Microsemi PD96XX Series

PD-9606G & PD-9612G

PD-RPS- 1000

User Guide

Rev. 1 CPG Poe B0 –BU

One Enterprise Aliso Viejo, CA 92656 USA

Note:

The information contained herein is believed to be accurate and reliable

at the time of printing. However, due to ongoing product improvements

and revisions, Microsemi cannot accept responsibility for inadvertent

errors, inaccuracies, subsequent changes, or omissions of printed

material.

Microsemi reserves the right to make changes to products and to their

speciﬁcations as described in this document, at any time, without prior

notice. photocopy or reproduce this material without permission. Do not

Disclaim er

Microsemi assumes no responsibility or liability arising from the use

of Midspans, as described herein, nor does it convey any license

under its patent rights or the rights of others. Applications that are

described herein for any of these products are for illustrative

purposes only. Microsemi makes no representation or warranty that

such applications will be suitable for the speciﬁed use without further

testing or modification.

Note:

The information in this guide refers to PD-96 series of Power ovexx r

Ethernet Midspans, unless otherwise stated.

Note that Midspan is designed for indoor use . only

This document is subject to change without notice.

Rev. 1 CPG Poe B0 –BU

One Enterprise Aliso Viejo, CA 92656 USA

Contents

1 F M RONT ATERIAL .............................................................................. 5

1.1 Model Numbers Deﬁnition: .................................................................... 5

1.2 Electrical Compatibility Approvals ......................................................... 5

1.3 Safety Standard Approvals .................................................................... 5

1.4 CE Marking ........................................................................................... 5

2 S I AFETY NFORMATION ....................................................................... 6

2.1 General Guidelines ............................................................................... 6

2.2 Warnings ............................................................................................... 6

2.3 Power Cord ........................................................................................... 7

2.4 Power Cord Speciﬁcations by Country .................................................. 7

3 A BOUT THE OWER OVER THERNET IDSPANP E M .................................. 9

3.1 10/100/1000BASE-TX Ports Deﬁnition ................................................ 10

3.1.1 Data Input Ports ................................................................. 10

3.1.2 Data and Power Output Ports ............................................ 10

3.2 Indicators ............................................................................................. 11

3.2.1 Power Indicator LED .......................................................... 11

3.2.2 Port Indications................................................................... 11

3.3 Connectors .......................................................................................... 13

4 P E OWER OVER THERNET IDSPAN NSTALLATIONM I ............................ 15

4.1 Background Information ...................................................................... 15

4.2 Verifying Kit Contents .......................................................................... 15

4.3 Rack Mounting Brackets ..................................................................... 16

4.4 Installation Factors .............................................................................. 16

Rev. 1 CPG Poe B0 –BU

One Enterprise Aliso Viejo, CA 92656 USA

4.5 Connecting Ethernet Cables ................................................................ 17

4.6 Connecting Power Cables .................................................................... 17

4.7 Powering Up the Unit ........................................................................... 18

5 T ROUBLESHOOTING......................................................................... 19

5.1 Preliminary Steps ................................................................................. 19

5.2 Troubleshooting Steps ......................................................................... 20

6 S PECIFICATIONS .............................................................................. 22

6.1 Physical Speciﬁcations ........................................................................22

6.2 Environmental Speciﬁcations ............................................................... 22

6.3 Electrical Speciﬁcations ....................................................................... 23

7 M P V P ICROSEMI’S OWER IEW RO ...................................................... 24

8 P B OWER ACKUP AND OWER EDUNDANCY ONNECTIONP R C ............... 26

8.1 Power Redundancy .............................................................................. 26

8.2 Power Backup ...................................................................................... 26

8.3 Connecto rs........................................................................................... 27

8.4 Connecting Backup and Redundancy Connectors ............................... 28

8.5 Power Backup and Power Redundancy Indications ............................. 30

Rev. 1 CPG Poe B0 –BU

One Enterprise Aliso Viejo, CA 92656 USA

1 Front Material

1.1 Model Numbers Deﬁnition:

 : 4 Pairs AC and DC Input familyPD-96xxG/ACDC/M ,

where:

o Represents number of ports (6 12) xx: or

o : Midspan has AC input AC

o : Midspan has DC input, current sharing, and power backup DC

features between two Midspans

o : Midspan includes PowerView Pro (refer to Section M7)

 : Redundant Power Supply, PD-RPS-AAAA

where represents available power atts. AAAA in W

1.2 Electrical Compatibility Approvals

Microsemi 96 G series complies with the following standards: xx

 FCC Part 15; class UTP cabling

 EN 55022 (CISPR 22); class B with UTP cabling

 EN 55024 (CISPR 24)

 Canadian ICES-003, class B

1.3 Safety Standard Approvals

Microsemi meets the following safety standards:

 UL/cUL per CSA/UL 60950-1

 GS mark per IEC60950-1

1.4 CE Marking

CE marking on this product indicates this product complies with

89/336/EEC (EMC Directive) and 73/23/EEC (Low Voltage Directive).

Rev. 1 CPG Poe B0 –BU

One Enterprise Aliso Viejo, CA 92656 USA

2 Safety Information

Read the following safety information before using your Power over

Ethernet Midspan unit.

2.1 General Guidelines

Read the following safety information before carrying out any installation,

removal, or maintenance procedure on the Power over Ethernet Midspan.

Warnings contain directions to be followed for the safety of personal and

product. Follow all directions carefully.

2.2 Warnings

 Read installation instructions in Section 4 before

connecting Power over Ethernet Midspan to its power

source.

 Read instructions in Section 4 before connecting

Midspan- -Midspan power backup. to

 Midspan must use a grounded power cord, as defined in

Section 2.3.

 This product relies on the building installation for short-

circuit (over-current) protection. Use only a fuse or circuit

breaker not higher than 15A for 120VAC (U.S.), or 10A

for 230VAC (international).

 Do not work on the system, connect, or disconnect

cables during periods of lightning.

 A voltage mismatch can cause equipment damage and

can pose a ﬁre hazard. If voltage indicated on the label is

diﬀerent from power outlet voltage, do not connect Power

over Ethernet Midspan to this outlet.

 For shelf-mounted equipment, verify surface is stable and

strong enough to support equipment. Do not stack more

than four Power over Ethernet Midspan units.

 When disposing this product, follow all local laws and

regulations.

Rev. 1 CPG Poe B0 –BU

One Enterprise Aliso Viejo, CA 92656 USA

 "DATA" and "DATA & POWER" ports of the Power over

Ethernet Midspan are shielded RJ-45 data sockets. They

cannot be used as Plain Old Telephone Service (POTS)

sockets. Only connect RJ-45 data connectors to these

sockets.

 Associated Ethernet wiring shall be limited to the inside

of the building.

2.3 Power Cord

In case power cord is replaced, replacement must meet local

requirements.

 To ensure a reliable connection to an AC mains supply,

equipment provides an appliance IEC60320 inlet used for

connecting a detachable power supply cord.

 Power socket outlet must be located near Midspan and

easily accessible. The only way of removing power from

unit is by disconnecting the power cord from the outlet

 This unit operates under SELV (Safety Extra Low

Voltage) conditions, according to EN60950-1/IEC60950-

1. Conditions are maintained only if the equipment to

which unit is connected also operates under SELV

conditions.

2.4 Power Cord Speciﬁcations by Country

U.S.A. and

Canada

 Cord must be UL-approved or CSA certified.

 Minimum speciﬁcation for ﬂexible cord is:

o No. 18 AWG

o Type SV or SJ

o Three-conductor

 Cord set must have a rated current capacity

of at least 13A for -9 G/ACDC/M, -PD 612 PD

9606G/ACDC/M;

 Attachment plug must be an earth-grounding

type with a NEMA 5-15P (15A, 125V) or

NEMA 6-15P (15A, 250V) conﬁguration.

Rev. 1 CPG Poe B0 –BU

One Enterprise Aliso Viejo, CA 92656 USA

Denmark

Supply plug must comply with section 107-2-D1, standard

DK2-1a or DK2-5a.

Switzerland

Supply plug must comply with SEV/ASE 1011.

France and

Peru

IT supplies cannot power this unit. If your supplies are an

IT type, unit must be powered by 230V (2P+T) via an

isolation transformer with a 1:1 ratio, and with secondary

connection point labeled Neutral and connected directly to

ground.

U.K

Power over Ethernet Midspan is covered by General

Approval NS/G/12345/J/100003, for indirect connection to

a public telecommunications system.
