the hardware bag,
connect the 3 grounding
wires (green, green/
yellow stripe, or bare
copper) coming from the
ceiling, downrod, and
hanging bracket.
(Grounding) Green/Yellow
Stripe
Green/Yellow
Stripe
White
Black
(Grounded)
Note: To connect the wires,
hold the bare metal leads
together and place a wire
connector over them, then twist
clockwise until tight.
Using the orange wire
connectors from
the hardware bag, connect
the black wire (ungrounded)
from the ceiling to the black
and the blue wires from the
fan. Connect the white wire
(grounded) from the ceiling to
the white wire from the fan.
Using the orange wire
connectors from
the hardware bag,
connect the white wire
(grounded) from the
ceiling to the white wire
from the fan.
Connect the black wire
(ungrounded) from the
ceiling to the black wire
from the fan. Connect the
second (ungrounded) wire
from the ceiling to the blue
wire from the fan.
F
R
O
M
F
A
N
White
(Ungrounded)
Black
Blue
(Grounded)
F
R
O
M
C
E
I
L
I
N
G
(Ungrounded)
Blue
For Dual Switches
For a Single Switch
F
R
O
M
C
E
I
L
I
N
G
F
R
O
M
C
E
I
L
I
N
G
Turn the splices upward and push them carefully back through the hanger bracket
into the outlet box. Spread the wires apart, with the grounded wires on one side of
the outlet box and the ungrounded wires on the other side of the outlet box.
Refer to CAUTION c.1 on pg. 2
11
M3548-01 • 12/19/13 • © Hunter Fan Company
(Ungrounded)
www.HunterFan.com
1.888.830.1326
12
M3548-01 • 12/19/13 • © Hunter Fan Company
Canopy
Lift the canopy into place so that
the screw holes are aligned.
Position the canopy so that, when
lifted into place, the canopy ts into
the hanging bracket as shown.
Insert the two canopy screws
found in the hardware bag.
Note: Fan style may vary.
Screw
Holes
www.HunterFan.com
1.888.830.1326
Feed the wire plug through the
center hole of the upper switch
housing, then wrap keyhole slots
around the screws and twist
counterclockwise.
Screw two switch housing
assembly screws from
the hardware bag halfway
into the motor housing. It does
not matter which two screw
holes you choose.
Insert the third screw, found in
the hardware bag, into
place and then tighten all three
screws.
Make sure the upper switch housing is securely
attached to the mounting plate. Failure to properly
secure all 3 assembly screws could result in the switch
housing xture falling.
Switch Housing & Light Kit
Connect the 9-pin connector
plugs from the motor housing and
switch housing. Make sure to line
up the colored markings on the
connectors.
Switch
Housing
Screw
13
M3548-01 • 12/19/13 • © Hunter Fan Company
www.HunterFan.com
1.888.830.1326
Switch Housing & Light Kit (continued)
Install three switch
housing screws, found in
the hardware bag.
Make sure the light kit assembly is securely attached to the
upper switch housing. Failure to properly secure all three
assembly screws could result in the light xture falling.
To make the connection between
the light kit and the switch housing,
connect the white wire from the
switch housing to the white wire
from the light kit, then connect the
black wire from the switch housing
to the black wire from the light kit.
Lift the light kit assembly and align
the screw holes on the sides of
the switch housing with the screw
holes in the light kit assembly.
Note: The screw holes will only
line up one way. Ensure that all
three screw holes are aligned
before installing the screws.
Install a bulb into each of
the sockets. When necessary,
replace with bulbs of the same
type and wattage.
Screw
Holes
Switch
Housing
Screw
14
M3548-01 • 12/19/13 • © Hunter Fan Company
www.HunterFan.com
1.888.830.1326
Switch Housing & Light Kit (continued)
CONGRATULATIONS!
YOU’RE DONE!
See next page for fan
operation instructions.
Loosen the pre-installed globe
assembly thumbscrews. Lift
the globe into the light xture
and retighten the thumbscrews
securely. Do not overtighten.
Connect the appropriate pull
chain pendant to each of the
short chains coming from the
switch housing. The fan pull chain
controls the speed: from high to
off. The light pull chain controls
the light xture: on and off.
Remove the pull chain
connectors from the pull chains
coming from the fan.
Note: In compliance with US federal energy regulations, this ceiling fan
contains a device that restricts its light output. Exceeding the wattage
limit marked on the MAX wattage sticker afxed to the light socket(s)
may result in re hazard or improper operation.
Globe
Assembly
Thumbscrew
M3548-01 • 12/19/13 • © Hunter Fan Company
15
www.HunterFan.com
1.888.830.1326
M3548-01 • 12/19/13 • © Hunter Fan Company
16
Maintenance & Cleaning
ON
Turn Power
Changing the bulb - unscrew the
thumbscrews while supporting
the globe with your other hand.
Carefully remove the globe.
Unscrew the bulb and replace with
a bulb of same type and wattage.
Reinstall the globe assembly.
Changing the direction of air
ow - move the reverse switch
to the opposite position.
Cleaning the fan - use soft
brushes or cloths to prevent
scratching. Cleaning products
may damage the nishes.
Reverse
Switch
www.HunterFan.com
1.888.830.1326
M3548-01 • 12/19/13 • © Hunter Fan Company
17
Troubleshooting
Excessive wobbling
• Tighten all of the blade and
blade iron screws until they
are snug.
• Turn the power off, support
the fan carefully, and check
that the hanger ball is
properly seated.
• Use the provided balancing
kit and instructions to balance
the fan.
Noisy Operation
• Tighten the blade and blade
iron screws until they are snug.
• Check to see if any of the
blades are cracked. If so, replace
all of the blades.
Fan doesn’t work
• Make sure power switch is on.
• Pull the pull chain to make sure
it is on.
• Push the motor reversing switch
rmly left or right to ensure that
it is engaged.
• Check the circuit breaker to
ensure the power is turned on.
• Make sure the blades spin freely.
• Turn off power from the circuit
breaker, then loosen the canopy
and check all the connections
according to the wiring diagram
on page 11.
• Check the plug connection in
the switch housing.
Lights dim when turned on or
do not turn on at all.
• Make sure the wattage of the
light bulbs installed matches
the specications on the light
sockets.
Produkt Specifikationer
Mærke: | Kogan |
Kategori: | Luftfugter |
Model: | SmarterHome |
Har du brug for hjælp?
Hvis du har brug for hjælp til Kogan SmarterHome stil et spørgsmål nedenfor, og andre brugere vil svare dig
Luftfugter Kogan Manualer
5 September 2024
14 August 2024
10 August 2024
Luftfugter Manualer
- Luftfugter DeLonghi
- Luftfugter Scheppach
- Luftfugter Sinbo
- Luftfugter SilverCrest
- Luftfugter OBH Nordica
- Luftfugter Sencor
- Luftfugter Zibro
- Luftfugter Samsung
- Luftfugter Wilfa
- Luftfugter Beurer
- Luftfugter Breville
- Luftfugter Gorenje
- Luftfugter TP-Link
- Luftfugter Philips
- Luftfugter Caso
- Luftfugter Concept
- Luftfugter Steba
- Luftfugter Vitek
- Luftfugter Medisana
- Luftfugter IFM
- Luftfugter Electrolux
- Luftfugter Whirlpool
- Luftfugter Mitsubishi
- Luftfugter Master
- Luftfugter Braun
- Luftfugter Sharp
- Luftfugter Melissa
- Luftfugter Qlima
- Luftfugter Korona
- Luftfugter TFA
- Luftfugter Soler & Palau
- Luftfugter Meaco
- Luftfugter Sanyo
- Luftfugter Carel
- Luftfugter Motorola
- Luftfugter Klarstein
- Luftfugter Güde
- Luftfugter Tefal
- Luftfugter Trisa
- Luftfugter Nedis
- Luftfugter Emerio
- Luftfugter Logik
- Luftfugter Vonroc
- Luftfugter Hyundai
- Luftfugter Edimax
- Luftfugter Dyson
- Luftfugter Black Box
- Luftfugter Imetec
- Luftfugter Hisense
- Luftfugter TriStar
- Luftfugter Blyss
- Luftfugter Topcom
- Luftfugter Adler
- Luftfugter Black And Decker
- Luftfugter Camry
- Luftfugter Eurom
- Luftfugter Trotec
- Luftfugter Blaupunkt
- Luftfugter Sandstrøm
- Luftfugter Honeywell
- Luftfugter Alpina
- Luftfugter Mesko
- Luftfugter Rowenta
- Luftfugter Noveen
- Luftfugter Soehnle
- Luftfugter Haier
- Luftfugter König
- Luftfugter Atika
- Luftfugter Elro
- Luftfugter Innoliving
- Luftfugter Thermex
- Luftfugter Bionaire
- Luftfugter Stadler Form
- Luftfugter Babymoov
- Luftfugter Carrier
- Luftfugter Comfee
- Luftfugter Wood's
- Luftfugter Terraillon
- Luftfugter Dimplex
- Luftfugter Tripp Lite
- Luftfugter Chicco
- Luftfugter Orbegozo
- Luftfugter Alecto
- Luftfugter Taurus
- Luftfugter Olympia
- Luftfugter Xiaomi
- Luftfugter Boneco
- Luftfugter Homedics
- Luftfugter Vicks
- Luftfugter MPM
- Luftfugter Vax
- Luftfugter Basetech
- Luftfugter Toyotomi
- Luftfugter Venta
- Luftfugter Lanaform
- Luftfugter Frigor
- Luftfugter APC
- Luftfugter Munters
- Luftfugter Domo
- Luftfugter Velleman
- Luftfugter JUNG
- Luftfugter Levoit
- Luftfugter Heylo
- Luftfugter Vemer
- Luftfugter Binatone
- Luftfugter Olimpia Splendid
- Luftfugter Fakir
- Luftfugter EQ3
- Luftfugter Thermaltake
- Luftfugter Midea
- Luftfugter Frigidaire
- Luftfugter Bimar
- Luftfugter Ardes
- Luftfugter Suntec
- Luftfugter Danby
- Luftfugter Scarlett
- Luftfugter Cotech
- Luftfugter ECG
- Luftfugter Solis
- Luftfugter Saturn
- Luftfugter Trebs
- Luftfugter Prixton
- Luftfugter Eldom
- Luftfugter Maxwell
- Luftfugter Sonnenkönig
- Luftfugter SPC
- Luftfugter Proline
- Luftfugter Hunter
- Luftfugter Brandson
- Luftfugter Lasko
- Luftfugter Eta
- Luftfugter Turmix
- Luftfugter Orion
- Luftfugter Duux
- Luftfugter Gemini
- Luftfugter Cecotec
- Luftfugter Solac
- Luftfugter Anslut
- Luftfugter Fibaro
- Luftfugter Panduit
- Luftfugter EQ-3
- Luftfugter Clean Air Optima
- Luftfugter Kenmore
- Luftfugter ATen
- Luftfugter Ferrex
- Luftfugter Oregon Scientific
- Luftfugter Arendo
- Luftfugter SereneLife
- Luftfugter Remko
- Luftfugter Duronic
- Luftfugter Philco
- Luftfugter Pingi
- Luftfugter Crestron
- Luftfugter LERAN
- Luftfugter DCG
- Luftfugter Emerson
- Luftfugter Elektrobock
- Luftfugter Ravanson
- Luftfugter Ufesa
- Luftfugter Homematic IP
- Luftfugter Vornado
- Luftfugter ResMed
- Luftfugter Lund
- Luftfugter Create
- Luftfugter Haus & Luft
- Luftfugter Air Naturel
- Luftfugter Royal Sovereign
- Luftfugter Alberello
- Luftfugter Workzone
- Luftfugter Holmes
- Luftfugter Jata
- Luftfugter Guzzanti
- Luftfugter Magnum
- Luftfugter GOTIE
- Luftfugter Oasis
- Luftfugter Inkbird
- Luftfugter Challenge
- Luftfugter Alpatec
- Luftfugter Lümme
- Luftfugter Mx Onda
- Luftfugter Get
- Luftfugter Duro
- Luftfugter Winix
- Luftfugter Arovec
- Luftfugter Argoclima
- Luftfugter Satel
- Luftfugter Magic Care
- Luftfugter Medel
- Luftfugter Bo Jungle
- Luftfugter Klarbach
- Luftfugter Ebac
- Luftfugter Crane
- Luftfugter X4-LIFE
- Luftfugter Plugwise
- Luftfugter Ausclimate
- Luftfugter Winland
- Luftfugter Minute Man
- Luftfugter Perfect Aire
- Luftfugter Nordmann
- Luftfugter Okoia
- Luftfugter Minuteman
- Luftfugter Condair
- Luftfugter Air & Me
- Luftfugter SPT
- Luftfugter Platinet
- Luftfugter Aktobis
- Luftfugter PureGuardian
- Luftfugter LightAir
- Luftfugter Merlin
- Luftfugter Heaven Fresh
- Luftfugter Prem-i-air
- Luftfugter InnoGIO
- Luftfugter Brune
- Luftfugter Jotechs
- Luftfugter Stylies
- Luftfugter WENKO
- Luftfugter House & Luft
- Luftfugter Sharper Image
- Luftfugter Medescan
- Luftfugter Coolix
- Luftfugter Sonoff
- Luftfugter Comfort Zone
- Luftfugter Norpole
- Luftfugter Cli-Mate
- Luftfugter Ionmax
- Luftfugter Respironics
- Luftfugter Mybeo
- Luftfugter Ruggard
Nyeste Luftfugter Manualer
30 December 2025
28 December 2024
28 December 2024
28 December 2024
27 December 2024
27 December 2024
26 December 2024
23 December 2024
18 December 2024
16 December 2024
