SIZE: 70x158mm
FCC NOTICE:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and
receiver.
● Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
● Consult the dealer or an experienced radio/TV
technician for help.
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
2. Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
FCC WARNING:
To assure continued operation, follow the attached
installation instructions and use only shield cables when
connecting to other devices. Changes or modifications not
expressly approved by the party responsible for
compliance could void the user's authority to operate the
equipment.
1
POSSIBLE SOLUTION
Recharge the built-in battery as
page 2.
Increase the volume by press
and hold the Button
Rise the volume level of the
paired/connected device
Reduce the volume level by
press and hold the Button
Reduce the volume level of the
connected/paired device
Pair the external BT Device to
the unit as page 3.
Place the external BT device
close to the unit
POSSIBLE CAUSE
Built-in battery drained
Volume of the unit was set
to minimum position
Volume level of
paired/connected device
is in low level
Volume level too high
Volume level of the
connected/paired device
too high
The external BT Device
had NOT paired to the unit
The external BT device
too far from the unit
SYMPTOM
Can’t power on
No sound or
sound weak
Sound
distortion
BT not
functioning
C
.
Do not over charge longer than 24 hours. Excessive
charging or running the unit until battery fully drains will
damage battery. Battery life will be extended if you keep
the battery fully charged.
D
.
Battery life naturally shortens slowly over time.
E
.
The rechargeable battery incorporated in this product is
not user replaceable.
OPERATION:
General Operation:
1.
Recharge the built-in Li-ion battery as previously instructed.
2. Press and hold the Button approximately 3 seconds to
power on the unit. The Blue Indicator on the front of unit
will illuminate.
3. Press and release the Button repeatedly to switch to
desired playback mode. The unit will sound the prompt
with your selection (see list below):
Note: If the Micro SD Card is NOT inserted into the SD
Card Slot and/or the External Audio Player is NOT
connecting to the AUX (in) Jack, the selection of Micro
SD Card/AUX IN (LINE IN) will not available.
4. During playback, press and hold the or Buttons to
adjust volume level as desired.
5. Press the Button repeatedly to turn On/Off and/or set
the blinking modes of the Decorative LED Lights.
6. When finished listening, press and hold the Button to
shut off the unit.
BT Mode:
BT (Bluetooth) pairing:
First time use or re-pairing the unit to a new BT Device, pair
as follows:
1. Power on the unit and enter to BT mode as previously
instructed. The Blue Indicator on the front of unit will
illuminate and blink. The unit also will sound a prompt
“Bluetooth ready for connection”.
2. Power on the external BT Device and enter to BT
searching mode. Start pairing following the on screen
instructions from the external BT Device. When paired，
the unit will sound a prompt “Bluetooth connected” and
the Blue Indicator will stop blinking.
3. If pairing is complete you may now play music and
answer calls with your external BT Device.
3
4. During playback:
● Press the Button on the unit to pause, press again
to resume normal playback.
● Pres
s and hold the or Buttons to adjust
volume
level as desired.
● Press and release the or Buttons repeatedly to
skip tracks.
5. If the unit is paired to a Cell Phone and a call is incoming
during an active music session, press the Button to
pause the music playback then speak to the built-in
microphone
to answer the call. When your call is complete,
press the Button to end the call and resume to music
playback.
6. When finished listening, press and hold the Button to
shut off the unit.
Notes:
● When
the external BT Device searched the unit, our
model
number “MMA3623” will appear on the display of external
BT Device.
● If while pairing you are asked for a code please try "0000"
or "1234".
Normal operation after pairing:
1. Power on the external BT Device and enter to BT
playback mode.
2. Power on the unit and enter to BT mode as previously
instructed. The Blue Indicator on the front of unit will
illuminate and blink. The unit also will sound a prompt
“Bluetooth ready for connection”.
3.
Wait a few seconds until the unit is automatically paired to
the external BT Device. The unit will sound a prompt
“Bluetooth
connected” and the Blue Indicator will stop blinking.
4. After pairing is complete you may now play music and
answer calls with your external BT Device.
AUX (in):
To listen from the external Music Player such as a MP3
Player, Discman…etc.
1. Open the Rubber Cover on the unit.
2. Connect one end of the supplied Audio Connection Cable
to the AUX Out/Line Out/Phone Jack on the external
Audio Player.
3. In power on mode, connect the other end of the cable to
the AUX (in) Jack as illustrated follows. The unit will turn
to AUX (in) mode automatically and will sound a prompt
"Line in".
Note: If the unit is not in AUX In (Line in) mode or you
want
to switch to other playback modes, press and release
the Button to switch to desired playback mode.
4
To AUX Out/Line Out/
Phone Jack on the
external Audio Player
4. Play
the music on the connected Player as usual. (Make
sure the volume level of the connected Audio Player is
turned to high level.)
5. During playback:
● Press and hold the or Button to adjust volume
level as desired.
● Press the Button to mute the sound, press again to
turn the sound back.
6. When finished listening, press and hold the Button to
shut off the unit.
TF Micro SD :( )
To play the music in Micro SD Card:
1. Open the Rubber Cover on the unit.
2. In
power off mode, insert the Micro SD Card (not included)
into the Micro SD Card Slot on the unit with contacts
facing up as illustrated below:
3. Power on the unit and enter to Micro SD Card mode as
previously instructed. The unit also will sound a prompt
“Memory Card" then automatically play the music stored
on the card.
4. During playback:
● Press the Button to pause, press again to resume
normal playback.
● Press and hold the or
Buttons to adjust volume
level as desired.
● Press and release the or Buttons repeatedly to
skip tracks.
5. When
finished listening, press and hold the Button
to
turn off the unit.
Notes:
● Up to 16 GB Micro SD Card the unit supports to play.
● Before replacing Micro SD Card, make sure the unit has
been powered off.
● When inserting the Micro SD Card, make sure the
direction you selected is correct. Never insert violently to
avoid damaging the Micro SD Card or the unit.
5
● If it doesn’t work, please check if the direction is correct.
● You also need to download the desired music in MP3
format into the Micro SD Card before insert into the unit.
TROUBLESHOOTING:
Check the following before requesting service:
SPECIFICATIONS:
PACKAGE INCLUDES:
1 x Owner's Manual
1 x USB Connection Cable (For charge only)
1 x Audio Connection Cables with 3.5mm Plugs
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT
TO CHANGE WITHOUT NOTICE.
6
LOCATION OF CONTROLS:
1. (Decorative LED Lights On/Off and
Blinking Modes Selection) Button
2. (Power On/Off and Mode Selection) Button
3. Button
4. Button
5. Button
6. Micro USB Port (For Charge only)
7. Micro SD Card Slot
8. AUX (in) Jack
9. Rubber Cover (This cover is for
water and dusts Ingress
Protection;
always make
sure it
is completely closed)
10. Metallic Buckle
11. Built-in Microphone
12. Decorative LED Lights
13. Indicators
POWER SOURCE:
The unit has a built-in Li-ion rechargeable battery, recharge
it before use or when it is drained as follows:
1. Open the Rubber Cover on the unit.
2. Connect the Micro USB Plug from the supplied USB
Connection Cable to the Micro USB Port.
3. Connect the full sized USB Plug from the supplied USB
Connection Cable to the USB Port on Computer or USB
Charger (Not included). Charging will automatically start.
● During charging, the Red Charging Indicator on the front
of unit will illuminate. When finished, it will turn off.
● During charging, you can also listen to music at the
same time.
To Computer or any
USB Charger
NOTES:
The Rubber cover is for water and dusts Ingress
Protection; always make sure it is completely closed.
IMPORTANT:
Your battery will last longer if you follow these simple guidelines
for caring and storing.
A
.
Before first time use
, charge it approximate 3 hours until
the unit is fully charged.
B.
Recharging
and store the unit within the temperature range
of 5°C~35°C (40°F~95°F).
2
Power Source
Dusts/Water Ingress
Protection Level
Impedance of Speakers
Audio Power
BT Version
BT Operation Distance
Built-in DC 3.7V, 1000 mAH (3.7WH) rechargeable Li-ion
battery; Recharge by DC 5V through Micro USB Port
IP67
5W; 3 ohm
1.5W (RMS）
4.1
≧ 32 Feet in open area
Voice Prompt:
Bluetooth ready for connection
Memory Card
Line in
Playback Mode:
BT (Bluetooth)
Micro SD Card
AUX IN (LINE IN)
Craig Electronics warrants this product to be free from
manufacturing defects in material and workmanship
under normal use for a period of 180 days from date of
purchase. If service is required, please return the product
to the store where it was purchased for exchange; or,
pack the unit in the original packing material with all
accessories if applicable, a copy of your sales receipt and
a Cashier’s check or Money Order for $7 (to cover
shipping and handling costs) payable to Craig Electronics
Inc. For consumers in Canada, please make sure that the
cashier check or money order is redeemable through a
U.S. bank. Ship your product freight pre-paid. Your unit
will be repaired, replaced or if the unit cannot be repaired
or replaced, a refund will be forwarded to you within four
weeks of receipt of your unit. Please ship your unit to:
Craig Electronics Inc.
1160 NW 163 Drive
Miami, Fl 33169
This warranty is void if the product has been: a) Used in a
commercial application or rental. b) Damaged through
misuse, negligence, or abuse. c) Modified or repaired by
anyone other than an authorized Craig service center. d)
Damaged because it is improperly connected to any other
equipment.
Note: This warranty does not cover: a) Ordinary adjustments
as outlined in the Owner’s Manual which can be performed
by the customer. b) Damage to equipment not properly
connected to the product. c) Any cost incurred in shipping
the product for repair. d) Damage to the product not used
in the USA.
This warranty is not transferable and only applies to the
original purchase. Any implied warranties, including the
warranty of merchantability, are limited in duration to the
period of this expressed warranty and no warranty
whether expressed or implied shall apply to the product
thereafter.
Under no circumstance shall Craig be liable for any loss or
consequential damage arising out of the use of this product.
This warranty gives specific legal rights. However, you
may have other rights which may vary from state to state.
Some states do not allow limitations on implied warranties
or exclusion of consequential damage. Therefore, these
restrictions may not apply to you.
This product has been manufactured by and is sold under
the responsibility of Craig Electronics Inc, and Craig
Electronics Inc is the warrantor in relation to this product.
MAGNAVOX and SMART. VERY SMART are registered
trademarks of Koninklijke Philips N.V. and are used under
license from Koninklijke Philips N.V.
To Obtain Service on your Product
email:service@craigelectronics.com
Printed in China MMA3623_WC_E0FK1_B0US
LIMITED WARRANTY
To AUX (in) Jack
To Micro USB Port

Produkt Specifikationer

Mærke: Magnavox
Kategori: Højttaler
Model: MMA3623

Har du brug for hjælp?

Hvis du har brug for hjælp til Magnavox MMA3623 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Højttaler Magnavox Manualer

Magnavox

Magnavox MSB5300 Manual

7 Januar 2025
Magnavox

Magnavox MSB5305 Manual

7 Januar 2025
Magnavox

Magnavox MMA3683n Manual

7 Januar 2025
Magnavox

Magnavox MMA3629 Manual

7 Januar 2025
Magnavox

Magnavox MD6949 Manual

7 Januar 2025
Magnavox

Magnavox MMA3680 Manual

7 Januar 2025
Magnavox

Magnavox MMA3685 Manual

7 Januar 2025
Magnavox

Magnavox MMA3717 Manual

7 Januar 2025
Magnavox

Magnavox MMA3679 Manual

7 Januar 2025
Magnavox

Magnavox MMA3652 Manual

7 Januar 2025

Højttaler Manualer

Nyeste Højttaler Manualer

MB

MB PS61 Manual

8 Januar 2025
Definitive Technology

Definitive Technology Dymension LS-400 Manual

8 Januar 2025
Definitive Technology

Definitive Technology Dymension Outdoor LS- Manual

8 Januar 2025
Definitive Technology

Definitive Technology Dymension LS-80 Manual

8 Januar 2025
Sonance

Sonance Visual Performance Extreme VPXT8R Manual

8 Januar 2025
Sonance

Sonance Visual Performance VP38R Manual

8 Januar 2025
Duronic

Duronic BX48 Manual

8 Januar 2025
Sonance

Sonance MAG5.1R Manual

8 Januar 2025
Sonance

Sonance MAG6R Manual

8 Januar 2025
Electro-Voice

Electro-Voice XLE191-FG Manual

8 Januar 2025
