MODEL: MHT913R

PLEASE READ BEFORE OPERATING THIS EQUIPMENT.

OWNER'S MANUAL

Size: 142(W) x 210(H)mm (A5)

STEREO SPEAKER

with Bluetooth® Wireless Technology

Notes:

　　　Make sure the Line In Connection Cable is NOT plugged in the LINE IN Jack. Otherwise, BT will

not functioning. Unplug it from the LINE IN Jack before using BT.

　　　For saving electricity, slide the POWER ON/OFF switch to OFF position and unplug the

AC/USB Adaptor from wall outlet if you will not use the unit for an extended period of time.

　　　When the external BT Device searched the unit, our model number “MHT913R” will appear on the

display of external BT Device.

　　　Pairing code “0000” or “1234” may need to be entered.

2. Slide the POWER ON/OFF Switch on the right side of unit to ON

position to turn the unit to Standby Mode. The Red Standby/BT

Indicator on the front of unit will illuminate.

3. Press and hold the Button on the unit or press the Button

on the Remote Control to power on the unit from Standby Mode.

The Blue Standby/BT Indicator on the front of unit will illuminate

and blink.

Note: If unplug the Line In Connection Cable from the Line

In Jack. The unit will turn to BT mode automatically

and the color of STANDBY Indicator will turns to blue.

4. Press the VOL +/- buttons to adjust volume levels as desire.

5. Press the button on the Remote Control to mute the

sound temporary, press again to resume.

6. When no longer in use, press and hold the button on the unit or press

the button on the Remote Control to turn the unit to standby mode.

NOTE: To saving the electric power, slide the POWER ON/OFF switch to OFF position and

unplug the AC/USB Adaptor from wall outlet if long period of time will not use.

1. Standby/BT Indicators

2. Charging Indicator

3. POWER ON/OFF switch

4. button

5. VOL (Volume) + button

6. VOL (Volume) - button

7. USB port (For DC IN)

8. LINE IN jack

AC/USB Adaptor

Power source:...............................................Built-in DC 3.7V, 1000mAh (3.7WH) rechargeable

Li-ion Battery, Recharge by DC 5V, 1500mA

through Micro USB Port

Impedance of the speakers:..........................2 x 5W; 4ohm

Audio power:..................................................2 x 3W (Total 6W RMS)

BT Version:....................................................4.0

BT Operation Distance:.................................96 Feet in opera area

1 x User’s Manual

1 x Remote Control (Uses 1 x CR2025 Button Cell, included)

1 x AC/USB Adapter (Input: AC 100-240V~ 50/60Hz; 0.4A, Output: DC 5V, 1500mA)

1 x Audio Connection Cables with 3.5mm Plugs

1 x USB Connection Cable (For Charging only)

SPECIFICATIONS AND ACCESSORIES ARE SUBJECT TO CHANGE WITHOUT NOTICE

Volume level of paired/connected device is in low

level

Built in battery consumed

Volume of the unit was set to minimum position

Recharge the battery as page 3

Increase the volume by press and

hold the VOL + Button on the unit

or press the VOL + Button on the

Remote Control

Rise the volume level of the

paired/connected device

Can’t power on

No sound or

sound weak

Sound distortion Volume level too high

Volume level of the connected/paired device too

high

Reduce the volume level of the

connected/paired device

Reduce the volume level by press

and hold the VOL - Button on the

unit or press the VOL - Button on

the Remote Control

1. Connect the Headphone/Earphone; AUX out; Line out jacks

from the external audio player (such like MP3 player;

Discman . . . etc) to the LINE IN jacks on the unit by the

supplied Line In Connection Cable as the figure on right :

Follow these Battery Precaution when using a battery in this device:

1. Use only the size and type of battery specified.

2. Be sure to follow the correct polarity when installing the battery as indicated in the battery

compartment. A reversed battery may cause damage to the device.

3. Do not mix different types of batteries together (e.g. Alkaline and Carbon-zinc) or old batteries

with fresh ones.

4. If the batteries in the device are consumed or the device is not to be used for a long period of

time, remove the batteries to prevent damage or injury from possible battery leakage.

1. Press and hold the Button on the unit or press the Button to power on the unit from Standby

Mode. The Blue BT Indicator on the front of unit will illuminate and blink.

2. Wait a few seconds until the unit is automatically paired to the external BT Device. (The Blue

Indicator will stop blinking).

3. Plays the music in the paired BT Device as usual.

For first time use or re-pairing the unit to a new BT Device, follow the instructions below:

1. Slide the POWER ON/OFF Switch on the right side of unit to ON position to turn the unit to Standby

Mode. The Red Standby Indicator on the front of unit will illuminate.

2. Press and hold the Button on the unit or press the Button on the Remote Control to power on

the unit from Standby Mode. The Blue BT Indicator on the front of unit will illuminate and

blink.

3. Power on the external BT Device and enter to BT searching mode. Start pairing following the on

screen instructions from the external BT Device. After paired, the Blue Indicator will stop blinking.

4. Play the music on the paired BT Device as usual.

5. During playback:

Press and release the Button on the unit or the Button on the Remote Control to pause;

press again to resume normal playback.

Press and hold the VOL (Volume) +/- Buttons on the unit or press and release the VOL (Volume)

+/- Buttons on the Remote Control to adjust volume level as desired.

Press and release the VOL (Volume) +/- Buttons on the unit or press the / Buttons on the

Remote Control repeatedly to skip tracks.

6. To shut off the unit, press and hold the Button on the unit or press the Button on the Remote

Control. The color of the Standby/BT Indicator will turns to Red.

BATTERY PRECAUTIONS

BT (BLUETOOTH):

BT PAIRING:

Normal operation after paired:

OPERATION

LOCATION OF CONTROLS

POWER SOURCE TROUBLESHOOTING

LISTENING FROM LINE IN JACKS

Maintenance

SPECIFICATIONS

PACKAGE INCLUDES:

Battery Recharging:

The unit has a built-in Li-ion rechargeable battery, recharge it before first time use or when needed

as follows:

1. Connect the small plug from the supplied USB Connection Cable to the DC IN Jack (Micro

USB Port) on the right side of unit.

2. Connect the full size USB plug from the supplied USB Connection Cable to the USB Port on

the supplied AC/USB Adaptor.

3. Connect the AC/USB Adaptor to wall outlet having AC 100-240V~, 50/60Hz as illustrated below:

4. During charging, the Red Charging Indicator on the front of unit will illuminate. When finished

charging, it will turned off.

Your battery will last longer if you follow these simple guidelines for charging and storing.

A. Before first time use, recharge the unit approximately 4 hours until the unit is fully recharged.

B. Recharge and store the unit within the temperature range of 5°C - 35°C (40°F - 95°F).

C. Do not overcharge (longer than 24 hours). Excessive charging or running the unit until battery

is fully drained will damage the battery. Battery life will be extended if you keep the battery fully

charged.

D. Battery life naturally shortens slowly over time.

E. The rechargeable battery incorporated in this product is not user replaceable.

IMPORTANT:

NOTES:

This AC/DC Adaptor is intended to be correctly orientated in a vertical or floor mount position.

To save energy, unplug the AC/USB Adaptor from the wall outlet if you will not use it for an

extended period of time.

During charging, you can also play and listen music at the same time.

POSSIBLE CAUSE POSSIBLE SOLUTIONSYMPTOM

The external BT Device had NOT paired to the unit

The external BT device too far from the unit

Pair the external BT Device to the

unit as page 5 & 6

Place the external BT device close

to the unit

BT not functioning

4 5 7 86

Check the following before requesting service:

1. button

2. button

3. VOL (Volume) - button

4. VOL (Volume) + button

5. (Skip Backward) button

6. (Skip Forward) button

1 2

For fist time use, slide the insulation film from the battery door and discard it as in the figure below:

5. Do not try to recharge non-chargeable batteries, It can overheat and rupture.

(Follow battery manufacturer’s instructions.)

6. Do not dispose of battery in fire. Battery may explode or leak.

7. Clean the battery contacts and also those of the device prior to battery installation.

8. This product contains a coin/button cell battery. If the coin/button cell battery is swallowed,

it can cause severe internal burn in just 2 hours and can lead to death. Keep new and used batteries

away from children. If the battery compartment does not close. If you think batteries might have been

swallowed or placed inside any part of the body, seek immediate medical attention.

Approx.12 feet

NOTES:

● When there is an obstacle between the unit and the

transmitter, the transmitter may not operate.

● When direct sunlight, an incandescent lamp,

fluorescent lamp or any other strong light shines on

the REMOTE SENSOR of the unit, the remote

operation may be unstable.

Printed in China MHT913R_WC_E0FG1_B0WU

LIMITED WARRANTY

Craig Electronics warrants this product to be free from manufacturing defects in

material and workmanship under normal use for a period of 180 days from date of

purchase. If service is required, please return the product to the store where it was

purchased for exchange; or, pack the unit in the original packing material with all

accessories if applicable, a copy of your sales receipt and a Cashier’s check or Money

Order for $7 (to cover shipping and handling costs) payable to Craig Electronics Inc.

For consumers in Canada, please make sure that the cashier check or money order is

redeemable through a U.S. bank. Ship your product freight pre-paid. our unit will be Y

repaired, replaced or if the unit can not be repaired or replaced, a refund will be

forwarded to you within four weeks of receipt of your unit. Please ship your unit to:

Craig Electronics Inc.

1160 NW 163 Drive

Miami, Fl 33169

This warranty is void if the product has been: a) Used in a commercial application or

rental. b) Damaged through misuse, negligence, or abuse. c) Modified or repaired by

anyone other than an authorized Craig service center. d) Damaged because it is

improperly connected to any other equipment.

Note: This warranty does not cover: a) Ordinary adjustments as outlined in the Owner’s

Manual which can be performed by the customer. b) Damage to equipment not properly

connected to the product. c) Any cost incurred in shipping the product for repair. d)

Damage to the product not used in the USA.

This warranty is not transferable and only applies to the original purchase. Any implied

warranties, including the warranty of merchantabilit , are limited in duration to the period y

of this expressed warranty and no warranty whether expressed or implied shall apply to

the product thereafter.

Under no circumstance shall Craig be liable for any loss or consequential damage arising

out of the use of this product. This warranty gives specific legal rights. However, you may

have other rights which may vary from state to state. Some states do not allow limitations

on implied warranties or exclusion of consequential damage. Therefore, these

restrictions may not apply to you.

This product has been manufactured by and is sold under the responsibility of Craig

Electronics Inc, and Craig Electronics Inc is the warrantor in relation to this product.

MAGNAVOX and SMAR . VERT Y SMAR are registered trademarks of Koninklijke Philips T

N.V. and are used under license from Koninklijke Philips N. .V

To Obtain Service on your Product

email:service@craigelectronics.com

Produkt Specifikationer

Mærke:	Magnavox
Kategori:	Højttaler
Model:	MHT913R

Har du brug for hjælp?

Hvis du har brug for hjælp til Magnavox MHT913R stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Højttaler Magnavox Manualer

Magnavox MSB5300 Manual

7 Januar 2025

Magnavox MSB5305 Manual

7 Januar 2025

Magnavox MMA3683n Manual

7 Januar 2025

Magnavox MMA3629 Manual

7 Januar 2025

Magnavox MD6949 Manual

7 Januar 2025

Magnavox MMA3680 Manual

7 Januar 2025

Magnavox MMA3685 Manual

7 Januar 2025

Magnavox MMA3717 Manual

7 Januar 2025

Magnavox MMA3679 Manual

7 Januar 2025

Magnavox MMA3652 Manual

7 Januar 2025

Højttaler Manualer

Nyeste Højttaler Manualer

MB PS61 Manual

8 Januar 2025

Definitive Technology Dymension LS-400 Manual

8 Januar 2025

Definitive Technology Dymension Outdoor LS- Manual

8 Januar 2025

Definitive Technology Dymension LS-80 Manual

8 Januar 2025

Sonance Visual Performance Extreme VPXT8R Manual

8 Januar 2025

Sonance Visual Performance VP38R Manual

8 Januar 2025

Duronic BX48 Manual

8 Januar 2025

Sonance MAG5.1R Manual

8 Januar 2025

Sonance MAG6R Manual

8 Januar 2025

Electro-Voice XLE191-FG Manual

8 Januar 2025
