OWNER'S MANUAL
DRYER
Read this owner's manual thoroughly before operating the
appliance and keep it handy for reference at all times.
ENGLISH
DL*840**E
MFL72045808
Rev.00_121923
www.lg.com
Copyright © 2023 LG Electronics Inc. All Rights Reserved.
Scan to see the online manual.
TABLE OF CONTENTS
2
3 IMPORTANT SAFETY
INSTRUCTIONS
3 READ ALL INSTRUCTIONS BEFORE USE
4 WARNING STATEMENTS
8 PRODUCT OVERVIEW
8 Product Features
10 INSTALLATION
10 Before Installing
11 Choosing the Proper Location
14 Leveling the Appliance
14 Reversing the Door
19 Installing the Vent Kit
20 Venting the Dryer
22 Connecting Gas Dryers
23 Connecting Electric Dryers
27 Final Installation Check
30 OPERATION
30 Before Use
31 Loading the Dryer
33 Control Panel
35 Dry Cycles
37 Cycle Modifiers
38 Options and Extra Functions
40 SMART FUNCTIONS
40 LG ThinQ Application
43 Smart DiagnosisTM Function
44 MAINTENANCE
44 Regular Cleaning
46 TROUBLESHOOTING
46 FAQs
47 Before Calling for Service
52 LIMITED WARRANTY
52 USA
3IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
Safety for a Dryer
WARNING
Fire Hazard
Failure to follow safety warnings exactly could result in serious injury,
death or property damage.
•Do not install a booster fan in the exhaust duct.
•Install all clothes dryers in accordance with the installation instructions
of the manufacturer of the dryer.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury,
death or property damage.
•Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.
•WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance.
- Do not touch any electrical switch; do not use any phone in your
building.
- Clear the room, building or area of all occupants.
- Immediately call your gas supplier from a neighbor’s phone. Follow
the gas supplier’s instructions.
- If you cannot reach your gas supplier, call the fire department.
•Installation and service must be performed by a qualified installer,
service agency or your gas supplier.
4IMPORTANT SAFETY INSTRUCTIONS
Safety Messages
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and
follow all safety messages.
WARNING STATEMENTS
WARNING
• To reduce the risk of explosion, fire, death, electric shock, scalding or injury to persons when using this
product, follow basic precautions, including the following:
Installation
• Adhere to all industry recommended safety procedures including the use of long-sleeved gloves and
safety glasses.
• Before use, the appliance must be properly installed as described in this manual.
• Connect to a properly rated, protected, and sized power circuit to avoid electrical overload.
WARNING
Risk of Fire
Install the clothes dryer according to the manufacturer’s instructions
and local codes.
•Clothes dryer installation must be performed by a qualified installer.
•Do not install a clothes dryer with flexible plastic venting materials. If
flexible metal (foil type) duct is installed, it must be of a specific type
identified by the appliance manufacturer as suitable for use with
clothes dryers. Flexible venting materials are known to collapse, be
easily crushed, and trap lint. These conditions will obstruct clothes
dryer airflow and increase the risk of fire.
•To reduce the risk of severe injury or death, follow all installation
instructions.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or injure you and others. All safety messages
will follow the safety alert symbol and either the word WARNING or CAUTION.
WARNING
You may be killed or seriously injured if you do not follow instructions.
CAUTION
You may be injured or cause damage to the product if you do not follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and
tell you what may happen if the instructions are not followed.
5IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
• The appliance must be installed and electrically grounded by qualified service personnel in accordance
with local codes.
• Disconnect the power cord, house fuse or circuit breaker before installing or servicing the appliance.
• When moving or installing the appliance in a different location, call qualified service personnel for
installation and service.
• Keep packing materials out of the reach of children. Packaging material can be dangerous for children.
There is a risk of suffocation.
• Moving or installation of the appliance requires two or more people.
• This appliance is not designed for maritime use or for mobile installations such as in RVs, trailers, or
aircraft.
• This appliance must be positioned near to an electrical power supply.
• Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
• When installing or moving the appliance, be careful not to pinch, crush, or damage the power cord.
• Do not install the appliance in humid spaces.
• Destroy the carton, plastic bag, and other packing materials after the appliance is unpacked. Children
might use them for play. Cartons covered with rugs, bedspreads, or plastic sheets can become airtight
chambers.
• Place the appliance at least 18 inches above the floor for a garage installation.
• Do not use sheet metal screws or other fasteners which extend into the duct that could catch lint and
reduce the efficiency of the exhaust system. Secure all joints with duct tape.
• Use only rigid, semi-rigid or flexible metal 4-inch diameter duct inside the dryer cabinet or for exhausting
to the outside. Use of plastic or other combustible ductwork may cause a fire. Punctured ductwork may
cause a fire if it collapses or becomes otherwise restricted in use or during installation.
• The exhaust duct must be 4 inches (10.2 cm) in diameter with no obstructions. The exhaust duct should
be kept as short as possible. Make sure to clean any old ducts before installing your new dryer.
• Rigid, semi-rigid or flexible metal ducting is recommended for use between the dryer and the wall. All
non-rigid metal transition duct must be UL-listed. Use of other materials for the transition duct could
affect the drying time.
• Ductwork is not provided with the dryer, and you should obtain the necessary ductwork locally. The end
cap should have hinged dampers to prevent backdraft when the dryer is not in use.
• Gas dryers MUST be exhausted to the outside.
• The dryer exhaust system must be exhausted to the outside of the dwelling. If the dryer is not exhausted
outdoors, some fine lint and large amounts of moisture will be expelled into the laundry area. An
accumulation of lint in any area of the home may create a health and fire hazard.
• Do not install near another heat source such as a stove, oven or heater.
• Keep the area around the exhaust opening and adjacent surrounding areas free from the accumulation
of lint, dust, and dirt.
• The appliance must not be supplied through an external switching device, such as a timer, or connected
to a circuit that is regularly switched on and off by a utility.
• Certain internal parts are intentionally not grounded and may present a risk of electronic shock only
during servicing. Service personnel - do not contact the following parts while the appliance is energized:
CONTROL BOARD
Operation
• Never attempt to operate this applia ing, partially disassembled, or has nce if it is damaged, malfunction
missing or broken parts, including a damaged cord or plug.
• Repair or immediately replace all power cords that have become frayed or otherwise damaged. Do not
use a cord that shows cracks or abrasion damage along its length or at either end.
6IMPORTANT SAFETY INSTRUCTIONS
• If you detect a strange sound, a chemical or burning smell, or smoke coming from the appliance, unplug
it immediately, and contact an LG Electronics customer information center.
• Never unplug the appliance by pulling on the power cord. Always grip the plug firmly and pull straight
out from the outlet.
• Do not use an extension cord or adapter with this appliance.
• Do not grasp the power cord or touch the appliance controls with wet hands.
• Do not modify or extend the power cord.
• If the appliance has been submerged, contact an LG Electronics customer information center for
instructions before resuming use.
• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
• Keep the area underneath and around your appliances free of combustible materials (lint, paper, rags,
etc.), gasoline, chemicals and other flammable vapors and liquids.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person responsible for their safety.
• Use this appliance only for its intended purpose.
• Do not abuse, sit on, or stand on the door of the appliance.
• Do not allow children to play on, in or with the appliance. Close supervision of children is necessary when
the appliance is used near children.
• Do not tamper with controls.
• In the event of a gas leak (propane gas, LP gas, etc.) do not operate this or any other appliance. Open a
window or door to ventilate the area immediately.
• Under certain conditions, hydrogen gas may be produced in a hot-water system that has not been used
for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has not been used for
such a period, before using the appliance turn on all hot water faucets and let the water flow from each
for several minutes. This will release any accumulated hydrogen gas. As the gas is flammable, do not
smoke or use an open flame during this time.
• Fix the drain hose securely in place.
• Do not put oily or greasy clothing, candles or flammable materials on top of the appliance.
• Do not use fabric softeners or products to eliminate static unless recommended by the manufacturer of
the fabric softener or product.
• Do not reach into the appliance if the drum is moving.
• Do not dry articles that have been previously cleaned in, washed in, soaked in, soiled with or spotted
with gasoline, dry cleaning solvents, vegetable oil, cooking oil or other flammable or explosive
substances, as they give off vapors that could ignite or explode.
• Do not use heat to dry articles containing foam rubber or similarly textured rubber-like materials.
• Do not store plastic, paper, or clothing that may burn or melt on top of the dryer during operation.
• Gas appliances can cause minor exposure to four potentially hazardous substances, namely benzene,
carbon monoxide, formaldehyde, and soot, caused primarily by the incomplete combustion of natural
gas or LP fuels.
• Properly adjusted dryers will minimize incomplete combustion. Exposure to these substances can be
minimized further by properly venting the dryer to the outdoors.
• Always check the inside of the appliance for foreign objects before operating.
• Do not place items exposed to cooking oils in your appliance. Items contaminated with cooking oils may
contribute to a chemical reaction th reduce the risk of fire due to at could cause a load to catch fire. To
contaminated loads, the final part of a tumble dryer cycle occurs without heat (cool down period). Avoid
stopping a tumble dryer before the end of the drying cycle unless all items are quickly removed and
spread out so that the heat is dissipated.
• Do not let children or pets climb inside the dryer drum.
7IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
SAVE THESE INSTRUCTIONS
• Do not put living animals such as pets inside the appliance.
• Do not put any part of your body, such as your hands or feet, or metal objects under the appliance.
• Do not let your hand get pinched when opening or closing the dryer door.
Maintenance
• Do not repair or replace any part of the appliance. All repairs and servicing must be performed by
qualified service personnel unless specifically recommended in this Owner’s Manual. Use only
authorized factory parts
• Do not disassemble or repair the appliance by yourself.
• Remove any dust or foreign matter from the power plug pins.
• Disconnect this appliance from the power supply before cleaning and attempting any user maintenance.
Turning the controls to the OFF position does not disconnect this appliance from the power supply.
• Remove the door before the appliance is removed from service or discarded to avoid the danger of
children or small animals getting trapped inside.
• Unplug the appliance before cleaning to avoid the risk of electric shock.
• The interior of the appliance and exhaust duct should be cleaned periodically by qualified service
personnel.
• Certain internal parts are intentionally not grounded and may present a risk of electronic shock only
during servicing. Service personnel - do not contact the following parts while the appliance is energized:
CONTROL BOARD
Grounding Instructions
• Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check
with a qualified electrician or service personnel if you are in doubt whether the appliance is properly
grounded. Do not modify the plug provided with the appliance; if it will not fit the outlet, have a proper
outlet installed by a qualified electrician.
• The appliance must be grounded. In the event of a malfunction or breakdown, grounding will reduce the
risk of electric shock by providing a path of least resistance for electric current. The appliance is
equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must
be plugged into an appropriate outlet that is installed and grounded in accordance with all local codes
and ordinances.
• The appliance must be plugged into a properly grounded outlet. Electrical shock may result if the
appliance is not properly grounded. Have the wall outlet and circuit checked by a qualified electrician to
make sure the outlet is properly grounded. Failure to follow these instructions may create an electric
shock hazard and/or a fire hazard.
8PRODUCT OVERVIEW
PRODUCT OVERVIEW
Product Features
The images in this guide may be different from the actual components and accessories, which are subject
to change by the manufacturer without prior notice for product improvement purposes.
Front View
aControl panel
bLint filter
cLeveling feet
dReversible door
Rear View
aTerminal block access panel (for electric models)
bGas connection (for gas models)
cPower cord (for gas models)
dWater inlet hose connection (for steam models)
9PRODUCT OVERVIEW
ENGLISH
eExhaust duct oulet
Product Specifications
Accessories
Included Accessories
aSafety Tether Kit (on some models)
Optional Accessories (sold separately)
aDrying Rack (No. 3750EL001C)
bSide vent kit (Kit No. 383EEL9001B)
NOTE
• For your safety and extended product life, use only authorized components. The manufacturer is not
responsible for product malfunction or accidents caused by the use of unauthorized components or
parts.
Model DL*X840**E
Description Non steam Dryer
Electrical Requirements Please refer to the rating label for detailed
information.
Dimensions (Width X Depth X Height) 27'' X 29 1/4'' X 42 3/4'' (68.6 cm X 74.3 cm X 108.7 cm)
Maximum Depth with Door Open 50 1/2'' (128.4 cm)
Net Weight Gas : 121.3 lb (55.0 kg)
Electric : 116.8 lb (53.0 kg)
Capacity 7.3 cu.ft. (22.5 lb / 10.2 kg)
Gas Requirements NG: 4 - 10.5-inch (10.2 - 26.7 cm) WC
LP: 8 - 13-inch (20.4 - 33.1 cm) WC
C
E
R
T
I
F
I
E
D
D
E
S
I
G
N
10 INSTALLATION
INSTALLATION
Before Installing
Installation Overview
Please read the following installation instructions first after purchasing this dryer or transporting it to
another location.
aChoose the proper location.
bLevel the appliance.
cVent the appliance.
dConnect the Gas / Electric dryer.
• Purchase a UL-listed, 3-wire or 4-wire power cord kit with UL-listed strain relief (electric dryer only)
ePlug in the power cord.
fInstallation test and test run.
• Refer to Test Exhaust System in INSTALLATION.
11INSTALLATION
ENGLISH
Choosing the Proper
Location
WARNING
• Read all installation instructions completely
before installing and operating the appliance. It
is important that you review this entire manual
before installing and using the appliance.
Detailed instructions concerning electrical
connections and additional requirements are
provided on the following pages.
Exhaust
• The location must allow for proper exhaust
installation. A gas dryer must be exhausted to
the outdoors.
Electricity
Use an individual, grounded electrical outlet
located within 2 ft. (61 cm) of either side of the
appliance.
WARNING
• Do not install or store the appliance in an area
where it will be exposed to water and/or
weather.
NOTE
• Check code requirements that limit, or do not
permit, installation of the dryer in garages,
mobile homes or sleeping quarters. If you have
questions, contact your local building inspector.
Flooring
To avoid noise and vibration, the appliance must
be installed and leveled on a solidly constructed
floor with a maximum slope of 1 inch (2.5 cm). If
required, adjust the leveling legs to compensate
for the unevenness of the floor.
NOTE
• A sturdy floor is needed to support the total
appliance weight when loaded. The combined
weight of additional appliances should also be
considered.
• Clothes may not tumble properly, and automatic
sensor cycles may not operate correctly if the
appliance is not level.
• For garage installation, you will need to place the
appliance at least 18 inches (45.7 cm) above the
floor. The standard pedestal height is 15 inches
(38 cm). You will need 18 inches (45.7 cm) from
the garage floor to the bottom of the appliance.
Ambient Temperature
Install the appliance in an area where the
temperature is over 45 ℉ ℃ (7 ).
If the temperature around the appliance is too low,
the appliance might not shut off at the end of an
automatic cycle. This can result in longer drying
times.
12 INSTALLATION
Dimensions and Clearances
The following clearances are recommended for the appliance.
• Additional clearances should be considered for ease of installation and servicing.
• Additional clearances should be considered on all sides of the dryer to reduce noise transfer.
Installation Spacing for Recessed Area or Closet Installation
Closet Ventilation Requirements
Closets with doors must have both an upper and lower vent to prevent heat and moisture buildup in the
closet. One upper vent opening with a minimum opening of 48 sq. in. (310 cm
2) must be installed no lower
than 6 feet above the floor. One lower vent opening with a minimum opening of 24 sq. in. (155 cm
2) must
be installed no more than one foot above the floor. Install vent grilles in the door or cut down the door at
the top and bottom to form openings. Louvered doors with equivalent ventilation openings are also
acceptable.
- Description Dimension/Clearance
A Upper Ventilation Opening 2 48 sq. in. (310 cm2)
B Lower Ventilation Opening 2 24 sq. in. (155 cm2)
C Distance to Ventilation Opening 2 3″ (76 mm)
D Overhead Cabinet Depth 1 14″ (356 mm)
E Distance to the Overhead Cabinet/Shelf 2 18″ (457 mm)
F Depth 29 1/4″ (743 mm)
G Length of Door Swing 22″ (558 mm)
H Maximum Depth with Door Open 50 1/2″ (1284 mm)
I Back Clearance 2 5″ (127 mm)
J Side Clearance 2 1″ (25 mm)
K Width 27″ (686 mm)
13INSTALLATION
ENGLISH
NOTE
• There should be at least a little space around the dryer (or any other appliance) to eliminate the transfer
of vibration from one appliance to another. If there is enough vibration, it could cause appliances to
make noise or come into contact, causing paint damage and further increasing noise.
• No other fuel-burning appliance can be installed in the same closet as a dryer.
Installation Spacing for Cabinet
For cabinet installation with a door, minimum ventilation openings in the top of the cabinet are required.
- Description Dimension/Clearance
A Depth of Ventilation Opening 2 7″ (178 mm)
B Back Clearance 2 5″ (127 mm)
C Depth 29 1/4″ (743 mm)
D Front Clearance 2 1″ (25mm)
E Side Clearance 2 1″ (25 mm)
F Width 27″ (686 mm)
14 INSTALLATION
Leveling the Appliance
WARNING
• Use long-sleeved gloves and safety glasses.
• The appliance is heavy. Two or more people are
required when installing the appliance.
Checking the Level
Position the appliance in the final location and
place a level across the top of the appliance.
aLevel
bLeveling Feet
NOTE
• All four leveling feet must rest solidly on the
floor. Gently push on the top corners of the
appliance to make sure that the appliance does
not rock from corner to corner.
• Adjust the leveling feet only as far as necessary
to level the appliance. Extending the leveling feet
more than necessary may cause the appliance to
vibrate.
• To ensure that the appliance provides optimal
drying performance, it must be level. To
minimize vibration, noise, and unwanted
movement, the floor must be a perfectly level,
solid surface.
Adjusting the Leveling Feet
Use an adjustable wrench to turn the leveling feet.
Unscrew the legs to raise the appliance or screw in
the legs to lower it. Raise or lower with the leveling
feet until the appliance is level from side to side
and front to back. Make sure that all four leveling
feet are in firm contact with the floor.
NOTE
• If you are installing the appliance on the optional
pedestal, you must use the leveling feet on the
pedestal to level the appliance. The appliance
leveling feet should be fully retracted.
Reversing the Door
WARNING
• Support the door with a stool or box that fits
under the door, or have an assistant support the
weight of the door.
• Avoid dropping the door.
• Unplug the appliance or turn off power at the
main circuit breaker before beginning door
reversal.
Tools Required
• Phillips screwdriver
• Large flat blade screwdriver (recommended for
hinge screws if they are tight or your Phillips
screwdriver is worn)
• Small flat blade screwdriver (for lifting out parts)
Door Reversal Instructions
The instructions here are for changing the door
swing from a right to a left side hinge. If the door
has been reversed, and it is necessary to change it
back, use care when following these instructions.
Some of the illustrations and the left/right
references will be reversed, and you will need to
read the instructions carefully.
WARNING
• Be sure to support the weight of the door before
removing the hinge screws.
Easy load door
WARNING
• Be sure to support the weight of the door before
installing the hinge screws.
ON THE CABINET :
1 Open the door from the side so that the hinge
screws are accessible.
a
b
15INSTALLATION
ENGLISH
2 Remove the four hinge screws.
• While supporting the door, remove the four
hinge screws, two from each hinge. Set the
door aside face down on a protected
surface to prevent damage to the door or
the work surface.
3 Reverse the components on the cabinet.
1) Use a Phillips screwdriver to remove the
two screws and the latch mechanism a
on the front panel of the cabinet.
2) Remove the latch hole cover b by gently
prying it up with a flat blade screwdriver,
being careful not to scratch the paint.
Install the latch hole cover on the
opposite side, where the latch mechanism
was removed. Install the latch mechanism
in the position from which you removed
the latch hole cover, using the two screws
removed in a previous step.
3) Remove the hinge cover c by gently
prying it up with a flat blade screwdriver,
being careful not to scratch the paint.
Rotate the hinge cover 180 degrees and
install it on the opposite side d, where
the hinge was attached.
4) Reverse the hinge e and the hinge
bracket f at the bottom of the cabinet.
Remove the two screws from the hinge
bracket at the bottom right and remove
the hinge bracket. Remove the lower of
the two screws behind the hinge bracket.
Do NOT remove the upper screw behind
the hinge bracket. Set the parts aside.
CAUTION
• Do NOT remove any of the eight screws on the
face of the cabinet (marked below). Doing so
could result in damage to the dryer and the need
for a service call to repair the dryer.
5) Remove the three screws on the hinge at
the bottom left. Remove the hinge and
reinstall it on the right side. The top screw
will occupy the hole where you removed
the screw behind the hinge bracket in a
previous step.
6) Install the hinge bracket on the bottom
left side, first installing one screw behind
the hinge bracket.
ON THE DOOR :
1 Lift off the door cover.
• With the door laid inside facing up on a
protected surface, remove the twelve
screws on the inside of the door. Carefully
lift off the door cover with the help of a
small flat blade screwdriver inserted in the
upper corner.
16 INSTALLATION
WARNING
• The edges of the door cover may be sharp. Take
care when handling, or wear gloves to avoid
injury.
2 Switch the door strike a and the blank cover
b.
• Remove the two screws on the door cover
that secure the door strike. Remove the
blank cover by pulling and raising.
Switch the door strike and the blank cover,
installing them on the opposite sides from
which they were removed.
• Gently pry out the hole plug on the side of
the door cover and install it in the hole on
the opposite side. Set the door cover aside.
3 Reverse the components inside the door.
• You will now be removing and reversing
various components inside the door. See a
few page later for a detailed diagram and
identification of the inner structure and
parts of the door. (The diagram shows the
“before view” of the door, with the default
set-up for a right side hinge swing. After
following these instructions, your door
should be a mirror image of the illustration.)
4 Lift out the gray interlock button in the side of
the door.
• Make sure to remove the spring with the
interlock button and to keep the two
together. Set the interlock button aside. Do
not confuse these with the interlock buttons
from the top of the outer door.
5 Remove the side lock rod.
• Remove the side lock rod from the lower
hinge bracket by lifting the top end of the
rod and sliding it toward the top of the
door. The spring should remain attached to
the lock rod. Set the lock rod aside.
6 Remove 2 screws and top lock rod holder. Set
the lock rod holder and screw aside.
7 Lift out the n upper hinge filler (on the right)
and set it aside.
17INSTALLATION
ENGLISH
8 Reverse the l n upper hinge assembly and
hinge filler.
• Carefully lift l the upper hinge assembly-
inner top lock rod (on the left) out of the
outer door frame. Rotate the lupper hinge
assembly - inner top lock rod 180 degrees
and install it on the upper right side of the
outer door. You will need to press firmly to
install the hinge assembly.
• Now rotate the n hinge filler 180 degrees
and install it on the upper left side of the
door.
9 Reinstall the g top lock rod holder using 2
screws removed in step 6.
10 Reverse the i k lower hinge bracket and
hinge assembly.
1) Remove the screw from the i lower
hinge bracket (on the right) and lift the
hinge bracket out. Set it aside. Remove
the two screws from the k lower hinge
assembly on the bottom left and lift the
hinge assembly out.
2) Rotate the k lower hinge assembly 180
degrees and install it on the right side
using the two screws removed in a
previous step.
3) Flip over the i lower hinge bracket and
release the tabs on the back locking the
e hinge filler to the hinge bracket.
4) Rotate the hinge filler 180 degrees and
snap it back onto the front of the hinge
bracket facing in the opposite direction.
18 INSTALLATION
5) Mount the lower hinge bracket and the
filler on the left side of the door with the
screw removed in a previous step.
11 Install the f side lock rod.
• Flip the side lock rod over and install it on
the opposite side. Insert the lower end into
the left hinge and lower the rod into the
guides on the door while compressing the
spring inside the recess.
• Make sure the top of the side lock rod is
beside the top lock rod and the two do not
overlap each other, so the two rods can
interact correctly. If they are not aligned
properly, the door will not operate properly.
12 Reinstall the d side interlock button.
• Reinstall the d side interlock button
removed in step 3. Center the spring in the
compartment and insert the interlock
button on top of it.
13 Reinstall the door cover.
• Clean the glass on the door and door cover,
if necessary.Make sure the three gray
interlock buttons are properly installed and
that the top and side lock rods are properly
aligned where they meet. Carefully lower
the door cover into place, aligning the holes
in the cover with the interlock buttons on
the top and side and the bumpers on the
bottom. Take care not to dislodge the lock
rods while mounting the door cover. Once
the door cover is in place, secure it with the
12 screws removed in step 1. The ten similar
screws go around the top and sides of the
door cover. Make sure to install the two
different screws on the bottom edge, in the
locations marked below.
※ A detailed diagram and identification of the inner structure and parts of the door
19INSTALLATION
ENGLISH
ON THE CABINET :
1 Reinstall the door.
• The door is now ready to remount on the
opposite side of the dryer.
• While supporting the door, install the two
small hinge screws removed from the
hinge. Test the swing of the door to make
sure the hinges and latch are properly
aligned and that the door opens, closes and
latches properly in both directions.
• If the door doesn’t operate smoothly,
remove the door and then the door cover to
check that the lock rods and interlock
buttons are properly mounted and aligned.
• The interlock buttons should be oriented
correctly and operating smoothly. The
interlock rods should be in the proper
position and should not overlap at the
contact point. (See steps 12-14.)
• If the door is damaged, or if the door does
notwork after reassembly, contact the call
centerat 1-800-243-0000.
Installing the Vent Kit
WARNING
• Use long-sleeved gloves and safety glasses.
• Use a heavy metal vent.
• Do not use plastic or thin foil ducts.
• Clean old ducts before installing the appliance.
The appliance is configured to vent to the rear. It
can also vent to the bottom or side.
NOTE
• An adapter kit, part number 383EEL9001B, may
be purchased from your LG retailer. This kit
contains duct components necessary to change
the appliance vent location.
• Right-side venting is not available on gas
models.
Side Venting
1 Remove the rear exhaust duct retaining screw
a b and pull out the exhaust duct .
d e f g Interlock buttons Lower hinge filler Side lock rod Top lock rod
h i j k Inner lock rods Lower hinge bracket Hole plug Lower hinge assembly
l m n Upper hinge assembly Upper hinge pivot Upper hinge filler
20 INSTALLATION
2 Press the tabs on the knockout c and
carefully remove the knockout for the desired
vent opening. (Right-side venting is not
available on gas models.) Press the adapter
duct d onto the blower housing and secure
to the base of the dryer as shown.
3 Preassemble a 4" (10.2 cm) elbow e to the
next 4" (10.2 cm) duct section, and secure all
joints with duct tape. Be sure that the male
end of the elbow faces AWAY from the dryer.
Insert the elbow/duct assembly through the
side opening and press it onto the adapter
duct. Secure it in place with duct tape. Be sure
that the male end of the duct protrudes 1.5"
(3.8 cm) to connect the remaining ductwork.
Attach the cover plate f to the back of the
dryer with the included screw.
Bottom Venting
1 Remove the rear exhaust duct retaining screw
a b. Pull out the exhaust duct .
2 Press the adapter duct c onto the blower
housing and secure it to the base of the dryer
as shown.
3 Insert the 4" (10.2 cm) elbow d through the
rear opening and press it onto the adapter
duct. Be sure that the male end of the elbow
faces down through the hole in the bottom of
the dryer. Secure it in place with duct tape.
Attach the cover plate e to the back of the
dryer with the included screw.
Venting the Dryer
WARNING
• Gas dryers MUST exhaust to the outdoors.
• To reduce the risk of fire, combustion, or
accumulation of combustible gases, DO NOT
exhaust dryer air into an enclosed and
unventilated area, such as an attic, wall, ceiling,
crawl space, chimney, gas vent, or concealed
space of a building.
• To reduce the risk of fire, DO NOT exhaust the
dryer with plastic or thin foil ducting.
• Do not exceed the recommended duct length
limitations noted in the chart. Failure to follow
a
b
c
d
f
e
a
b
c
d
e
21INSTALLATION
ENGLISH
these instructions may result in extended drying
times, fire or death.
• Do not crush or collapse ductwork.
• Do not allow ductwork to rest on or contact
sharp objects.
• If connecting to existing ductwork, make sure it
is suitable and clean before installing the dryer.
• Venting must conform to local building codes.
• Use only 4-inch (10.2 cm) rigid, semi-rigid or
flexible metal ductwork inside the dryer cabinet
and for venting outside.
• The exhaust duct must be 4 inches (10.2 cm) in
diameter with no obstructions. The exhaust duct
should be kept as short as possible. Make sure to
clean any old ducts before installing the new
dryer.
• Rigid, semi-rigid or flexible metal ducting is
recommended for use between the dryer and
the wall. All non-rigid metal transition duct must
be UL-listed. Use of other materials for transition
duct could affect drying time.
• DO NOT use sheet metal screws or other
fasteners which extend into the duct that could
catch lint and reduce the efficiency of the
exhaust system. Secure all joints with duct tape.
• Ductwork is not provided with the dryer. You
should obtain the necessary ductwork locally.
The vent hood should have hinged dampers to
prevent backdraft when the dryer is not in use.
• The total length of flexible metal duct must not
exceed 8 ft. (2.4 m).
• When pushing the dryer into the installed
position, do not crush or collapse ductwork.
Ductwork
NOTE
• Deduct 6 ft. (1.8 m) for each additional elbow. Do
not use more than four 90° elbows.
• In Canada, only those foil-type flexible ducts, if
any, specifically identified for use with the
appliance by the manufacturer should be used.
In the United States, only those foil-type flexible
ducts, if any, specifically identified for use with
the appliance by the manufacturer and that
comply with the Outline for Clothes Dryer
Transition Duct, Subject 2158A, should be used.
Routing and Connecting Ductwork
Follow the guidelines below to maximize drying
performance and reduce lint buildup and
condensation in the ductwork. Ductwork and
fittings are NOT included and must be purchased
separately.
• Use 4-inch (10.2 cm) diameter rigid, semi-rigid or
flexible metal ductwork.
• The exhaust duct run should be as short as
possible.
• Use as few elbow joints as possible.
• The male end of each section of exhaust duct
must point away from the dryer.
• Use duct tape on all duct joints.
• Insulate ductwork that runs through unheated
areas in order to reduce condensation and lint
buildup on duct surfaces.
• Incorrect or inadequate exhaust systems are not
covered by the dryer warranty. Dryer failures or
service required because of such exhaust
systems will not be covered by the dryer
warranty.
Wall Cap Type
No. of
90°
Elbows
Maximum length
of 4-inch
diameter rigid
metal duct
Recommended 0 65 ft. (19.8 m)
1 55 ft. (16.8 m)
2 47 ft. (14.3 m)
3 36 ft. (11.0 m)
4 28 ft. (8.5 m)
a
a
a .: 4 ‘’ (10 2 cm)
Use for only
short run
installations
0 55 ft. (16.8 m)
1 47 ft. (14.3 m)
2 41 ft. (12.5 m)
3 30 ft. (9.1 m)
4 22 ft. (6.7 m)
Wall Cap Type
No. of
90°
Elbows
Maximum length
of 4-inch
diameter rigid
metal duct
b: 2 35 ).5 ‘’ (6. cm
b
22 INSTALLATION
Correct Venting
Incorrect Venting
Connecting Gas Dryers
WARNING
• To reduce the risk of fire or explosion, electric
shock, property damage, injury to persons, or
death when using this appliance, follow
requirements including the following.
Electrical Requirements for Gas
Models
WARNING
• This dryer is equipped with a three-prong
grounding plug for protection against shock
hazard which should be plugged directly into a
properly grounded three-prong receptacle. Do
not cut or remove the grounding prong from
this plug.
• Do not, under any circumstances, cut or remove
the third (ground) prong from the power cord.
• For personal safety, this dryer must be properly
grounded.
• This dryer must be plugged into a 120-VAC, 60-
Hz. grounded outlet protected by a 15-ampere
fuse or circuit breaker.
• Where a standard 2-prong wall outlet is
encountered, it is your personal responsibility
and obligation to have it replaced with a
properly grounded 3-prong wall outlet.
Gas Supply Requirements
WARNING
• DO NOT attempt any disassembly of the dryer;
disassembly requires the attention and tools of
an authorized and qualified service technician or
company.
• DO NOT use an open flame to inspect for gas
leaks. Use a noncorrosive leak detection fluid.
• Gas pressure must not exceed 10.5-inch (26.7
cm) water column for NG, or 13-inch (33.1 cm)
water column for LP.
• Isolate the dryer from the gas supply system by
closing its individual manual shutoff valve during
any pressure testing of the gas supply at
pressures greater than 3.5 kPa.
• Supply line requirements: Your laundry room
must have a rigid gas supply line to your dryer.
In the United States, an individual manual
shutoff valve MUST be installed within at least 6
ft. (1.8 m) of the dryer, in accordance with the
National Fuel Gas Code ANSI Z223.1 or Canadian
gas installation code CSA B149.1. A 1/8-inch NPT
pipe plug must be installed.
• If using a rigid pipe, the rigid pipe should be 0.5-
inch IPS. If acceptable under local codes and
ordinances and when acceptable to your gas
supplier, 3/8-inch approved tubing may be used
where lengths are less than 20 ft. (6.1 m). Larger
tubing should be used for lengths in excess of 20
ft. (6.1 m).
• To prevent contamination of the gas valve,
purge the gas supply of air and sediment before
connecting the gas supply to the dryer. Before
tightening the connection between the gas
supply and the dryer, purge remaining air until
the odor of gas is detected.
• Use only a new AGA- or CSA-certified gas supply
line (in compliance with the Standard for
Connectors for Gas Appliances, ANSI Z21.24 •
CSA 6.10) with flexible stainless steel connectors.
• Use Teflon tape or a pipe-joint compound that is
insoluble in propane (LP) gas on all pipe threads.
Connecting the Gas Supply
NOTE
• In the Commonwealth of Massachusetts: This
product must be installed by a licensed plumber
or gas fitter. When using ball-type gas shut off
valves, they must be T-handle-type. A flexible gas
connector, when used, must not exceed 3 feet.
23INSTALLATION
ENGLISH
• Installation and service must be performed by a
qualified installer, service agency, or the gas
supplier.
• The dryer is configured for natural gas when
shipped from the factory. Make sure that the
dryer is equipped with the correct burner nozzle
for the type of gas being used (natural gas or
propane gas).
• Use only a new stainless steel flexible connector
and a new AGA-certified connector.
• A gas shutoff valve must be installed within 6 ft.
(1.8 m) of the dryer.
• If necessary, the correct nozzle should be
installed by a qualified technician and the
change should be noted on the dryer. (For the LP
nozzle kit, order part number 383EEL3002D.)
• All connections must be in accordance with local
codes and regulations. Gas dryers MUST exhaust
to the outdoors.
1 Make sure that the gas supply to the laundry
room is turned OFF and the dryer is
unplugged. Confirm that the type of gas
available in your laundry room is appropriate
for the dryer.
2 Remove the shipping cap from the gas fitting
at the back of the dryer. Be careful not to
damage the threads of the gas connector
when removing the shipping cap.
3 Connect the dryer to your laundry room’s gas
supply using a new flexible stainless steel
connector with a 3/8-inch NPT fitting.
WARNING
• DO NOT use old connectors.
4 Securely tighten all connections between the
dryer and your laundry room’s gas supply.
5 Turn on your laundry room’s gas supply.
6 Check all pipe connections (both internal and
external) for gas leaks with a noncorrosive
leak-detection fluid.
7 Proceed to Venting the Dryer.
a3/8” NPT gas Connection
bAGA/CSA-Certified Stainless Steel Flexible
Connector
c1/8” NPT Pipe Plug
dGas Supply Shutoff Valve
High-Altitude Installations
The BTU rating of this dryer is AGA-certified for
elevations below 10,000 feet.
If your gas dryer is being installed at an elevation
above 10,000 feet, it must be derated by a
qualified technician or gas supplier.
Connecting Electric Dryers
WARNING
• To reduce the risk of fire or explosion, electric
shock, property damage, injury to persons, or
death when using this appliance, fulfill the
following requirements.
Electrical Requirements for Electric
Models
WARNING
• The wiring and grounding must conform to the
latest edition of the National Electrical Code,
ANSI/NFPA 70 and all applicable local
regulations. Please contact a qualified electrician
to check your home’s wiring and fuses to ensure
that your home has adequate electrical power to
operate the appliance.
• This appliance must be connected to a grounded
metal, permanent wiring system, or an
equipment-grounding conductor must be run
with the circuit conductors and connected to the
equipment-grounding terminal or lead on the
appliance.
a
b
c
d
24 INSTALLATION
WARNING
• The appliance has its own terminal block that
must be connected to a separate 240 VAC, 60-
Hertz, single-phase circuit, fused at 30 amperes.
(The circuit must be fused on both sides of the
line.) ELECTRICAL SERVICE FOR THE APPLIANCE
SHOULD BE OF THE MAXIMUM RATE VOLTAGE
LISTED ON THE NAMEPLATE. DO NOT CONNECT
THE APPLIANCE TO 110-, 115-, OR 120-VOLT
CIRCUIT.
• If the branch circuit to appliance is 15 ft. (4.5 m)
or less in length, use UL (Underwriters
Laboratories) listed No.-10 AWG wire (copper
wire only), or as required by local codes. If over
15 ft. (4.5 m), use UL-listed No.-8 AWG wire
(copper wire only), or as required by local codes.
Allow sufficient slack in wiring so the appliance
can be moved from its normal location when
necessary.
• The power cord (pigtail) connection between the
wall receptacle and the appliance terminal block
IS NOT supplied with the appliance. Type of
pigtail and gauge of wire must conform to local
codes and with instructions on the following
pages.
• Do not modify the plug and internal wire
provided with the appliance.
• The appliance should be connected to a 4-hole
outlet.
• If the plug does not fit the outlet, a proper outlet
will need to be installed by a qualified electrician.
• Connect the power cord to the terminal block.
Each colored wire should be connected to the
same color screw. Wire color indicated in manual
is connected to the same color screw in the
block.
• Grounding through the neutral conductor is
prohibited for: (1) new branch-circuit
installations and (2) areas where local codes
prohibit grounding through the neutral
conductor.
• This appliance is supplied with the neutral wire
grounded. This white ground wire MUST BE
MOVED to the neutral terminal when a 4-wire
cord is to be used, or where grounding through
the neutral conductor is prohibited.
Four-Wire Power Cord
1 Remove the terminal block access cover on
the upper back of the appliance.
2 Install UL-listed strain relief into the power
cord through-hole.
3 Thread a 30-amp, 240-volt, 4-wire, UL-listed
power cord with #10 AWG-minimum copper
conductor through the strain relief.
aTerminal Block
bUL-Listed Strain Relief
cUL-Listed 4-Wire Power Cord
4 Transfer the appliance's ground wire from
behind the green ground screw to the center
screw of the terminal block.
5 Attach the two hot leads (black and red) of the
power cord to the outer terminal block
screws.
6 Attach the neutral (white) wire to the center
screw of the terminal block.
7 Attach the power cord ground wire to the
green ground screw.
8 Tighten all screws securely.
9 Reinstall the terminal block access cover.
• A UL-listed strain relief is
required.
• Use a 30-amp, 240-volt, 4-wire, UL-listed
power cord with #10 AWG-minimum copper
conductor and closed loop or forked terminals
with upturned ends.
25INSTALLATION
ENGLISH
aWhite Wire moved from Ground Screw
bHot Leads of Power Cord (Black and Red)
cNeutral Wire (White)
dPower Cord Ground Wire
eGround Screw
Four-Wire Direct Wire
1 Remove 5 inches (12.7 cm) of the outer
covering from the wire and remove 5 inches
of insulation from the ground wire. Cut off
approximately 1.5 inches (3.8 cm) from the
other three wires and strip 1 inch (2.5 cm)
insulation from each wire. Bend the ends of
the three shorter wires into a hook shape.
aGround Wire
2 Remove the terminal block access cover on
the upper back of the appliance.
3 Install UL-listed strain relief into the power
cord through-hole.
4 Thread the 4-wire #10 AWG minimum copper
power cable prepared in step 1 through the
strain relief.
aTerminal Block
bUL-Listed Strain Relief
cUL-Listed 4-Wire Power Cord
5 Transfer the appliance's ground wire from
behind the green ground screw to the center
of the terminal block.
6 Attach the two hot leads (black and red) of the
power cord to the outer terminal block
screws.
7 Attach the neutral (white) wire to the center
screw of the terminal block.
8 Attach the power cord ground wire to the
green ground screw.
9 Tighten all screws securely.
10 Reinstall the terminal block access cover.
aWhite Wire moved from Ground Screw
• A UL-listed strain relief is
required.
• Use UL-listed 4-wire #10 AWG minimum
copper conductor cable. Allow at least 5 ft. (1.5
m) of wire to allow for removal and
reinstallation of the dryer.
a
b
b
c
d
e
5’’ (12 ).7 cm
1’’ (2 ).5 cm
a
a
b
c
a
b
b
c
d
e
26 INSTALLATION
bHot Leads of Power Cord (Black and Red)
cNeutral Wire (White)
dPower Cord Ground Wire
eGround Screw
Three-Wire Power Cord
1 Remove the terminal block access cover on
the upper back of the appliance.
2 Install the UL-listed strain relief into the
power cord through-hole.
3 Thread a 30-amp, 240 volt, 3-wire, UL-listed
power cord with #10 AWG-minimum copper
conductor through the strain relief.
aTerminal Block
bUL-Listed Strain Relief
cUL-Listed 3-Wire Power Cord
4 Attach the two hot leads (black and red) of the
power cord to the outer terminal block
screws.
5 Attach the neutral (white) wire to the center
terminal block screw.
6 Connect the external ground (if required by
local codes) to the green ground screw.
7 Tighten all screws securely.
8 Reinstall the terminal block access cover.
aWhite Wire from Dryer Harness
bHot Leads of Power Cord (Black and Red)
cNeutral Wire (White)
dExternal Ground Wire (if required by local
codes)
eGround Screw
Three-Wire Direct Wire
1 Remove 3.5 inches (8.9 cm) of the outer
covering from the wire. Strip 1 inch (2.5 cm)
insulation from each wire. Bend the ends of
the three wires into a hook shape.
2 Remove the terminal block access cover on
the upper back of the appliance.
• A 3-wire connection is NOT
permitted on new construction after
January 1, 1996.
• A UL-listed strain relief is required.
• Use a 30-amp, 240-volt, 3-wire, UL-listed
power cord with #10 AWG-minimum copper
conductor and closed loop or forked terminals
with upturned ends.
• A 3-wire connection is NOT
permitted on new construction after
January 1, 1996.
• A UL-listed strain relief is required.
• Use UL-listed 3-wire, #10 AWG minimum
copper conductor cable. Allow at least 5 ft. (1.5
m) length to allow for removal and installation
of dryer.
1’’ (2 ).5 cm
27INSTALLATION
ENGLISH
3 Install UL-listed strain relief into the power
cord through-hole.
4 Thread the 3-wire, #10 AWG minimum copper
conductor power cable prepared in step 1
through the strain relief.
aTerminal block
bUL-listed strain relief
cUL-listed 3-wire power cord
5 Attach the two hot leads (black and red) of the
power cord to the outer terminal block
screws.
6 Attach the neutral (white) wire to the center
terminal block screw.
7 Connect the external ground (if required by
local codes) to the green ground screw.
8 Tighten all screws securely.
9 Reinstall the terminal block access cover.
aHot lead (black and red)
bNeutral wire (white)
cExternal ground wire (if required by local
codes)
dWire from the appliance harness
eGround screw (green)
Final Installation Check
Once you have completed the installation of the
dryer and it is in its final location, confirm proper
operation with the following tests.
Test Dryer Heating
Gas Models
Close the dryer door and press the Power button
to turn the dryer on. Turn the knob and select the
Quick Dry. Press the Start/Pause buttons to start
the test. When the dryer starts, the igniter should
ignite the main burner.
NOTE
• If all air is not purged from the gas line, the gas
igniter may turn off before the main burner
ignites. If this happens, the igniter will reattempt
gas ignition after approximately two minutes.
Electric Models
Close the dryer door and press the Power button
to turn the dryer on. Turn the knob and select the
Quick Dry. Press the Start/Pause buttons to start
the test. The exhaust air should be warm after the
dryer has been operating for 3 minutes.
Checking Airflow
Effective dryer operation requires proper airflow.
The adequacy of the airflow can be measured by
evaluating the static pressure. Static pressure in
the exhaust duct can be measured with a
manometer, placed on the exhaust duct
approximately 2 ft. (60.9 cm) from the dryer. Static
pressure in the exhaust duct should not exceed 0.6
inch (1.5 cm). The dryer should be checked while
the dryer is running with no load.
Checking Levelness
Once the dryer is in its final location, recheck the
dryer to be sure it is level. Make sure it is level front
to back and side to side, and that all four leveling
feet are in firm contact with the floor.
Test Exhaust System
Once you have completed the installation of the
appliance, use this test to make sure the condition
28 INSTALLATION
of the exhaust system is adequate for proper
operation of the appliance. This test should be
performed to alert you to any serious problems in
the exhaust system of your home.
• Your appliance features Flow SenseTM, an
innovative sensing system that automatically
detects blockages and restrictions in dryer
ductwork. Keeping ductwork clean of lint
buildup and free of restrictions allows clothes to
dry faster and reduces energy use.
NOTE
• The appliance should be cool before starting this
test. If the appliance was warmed up during
installation, run the Air Dry cycle for a few
minutes to reduce the interior temperature.
Activating the Installation Test
1 Remove the literature and then close the
door.
• Do not load anything in the drum for this
test, as it may affect the accuracy of the
results.
2 Press and hold the Damp Signal and Wrinkle
Care buttons and then press the Power
button.
• This button sequence activates the
installation test. The code 1Ns will display if
the activation is successful.
3 Press the Start/Pause button.
• The appliance will start the test, which will
last a few minutes. The heat will be turned
on and the temperatures in the drum will be
measured.
4 Check the display for results.
• During the test cycle, monitor the Flow
SenseTM display on the control panel. If
Flow Sense indicator lights up when the
cycle ends, the exhaust system is adequate.
If the exhaust system is severely restricted,
the display will lights up. Have the system
checked immediately, as performance will
be poor. Other problems may also be
shown with error codes. Refer to the the
Error Code table for details and solutions.
5 End of cycle.
• At the end of the test cycle, ENd will display.
The test cycle will end and the appliance will
shut off automatically after a short delay.
Check the Duct Condition
If the Flow SenseTM LED is turned on, check the
exhaust system for restrictions and damage.
Repair or replace the exhaust system as needed.
NOTE
• When the appliance is first installed, this test
should be performed to alert you to any existing
problems with the exhaust duct in your home.
However, since the test performed during
normal operation provides more accurate
information on the condition of the exhaust duct
than the installation test, the results during the
two tests may not be the same.
• Do not interrupt the test cycle, as this could
result in inaccurate results.
• Even if the LED doesn't light up during the test
cycle, some restrictions may still be present in
the exhaust system. Refer to the Venting the
Dryer section of this manual for complete
exhaust system and venting requirements.
Error Codes
Check the error code before you call for service.
Error
Code Possible Cause & Solution
tE1 or
tEz
Temperature snesor failure.
• Turn off the appliance and call for
service.
Hs Humidity sensor failure.
• Turn off the appliance and call for
service.
Ps, PF,
or NP
Electric dryer power cord is not
connected correctly, or house power
supply is incorrect.
• Reset circuit breaker or replace
fuse. Do not increase the fuse
capacity.
House fuse is blown, circuit breaker
has tripped, or power outage has
occurred.
• If the problem is a circuit overload,
have it corrected by a qualified
electrician.
29INSTALLATION
ENGLISH
Restricted or Blocked Airflow
Avoid long runs or runs with multiple elbows or
bends.
Check for blockages and lint buildup.
Make sure the ductwork is not crushed or
restricted.
GAs Gas supply or service turned off. (Gas
Model only.)
• Confirm that house gas shutoff and
the dryer gas shutoff are both fully
open.
Excess or crushed
transition duct
Too many elbows or
exhaust too long
Error
Code Possible Cause & Solution
30 OPERATION
OPERATION
Before Use
WARNING
• To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY
INSTRUCTIONS before operating this appliance.
Operation Overview
1 Clean the Lint Filter
• If the lint filter has not already been
cleaned, lift out the filter and remove the
lint from the last load. This will help ensure
the fastest and most efficient drying
performance. Make sure to reinstall the
filter, pressing down until it clicks firmly into
place.
2 Load the Dryer
• Make sure that clothing is pushed entirely
into the drum and away from the door seal
area. Clothing that gets stuck between the
door and seal may be damaged or damage
the seal.
• If the load is extra large, you may need to
divide it into smaller loads for proper
performance and fabric care.
• All strings and attached belts of clothes
should be well tied and secured before
being put into the drum.
3 Turn on the Dryer
• Press the Power button to turn on the
dryer. The cycle LEDs will illuminate and a
chime will sound.
4 Select a Cycle
• Turn the cycle selector knob in either
direction until the LED for the desired cycle
is on. The preset temperature, dry level, and
option settings for that cycle will be shown.
• Pressing the Start/Pause button without
selecting a cycle immediately starts the
Normal cycle with the default settings.
Select the Normal cycle to change the
default settings.
5 Adjust Settings
Default settings for the selected cycle can now
be changed, if desired, using the cycle
modifier and option buttons.
• Not all modifiers and options are available
on all cycles. A different chime will sound
and the LED will not come on if the selection
is not allowed.
6 Begin Cycle
• Press the Start/Pause button to begin the
cycle. The cycle can be paused at any time
either by opening the door or by pressing
the Start/Pause button.
• If the Start/Pause button is not pressed
within a certain time, the dryer shuts off
and all settings are lost.
7 End of Cycle
• When the cycle is finished, the chime will
sound. Immediately remove your clothing
from the dryer to reduce wrinkling. If
Wrinkle Care is selected, the dryer will
tumble briefly every few minutes to help
prevent wrinkles from setting in the clothes.
Check the Lint Filter Before Every
Load
Always make sure the lint filter a is clean before
starting a new load; a clogged lint filter will
increase drying time. To clean, pull the lint filter
straight up and roll any lint off the filter with your
31OPERATION
ENGLISH
fingers. Push the lint filter firmly back into place.
See Regular Cleaning for more information.
Always ensure that the lint filter is properly
installed before running the dryer. Running the
dryer with a loose or missing lint filter will damage
the dryer and articles in the dryer.
Loading the Dryer
NOTE
• For the best drying performance and most
efficient energy usage, do not overload the
appliance.
General Tips
• Combine large and small items in the same load.
• Use mesh laundry bags to separate clothes with
zippers, hooks, straps, and drawstrings to
prevent them from catching on or tangling with
other clothes or damaging the lint filter.
NOTE
• Damp clothes will expand as they dry. Do not
overload the dryer; clothes require room to
tumble and dry properly.
Grouping Similar Items
For the best drying results, and to reduce the
possibility of damage to clothing, sort clothes into
loads that can be dried with the same drying cycle.
Different fabrics have different care requirements,
and some fabrics will dry more quickly than others.
Woolen Items
• Always follow fabric care labels before drying
woolen items in a dryer. After the cycle, the
items may still be damp. Do not repeat the cycle.
Pull the items to their original shape if needed
and lay them flat to finish drying.
Woven and Loopknit Materials
• Some woven and loopknit materials may shrink,
depending on quality.
Permanent Press and Synthetics
• Do not overload your dryer. Take out permanent
press items as soon as the dryer stops to reduce
wrinkles.
Baby Clothes and Nightgowns
• Always check the manufacturer’s instructions.
Rubber and Plastics
• Do not dry any items made from or containing
rubber or plastics such as:
- Aprons, bibs and chair covers
- Curtains and tablecloths
- Bath mats
Fiberglass
• Do not dry fiberglass articles in your dryer. Glass
particles left in the dryer could be picked up by
your clothes the next time you use the dryer and
irritate your skin.
Fabric Care Labels
• Sort and dry laundry according to care labels,
size, and fabric type. Do not overload the dryer.
This will save energy and time and give the best
drying performance.
Fabric Care Labels
Many articles of clothing include a fabric care label.
Using the chart below, adjust the cycle and option
selections to care for your clothing according to
the manufacturer's recommendations.
Tumble Dry
Label Directions
Dry
Normal
Permanent Press /
Wrinkle Resistant
Gentle / Delicate
32 OPERATION
Do not tumble dry
Do not dry (used with
do not wash)
Heat Setting
Label Directions
High
Medium
Low
No Heat / Air
Tumble Dry
Label Directions
33OPERATION
ENGLISH
Control Panel
Control Panel Features
aPower Button
• Press the button to turn the appliance on. Press again to turn the appliance off.
NOTE
• Pressing the Power button during a cycle will cancel that cycle, and any load settings will be lost.
bCycle Selector Knob
• Turn this knob to select the desired cycle. Once the desired cycle has been selected, the standard
presets will be shown in the display. On some cycles, these settings can be adjusted using the cycle
modifier buttons anytime before starting the cycle.
cStart/Pause Button
• Press this button to start the selected cycle. If the appliance is running, use this button to pause the
cycle without losing the current settings.
NOTE
• If you do not press the Start/Pause button to resume a cycle within a certain time, the appliance turns
off automatically and all cycle settings are lost.
dExtra Options and Functions / Cycle Modifier Buttons
• Use these buttons to select the desired options for the selected cycle. Not all options are available for
each cycle.
eTime and Status Display
• The display shows the settings, estimated time remaining, options, and status messages for the
appliance. When the appliance is turned on, the default settings in the display will illuminate.
34 OPERATION
Time and Status Display
aFlow Sense Indicator
• The Flow Sense™ duct blockage sensing system detects and alerts you to blockages in the ductwork
that reduce exhaust flow from the dryer. Maintaining a clean exhaust system improves operating
efficiency and helps minimize service calls, saving you money.
bClean Filter Reminder
• This indicator lights up at the beginning of the cycle to remind you to check the lint filter. It turns off
when the Start/Pause button is pressed.
cCycle Status Indicators
•Dry indicator lights up when the appliance is in the drying stage.
•Cool indicator lights up when the appliance is in the cool down stage.
dEstimated Time Remaining
• When a drying cycle is selected, the estimated drying time for the selected cycle is displayed. This
time will change if you select extra options for the cycle.
• The cycle time on Sensor Dry cycles may fluctuate as the appliance recalculates drying time for
optimal results.
eThis indicator lights up When the Control Lock feature is activated.
f┬ lights up when a new ThinQ Up Feature is created. you can update it using ThinQ Application.
gThis indicator lights up when the Remote Start feature is activated.
hf lights up when the appliance is connected to a home Wi-Fi network.
35OPERATION
ENGLISH
Dry Cycles
Turn the knob or press the button to select the desired cycle. When you select a dry cycle the light for the
corresponding dry cycle will turn on.
Cycle Guide
Cycle Normal
Description Use this cycle for drying all normal items such as cotton, linen, shirts, jeans or mixed
loads, except delicate fabrics such as wool or silk.
Dryness Default: Normal Available: All
Temperature Default: Med. High Available: Med. High
Cycle Quick Dry
Description Use this cycle to quickly dry a small load of laundry.
Time Default: 30 minutes Available: 10 -100 minutes
Temperature Default: High Available: All
Cycle Heavy Duty
Description Use this cycle for drying heavy-duty clothes like jeans or garments that need extra
drying.
Dryness Default: Normal Available: All
Temperature Default: High HighAvailable:
Cycle Bedding
Description Use this cycle for drying blankets or bulky items such as pillows, blankets, comforters,
sheets or pet bedding.
Dryness Default: Normal Available: Very, More, Normal
Temperature Default: Medium MediumAvailable:
Cycle AI Dry
Description This cycle optimizes drying times and temperatures by detecting the laundry’s
characteristics.
Dryness Default: Normal Available: Normal
Temperature Default: Med. High Available: Med. High
Cycle Delicates
Description Use this cycle for drying dress shirts/blouses, nylons, lingerie, or sheer and lacy clothes
which can easily be damaged.
Dryness Default: Normal Available: All
Temperature Default: Med. Low Available: Med. Low
36 OPERATION
† Shirts : 70% cotton, 30% poly blend. Except especially delicate fabrics
Special Drying Cycles
Selectable Drying Options
† This option helps to reduce the energy use by drying clothes at lower temperatures than the normal
mode. When this option is set, the drying time will increase.
Cycle Perm. Press
Description Use this cycle to minimize wrinkles when drying tablecloths or wrinkle-free clothes.
Dryness Default: Normal Available: All
Temperature Default: Medium MediumAvailable:
Cycle Downloaded (Antibacterial)
Description This cycle allows you to download a ne ng cycle to your w and specialized dryi
appliance with a smartphone.
• Refer to the LG ThinQ smartphone application to see the cycles available
for download.
• The default cycle is Antibacterial. This cycle is also available for download.
Cycle
Option
Energy Saver†Wrinkle Care Damp Signal
Normal ###
Quick Dry #
Heavy Duty # #
Bedding
AI Dry # #
Delicates # #
Perm. Press # #
37OPERATION
ENGLISH
Cycle Modifiers
About Modifier Buttons
Each cycle has default settings that are selected
automatically. Customize these settings using the
cycle modifier buttons. Repeatedly press the
button for the desired modifier until the indicator
light for the desired setting is lit. Not every option
is available with every cycle. If a modifier is not
available, the button chimes twice and the setting
does not change.
Temp.
Use this button to adjust the temperature setting.
This allows precise care of fabrics and garments.
Press the Temp. button repeatedly to scroll
through available settings.
• Temperature indicator lights up and the selected
setting is shown in the knob display: Low, Med
Low, Medium, Med High, High
Dryness
Use this button to select the dryness level for the
cycle. Press the Dryness button repeatedly to
scroll through available settings.
• The appliance will automatically adjust the cycle
time according to the selected dryness level.
Selecting More or Very will increase the cycle
time, while Less or Damp will decrease the cycle
time.
• Use a Less or Damp setting for items that you
wish to iron.
NOTE
• The appliance will automatically adjust the cycle
time according to the selected dryness level.
Selecting dry levels above Normal will increase
the cycle time. Selecting dry levels below
Normal will decrease the cycle time.
• Use dry level between Normal and Damp or the
Damp dry level for items that you wish to iron.
Time
Allows you to manually select the drying time,
from 20 to 60 minutes, in 10-minute increments.
Use this for small loads or to remove wrinkles.
• You can add or reduce the drying time using
More Time / Less Time button. (10 - 100
minutes)
38 OPERATION
Options and Extra Functions
Your dryer includes several additional cycle
options to customize cycles to meet your individual
needs.
Select the desired option after selecting the
desired cycle and settings.
NOTE
• The LED for the option will light up when the
option is selected.
• To protect your garments, not every option is
available with every cycle.
• A chime will sound twice and the LED will not
light up if the selected option is not allowed for
the selected cycle.
Damp Signal
When this option is selected, the appliance signals
when the load is approximately 80% dry. This
allows you to remove faster-drying lightweight
items or items that you would like to iron or hang
while they are still slightly damp.
Press the Damp Signal button before you start a
drying cycle.
Energy Saver
This option helps to reduce the energy
consumption of the Normal cycle, depending on
the load size. When the Energy Saver option is
selected, the cycle begins with an air dry section
and the drying time is increased.
NOTE
• The Energy Saver option is turned on by default
in the Normal cycle.
• Turning the Energy Saver option off changes
the default cycle to the last cycle used. To return
to the default settings, turn the Energy Saver
option on.
Air Dry
Use this cycle to dry all items (such as plastics or
rubber) that can be tumble dried without using
heat.
Default dry time is 30 minute. You can add or
reduce the drying time using More Time / Less
Time button. (10 - 100 minutes)
Wrinkle Care
Selecting this option will tumble the load
periodically for up to 3 hours after the selected
cycle, or until the door is opened. This is helpful in
preventing wrinkles when you are unable to
remove items from the dryer immediately.
Press the Wrinkle Care button before you start a
drying cycle.
NOTE
• When the option is turned on, a rectangle with a
dashed line and ENd appears on the display until
the feature is off.
• When the option is turned on, only the Power
button works after the drying cycle ends.
• To select the option after starting a cycle, pause
the cycle, set the option, and press Start/Pause.
• Always turn off the appliance before unloading
the clothes.
More Time / Less Time
Use these buttons to increase or decrease drying
time in 5 minute increments when you use some
drying cycles such as Quick Dry and Air Dry.
Signal
The appliance plays a melody when the drying
cycle is finished. The buttons make a sound each
time they are pressed. Use this button to turn the
melody and button tones on or off.
• To turn on/off, press and hold the Damp Signal
button for 3 seconds.
Control Lock
Use this function to disable the controls. This
function can prevent children from changing
cycles or operating the dryer.
NOTE
• The function does not lock the door.
• Once this function is set, all buttons are locked
except the Power button.
• When the controls are locked, CL and the
remaining time are alternately shown on the
display during the dry cycle.
39OPERATION
ENGLISH
• Turning off the power will not reset this function.
You must deactivate this function before you can
access any other options and functions.
Locking/Unlocking the Control Panel
1 Turn on the power.
2 Press and hold the Air Dry button for 3
seconds to activate/deactivate this function.
• When the function is deactivated, a chime will
sound and the remaining time for the current
cycle will reappear on the display.
Produkt Specifikationer
Mærke: | LG |
Kategori: | Tørretumbler |
Model: | D8401WE |
Har du brug for hjælp?
Hvis du har brug for hjælp til LG D8401WE stil et spørgsmål nedenfor, og andre brugere vil svare dig
Tørretumbler LG Manualer
1 Januar 2025
22 December 2024
22 December 2024
19 December 2024
19 December 2024
19 December 2024
6 September 2024
2 September 2024
2 September 2024
2 September 2024
Tørretumbler Manualer
- Tørretumbler DeLonghi
- Tørretumbler Sinbo
- Tørretumbler Bosch
- Tørretumbler PKM
- Tørretumbler Gram
- Tørretumbler EasyMaxx
- Tørretumbler Siemens
- Tørretumbler Samsung
- Tørretumbler Scandomestic
- Tørretumbler GE
- Tørretumbler Zanussi
- Tørretumbler Cylinda
- Tørretumbler Panasonic
- Tørretumbler Candy
- Tørretumbler Fisher & Paykel
- Tørretumbler Gorenje
- Tørretumbler VOX
- Tørretumbler Miele
- Tørretumbler Blomberg
- Tørretumbler Concept
- Tørretumbler Teka
- Tørretumbler OK
- Tørretumbler AEG
- Tørretumbler Electrolux
- Tørretumbler Bauknecht
- Tørretumbler Whirlpool
- Tørretumbler Vestfrost
- Tørretumbler Mitsubishi
- Tørretumbler Master
- Tørretumbler Sharp
- Tørretumbler Hotpoint
- Tørretumbler Omega
- Tørretumbler Hoover
- Tørretumbler Daewoo
- Tørretumbler Arçelik
- Tørretumbler ProfiCare
- Tørretumbler Grundig
- Tørretumbler Indesit
- Tørretumbler Hotpoint Ariston
- Tørretumbler Klarstein
- Tørretumbler Ardo
- Tørretumbler Etna
- Tørretumbler Infiniton
- Tørretumbler Emerio
- Tørretumbler Logik
- Tørretumbler Bartscher
- Tørretumbler Sauber
- Tørretumbler Westinghouse
- Tørretumbler Element
- Tørretumbler Thomson
- Tørretumbler Constructa
- Tørretumbler Hyundai
- Tørretumbler AKAI
- Tørretumbler Hisense
- Tørretumbler Brandt
- Tørretumbler Adler
- Tørretumbler Black And Decker
- Tørretumbler Camry
- Tørretumbler TecLime
- Tørretumbler Blaupunkt
- Tørretumbler Tomado
- Tørretumbler AEG-Electrolux
- Tørretumbler Ariston
- Tørretumbler Asko
- Tørretumbler Atlas
- Tørretumbler Becken
- Tørretumbler BEKO
- Tørretumbler Gaggenau
- Tørretumbler Iberna
- Tørretumbler Ignis
- Tørretumbler Küppersbusch
- Tørretumbler Neff
- Tørretumbler Privileg
- Tørretumbler Smeg
- Tørretumbler Clatronic
- Tørretumbler Remington
- Tørretumbler Ariston Thermo
- Tørretumbler Fagor
- Tørretumbler Haier
- Tørretumbler Bomann
- Tørretumbler Russell Hobbs
- Tørretumbler Ariete
- Tørretumbler Leifheit
- Tørretumbler Vivax
- Tørretumbler Crosley
- Tørretumbler UPO
- Tørretumbler Zanker
- Tørretumbler Galanz
- Tørretumbler Amana
- Tørretumbler Amica
- Tørretumbler Arthur Martin-Electrolux
- Tørretumbler Euromaid
- Tørretumbler Kernau
- Tørretumbler Caple
- Tørretumbler SIBIR
- Tørretumbler Zerowatt
- Tørretumbler Taurus
- Tørretumbler Zenith
- Tørretumbler Balay
- Tørretumbler Exquisit
- Tørretumbler Pelgrim
- Tørretumbler Elba
- Tørretumbler Elektra Bregenz
- Tørretumbler ELIN
- Tørretumbler Faure
- Tørretumbler Rommer
- Tørretumbler Schneider
- Tørretumbler MPM
- Tørretumbler Profilo
- Tørretumbler Tesla
- Tørretumbler Hanseatic
- Tørretumbler Thor
- Tørretumbler V-Zug
- Tørretumbler Maytag
- Tørretumbler Auto Joe
- Tørretumbler Schulthess
- Tørretumbler Thomas
- Tørretumbler Bush
- Tørretumbler Heylo
- Tørretumbler Aspes
- Tørretumbler Salora
- Tørretumbler Inventum
- Tørretumbler Cleanmaxx
- Tørretumbler White Knight
- Tørretumbler Midea
- Tørretumbler CDA
- Tørretumbler Frigidaire
- Tørretumbler Frilec
- Tørretumbler Bimar
- Tørretumbler Esatto
- Tørretumbler SVAN
- Tørretumbler Everglades
- Tørretumbler Danby
- Tørretumbler RCA
- Tørretumbler Koenic
- Tørretumbler ECG
- Tørretumbler General Electric
- Tørretumbler Eldom
- Tørretumbler Proline
- Tørretumbler Stirling
- Tørretumbler Saivod
- Tørretumbler ElectriQ
- Tørretumbler Lavorwash
- Tørretumbler Gemini
- Tørretumbler Rinnai
- Tørretumbler Friac
- Tørretumbler Technika
- Tørretumbler Seiki
- Tørretumbler Baumatic
- Tørretumbler Beper
- Tørretumbler Morris
- Tørretumbler Kenmore
- Tørretumbler Avanti
- Tørretumbler Continental Edison
- Tørretumbler Corbero
- Tørretumbler Otsein-Hoover
- Tørretumbler Artusi
- Tørretumbler Orima
- Tørretumbler Magic Chef
- Tørretumbler Lamona
- Tørretumbler Philco
- Tørretumbler Zanussi-Electrolux
- Tørretumbler Sôlt
- Tørretumbler Rex
- Tørretumbler Classique
- Tørretumbler Kunft
- Tørretumbler Simpson
- Tørretumbler Euro Appliances
- Tørretumbler Summit
- Tørretumbler Kogan
- Tørretumbler LERAN
- Tørretumbler New Pol
- Tørretumbler Insignia
- Tørretumbler Andis
- Tørretumbler Jocel
- Tørretumbler Ufesa
- Tørretumbler SanGiorgio
- Tørretumbler Electra
- Tørretumbler IFB
- Tørretumbler Mistral
- Tørretumbler Wisberg
- Tørretumbler KDK
- Tørretumbler AYA
- Tørretumbler Vedette
- Tørretumbler Royal Sovereign
- Tørretumbler Nordland
- Tørretumbler John Lewis
- Tørretumbler Mabe
- Tørretumbler Castor
- Tørretumbler Heinner
- Tørretumbler Nabo
- Tørretumbler Defy
- Tørretumbler Nordmende
- Tørretumbler WLA
- Tørretumbler Ansonic
- Tørretumbler Kelvinator
- Tørretumbler Listo
- Tørretumbler EAS Electric
- Tørretumbler Speed Queen
- Tørretumbler WhiteLine
- Tørretumbler Creda
- Tørretumbler Kleenmaid
- Tørretumbler Essentiel B
- Tørretumbler Edy
- Tørretumbler Altus
- Tørretumbler Eurotech
- Tørretumbler Equator
- Tørretumbler Coline
- Tørretumbler Trieste
- Tørretumbler Bluesky
- Tørretumbler Icecool
- Tørretumbler Marynen
- Tørretumbler Ormond
- Tørretumbler Sichler
- Tørretumbler Eudora
- Tørretumbler Hiberg
- Tørretumbler Romo
- Tørretumbler Microstar
- Tørretumbler Amba
- Tørretumbler Winia
- Tørretumbler Huebsch
- Tørretumbler Novamatic
- Tørretumbler T4223C
- Tørretumbler Miele Professional
- Tørretumbler Mio Star
- Tørretumbler One Concept
- Tørretumbler Dexter Laundry
- Tørretumbler TESLA Electronics
- Tørretumbler Smart Brand
- Tørretumbler Mybeo
- Tørretumbler CEEM
- Tørretumbler Ulsonix
- Tørretumbler Yamazen
Nyeste Tørretumbler Manualer
5 Januar 2025
5 Januar 2025
5 Januar 2025
5 Januar 2025
5 Januar 2025
5 Januar 2025
5 Januar 2025
5 Januar 2025
5 Januar 2025
5 Januar 2025
