Detach the Front Panel
Press button in the upper left corner, and then the front panel will be folded down.
(release button)
PWR (Power button)
9/ button (Skip forward)
7/MODE button
SEL/VOL knob (Audio / volume)
AMS/SCH button (Automatic
storing)
TA button (Traffi c alarm)
disc slot
LCD display
(Eject button)
USB slot
AUX in jack
0/DSP button (Display time)
6/DIR+ button (Directory up)
5/DIR- button (Directory down)
4/RDM button (Random)
3/RPT button (Repeat)
2/INT button (Intro)
1/PAU button (Pause)
BAND/LOUD button
PTY button (Program type
selecting)
EQ button (equalizer)
8/ (skip backward)
AF button (Alternative Frequency)
Reset button
SD/MMC slot
Do not attempt to modify the unit, modifying the unit may cause an accident.
Installation or servicing of the unit by persons without training and experience in
electronic equipment and automotive accessories may be dangerous and could
expose you to the risk of electric shock or other hazards.
Stop the vehicle before carrying out any operation that could interfere with your
driving.
Keep the volume at a level which you could hear sounds from outside the vehicle.
Do not work in extremely high or low temperature. Be sure the temperature inside
the vehicle is between +60°C and -10°C before turning on your unit.
When replacing the fuse(s), the replacement must be of the same amperage as
shown on the fuse holder.
Do not block vents or radiator panels. Blocking them will cause heat to build up
inside and may result in fi re.
Using this unit without running the engine can result in battery drainage
Use only in cars with a 12 volt negative ground.
After completing the installation and beginning to play the unit(including replacing
the battery), please remove the front panel at fi rst, and then press RESET button
on the base with pointed object (such as ball-point pen) to set the unit to initial
status.
Before you install the unit, remove absolutely the two transportation screws on top
of the unit.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
M-1015 MR
GB - 1
User Manual
CAR RADIO CD/MP3
PLAYER WITH USB/SD/MMC
Please read the instruction carefully
before operating the unit.
PRECAUTIONS
English
* Do not attempt to load more than one disc.
* Only 12cm discs are compatible.
* New discs may have some roughness around the edges. Before load such disc into
the player, use a ball-point pen or the like to remove any roughness from the edge of
the disc.
* If there is a scratch, dirt or fi ngerprints on the disc, it may cause tracking error. Before
playing, clean the disc with a clean cloth. Wipe the disc from the center out.
* Don’t store discs in places with high temperatures or high humidity, they can become
warped. After playing, store the disc in its case.
GB - 2 GB - 3
CONNECTION
1. Antenna Receptacle
2. Line out Right (red)
3. Line out Left (white)
4. Output plug (male)
5. Output plug (female)
6. FUSE holder (15 A)
Caution!
- Make sure to connect the color coded leads according to the diagram. Incorrect
connections may cause the unit to malfunction or damage the vehicle’s electrical system.
- Make sure to connect the speaker (-) leads to the speaker (-) terminal. Never
connect the left and right channel speaker cables each other or to the vehicle body.
- Make sure all the connections are completely correct before turning on your unit.
Do not connect the ignition wire (red) and the battery wire (yellow), it may cause a short circuit,
even result in fi re.
Install the unit
- Method 1: DIN Front-Mount
1. Remove the outer trim frame
2. Select a position where the screw holes of
the mounting bracket supplied with the car
and the screw holes of the main unit become
aligned (are fi tted).
3. Tighten the screws. And then fasten them to
the car.
GB - 4 GB - 5
Install the front panel
Insert the panel into the housing and make sure the panel is properly installed.
Otherwise, abnormality occurs on the display or some keys will not function properly.
Note: Never put any objects into the front panel.
Detach the unit
1. Detach the front panel. (please refer to upper part)
2. Take out the outer trim frame.
3. Insert the keys supplied to the unit at the both sides of the unit (shown as illustrated)
until they click. Pulling the keys and makes them to remove the unit from the dash-
board.
GB - 6
LOCATION OF CONTROLS
Front panel
Base
GB - 7
Notice on disc
Use such discs may cause malfunction or breakdown of the internal mechanism:
with large scratches; with irregular shape; cracked; with any cellophane tape or other
glue on it or with peeling off marks; with protection sheet; equipped with stabilizers, etc.
- Method 2 DIN Rear-mount (For Japanese car)
BASIC OPERATION
Turning on/off the unit
Press button (2) to turn on the unit. Press this button again to turn off the unit.PWR
Note: When the unit is off, press any key except (1) to turn on the unit.
Selecting the mode
After the unit is on, press (4) button to select different sourcing mode: Radio MODE
CD USB SD/MMC AUX
UNPACK YOUR UNIT
When you unpack your new car radio, make sure that you have removed all the acces-
sories and information papers:
Main unit
User manual
Accessories:
INSTALL AND DETACH THE UNIT
SOUND FEATURES
Setting the Sound:
Repeatedly press knob (5) to select the desired mode in the following order: SEL/ VOL
“BAS” (Bass) -> “TRB” (Treble) -> “BAL” (Balance) -> “FAD“ (Fade) ->“BEEP“ (BEEP
ON/OFF) -> “TA VOL“ (TA volume) ->“EON” (EON ON/OFF) -> “VOL” (Volume). After
selecting the desired mode, you can adjust the current level by rotating the SEL/ VOL
knob (5).
- BEEP: under Beep mode, rotate SEL/VOL (5), LCD shows “BEEP ON” or “BEEP
OFF”, choosing corresonding status can turn on or turn off beep.
- please refer to RDS operationEON:
Note: The unit will return to the previous mode if no adjusting within 3 seconds.
Time display
Press button (13) to show the current time on displayDSP
Adjust time: Long press DSP (13) until clock time with fl ashing hour digits appears.
Then Press and button to adjust the hour value and press DSP (13) to confi rm.
Then minute digits fl ash. Press and button to adjust the minute value and
press (13) to conDSP fi rm
Reset the unit
Operating the unit for the fi rst time or after replacing the car battery, you must reset the
unit. To set the unit to initial status, press RESET button (25) located on the base with
a pointed object. When some errors occur in display, you can also reset the unit, but it
will erase the clock setting and some memorized functions.
Volume adjusting:
To increase or decrease the sound level, rotate knob (5) clockwise or SEL/VOL
anti-clockwise.
2625
Preset equalizer
When you are listening to popular music, classic music or rock music, using EQ
to select relative status can adjust the sound quality. Repeatedly press (8) to select EQ
different equalizer mode in following order: FLAT->POP->ROCK->CLASS -> EQ off.
Switching Loudness On/off
Press and hold button (20) until “LOUD ON” shows on display to BAND/LOUD
activate LOUD function. By this function, you can increase the low frequency, which
can improve sound sensitivity. Press and hold this button again until “LOUD OFF”to
cancel LOUD function.
NOTE: It will return to normal play mode if no key is pressed within 5 second.
Information display
- In case of receiving a RDS station.
In radio mode: CT -> FREQ ->PTY ->PS
In CD (MP3 / WMA) mode: CD (MP3/WMA) -> CT -> FREQ -> PTY ->PS
- In case of not receiving a RDS station.
In radio mode: CT -> FREQ -> NO PTY -> NO PS
In CD mode: CD -> CT -> FREQ -> NO PTY -> NO PS
1 2 3 5 6 74
8 9 11 1210
M5 X 21
M5 X 21
1
24 23 22 21 20 19 18 17 16 15 14 13 12
2 3 4 5 6 7 8 9 10 11
AR-3045 IB MUSE 001 REV0 GB.indd1 1
AR-3045 IB MUSE 001 REV0 GB.indd1 1
AR-3045 IB MUSE 001 REV0 GB.indd1 1
AR-3045 IB MUSE 001 REV0 GB.indd1 1AR-3045 IB MUSE 001 REV0 GB.indd1 1 2011-2-28 15:58:30
2011-2-28 15:58:30
2011-2-28 15:58:30
2011-2-28 15:58:302011-2-28 15:58:30
