SIZE: 70x158mm
FCC NOTICE:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and
receiver.
● Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
● Consult the dealer or an experienced radio/TV
technician for help.
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
2. Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
FCC WARNING:
To assure continued operation, follow the attached
installation instructions and use only shield cables when
connecting to other devices. Changes or modifications not
expressly approved by the party responsible for
compliance could void the user's authority to operate the
equipment.
1
POSSIBLE SOLUTION
Recharge the battery as page2
Turn the Power On-Off/Volume
Control Knob clockwise until “Click”
sound was heard to power on the
unit. The Blue Indicator on the front
of unit will illuminate
Increase the volume level by turn
the Power On-Off/Volume Control
Knob clockwise
Rise the volume level of the
paired/connected device
Reduce the volume level by turn the
Power On-Off/Volume Control Knob
counterclockwise
Reduce the volume level of the
paired/connected device
Pair the external BT device to the
unit as page 3-4
Place the external BT device close
to the unit
Reassemble the other direction/
location to improve reception.
Search and store the available FM
station into the unit and play the
desired stored FM station as page 6
POSSIBLE CAUSE
Built-in battery drained
The unit in power off
mode
Volume of the unit was
set to minimum
position
Volume level of
paired/connected
device is in low level
Volume level too high
Volume level of the
paired/connected
device too high
The external BT device
had NOT paired to the
unit
The external BT device
too far from the unit
The location not good
for radio reception
The available FM
stations had not stored
into the unit
SYMPTOM
Can’t power on
No sound or
sound weak
Sound
distortion
BT not
functioning
Radio reception
not good
No radio station
received
damage battery. Battery life will be extended if you keep
the battery fully charged.
D.
Battery life naturally shortens slowly over time.
E. The rechargeable battery incorporated in this product is
not user replaceable.
OPERATION:
General Operation:
1. Recharge the built-in Li-ion battery as previously
instructed.
2. Turn the Power On-Off/Volume Control Knob clockwise
to power on the unit and set the volume level as desired.
The Blue Power On Indicator on the front of unit will
illuminate.
3. Press the MODE Button repeatedly to switch to desired
playback mode. The unit will display and sound the
prompt with your selection (see list below):
Note:
If the TF (Micro SD) Card; USB Device and/or Line In
Plug had NOT inserted/installed into the unit, the
corresponding selection will not available.
4. During playback, turn the Power On-Off/Volume Control
Knob to adjust volume level as desired.
5. Press the Light (On/Off) Button to turn off the Decorative
LED Lights; press again to turn it back.
6. When finished listening, turn the Power On-Off/Volume
Control Knob counterclockwise until “Click” sound was
heard to shut off the unit. The Blue Indicator on the front
of unit will not light.
BT Mode:
BT (Bluetooth) pairing:
First time use or re-pairing the unit to a new BT Device,
pairas follows:
1. Power on the unit and enter to BT mode as previously
instructed. The Blue BT Indicator on front of the unit will
illuminate and blink. (“bLUE” will appear on the Display
and you will hear an audible prompt say “Bluetooth ready
for connection”.)
3
2. Power on the external BT Device and enter to BT
searching mode. Start pairing following the on screen
instructions from the external BT Device. When paired,
the unit will sound a prompt “Bluetooth connected” and
the Blue BT Indicator will stop blinking.
3. If pairing is complete you may now play music with your
external BT Device.
4. During playback:
● Turn the Power On-Off/Volume Control Knob to adjust
volume level as desired.
● Press the Button on the unit to pause, press again to
resume normal playback.
● Press and release the or Buttons repeatedly to
skip tracks.
5. When finished listening, turn the Power On-Off/Volume
Control Knob counterclockwise until “Click” sound was
heard to shut off the unit. The Blue Indicator on the front
of unit will not light.
Notes:
● When the external BT Device searched the unit, our
model number “MMA3683n” will appear on the display of
external BT Device.
● If while pairing you are asked for a code please try "0000"
or "1234".
Normal operation after pairing:
1. Power on the external BT Device and enter to BT
playback mode.
2. Power on the unit and enter to BT mode as previously
instructed. The Blue BT Indicator on the front of unit will
illuminate and blink. (You will also hear an audible prompt
say “Bluetooth ready for connection”.)
3. Wait a few seconds until the unit is automatically paired to
the external BT Device. The unit will sound a prompt
“Bluetooth connected” and the Blue BT Indicator will stop
blinking.
4. After pairing is complete you may now play music with
your external BT Device.
TF Micro SD Card:( )
To play the music in TF (Micro SD) Card:
1. In power off mode, insert the TF (Micro SD) Card (not
included) into the TF (Micro SD) Card Slot on the top of
unit with contacts facing to front as illustrated below:
4
on the Display and the current track will be playback
repeatedly until the unit was shut off.
● Press the REP (Repeat) Button twice on the front of
unit to activate repeat all function. “ALL” will appear
on the Display and the all the tracks in the USD
Device will be playback repeatedly until the unit was
shut off.
4. When finished listening, turn the Power On-Off/Volume
Control Knob counterclockwise until “Click” sound was
heard to shut off the unit. The Blue Indicator on the front
of unit will not light.
Notes:
● Up to 16 GB TF (Micro SD) Card/USB Device the unit
supports to play.
● When inserting the TF (Micro SD) Card/USB Device,
make sure the direction you selected is correct. Never
insert violently to avoid damaging the TF (Micro SD)
Card/USB Device or the unit. If it doesn’t work, please
check if the direction is correct.
● Before replacing TF (Micro SD) Card/USB Device, make
sure the unit has been powered off.
● You also need to download the desired music in MP3
format into the TF (Micro SD) Card/USB Device before
insert into the unit.
FM Radio:
1. Power on the unit and enter to radio mode as previously
instructed. “FM” Indicator on the Display will illuminate
and the unit will sound a prompt “Radio".
2. In first time use (or removed the unit to a new location),
search and store the available FM stations by press the
Button once. The unit will automatically to search and
store all available FM radio stations then play the first
stored FM station.
3. After settings, press the or Buttons repeatedly to
select and plays the desired stored radio station.
4. During playback, turn the Power On-Off/Volume Control
Knob to adjust volume level as desired.
5. When finished listening, turn the Power On-Off/Volume
Control Knob counterclockwise until “Click” sound was
heard to shut off the unit. The Blue Indicator on the front
of unit will not light.
Antennas:
This unit has a built-in FM antenna, which provides
adequate reception in most areas. If reception is weak,
reassemble the other direction/location to improve
reception.
6
LINE IN:
To listen from an external Audio Player such as MP3 Player,
Discman…etc.
1. In power off mode, connect one end of the supplied
Audio Connection Cable to the AUX Out / Line Out /
Phone Jack on the external Audio Player.
2. Connect the other end of the cable to the LINE IN Jack
on the top of unit as illustrated below:
To AUX Out/Line Out/
Phone Jack on the
external Audio Player
To LINE IN Jack
3. Power on the unit and enter to LINE IN mode as
previously instructed. “LlnE” will appear on the Display
and you will hear an audible prompt say “Line in”.
4. Play the music on the connected Player as usual.
(Make sure the volume level of the connected Audio
Player is turned to high level.)
5. During playback:
● Turn the Power On-Off/Volume Control Knob to adjust
volume level as desired.
● Press the Button on the unit to mute, press again
to turn the sound back.
6. When finished listening, turn the Power On-Off/Volume
Control Knob counterclockwise until “Click” sound was
heard to shut off the unit. The Blue Indicator on the front
of unit will not light.
Microphone:
To sing with the playing music:
1. Power on the unit and plays music in any modes as
instructed earlier.
2. Connect the plug from the Microphone (Not included) to
the MIC (Microphone) Jack on the top of unit.
3. Turn the Power On-Off/ Volume Control Knob to adjust
the sound level.
Note:
If feedback noise (high audio frequency noise) is hearing
from the speakers, turn the Power On-Off/ Volume Control
Knob counterclockwise to reduce the volume level or
moving the Microphone away from the speakers.
7
TROUBLESHOOTING:
Check the following before requesting service:
SPECIFICATIONS:
PACKAGE INCLUDES:
1 x Owner’s Manual
1 x USB Connection Cable (For Charging only)
1 x Audio Connection Cable with 3.5 mm plugs
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT
TO CHANGE WITHOUT NOTICE
8
LOCATION OF CONTROLS::
1. MIC (Microphone Input) Jack
2. USB Port
3. DC 5V Jack (Micro USB Port,
for charging only)
4. LINE IN Jack
5. TF (Micro SD) Card Slot
6. LED Display
7. MODE Button
8. REP ( Repeat ) Button
9. Light (On/Off) Button
10. Power On-Off/Volume
Control Knob
11. Buttton
12.
Button
13. Button
14. Red Charge Indicator
15. Blue Power On Indicator
16. Blue BT (Bluetooth) Indicator
17. Decorative LED Lights
POWER SOURCE:
The unit has a built-in Li-ion rechargeable battery, charge it
before first time use or when it is drained as follows:
1. Connect the small plug from the supplied USB Connection
Cable to the DC 5V Jack (Micro USB Port) on the top of unit.
2. Connect the full size USB Plug from the supplied USB
Connection Cable to the USB Port on the Personal
Computer or USB Charger (Computer and USB Charger
not included).
3. When charging, the Red Charge Indicator on the top of
unit will illuminate. When charging is complete, it will turn
off.
To Computer or any
USB Charger
To DC 5V Jack (Micro USB Port)
Notes:
Your battery will last longer if you following these simple
guidelines for caring and storing:
A.
Before first time use, recharge the unit approximately 4
hours until the unit is fully charged.
B.
Charge and store the unit within the temperature range of
5°C~35° (40°F~95°F).
C.
Do not overcharge (longer than 24 hours). Excessive
charging or running the unit until battery fully drains will
2
Showing on Display: Voice Prompt:Playback Modes:
bLUE
“SD” Indicator on the
Display will illuminate
“USB” Indicator on the
Display will illuminate
“FM” Indicator on the
Display will illuminate
LlnE
BT (Bluetooth)
TF (Micro SD) Card
USB
FM Radio
Line In (AUX In)
Bluetooth ready
for connection
Memory Card
USB
Radio
Line in
Built-in DC 3.7V, 1200 mAH (4.44WH) rechargeable
Li-ion battery; Recharge by DC 5V through DC 5V
Jack (Micro USB Port)
5 W; 3 Ω
3 W (RMS)
87.5 - 108 MHz
4.1
≧ 32 Feet in open area
Power Source
Impedance of Speakers
Audio Power
FM Radio Frequency:
BT Version
BT Operation Distance
2. Power on the unit and enter to TF (Micro SD) Card
mode as previously instructed. “SD” Indicator on the
Display will illuminate and the unit will sound a prompt
“Memory Card" then automatically play the music stored
in the card.
3. During playback:
● Turn the Power On-Off/Volume Control Knob to adjust
volume level as desired.
● Press the Button on the unit to pause, “ ” will
appear on the Display. Press again to resume normal
playback, “ ” on Display will disappear.
● Press and release the or Buttons repeatedly to
skip tracks.
● Press the REP (Repeat) Button once on the front of
unit to activate repeat one function. “ONE” will appear
on the Display and the current track will be playback
repeatedly until the unit was shut off.
● Press the REP (Repeat) Button twice on the front of
unit to activate repeat all function. “ALL” will appear
on the Display and the all the tracks in the card will
be playback repeatedly until the unit was shut off.
4. When finished listening, turn the Power On-Off/Volume
Control Knob counterclockwise until “Click” sound was
heard to shut off the unit. The Blue Indicator on the front
of unit will not light.
USB:
To play the music in USB Device:
1. In power off mode, connect the USB Device into the
USB Port on the top of unit as illustrated below:
2. Power on the unit and enter to USB mode as previously
instructed. “USB” Indicator on the Display will illuminate
and the unit will sound a prompt “USB" then automati-
cally play the music stored on the USB Device.
3. During playback:
● Turn the Power On-Off/Volume Control Knob to adjust
volume level as desired.
● Press the Button on the unit to pause, “ ” will
appear on the Display. Press again to resume normal
playback, “ ” on Display will disappear.
● Press and release the or Buttons repeatedly to
skip tracks.
● Press the REP (Repeat) Button once on the front of
unit to activate repeat one function. “ONE” will appear
5
Craig Electronics warrants this product to be free from
manufacturing defects in material and workmanship under
normal use for a period of 180 days from date of purchase. If
service is required, please return the product to the store
where it was purchased for exchange; or, pack the unit in the
original packing material with all accessories if applicable, a
copy of your sales receipt and a Cashier’s check or Money
Order for $10 (to cover shipping and handling costs) payable
to Craig Electronics Inc. For consumers in Canada, please
make sure that the cashier check or money order is
redeemable through a U.S. bank. Ship your product freight
pre-paid. Your unit will be repaired, replaced or if the unit
cannot be repaired or replaced, a refund will be forwarded to
you within four weeks of receipt of your unit. Please ship your
unit to:
Craig Electronics Inc.
1160 NW 163 Drive
Miami, Fl 33169
This warranty is void if the product has been: a) Used in a
commercial application or rental. b) Damaged through
misuse, negligence, or abuse. c) Modified or repaired by
anyone other than an authorized Craig service center. d)
Damaged because it is improperly connected to any other
equipment.
Note: This warranty does not cover: a) Ordinary adjustments
as outlined in the Owner’s Manual which can be performed
by the customer. b) Damage to equipment not properly
connected to the product. c) Any cost incurred in shipping the
product for repair. d) Damage to the product not used in the
USA.
This warranty is not transferable and only applies to the
original purchase. Any implied warranties, including the
warranty of merchantability, are limited in duration to the
period of this expressed warranty and no warranty whether
expressed or implied shall apply to the product thereafter.
Under no circumstance shall Craig be liable for any loss or
consequential damage arising out of the use of this product.
This warranty gives specific legal rights. However, you may
have other rights which may vary from state to state. Some
states do not allow limitations on implied warranties or
exclusion of consequential damage. Therefore, these
restrictions may not apply to you.
This product has been manufactured by and is sold under
the responsibility of Craig Electronics Inc, and Craig
Electronics Inc is the warrantor in relation to this product.
MAGNAVOX and SMART. VERY SMART are registered
trademarks of Koninklijke Philips N.V. and are used under
license from Koninklijke Philips N.V.
To Obtain Service on your Product
email:service@craigelectronics.com
Printed in China MMA3683n_WC_E0FK1_B0US
LIMITED WARRANTY

Produkt Specifikationer

Mærke: Magnavox
Kategori: Højttaler
Model: MMA3683n

Har du brug for hjælp?

Hvis du har brug for hjælp til Magnavox MMA3683n stil et spørgsmål nedenfor, og andre brugere vil svare dig


Højttaler Magnavox Manualer

Magnavox

Magnavox MSB5300 Manual

7 Januar 2025
Magnavox

Magnavox MSB5305 Manual

7 Januar 2025
Magnavox

Magnavox MMA3683n Manual

7 Januar 2025
Magnavox

Magnavox MMA3629 Manual

7 Januar 2025
Magnavox

Magnavox MD6949 Manual

7 Januar 2025
Magnavox

Magnavox MMA3680 Manual

7 Januar 2025
Magnavox

Magnavox MMA3685 Manual

7 Januar 2025
Magnavox

Magnavox MMA3717 Manual

7 Januar 2025
Magnavox

Magnavox MMA3679 Manual

7 Januar 2025
Magnavox

Magnavox MMA3652 Manual

7 Januar 2025

Højttaler Manualer

Nyeste Højttaler Manualer

HK Audio

HK Audio DFP Manual

8 Januar 2025
Electro-Voice

Electro-Voice Sb122 Manual

8 Januar 2025
Origin Acoustics

Origin Acoustics C65EX Manual

8 Januar 2025
Origin Acoustics

Origin Acoustics D65EX Manual

8 Januar 2025
Bauhn

Bauhn APVK-1224 Manual

7 Januar 2025
GMB Audio

GMB Audio SPK-BT-LED-01 Manual

7 Januar 2025
GMB Audio

GMB Audio SPK-BTOD-01 Manual

7 Januar 2025
Bauhn

Bauhn APMP-1224 Manual

6 Januar 2025
Renkforce

Renkforce RF-ENC-200 Manual

5 Januar 2025
Audibax

Audibax Denver 12 Manual

5 Januar 2025
